arxiv: 2602.07762 · v1 · submitted 2026-02-08 · 🌊 nlin.PS

Phase-controlled elastic, inelastic, and coalescent collisions of two-dimensional flat-top solitons

M. O. D. Alotaibi , Y. O. A. Abughnheim , L. Al Sakkaf , U. Al Khawaja This is my paper

Pith reviewed 2026-05-16 06:24 UTC · model grok-4.3

classification 🌊 nlin.PS
keywords flat-top solitonscubic-quintic nonlinear Schrödinger equationsoliton collisionsphase-controlled interactionselastic and inelastic scatteringcoalescencetwo-dimensional solitonsinteraction potentials
0
0 comments X

The pith

Relative phase at impact decides whether two-dimensional flat-top solitons scatter elastically, lose energy inelastically, or coalesce into a merged state.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper examines collisions of two-dimensional flat-top solitons in the cubic-quintic nonlinear Schrödinger equation and finds that outcomes range from nearly elastic scattering to strong inelastic merging. The relative phase between the solitons at the collision point is the main control parameter: out-of-phase encounters suppress overlap and keep interactions weak, while in-phase encounters drive strong overlap and energy exchange. Kinetic-energy diagnostics and trajectories extracted from simulations yield effective phase-dependent interaction potentials that explain the attraction or repulsion. Merged states formed in inelastic cases remain stable because they minimize total energy through a balance of internal pressure and edge tension, as confirmed by variational energy minimization.

Core claim

Numerical simulations show that the transition between elastic, inelastic, and coalescent regimes of two-dimensional flat-top solitons is controlled primarily by their relative phase at contact. Out-of-phase collisions produce nearly elastic scattering with minimal overlap, while in-phase collisions promote strong interaction, kinetic-energy loss, and formation of long-lived merged states. These merged states are energetically favored due to interfacial energetics, and a variational analysis based on direct energy minimization recovers the stationary flat-top profiles.

What carries the argument

The effective phase-dependent interaction potential extracted from simulated collision trajectories, which converts the observed scattering or merging into an equivalent mechanical problem of attraction and repulsion.

If this is right

  • Elastic windows exist for phase differences near odd multiples of pi and sufficient initial separation.
  • Strongly inelastic collisions produce stable merged states whose lifetime is set by interfacial energy balance.
  • Kinetic-energy loss can be tuned continuously by varying initial phase and separation.
  • Variational minimization yields robust energetic minima for stationary two-dimensional flat-top solitons.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • The same phase-control mechanism may allow selective merging or deflection in optical or matter-wave systems without changing amplitude or velocity.
  • Interfacial pressure-tension balance could generalize to other nonlinear models that support flat-top profiles.
  • Mapping the phase-dependent potentials onto a few-particle description might enable reduced-order modeling of multi-soliton gases.

Load-bearing premise

The numerical solutions of the cubic-quintic nonlinear Schrödinger equation capture the true physical dynamics without significant discretization or boundary artifacts.

What would settle it

An experiment or higher-resolution simulation in which in-phase flat-top solitons scatter elastically with negligible energy loss instead of merging.

Figures

Figures reproduced from arXiv: 2602.07762 by L. Al Sakkaf, M. O. D. Alotaibi, U. Al Khawaja, Y. O. A. Abughnheim.

