arxiv: 2604.24937 · v1 · submitted 2026-04-27 · ❄️ cond-mat.str-el

Dielectric signatures of crystal-field and low-temperature correlated dynamics in NdMgAl11O19

Sonu Kumar , Ga\"el Bastien , Maxim Savinov , Ma{\l}gorzata \'Sliwi\'nska-Bartkowiak , Ross H. Colman , Stanislav Kamba This is my paper

Pith reviewed 2026-05-08 01:28 UTC · model grok-4.3

classification ❄️ cond-mat.str-el
keywords dielectric spectroscopycrystal electric fieldNdMgAl11O19Kramers doubletantiferromagnetic correlationsZeeman splittingmagnetoplumbitepermittivity
0
0 comments X

The pith

Dielectric permittivity in NdMgAl11O19 follows a Barrett formula that yields a 26 K gap matching the lowest Nd crystal-field splitting, with a low-temperature crossover at 0.85 T marking competition between antiferromagnetic correlations.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper establishes that dielectric spectroscopy along the c-axis of NdMgAl11O19 separates two distinct energy scales in this frustrated magnetoplumbite. High-frequency data above 30 K are captured by a Barrett expression plus a two-level term that returns a gap of 25.85 K, matching the expected lowest crystal-electric-field excitation of the Nd3+ ions. Below 30 K the permittivity turns strongly frequency- and field-dependent, and isothermal sweeps reveal a reproducible crossover near 0.85 T that the authors link to the point where Zeeman splitting begins to dominate antiferromagnetic correlations within the ground-state Kramers doublet. A sympathetic reader would care because the work shows how ordinary dielectric measurements can resolve both excited-state crystal-field physics and ground-state spin correlations in a centrosymmetric host without requiring neutron scattering.

Core claim

High-frequency permittivity ε'c(T) is described by a Barrett formula supplemented by an effective two-level contribution, yielding Δ = 25.85 ± 0.32 K consistent with the lowest Nd3+ crystal-electric-field splitting. Below ~30 K the dielectric response becomes strongly frequency- and magnetic-field-dependent. Isothermal εc'(H) measurements reveal a reproducible low-field crossover near μ0Hc ≃ 0.85 T attributed to the competition between antiferromagnetic correlations and Zeeman splitting of the ground-state Kramers doublet. NdMgAl11O19 therefore supplies a Kramers reference system in which dielectric signatures of the excited-state CEF manifold can be distinguished from those of the field-tun

What carries the argument

Barrett formula plus effective two-level contribution applied to high-frequency permittivity, which isolates the crystal-field gap; the same permittivity then registers a field-tuned crossover that tracks competition between antiferromagnetic correlations and Zeeman energy in the ground-state Kramers doublet.

If this is right

  • The extracted 25.85 K gap corresponds directly to the lowest crystal-electric-field splitting of the Nd3+ ions.
  • Dielectric response can serve as a probe that distinguishes excited CEF levels from ground-state doublet dynamics in centrosymmetric rare-earth hosts.
  • The 0.85 T crossover sets the magnetic-field scale at which Zeeman energy overtakes antiferromagnetic interactions within the Kramers doublet.
  • NdMgAl11O19 functions as a model Kramers system for testing how dielectric signatures evolve when CEF and correlation energies are tuned separately.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • Dielectric spectroscopy might be extended to other rare-earth magnetoplumbites to extract CEF gaps without neutron data.
  • The clean separation of scales in a centrosymmetric lattice suggests the method could be applied to related frustrated magnets where electric and magnetic degrees of freedom coexist.
  • Field-dependent dielectric measurements in different crystal orientations could test whether the 0.85 T scale is isotropic or reflects the anisotropy of the ground-state doublet.

Load-bearing premise

The low-field crossover at 0.85 T is produced specifically by competition between antiferromagnetic correlations and Zeeman splitting rather than by impurities, domain motion, or other extrinsic low-energy processes.

What would settle it

A magnetization or specific-heat measurement on the same crystals that finds no feature or anomaly at 0.85 T in the 2–10 K window would falsify the attribution of the dielectric crossover to magnetic-correlation versus Zeeman competition.

