A Novel Two-Step Approach for Reactive Power Demand Calculation Using Integrated Voltage Stability Analysis

Hassan Abouelgheit , Hendrik Lens
Authors on Pith no claims yet

Pith reviewed 2026-05-08 01:26 UTC · model grok-4.3

classification 📡 eess.SY cs.SY
keywords reactive power demandvoltage stabilitypower system planningquasi-dynamic simulationQ-V analysisdynamic simulationtime-series analysisvoltage violations
0
0 comments X

The pith

A two-step simulation method directly calculates the reactive power a power grid needs by checking voltage stability over a full year.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper introduces a methodology that calculates reactive power demand by running a sequence of simulations that together assess both long-term and short-term voltage stability. It combines quasi-dynamic simulation, Q-V analysis, and dynamic simulation iteratively across all 8760 hours of a year, judging violations by their number, severity, and duration. A sympathetic reader would care because knowing the true demand lets planners install the right amount of compensation equipment to keep voltages stable without waste or risk. This differs from prior work that usually optimizes equipment placement in a single simulation step rather than first measuring the actual demand through back-to-back checks.

Core claim

The proposed two-step approach directly calculates actual reactive power demand by integrating Quasi-Dynamic Simulation, Q-V analysis, and dynamic simulation sequentially in an iterative framework that performs comprehensive time-series analysis over 8760 hours with multi-criteria assessment of voltage violations. In the case study, the method identified and addressed all buses experiencing voltage issues and produced the total reactive power demand required across the network.

What carries the argument

The two-step back-to-back simulation framework that sequentially applies quasi-dynamic simulation, Q-V analysis, and dynamic simulation with annual time-series and multi-criteria violation scoring.

If this is right

  • All voltage-violating buses in the network can be systematically identified and resolved through the integrated checks.
  • The exact total reactive power demand for the entire network can be quantified for use in planning compensation equipment.
  • Single-simulation optimization approaches are insufficient because they miss the combined long-term and short-term stability picture.
  • Time-series analysis over 8760 hours provides a more complete demand figure than methods using only representative snapshots.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • The approach could be extended to grids with high shares of renewables to track how reactive needs shift with variable generation patterns.
  • It might support real-time grid operators by updating demand estimates as conditions change throughout the year.
  • Computational cost for very large networks would need testing, since running full dynamic simulations hourly could become expensive.

Load-bearing premise

The sequential combination of these three simulation types over a full year accurately reflects the grid's true reactive power needs without missing interactions or introducing large modeling errors.

What would settle it

Applying the calculated reactive power amounts in a follow-up simulation or real grid test and still observing voltage violations that exceed the multi-criteria thresholds of number, severity, and duration would show the method underestimates demand.

Figures

Figures reproduced from arXiv: 2604.25016 by Hassan Abouelgheit, Hendrik Lens.

Figure 1
Figure 1. Figure 1: Proposed two-step approach for reactive power demand calculation highest-priority bus, to calculate the reactive power demand (∆Qi) required to compensate for the volt￾age violation (∆Vi) at that specific bus. A reactive power compensation equipment is then installed at the identified bus location, followed by another QDS to assess the system’s improved performance and pos￾sible new voltage violations. Thi… view at source ↗
Figure 2
Figure 2. Figure 2: Illustrative graph showing TVI and its boundaries [12] analyze voltage stability [6]. It illustrates the rela￾tionship between the reactive power Q injected or absorbed at a specific bus and the resulting voltage V at that bus. The vertical axis represents the re￾active power, while the horizontal axis represents the bus voltage in per unit (p.u.). Reference [27] provides detailed information on Q-V-curve … view at source ↗
Figure 3
Figure 3. Figure 3: Voltage magnitudes of all buses in the 39- view at source ↗
Figure 4
Figure 4. Figure 4: Voltage magnitudes of the buses that vio view at source ↗
Figure 6
Figure 6. Figure 6: Q-V Curve for Bus 04 in iteration 1 view at source ↗
Figure 9
Figure 9. Figure 9: Voltage magnitudes of all buses in the transmission system in iteration 3 view at source ↗
Figure 8
Figure 8. Figure 8: Analysis of simulation results using generic view at source ↗
Figure 10
Figure 10. Figure 10: TVI analysis and voltage curves of all buses in iteration 1 A contingency list was defined including a short circuit fault on line 09-39 at t = 2.5 s with a fault clearing time of 100 ms combined with a generator event in which G 03 went out of service at t = 2.66 s. These two events have caused a large disturbance in the system with a noticeable voltage drop following the short-circuit recovery, see 10. … view at source ↗
Figure 11
Figure 11. Figure 11: Q-V Analysis for Bus 07 after iteration 1 view at source ↗
Figure 13
Figure 13. Figure 13: TVI analysis and voltage curves of all buses – after compensation in step 2 voltage violations. This could lead to an overestima￾tion of the actual reactive power demand. Moreover, in real networks it is not feasible to install a compen￾sation equipment at each critical bus that experiences voltage deviations due to space limitations and regu￾latory constraints. Looking ahead, future work will focus on ap… view at source ↗
read the original abstract