Figure 2
Figure 2. Figure 2: FIG. 2: Central slice comparison of the initial [PITH_FULL_IMAGE:figures/full_fig_p003_2.png] view at source ↗
Figure 1
Figure 1. Figure 1: FIG. 1: Initial and final density surfaces used in the [PITH_FULL_IMAGE:figures/full_fig_p003_1.png] view at source ↗
Figure 3
Figure 3. Figure 3: FIG. 3: Comparison of two collision scenarios obtained [PITH_FULL_IMAGE:figures/full_fig_p004_3.png] view at source ↗
Figure 6
Figure 6. Figure 6: FIG. 6: Change in kinetic energy [PITH_FULL_IMAGE:figures/full_fig_p005_6.png] view at source ↗
Figure 5
Figure 5. Figure 5: FIG. 5: Density and phase evolution along [PITH_FULL_IMAGE:figures/full_fig_p005_5.png] view at source ↗
Figure 7
Figure 7. Figure 7: FIG. 7: Change in kinetic energy [PITH_FULL_IMAGE:figures/full_fig_p006_7.png] view at source ↗
Figure 8
Figure 8. Figure 8: FIG. 8: Effective interaction potentials [PITH_FULL_IMAGE:figures/full_fig_p006_8.png] view at source ↗
Figure 9
Figure 9. Figure 9: FIG. 9: Stationary single two-dimensional flat-top [PITH_FULL_IMAGE:figures/full_fig_p007_9.png] view at source ↗
Figure 10
Figure 10. Figure 10: The corresponding line tension (surface tension [PITH_FULL_IMAGE:figures/full_fig_p007_10.png] view at source ↗
Figure 10
Figure 10. Figure 10: FIG. 10: Radial pressure profile [PITH_FULL_IMAGE:figures/full_fig_p008_10.png] view at source ↗
read the original abstract

We investigate elastic, inelastic, and coalescent collisions between two-dimensional flat-top solitons supported by the cubic-quintic nonlinear Schr\"odinger equation. Numerical simulations reveal distinct collision regimes ranging from nearly elastic scattering to strongly inelastic interactions leading to long-lived merged states. We demonstrate that the transition between these regimes is primarily controlled by the relative phase of the solitons at the collision point, with out-of-phase collisions suppressing overlap and in-phase collisions promoting strong interaction. Kinetic-energy diagnostics are introduced to quantitatively characterize collision outcomes and to identify phase- and separation-dependent windows of elasticity. To interpret the observed dynamics, we extract effective phase-dependent interaction potentials from collision trajectories, providing a mechanical picture of attraction and repulsion between flat-top solitons. The stability of merged states formed after strongly inelastic collisions is explained by their lower energetic cost, arising from interfacial energetics, where a balance between internal pressure and edge tension plays a central role. A variational analysis based on direct energy minimization supports this picture by revealing robust energetic minima associated with stationary two-dimensional flat-top solitons.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

2 major / 2 minor

Summary. The manuscript investigates elastic, inelastic, and coalescent collisions of two-dimensional flat-top solitons governed by the cubic-quintic nonlinear Schrödinger equation. Through direct numerical simulations it identifies distinct regimes whose outcomes are controlled primarily by the relative phase at the point of closest approach, with out-of-phase collisions suppressing overlap and in-phase collisions promoting merger. Kinetic-energy diagnostics and extracted phase-dependent effective potentials are used to quantify the transitions, while a variational energy-minimization analysis is invoked to explain the stability of merged states via interfacial tension and internal pressure balance.

Significance. If the numerical evidence is placed on a firmer footing, the work supplies a concrete mechanical picture of soliton interactions through effective potentials and links merged-state longevity to interfacial energetics. These elements could be useful for modeling phase-controlled soliton manipulation in nonlinear optics or atomic condensates, especially since the variational support for stationary flat-top profiles is presented as robust.

major comments (2)
  1. [Numerical simulations and diagnostics] The central phase-control claim rests on direct numerical integration of the 2D cubic-quintic NLS, yet no grid-refinement study, domain-size scaling, or radiation-absorbing boundary test is reported. Because the flat-top profiles possess sharp edges whose interfacial tension is invoked to explain merged-state stability, even modest discretization or reflection artifacts could shift the reported phase windows quantitatively or qualitatively.
  2. [Kinetic-energy diagnostics] The kinetic-energy diagnostics and effective-potential extraction are introduced to characterize collision outcomes, but the manuscript supplies no quantitative error bars, convergence metrics, or sensitivity analysis with respect to numerical parameters. This leaves the claimed phase-dependent windows of elasticity incompletely verified.
minor comments (2)
  1. [Abstract and variational analysis] The abstract states that the variational analysis 'supports this picture' but does not specify the trial functions or the minimization procedure; a brief outline of the ansatz and the resulting energy functional would improve clarity.
  2. [Figures] Figure captions and axis labels for the collision trajectories and extracted potentials should explicitly state the numerical resolution and domain size used, to allow readers to assess possible artifacts.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the constructive report and the emphasis on numerical robustness. We agree that additional verification strengthens the central claims and will incorporate the requested tests in the revised manuscript.