Figures

Figures reproduced from arXiv: 2604.24937 by Ga\"el Bastien, Ma{\l}gorzata \'Sliwi\'nska-Bartkowiak, Maxim Savinov, Ross H. Colman, Sonu Kumar, Stanislav Kamba.

Figure 1
Figure 1. Figure 1: (a) shows the temperature dependence of the real part of the dielectric permittivity, ε ′ c (T), measured in zero magnetic field at f = 9 kHz up to 275 K. On cool￾ing, ε ′ c (T) increases, passes through a broad maximum near ∼ 25–30 K, then decreases and finally shows a fur￾ther upturn below a few kelvin. Between approximately 35 and 200 K, the response is nearly frequency indepen￾dent within the experimen… view at source ↗
Figure 2
Figure 2. Figure 2: FIG. 2. Temperature dependence of view at source ↗
Figure 3
Figure 3. Figure 3: FIG. 3. Field dependence of the real permittivity view at source ↗
Figure 4
Figure 4. Figure 4: FIG. 4. Temperature dependence of the loss tangent view at source ↗
Figure 5
Figure 5. Figure 5: FIG. 5. Cole–Cole analysis of the frequency-dependent real permittivity of NdMgAl view at source ↗
Figure 6
Figure 6. Figure 6: FIG. 6. Qualitative schematic of broadening and field evolution in the low-energy CEF sector of NdMgAl view at source ↗
read the original abstract

We report dielectric spectroscopy of single-crystalline \ce{NdMgAl11O19}, a magnetoplumbite hexaaluminate in which localized \ce{Nd^{3+}} moments coexist with a polarizable \ce{AlO5} bipyramidal network. The real part of the permittivity, $\varepsilon'_{c}(T)$, measured along the crystallographic $c$ axis, increases as the temperature is lowered from 275~K to 30~K and is frequency-independent between 4~Hz and 50~kHz. At lower temperatures, a frequency-dependent decrease in permittivity is observed, followed by a further upturn below 2~K. The high-frequency $\varepsilon'_{c}(T)$ is described by a Barrett formula supplemented by an effective two-level contribution, yielding a robust gap of $\Delta = 25.85 \pm 0.32$~K consistent with the lowest \ce{Nd^{3+}} crystal-electric-field (CEF) splitting. Below $\sim 30$~K, the dielectric response becomes strongly frequency and magnetic-field dependent. Isothermal $\varepsilon_c'(H)$ measurements reveal a reproducible low-field crossover near $\mu_0H_c \simeq 0.85$~T, which we attribute to the competition between antiferromagnetic correlations and Zeeman splitting of the ground-state Kramers doublet. \ce{NdMgAl11O19} thus provides a Kramers reference system in which dielectric signatures of the excited-state CEF manifold can be distinguished from those of the field-tuned, correlation-dominated ground-state doublet sector in a centrosymmetric frustrated magnetoplumbite host

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

1 major / 0 minor

Summary. The manuscript reports dielectric spectroscopy on single-crystalline NdMgAl11O19, showing that the c-axis real permittivity ε'_c(T) increases upon cooling from 275 K to 30 K while remaining frequency-independent (4 Hz–50 kHz). Below ~30 K a frequency-dependent decrease appears, followed by an upturn below 2 K. High-frequency data are fit to a Barrett formula supplemented by an effective two-level contribution, producing a gap Δ = 25.85 ± 0.32 K that matches the lowest Nd^{3+} crystal-electric-field splitting reported in the literature. Below 30 K the response becomes strongly frequency- and field-dependent; isothermal ε'_c(H) scans exhibit a reproducible crossover near μ_0 H_c ≃ 0.85 T, which the authors attribute to competition between antiferromagnetic correlations and Zeeman splitting of the ground-state Kramers doublet. The work presents NdMgAl11O19 as a centrosymmetric frustrated magnetoplumbite reference system in which dielectric signatures of the excited CEF manifold can be separated from those of the field-tuned, correlation-dominated ground-state sector.

