System representations in subspaces of finite-sample signals and their application to data-driven fault detection

Jiahao Wang; Linlin Li; Maiying Zhong; Steven X. Ding; Wei Cheng

arxiv: 2604.17444 · v1 · submitted 2026-04-19 · 📡 eess.SY · cs.SY

System representations in subspaces of finite-sample signals and their application to data-driven fault detection

Linlin Li , Steven X. Ding , Jiahao Wang , Maiying Zhong , Wei Cheng This is my paper

Pith reviewed 2026-05-10 05:39 UTC · model grok-4.3

classification 📡 eess.SY cs.SY

keywords finite-sample signalsimage subspaceresidual subspacefundamental lemmadata-driven fault detectionsingular value decompositionorthogonal projectionsystem representation

0 comments

The pith

The fundamental lemma is equivalent to the image subspace of finite-sample signals, enabling SVD-based projections for data-driven fault detection.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper shows that finite-sample input-output signals admit an image subspace that captures nominal system dynamics and a residual subspace that captures uncertainties. It proves this image subspace is equivalent to the fundamental lemma of subspace identification. The equivalence supports a fault detection method that applies singular value decomposition to realize orthogonal projections onto both subspaces, generating residuals that flag deviations from nominal behavior. A reader would care because the approach works directly from collected data without first building an explicit model of the system.

Core claim

The paper claims that the image representation of finite-sample signals models the nominal system dynamics and is equivalent to the fundamental lemma, while the residual representation describes uncertainties essential for fault detection. Orthogonal projections realized via singular value decomposition in a low-rank matrix approximation produce projection-based residuals whose evaluation detects faults, with performance bounds derived from matrix perturbation theory.

What carries the argument

Finite-sample image and residual subspaces obtained from low-rank approximation via singular value decomposition, which enable orthogonal projections to separate nominal dynamics from faults.

If this is right

The equivalence extends the fundamental lemma to finite-sample settings for direct system representation.
Fault detection proceeds by generating residuals through orthogonal projection onto the residual subspace without intermediate model identification.
Matrix perturbation analysis supplies quantitative bounds on how uncertainties affect detection thresholds.
The method relates to and can be compared against other data-driven fault detection techniques that rely on subspace or parity-space ideas.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

The same subspaces could be updated recursively when new data arrives, supporting online monitoring without recomputing the full decomposition each time.
The approach might combine with existing subspace identification routines so that the same data batch serves both modeling and fault detection.
In high-dimensional sensor arrays the low-rank structure could reduce computational cost by working only with the dominant singular vectors.
Testing on systems whose dynamics slowly drift would check whether the subspace separation remains useful beyond the paper's static assumptions.

Load-bearing premise

The collected finite-sample signals must possess well-defined low-rank image and residual subspaces that singular value decomposition can reliably separate to isolate faults from normal operation.

What would settle it

Apply the SVD projection procedure to input-output data from a system with an injected fault of known size and timing; if the resulting residual signal shows no statistically significant increase above the fault-free case, the separation claim is falsified.

read the original abstract

This paper deals with system representations in finite-sample signal subspaces and their application to data-driven fault detection. The first part addresses concepts of finite-sample image and kernel system representations and, associated with them, image and residual subspaces of finite-sample signals. On this basis, the equivalence between the fundamental lemma and finite-sample image subspace is demonstrated. While the image representation models the nominal system dynamics, the residual representation describes uncertainties in the input-output data and is essential for fault detection. This result extends the fundamental lemma and builds the basis for exploring data-driven fault detection. In the second part, a data-driven projection-based fault detection approach is developed. By means of a singular value decomposition, orthogonal projections onto the image and residual subspaces are realized in the context of a low-rank matrix approximation, leading to projection-based residual generation and evaluation. Finally, analysis of detection performance in the framework of matrix perturbation theory and comparison with existing data-driven fault detection methods are explored.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

It gives a finite-sample version of the fundamental lemma via image and residual subspaces, then builds an SVD projection method for fault detection, but the noise robustness rests on unverified low-rank gaps.

read the letter

The punchline for this paper is that it establishes an equivalence between the fundamental lemma and the image subspace of finite-sample signals, then uses that to develop a projection-based method for data-driven fault detection. What stands out is how they define finite-sample image and residual subspaces and show that the image one captures the nominal dynamics while the residual handles uncertainties. The SVD-based orthogonal projections for residual generation are a practical step, and the perturbation analysis provides some theoretical backing for detection performance. This extends the data-driven control literature in a logical way without overclaiming a complete overhaul. The soft spots are around the practical applicability under noise. The equivalence holds for exact data, but when noise is present, the low-rank property of the data matrix and the singular value gap needed for reliable subspace separation aren't guaranteed without additional conditions on sampling length or noise intensity. The paper uses general matrix perturbation results instead of tailored bounds for the structured case, which leaves the detection guarantees somewhat loose. There's also no mention of empirical tests in the abstract, so we don't see how it performs on real or simulated data compared to existing methods. This paper is for people already working in subspace-based fault detection and data-driven methods in systems and control. A reader who knows the fundamental lemma will appreciate the finite-sample extension and the direct application to fault detection. It deserves a serious referee because the core technical steps are coherent and the problem it addresses is relevant, even if some assumptions need more scrutiny and validation would strengthen it.