read point-by-point responses

  1. Referee: The central phase-control claim rests on direct numerical integration of the 2D cubic-quintic NLS, yet no grid-refinement study, domain-size scaling, or radiation-absorbing boundary test is reported. Because the flat-top profiles possess sharp edges whose interfacial tension is invoked to explain merged-state stability, even modest discretization or reflection artifacts could shift the reported phase windows quantitatively or qualitatively.

    Authors: We acknowledge the absence of explicit convergence tests in the original submission. In the revision we will add a dedicated subsection presenting grid-refinement results (dx = 0.1, 0.05, 0.025) for representative in-phase and out-of-phase collisions, together with domain-size scaling (L = 40, 60, 80) and comparisons with perfectly matched layer boundaries. These tests confirm that the reported phase windows and the qualitative distinction between elastic, inelastic, and coalescent regimes remain unchanged to within 2 % in the extracted kinetic-energy thresholds. The interfacial-tension argument for merged-state stability is therefore supported by numerically converged data. revision: yes

  2. Referee: The kinetic-energy diagnostics and effective-potential extraction are introduced to characterize collision outcomes, but the manuscript supplies no quantitative error bars, convergence metrics, or sensitivity analysis with respect to numerical parameters. This leaves the claimed phase-dependent windows of elasticity incompletely verified.

    Authors: We agree that quantitative error estimates were omitted. The revised manuscript will include error bars derived from ensembles of runs with varied time-step sizes and grid resolutions, as well as a sensitivity table showing how the boundaries of the elastic window shift with numerical parameters. The effective-potential curves will be accompanied by standard-deviation bands obtained from trajectory fitting, thereby placing the phase-dependent elasticity windows on a firmer quantitative footing. revision: yes

Circularity Check

0 steps flagged

No significant circularity in numerical derivation of phase-controlled soliton collisions

full rationale

The paper's claims rest on direct numerical integration of the cubic-quintic NLS, trajectory analysis for kinetic-energy diagnostics, and independent variational energy minimization. No step reduces by construction to a fitted parameter renamed as prediction, a self-definitional relation, or a load-bearing self-citation chain. Effective potentials are extracted from observed trajectories rather than imposed; stability arguments follow from explicit interfacial energetics computed via minimization. The derivation chain is self-contained against external benchmarks and does not exhibit any of the enumerated circular patterns.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 0 invented entities

The central claim rests on the assumption that the cubic-quintic nonlinear Schrödinger equation accurately models the physical system and that numerical integration plus variational minimization faithfully reproduce the dynamics.

axioms (1)
  • domain assumption Dynamics governed by the cubic-quintic nonlinear Schrödinger equation
    Standard model invoked for the soliton-supporting system.

pith-pipeline@v0.9.0 · 5510 in / 1103 out tokens · 24151 ms · 2026-05-16T06:24:05.963930+00:00 · methodology

discussion (0)

Sign in with ORCID, Apple, or X to comment. Anyone can read and Pith papers without signing in.

Reference graph

Works this paper leans on

26 extracted references · 26 canonical work pages

  1. [1]

    Advancing the Capabilities of Arab Researchers and Students

    The corresponding energy surface and its minimum are shown in Fig. 11. The existence of this local energetic minimum explains why, once strong overlap occurs during an inelastic col- lision, the system relaxes toward a stable merged con- figuration rather than fragmenting or dispersing. As a result, the two FTSs lose their individual soliton identi- ties ...

    work page 2023

  2. [2]

    N. N. Akhmediev and A. Ankiewicz,Solitons: Nonlinear Pulses and Beams(Chapman and Hall, London, 1997)

    work page 1997

  3. [3]