Significance. If the low-temperature interpretation holds, the result is significant because it supplies a dielectric route to separate CEF excitations from field-tuned ground-state correlations in a Kramers frustrated host. Credit is due for the clean, frequency-independent high-T data, the quantitative Barrett-plus-two-level fit whose gap agrees with independent CEF spectroscopy, and the reproducibility of the 0.85 T crossover across multiple isotherms. These elements make the high-temperature claim robust and position the material as a useful reference for future studies of dielectric response in magnetoplumbites.

major comments (1)
  1. In the section presenting the isothermal ε_c'(H) data and its interpretation (the paragraph immediately following the description of the low-T frequency dependence), the assignment of the reproducible crossover at μ_0 H_c ≃ 0.85 T to competition between antiferromagnetic correlations and Zeeman splitting of the ground-state Kramers doublet rests on qualitative matching of energy scales. No independent determination of the AF correlation energy (via magnetization, specific heat, or neutron scattering on the same crystals and in the same temperature window) is provided, nor is a calculation shown that g μ_B H_c equals the expected exchange field for the observed doublet. This leaves extrinsic mechanisms (impurity relaxations, domain-wall motion, or residual two-level systems) as viable alternative explanations for the observed field scale and therefore weakens the central claim that the 0.

Simulated Author's Rebuttal

1 responses · 0 unresolved

We thank the referee for the careful reading, the positive assessment of the high-temperature Barrett fit and its agreement with CEF spectroscopy, and the recognition that the work positions NdMgAl11O19 as a useful reference system. We address the single major comment below.

read point-by-point responses

  1. Referee: In the section presenting the isothermal ε_c'(H) data and its interpretation (the paragraph immediately following the description of the low-T frequency dependence), the assignment of the reproducible crossover at μ_0 H_c ≃ 0.85 T to competition between antiferromagnetic correlations and Zeeman splitting of the ground-state Kramers doublet rests on qualitative matching of energy scales. No independent determination of the AF correlation energy (via magnetization, specific heat, or neutron scattering on the same crystals and in the same temperature window) is provided, nor is a calculation shown that g μ_B H_c equals the expected exchange field for the observed doublet. This leaves extrinsic mechanisms (impurity relaxations, domain-wall motion, or residual two-level systems) as viable alternative explanations for the observed field scale and therefore weakens the central claim that the 0.

    Authors: We agree that the original wording presented the 0.85 T crossover as direct evidence of competition between AF correlations and Zeeman splitting on the basis of energy-scale matching alone, without an explicit calculation or new thermodynamic data on the same crystals. In the revised manuscript we will (i) add a quantitative estimate of the Zeeman energy g μ_B H_c at 0.85 T using the g-factor of the ground-state Kramers doublet reported in the CEF literature, (ii) compare this scale to published exchange constants for Nd^{3+} in related magnetoplumbites, and (iii) explicitly discuss why extrinsic mechanisms (impurity relaxations, domain-wall motion) are disfavored by the reproducibility across multiple isotherms and crystals and by the absence of analogous features in non-magnetic isostructural compounds. We will change the language from “we attribute” to “we interpret as consistent with” to reflect the qualitative nature of the supporting evidence. New magnetization or specific-heat measurements on the identical crystals lie outside the scope of the present dielectric study and cannot be added at this stage. revision: partial

Circularity Check

0 steps flagged

No circularity: experimental fits and attributions are independent of inputs

full rationale

The manuscript fits high-frequency ε'_c(T) data to the standard Barrett formula supplemented by a two-level term, extracting Δ = 25.85 ± 0.32 K and noting consistency with prior independent CEF literature; this is a comparison, not a derivation that reduces to the fit by construction. The 0.85 T crossover is directly observed in isothermal ε_c'(H) sweeps below 30 K and attributed via physical reasoning to AF correlations versus Zeeman splitting, without any self-referential equations, self-citations, or uniqueness theorems that force the interpretation from the data alone. All load-bearing steps rely on external benchmarks (literature CEF values, standard dielectric models) rather than internal redefinitions or fitted parameters renamed as predictions.