The assessment of reactive power demand plays an instrumental role in power system planning. This paper presents a methodology for calculating reactive power demand based on a two-step approach. Unlike existing methodologies in the literature that focus primarily on optimization of reactive power compensation equipment placement and sizing through single-simulation approaches, this methodology directly calculates the actual reactive power demand through a comprehensive back-to-back simulation framework. While existing methods address either long-term or short-term voltage stability using either steady-state analysis or individual dynamic simulations, the proposed approach integrates both stability assessments sequentially through iterative Quasi-Dynamic Simulation, Q-V analysis and dynamic simulation. Furthermore, this methodology employs comprehensive time-series analysis over a full annual period (8760 hours) with multi-criteria violation assessment (number, severity and duration of voltage violations). In the final section of this paper, a case study was conducted to demonstrate the application of the proposed methodology. Simulations were performed to validate the effectiveness of the methodology, with the results showing that all buses with voltage issues were successfully addressed and finally the total reactive power demand across the network was calculated.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

2 major / 2 minor

Summary. The paper proposes a two-step methodology for calculating reactive power demand in power systems by sequentially integrating Quasi-Dynamic Simulation, Q-V analysis, and dynamic simulation over a full annual period (8760 hours), employing multi-criteria violation assessment based on number, severity, and duration of voltage issues. Unlike single-simulation optimization approaches in the literature, it claims to directly compute the actual demand through this back-to-back framework. A case study is presented in which all buses with voltage issues were successfully addressed and the total reactive power demand across the network was calculated.

Significance. If the mapping from violation metrics to a reproducible demand value can be made explicit, the integrated long-term/short-term stability assessment over comprehensive time-series data could provide a more complete alternative to existing placement/sizing optimization methods. The multi-criteria, full-year evaluation is a methodological strength relative to steady-state-only or single-dynamic-simulation techniques.

major comments (2)
  1. [Abstract and case-study section] Abstract and final (case-study) section: the central claim that the framework 'directly calculates the actual reactive power demand' requires an explicit, reproducible aggregation rule that converts the multi-criteria violation statistics (number/severity/duration over 8760 h) into a single numerical Q value or set of per-bus injections. No such formula, threshold definitions, or iterative feedback procedure between the three simulation layers is supplied; the text only states that violations 'were successfully addressed' and demand 'was calculated.' This mapping is load-bearing for the claimed advantage over optimization-based methods.
  2. [Methodology and case-study sections] Methodology and case-study sections: no quantitative performance metrics, error bars, baseline comparisons against existing Q-compensation sizing methods, or sensitivity analysis on simulation parameters are reported. The case study supplies only the qualitative statement that 'all buses with voltage issues were successfully addressed,' which is insufficient to substantiate the demand-calculation claim.
minor comments (2)
  1. [Abstract] The abstract would be strengthened by including at least one key quantitative outcome (e.g., total MVAR demand or number of buses corrected) from the case study.
  2. [Methodology] Notation for the three simulation stages and the violation criteria should be defined consistently when first introduced.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the thorough and constructive review. The comments identify key areas where the manuscript can be strengthened to better substantiate the proposed methodology. We address each major comment below and will revise the manuscript accordingly.

read point-by-point responses

  1. Referee: [Abstract and case-study section] Abstract and final (case-study) section: the central claim that the framework 'directly calculates the actual reactive power demand' requires an explicit, reproducible aggregation rule that converts the multi-criteria violation statistics (number/severity/duration over 8760 h) into a single numerical Q value or set of per-bus injections. No such formula, threshold definitions, or iterative feedback procedure between the three simulation layers is supplied; the text only states that violations 'were successfully addressed' and demand 'was calculated.' This mapping is load-bearing for the claimed advantage over optimization-based methods.

    Authors: We acknowledge that the explicit mapping from multi-criteria violation statistics to the computed reactive power demand values was not presented with sufficient detail. In the revised manuscript we will add a new subsection in the Methodology section that defines the violation thresholds (for number, severity, and duration), describes the iterative feedback procedure linking the quasi-dynamic, Q-V, and dynamic simulation layers, and provides the aggregation formula that converts the violation metrics into per-bus reactive power injections and the network-wide total demand. This addition will make the calculation reproducible and directly address the referee's concern. revision: yes

  2. Referee: [Methodology and case-study sections] Methodology and case-study sections: no quantitative performance metrics, error bars, baseline comparisons against existing Q-compensation sizing methods, or sensitivity analysis on simulation parameters are reported. The case study supplies only the qualitative statement that 'all buses with voltage issues were successfully addressed,' which is insufficient to substantiate the demand-calculation claim.