Referee Report

2 major / 3 minor

Summary. The paper introduces finite-sample image and kernel system representations along with their associated image and residual subspaces. It demonstrates an equivalence between the fundamental lemma and the finite-sample image subspace representation. This is then used to develop a data-driven fault detection scheme that employs SVD-based low-rank approximation to construct orthogonal projections onto the image and residual subspaces, enabling residual generation and evaluation, with detection performance analyzed via matrix perturbation theory.

Significance. If the central equivalence and projection construction hold under the stated conditions, the work extends the fundamental lemma to finite-sample settings and supplies a concrete SVD-based method for model-free fault detection. The explicit use of image/residual subspace projections and the perturbation-theoretic performance bounds represent a clear technical contribution that could strengthen data-driven approaches in systems and control.

major comments (2)

[§3] §3 (equivalence demonstration): The equivalence between the fundamental lemma and the finite-sample image subspace is established for exact (noise-free) data where the Hankel-like matrix has exact low rank; the fault-detection extension in §4 applies the same subspaces to noisy data without deriving explicit conditions (e.g., on sampling length T or noise variance) that guarantee a sufficient singular-value gap persists after finite sampling.
[§4.3] §4.3 (perturbation analysis): The detection-performance bounds rely on generic matrix perturbation results applied to the SVD of the data matrix; because the underlying matrix is a structured (Hankel) matrix formed from finite-sample trajectories, it is not shown that the generic bounds remain tight or that fault-induced perturbations dominate finite-sample effects in the residual subspace.

minor comments (3)

[§2] Notation for the image subspace projector P_I and residual projector P_R is introduced in §2 but used without an explicit matrix expression until §4; adding the explicit formulas early would improve readability.
[§5] The comparison with existing data-driven fault-detection methods (e.g., parity-space or subspace-based approaches) is mentioned in the abstract and conclusion but lacks a quantitative table or explicit metric-by-metric discussion; a short comparative table would strengthen the claims.
[§2.1] A few typographical inconsistencies appear in the definition of the finite-sample Hankel matrix (e.g., row/column indexing) between §2.1 and the appendix; these should be unified.

Simulated Author's Rebuttal

2 responses · 0 unresolved

Thank you for the constructive review and for recognizing the technical contributions of the work. We address each major comment point by point below and indicate the revisions we intend to make.

read point-by-point responses

Referee: [§3] §3 (equivalence demonstration): The equivalence between the fundamental lemma and the finite-sample image subspace is established for exact (noise-free) data where the Hankel-like matrix has exact low rank; the fault-detection extension in §4 applies the same subspaces to noisy data without deriving explicit conditions (e.g., on sampling length T or noise variance) that guarantee a sufficient singular-value gap persists after finite sampling.

Authors: The equivalence in Section 3 is derived under the exact, noise-free setting with the data matrix having exact low rank, as explicitly stated. In Section 4 the fault-detection scheme applies SVD-based low-rank approximation to noisy trajectories, which is the standard practical extension used throughout the data-driven control literature. We agree that explicit, quantitative conditions on T and noise variance guaranteeing a sufficient singular-value gap are not derived. In the revised manuscript we will insert a clarifying paragraph (likely in Section 4.1) that states the working assumptions required for the approximation to remain valid and that points to existing finite-sample results in the literature. revision: partial
Referee: [§4.3] §4.3 (perturbation analysis): The detection-performance bounds rely on generic matrix perturbation results applied to the SVD of the data matrix; because the underlying matrix is a structured (Hankel) matrix formed from finite-sample trajectories, it is not shown that the generic bounds remain tight or that fault-induced perturbations dominate finite-sample effects in the residual subspace.

Authors: The performance bounds in Section 4.3 are obtained from standard, matrix-agnostic perturbation results; these results remain valid for any matrix, including the structured Hankel matrix generated by finite trajectories. The bounds are therefore conservative and are not claimed to be tight. We acknowledge that a structure-exploiting analysis that would prove dominance of fault-induced perturbations over finite-sample effects is absent. In the revision we will add a short discussion in Section 4.3 that (i) clarifies the applicability of generic bounds to structured matrices and (ii) states the implicit assumption that the fault is sufficiently strong relative to the residual subspace dimension and data length; we will also include a brief numerical illustration of this dominance. revision: partial

Circularity Check

0 steps flagged

No circularity: equivalence shown to external fundamental lemma; SVD projections and perturbation analysis are independent constructions.

full rationale

The derivation begins from the external fundamental lemma (Willems et al.), demonstrates its equivalence to finite-sample image subspaces via direct matrix arguments on Hankel-like data matrices, then applies standard SVD for orthogonal projections onto image/residual subspaces and matrix perturbation theory for detection bounds. None of these steps reduce to self-definition, fitted parameters renamed as predictions, or load-bearing self-citations; the low-rank assumptions are stated explicitly as conditions rather than derived from the target result. The central claims remain self-contained against external benchmarks.

Axiom & Free-Parameter Ledger

0 free parameters · 0 axioms · 0 invented entities

Abstract provides no explicit free parameters, axioms, or invented entities; the work references the fundamental lemma as background and introduces subspace concepts without detailing new postulates or fitted quantities.