Axiom & Free-Parameter Ledger

1 free parameters · 2 axioms · 0 invented entities

The analysis relies on the standard Barrett formula for quantum paraelectrics and a phenomenological two-level system for the CEF contribution; the low-temperature interpretation invokes the existence of antiferromagnetic correlations without a microscopic model of their dielectric coupling.

free parameters (1)
  • Δ (CEF gap)
    Fitted from the high-frequency permittivity data using the Barrett-plus-two-level model; value 25.85 ± 0.32 K is reported as robust.
axioms (2)
  • domain assumption The dielectric response above 30 K is dominated by the lowest CEF excitation of Nd3+ and can be modeled by a two-level system plus Barrett background.
    Invoked to extract the gap value and to separate it from the low-temperature correlated regime.
  • ad hoc to paper The observed low-field crossover arises from competition between antiferromagnetic correlations and Zeeman splitting rather than extrinsic effects.
    Central interpretive step for the 0.85 T feature; no quantitative dielectric model under field is provided.

pith-pipeline@v0.9.0 · 5633 in / 1691 out tokens · 36621 ms · 2026-05-08T01:28:07.294692+00:00 · methodology

discussion (0)

Sign in with ORCID, Apple, or X to comment. Anyone can read and Pith papers without signing in.

Reference graph

Works this paper leans on

34 extracted references · 34 canonical work pages

  1. [1]

    A. P. Ramirez and S. V. Syzranov, Short-range order and hidden energy scale in geometrically frustrated magnets, Materials Advances6, 1213 (2025)

    work page 2025

  2. [2]

    Balents, Spin liquids in frustrated magnets, Nature 464, 199 (2010)

    L. Balents, Spin liquids in frustrated magnets, Nature 464, 199 (2010)

    work page 2010

  3. [3]

    Savary and L

    L. Savary and L. Balents, Quantum spin liquids: a re- view, Reports on Progress in Physics80, 016502 (2017)

    work page 2017

  4. [4]

    Y.-Y. Qin, Y. Shen, G. Chen, and J. Zhao, Magnetic frus- tration and quantum fluctuation in rare-earth triangular- lattice magnets, Physics50, 454 (2021)

    work page 2021

  5. [5]

    M. Xie, W. Zhuo, Y. Cai, Z. Zhang, and Q. Zhang, Rare- earth chalcogenides: an inspiring playground for explor- ing frustrated magnetism, Chinese Physics Letters41, 117505 (2024)

    work page 2024

  6. [6]

    A.Scheie, M.B.Sanders, P.Dai, V.O.Garlea, T.M.Mc- Queen, M. A. Taylor, M. B. Stone, and M. D. Lumsden, Emergent vibronic excitations in the magnetodielectric regime of Ce2O3, Physical Review Letters122, 177601 (2019)

    work page 2019

  7. [7]

    McDannald, A

    A. McDannald, A. Gunasekera, M. S. Seehra, and J. L. Musfeldt, Pressure- and magnetic-field-dependent cou- pling of phonons and crystal-field excitations in Pr2O3, Physical Review Research2, 043169 (2020)

    work page 2020

  8. [8]

    Bhowal, V

    S. Bhowal, V. Caignaert, G. Férey, M. S. Seehra, and J. L. Musfeldt, Kramers doublets, phonons, crystal-field excitations, and their coupling in Nd2ZnIrO6, Physical Review Research2, 023162 (2020)

    work page 2020

  9. [9]

    Kumar, G

    S. Kumar, G. Bastien, R. H. Colman, M. Savinov, P. Proschek, M. Vališka, M. Kempiński, W. Kempiński, M. Śliwińska-Bartkowiak, and S. Kamba, Crystal-field- driven magnetoelectric coupling in the non-Kramers hex- aaluminate PrMgAl11O19, Journal of Alloys and Com- pounds1061, 187535 (2026)

    work page 2026

  10. [10]

    Kumar, G

    S. Kumar, G. Bastien, M. Savinov, P. Proschek, A. Eliáš, K. Załęski, M. Śliwińska-Bartkowiak, R. H. Colman, and S. Kamba, Crystal field driven magnetoelectricity in the triangular quantum magnet CeMgAl11O19, Physical Re- view B112, 224431 (2025)

    work page 2025

  11. [11]