    Authors: We agree that the case-study results are currently limited to qualitative statements. In the revision we will expand the case-study section to include quantitative metrics (e.g., total violation duration reduction, severity index before/after compensation), error bars derived from repeated simulations with varied initial conditions, direct numerical comparisons against two established optimization-based Q-placement methods, and a sensitivity analysis on key parameters such as quasi-dynamic time step and Q-V curve resolution. These additions will provide the necessary quantitative support for the demand-calculation claim. revision: yes

Circularity Check

0 steps flagged

No significant circularity; simulation framework is independent of target result

full rationale

The paper describes a two-step methodology that chains quasi-dynamic simulation, Q-V analysis, and dynamic simulation over 8760 hours, using multi-criteria voltage violation detection to arrive at a reactive power demand figure. No equations, parameters, or steps are shown that reduce the final demand value to a fitted input, self-citation, or definitional tautology. The derivation relies on external simulation outputs and explicit (if unstated in the abstract) aggregation rules rather than constructing the result from itself. This is the normal case of a self-contained engineering procedure.

Axiom & Free-Parameter Ledger

0 free parameters · 0 axioms · 0 invented entities

Based on abstract only; no explicit free parameters, axioms, or invented entities are detailed. Standard power-system assumptions about simulation fidelity are implicit but not enumerated.

pith-pipeline@v0.9.0 · 5488 in / 1282 out tokens · 105550 ms · 2026-05-08T01:26:48.620095+00:00 · methodology

discussion (0)

Sign in with ORCID, Apple, or X to comment. Anyone can read and Pith papers without signing in.

Reference graph

Works this paper leans on

30 extracted references · 22 canonical work pages

  1. [1]

    Comprehensive review of short-term voltage stability evaluation methods in modern power systems,

    A. Boriˇ ci´ c, J. L. R. Torres, and M. Popov, “Comprehensive review of short-term voltage stability evaluation methods in modern power systems,”Energies, vol. 14, no. 14, p. 4076, Jul. 6, 2021.doi:10.3390/en14144076

    work page doi:10.3390/en14144076 2021

  2. [2]

    [Online]

    IEA,Germany 2020 - energy policy review. [Online]. Available:https://iea.blob.core. windows.net/assets/60434f12-7891-4469- b3e4-1e82ff898212/Germany_2020_Energy_ Policy_Review.pdf

    2020

  3. [3]

    Reactive power planning considering high penetration of wind energy,

    X. Fang, F. Li, and Y. Xu, “Reactive power planning considering high penetration of wind energy,” in2014 IEEE PES T&D Conference and Exposition, Chicago, IL, USA: IEEE, Apr. 2014, pp. 1–5.doi:10 . 1109 / TDC . 2014 . 6863471

    2014

  4. [4]

    Evaluation of volt- age stability assessment methodologies in mod- ern power systems with increased penetra- tion of inverter-based resources,

    Technical Committee: Power Systems Dynamic Performance Committee, “Evaluation of volt- age stability assessment methodologies in mod- ern power systems with increased penetra- tion of inverter-based resources,” The Institute of Electrical and Electronics Engineers, Inc., Technical Report PES-TR126, 2024

    2024

  5. [5]

    Definition and classi- fication of power system stability – revisited & extended,

    N. Hatziargyriou et al., “Definition and classi- fication of power system stability – revisited & extended,”IEEE Transactions on Power Sys- tems, vol. 36, no. 4, pp. 3271–3281, Jul. 2021. doi:10.1109/TPWRS.2020.3041774

    work page doi:10.1109/tpwrs.2020.3041774 2021

  6. [6]

    Kundur,Power System Stability and Con- trol

    P. Kundur,Power System Stability and Con- trol. McGraw-Hill Education, 1994

    1994

  7. [7]

    Reactive power planning of power system using trajectory sen- sitivity index,

    T. A. Pranto and T. Aziz, “Reactive power planning of power system using trajectory sen- sitivity index,” in2021 International Confer- ence on Technology and Policy in Energy and Electric Power (ICT-PEP), Jakarta, Indonesia: 10 IEEE, Sep. 29, 2021, pp. 80–84.doi:10.1109/ ICT-PEP53949.2021.9600933

    work page arXiv 2021

  8. [8]

    Optimal re- active power planning and compensation ef- fects on transmission loss components,