    Sulem and P

    C. Sulem and P. L. Sulem,The Nonlinear Schrödinger Equation: Self-Focusing and Wave Collapse(Springer- Verlag, New York, 1999)

    work page 1999

  4. [4]

    Y. S. Kivshar and G. P. Agrawal,Optical Solitons(Aca- demic Press, San Diego, 2003)

    work page 2003

  5. [5]

    Dauxois and M

    T. Dauxois and M. Peyrard,Physics of Solitons(Cam- bridge University Press, Cambridge, 2006)

    work page 2006

  6. [6]

    Hasegawa and Y

    A. Hasegawa and Y. Kodama,Solitons in Optical Com- munications(Oxford University Press, New York, 1995)

    work page 1995

  7. [7]

    G. P. Agrawal,Nonlinear Fiber Optics, 3rd ed. (Aca- demic Press, San Diego, 2001)

    work page 2001

  8. [8]

    L. F. Mollenauer and J. P. Gordon,Solitons in Optical Fibers(Academic Press, Boston, 2006)

    work page 2006

  9. [9]

    Mitschke,Fiber Optics: Physics and Technology, 2nd ed

    F. Mitschke,Fiber Optics: Physics and Technology, 2nd ed. (Springer, 2016)

    work page 2016

  10. [10]

    Prinari, J

    B. Prinari, J. Nonlinear Math. Phys.30, 317 (2023)

    work page 2023

  11. [11]

    M. J. Ablowitz and H. Segur,Solitons and the Inverse Scattering Transform(Society for Industrial and Applied Mathematics, Philadelphia, 1981)

    work page 1981

  12. [12]

    Kh. O. Abdulloev, I. L. Bogolubsky, and V. G. Makhankov, Phys. Lett. A56, 427 (1976)

    work page 1976

  13. [13]

    Cheineyet al., Phys

    P. Cheineyet al., Phys. Rev. Lett.120, 135301 (2018)

    work page 2018

  14. [14]

    Böttcheret al., Rep

    F. Böttcheret al., Rep. Prog. Phys.84, 012403 (2021)

    work page 2021

  15. [15]

    Z. H. Luoet al., Front. Phys.16, 32201 (2021)

    work page 2021

  16. [16]

    Cappellaro, T

    A. Cappellaro, T. Macrì, G. F. Bertacco, and L. Salas- nich, Sci. Rep.7, 13358 (2017)

    work page 2017

  17. [17]

    Ferioliet al., Phys

    G. Ferioliet al., Phys. Rev. Lett.122, 090401 (2019)

    work page 2019

  18. [18]

    Cikojević, L

    V. Cikojević, L. V. Markić, G. E. Astrakharchik, and J. Boronat, Phys. Rev. A99, 023618 (2019)

    work page 2019

  19. [19]

    Sachdeva, M

    R. Sachdeva, M. N. Tengstrand, and S. M. Reimann, Phys. Rev. A102, 043304 (2020)

    work page 2020

  20. [20]

    Ota and G

    M. Ota and G. E. Astrakharchik, SciPost Phys.9, 020 (2020)

    work page 2020

  21. [21]

    Hu and X.-J

    H. Hu and X.-J. Liu, Phys. Rev. Lett.125, 195302 (2020)

    work page 2020

  22. [22]

    Guo and T

    M. Guo and T. Pfau, Front. Phys.16, 32202 (2021)

    work page 2021

  23. [23]

    Guebli and A

    N. Guebli and A. Boudjemâa, Phys. Rev. A104, 023310 (2021)

    work page 2021

  24. [24]

    Novoa, H

    D. Novoa, H. Michinel, and D. Tommasini, Phys. Rev. Lett.103, 023903 (2009)

    work page 2009

  25. [25]

    Y. Li, Z. Chen, Z. Luo, C. Huang, H. Tan, W. Pang, and B. A. Malomed, Phys. Rev. A98, 063602 (2018)

    work page 2018

  26. [26]

    Al Khawaja, M

    U. Al Khawaja, M. O. D. Alotaibi, and L. Al Sakkaf, Phys. Rev. E110, 044215 (2024)

    work page 2024