    Bastien, D

    G. Bastien, D. Repček, A. Eliáš, A. Kancko, Q. Cour- tade, T. Haidamak, M. Savinov, V. Bovtun, M. Kempa, K. Carva, M. Vališka, P. Doležal, M. Kratochvílová, S. A. Barnett, P. Proschek, J. Prokleška, C. Kadlec, P. Kužel, R. H. Colman, and S. Kamba, A frustrated antipolar phase analogous to classical spin liquids, Advanced Ma- terials36, 2410282 (2024)

    work page 2024

  12. [12]

    Kimura, M

    K. Kimura, M. Ohgaki, K. Tanaka, H. Morikawa, and F. Marumo, Study of the bipyramidal site in magnetoplumbite-like compounds, SrM12O19 (M = Al, Fe, Ga), Journal of Solid State Chemistry88, 370 (1990)

    work page 1990

  13. [13]

    N. Iyi, S. Takekawa, and S. Kimura, Refinement of the structure of lead hexaaluminate (PbAl12O19), Journal of Solid State Chemistry82, 150 (1989)

    work page 1989

  14. [14]

    Y. Li, H. Liao, Z. Zhang, S. Li, F. Jin, L. Ling, L. Zhang, Y. Zou, L. Pi, Z. Yang, J. Wang, Z. Wu, and Q. Zhang, Gapless quantum spin liquid ground state in the two-dimensional spin-1/2 triangular antiferromagnet YbMgGaO4, Scientific Reports5, 16419 (2015)

    work page 2015

  15. [15]

    P.S.WangandH.J.Xiang,Room-temperatureferrimag- net with frustrated antiferroelectricity: promising candi- date toward multiple-state memory, Physical Review X 4, 011035 (2014)

    work page 2014

  16. [16]

    J. Li, E. A. Medina, J. K. Stalick, A. W. Sleight, and M. A. Subramanian, Structural studies of CaAl 12O19, SrAl12O19, La2/3+δAl12−δO19, and CaAl10NiTiO19 with the hibonite structure; indications of an unusual type of ferroelectricity, Zeitschrift für Naturforschung B71, 475 (2016)

    work page 2016

  17. [17]

    Kumar, G

    S. Kumar, G. Bastien, J. Prokleška, M. Kempiński, W. Kempiński, K. Załęski, A. Kancko, C. Antunes Cor- rêa, T. Treu, P. Gegenwart, M. Śliwińska-Bartkowiak, and R. H. Colman, Magnetic anisotropy and absence of long-range order in the triangular magnet NdMgAl11O19 (2025), arXiv:2505.18898 [cond-mat.str-el]

    work page arXiv 2025

  18. [18]

    J. G. Rau and M. J. P. Gingras, Effective point- charge analysis of crystal fields: application to rare-earth triangular-lattice magnets, Physical Review Research3, 10 023012 (2021)

    work page 2021

  19. [19]

    Kumar, M

    S. Kumar, M. Klicpera, A. Eliáš, M. Kratochvílová, A. Kancko, C. A. Corrêa, K. Załęski, M. Śliwińska- Bartkowiak, R. H. Colman, and G. Bastien, Induced quantum magnetism on a triangular lattice of non- Kramers ions in PrMgAl11O19, Physical Review B111, 174444 (2025)

    work page 2025

  20. [20]

    Kumar, B

    S. Kumar, B. Salajová, A. Kancko, C. A. Corrêa, S. Halder, and R. H. Colman, Strongly quenched Kramers doublet magnetism in SmMgAl 11O19 (2026), arXiv:2601.13439 [cond-mat.str-el]

    work page arXiv 2026

  21. [21]

    Bastien, A

    G. Bastien, A. Eliáš, V. Anderle, A. Kancko, C. A. Corrêa, S. Kumar, P. Proschek, J. Prokleška, L. Nád- herný, D. Sedmidubský, T. Treu, P. Gegenwart, M. Kra- tochvílová, M.Žonda,andR.H.Colman,Quantumdisor- dered ground state and relative proximity to an exactly solvable model in the frustrated magnet CeMgAl11O19 (2025), arXiv:2506.16207 [cond-mat.str-el]

    work page arXiv 2025

  22. [22]

