On peculiarities of the annealing process for highly transparent silica-based aerogel tiles manufactured in Novosibirsk

A.Yu. Barnyakov (1 , Novosibirsk State Technical University , Novosibirsk , Russia) , A.F. Danilyuk (2) , A.A. Kattsin (1 , 3) , E.A. Kravchenko (1

show 5 more authors

A.A. Pochtar (2) A.Yu. Predein (2) ((1) Budker Institute of Nuclear Physics Russia (2) Boreskov Institute of Catalysis (3) Novosibirsk State University

Authors on Pith no claims yet

Pith reviewed 2026-05-15 01:09 UTC · model grok-4.3

classification ⚛️ physics.ins-det

keywords silica aerogelannealing processRICH detectorsCherenkov radiatorsoptical transparencyproduction yieldrefractive index

0 comments

The pith

Refining the annealing step increases the yield of large transparent silica aerogel tiles for RICH detectors.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper examines the annealing stage in the long-running Novosibirsk process for making silica aerogel blocks used as radiators in Cherenkov detectors. By mapping temperature and duration changes during this step, the authors identify adjustments that raise the fraction of finished tiles that meet optical and mechanical specifications for Ring-Imaging Cherenkov detectors. They report the transmission, refractive index, and density values achieved for the largest tiles produced with the revised schedule. These results matter because higher yield directly reduces the cost and time needed to supply radiators for experiments such as LHCb, AMS-02, and CLAS12.

Core claim

The annealing procedure was investigated in detail and optimized to improve the yield of aerogel tiles useful for the RICH detectors. The optical and mechanical parameters of the largest silica aerogel samples produced in Novosibirsk using the new annealing procedure are presented.

What carries the argument

The controlled annealing schedule that removes residual solvents and strengthens the gel network while limiting scattering centers and cracks.

If this is right

Higher fractions of usable large tiles become available for current and future RICH systems.
Optical transmission and refractive-index uniformity reach levels suitable for precise Cherenkov angle reconstruction.
Mechanical integrity remains adequate for detector assembly and operation.
Production throughput rises because fewer tiles are discarded after annealing.
The same process window can be applied to blocks of varying target refractive indices.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

If the new schedule is adopted elsewhere, the same yield gain could appear in aerogel production lines that follow similar sol-gel routes.
The reported parameters provide a concrete benchmark against which other annealing methods can be compared for transmission loss at short wavelengths.
Further size increases may still be limited by heat-transfer uniformity across the tile volume during the ramp phases.

Load-bearing premise

The described annealing optimizations can be reproduced at scale to consistently produce large tiles that meet detector specifications without new defects.

What would settle it

A side-by-side production run in which tiles annealed with the revised schedule show lower light transmission or higher cracking rates than tiles from the prior schedule.

Figures

Figures reproduced from arXiv: 2603.24630 by (2) Boreskov Institute of Catalysis, 3), (3) Novosibirsk State University, A.A. Kattsin (1, A.A. Pochtar (2), A.F. Danilyuk (2), A.Yu. Barnyakov (1, A.Yu. Predein (2) ((1) Budker Institute of Nuclear Physics, E.A. Kravchenko (1, Novosibirsk, Novosibirsk State Technical University, Russia, Russia).

**Figure 2.** Figure 2: The first four-layer sample produced in 2004 (left). The four-layer tile [PITH_FULL_IMAGE:figures/full_fig_p002_2.png] view at source ↗

**Figure 3.** Figure 3: X-ray image and profile of the 461f10 aerogel tile (side view). [PITH_FULL_IMAGE:figures/full_fig_p003_3.png] view at source ↗

**Figure 4.** Figure 4: The transmittance of the focusing aerogel tiles 461f5 (blue circles) and [PITH_FULL_IMAGE:figures/full_fig_p003_4.png] view at source ↗

**Figure 5.** Figure 5: Thick aerogel tiles: sample 461f13, the quarter-tile ( [PITH_FULL_IMAGE:figures/full_fig_p004_5.png] view at source ↗

**Figure 6.** Figure 6: Transmittance of thick aerogel tiles: 461f13 ( [PITH_FULL_IMAGE:figures/full_fig_p004_6.png] view at source ↗

read the original abstract

A collaboration between the Boreskov Institute of Catalysis and the Budker Institute of Nuclear Physics (BINP) has been producing silica aerogel blocks for Cherenkov detectors since 1986. Novosibirsk-manufactured aerogel is used in several experiments: KEDR and SND (BINP, Russia), LHCb (CERN, Switzerland), AMS-02 (ISS), and CLAS12 RICH (Jefferson Lab, USA). This work describes key advancements in the production technology for large-scale aerogel radiators used in Ring-Imaging CHerenkov (RICH) detectors. Annealing is one of the major stages of the highly transparent aerogel production in Novosibirsk. Its procedure was investigated in detail and optimized to improve the yield of aerogel tiles useful for the RICH detectors. The optical and mechanical parameters of the largest silica aerogel samples produced in Novosibirsk using the new annealing procedure are presented.
