Simulation of Switching Converters on the Level of Averaged Voltages and Currents

Aleksandra Leki\'c , Predrag Pejovi\'c This is my paper

Pith reviewed 2026-05-10 03:31 UTC · model grok-4.3

classification 📡 eess.SY cs.SY
keywords switching convertersaveraged modelssimulation algorithmswitching cellcontinuous conduction modediscontinuous conduction modepower electronicsquasi-steady-state approximation
0
0 comments X

The pith

An algorithm simulates switching converters on averaged voltages and currents then reconstructs instantaneous waveforms using quasi-steady-state and linear ripple approximations.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper presents an algorithm that first solves an averaged circuit model of switching converters built around the switching cell concept. Instantaneous values of voltages and currents are then constructed from that averaged solution by applying quasi-steady-state and linear ripple approximations. The method is shown to work for both continuous and discontinuous conduction modes and is demonstrated on the buck, boost, buck-boost, and flyback converters, the last requiring only a minor generalization of the switching cell. A sympathetic reader would care because the approach supplies both average quantities and detailed ripple information without requiring a full time-step simulation of every switching event.

Core claim

By simulating the averaged circuit model that uses the switching cell concept and then applying quasi-steady-state and linear ripple approximations, both the averaged and the instantaneous waveforms of voltages and currents can be obtained for switching converters operating in continuous or discontinuous conduction mode, as verified by simulations of buck, boost, buck-boost, and flyback topologies.

What carries the argument

The switching cell concept, which replaces the switching elements with an averaged equivalent circuit whose solution is then post-processed with quasi-steady-state and linear ripple approximations to recover instantaneous waveforms.

If this is right

  • The same averaged-model simulation plus reconstruction steps apply directly to buck, boost, and buck-boost converters in both continuous and discontinuous conduction.
  • A small generalization of the switching cell permits the method to cover the flyback converter as well.
  • Both averaged dc values and the superimposed ripple waveforms are produced from a single averaged simulation run.
  • The approach supplies an efficient alternative to cycle-by-cycle switching simulation while still delivering the instantaneous waveform details needed for design.