    S. E. Rowley, L. J. Spalek, R. P. Smith, M. P. M. Dean, M. Itoh, J. F. Scott, G. G. Lonzarich, and S. S. Saxena, Ferroelectric quantum criticality, Nature Physics10, 367 (2014)

    work page 2014

  23. [23]

    Orenstein, V

    G. Orenstein, V. Krapivin, Y. Huang, Z. Zhang, G. de la Peña Muñoz, R. A. Duncan, Q. Nguyen, J. Stanton, S. Teitelbaum, H. Yavas,et al., Observation of polar- ization density waves in SrTiO3, Nature Physics21, 961 (2025)

    work page 2025

  24. [24]

    O. G. Vendik and S. P. Zubko, Modeling the dielectric response of incipient ferroelectrics, Journal of Applied Physics82, 4475 (1997)

    work page 1997

  25. [25]

    Fujishita, S

    H. Fujishita, S. Kitazawa, M. Saito, R. Ishisaka, H. Okamoto, and T. Yamaguchi, Quantum paraelectric states in SrTiO3 and KTaO3: Barrett model, Vendik model, and quantum criticality, Journal of the Physical Society of Japan85, 074703 (2016)

    work page 2016

  26. [26]

    W. A. Phillips, Two-level states in glasses, Reports on Progress in Physics50, 1657 (1987)

    work page 1987

  27. [27]

    E. A. Goremychkin, R. Osborn, C. H. Wang, M. D. Lumsden, M. A. McGuire, A. S. Sefat, B. C. Sales, D. Mandrus, H. M. Rønnow, Y. Su, and A. D. Christian- son, Spatial inhomogeneity inRFeAsO 1−xFx (R= Pr, Nd) determined from rare-earth crystal-field excitations, Physical Review B83, 212505 (2011)

    work page 2011

  28. [28]

    Vayer, S

    F. Vayer, S. Petit, F. Damay, J. Embs, S. Rols, C. Colin, E. Lhotel, D. Bounoua, N. Dragoe, D. Bérardan, and C. Decorse, Entropy-stabilized materials as a platform to explore terbium-based pyrochlore frustrated magnets, Communications Materials5, 162 (2024)

    work page 2024

  29. [29]

    Jensen and A

    J. Jensen and A. R. Mackintosh,Rare Earth Magnetism: Structures and Excitations(Clarendon Press, Oxford, 1991)

    work page 1991

  30. [30]

    Reif,Fundamentals of Statistical and Thermal Physics (Waveland Press, 2009)

    F. Reif,Fundamentals of Statistical and Thermal Physics (Waveland Press, 2009)

    work page 2009

  31. [31]

    L. D. Landau and E. M. Lifshitz,Statistical Physics(El- sevier, 2013)

    work page 2013

  32. [32]

    B. Gao, T. Chen, C. Liu, M. L. Klemm, S. Zhang, Z. Ma, X. Xu, C. Won, G. T. McCandless, K. Rao, N. Murai, S. Ohira-Kawamura, S. J. Moxim, J. T. Ryan, X. Huang, X. Wang, M. D. Le, E. Morosan, J. Y. Chan, S.-W. Cheong, O. Tchernyshyov, L. Balents, and P. Dai, Spin excitationcontinuumfromdegeneratestatesinthemixed ferro-antiferromagnetic exchange system CeMg...

    work page doi:10.1126/sciadv.aed7778 2026

  33. [33]

    C. P. Tu, Z. Ma, H. R. Wang, Y. H. Jiao, D. Z. Dai, and S. Y. Li, Gapped quantum spin liquid in a triangular- lattice ising-type antiferromagnet PrMgAl11O19, Physi- cal Review Research6, 043147 (2024)

    work page 2024

  34. [34]

    Y. Cao, H. Bu, Z. Fu, J. Zhao, J. S. Gardner, Z. Ouyang, Z. Tian, Z. Li, and H. Guo, Synthesis, disorder and ising anisotropy in a new spin liquid candidate PrMgAl11O19, Materials Futures3, 035201 (2024)

    work page 2024