    H. Barot and K. Bhattacharya, “Optimal re- active power planning and compensation ef- fects on transmission loss components,” in 2007 IEEE Power Engineering Society General Meeting, ISSN: 1932-5517, Tampa, FL, USA: IEEE, Jun. 2007, pp. 1–7.doi:10.1109/PES. 2007.386161

    work page doi:10.1109/pes 2007

  9. [9]

    Reac- tive shunt compensation planning by optimal power flows and linear sensitivities,

    U. A. R. Diaz and J. H. T. Hernandez, “Reac- tive shunt compensation planning by optimal power flows and linear sensitivities,” in2009 Electronics, Robotics and Automotive Mechan- ics Conference (CERMA), Cuernavaca, More- los, Mexico: IEEE, Sep. 2009, pp. 326–331.doi: 10.1109/CERMA.2009.73

    work page doi:10.1109/cerma.2009.73 2009

  10. [10]

    Reactive power optimization con- trol strategy for large-scale new energy access grid based on optimized particle swarm algo- rithm,

    X. Han, H. Cai, S. Xu, Z. Peng, F. Zhao, and W. Qi, “Reactive power optimization con- trol strategy for large-scale new energy access grid based on optimized particle swarm algo- rithm,” in2022 4th International Conference on Electrical Engineering and Control Tech- nologies (CEECT), Shanghai, China: IEEE, Dec. 2022, pp. 1216–1221

    2022

  11. [11]

    Der reac- tive services and distribution network losses,

    D. Pudjianto, P. Djapic, G. Strbac, E. T. Van Schalkwyk, and B. Stojkovska, “Der reac- tive services and distribution network losses,” CIRED - Open Access Proceedings Journal, vol. 2020, no. 1, pp. 541–544, Jan. 1, 2020.doi: 10.1049/oap-cired.2021.0111

    work page doi:10.1049/oap-cired.2021.0111 2020

  12. [12]

    Optimal allocation and sizing of dynamic var sources using heuristic optimization,

    S. Wildenhues, J. L. Rueda, and I. Erlich, “Optimal allocation and sizing of dynamic var sources using heuristic optimization,”IEEE Transactions on Power Systems, vol. 30, no. 5, pp. 2538–2546, Sep. 2015.doi:10 . 1109 / TPWRS.2014.2361153

    work page arXiv 2015

  13. [13]

    Dis- tribution network reactive power optimization considering multi flexible controlled resources,

    L. Xiaojiao, S. Juncheng, W. Yuanyuan, C. Yanbin, Z. Shuangle, and G. Yongchang, “Dis- tribution network reactive power optimization considering multi flexible controlled resources,” in2022 China Automation Congress (CAC), Xiamen, China: IEEE, Nov. 25, 2022, pp. 5587– 5591.doi:10.1109/CAC57257.2022.10055509

    work page doi:10.1109/cac57257.2022.10055509 2022

  14. [14]

    Reactive power opti- mization for voltage stability in energy inter- net based on graph convolutional networks and deep q-learning,

    S. Guo and J. Cao, “Reactive power opti- mization for voltage stability in energy inter- net based on graph convolutional networks and deep q-learning,” in2021 4th IEEE Interna- tional Conference on Industrial Cyber-Physical Systems (ICPS), Victoria, BC, Canada: IEEE, May 10, 2021, pp. 511–516.doi:10 . 1109 / ICPS49255.2021.9468118

    work page arXiv 2021

  15. [15]

    Research on reactive power optimiza- tion strategy under the intelligent improvement model of the distribution network,

    M. Yu, “Research on reactive power optimiza- tion strategy under the intelligent improvement model of the distribution network,”Advances in Multimedia, vol. 2022, Q. Li, Ed., pp. 1–11, Oct. 4, 2022.doi:10.1155/2022/9310507

    work page doi:10.1155/2022/9310507 2022

  16. [16]

    Quantification index of voltage stability based on physical mecha- nism of reactive power distribution,

    H. Jiang and H. Zhang, “Quantification index of voltage stability based on physical mecha- nism of reactive power distribution,” in2021 IEEE 4th Student Conference on Electric Ma- chines and Systems (SCEMS), Huzhou, China: IEEE, Dec. 1, 2021, pp. 1–6.doi:10 . 1109 / SCEMS52239.2021.9646127

    work page arXiv 2021

  17. [17]

    Voltage sta- bility assessment and improvement in power systems with solar photovoltaic penetration,

    C. Dondariya and D. Sakravdia, “Voltage sta- bility assessment and improvement in power systems with solar photovoltaic penetration,” in2021 IEEE 2nd International Conference On Electrical Power and Energy Systems (ICEPES), Bhopal, India: IEEE, Dec. 10, 2021, pp. 1–4.doi:10 . 1109 / ICEPES52894 . 2021 . 9699827

    2021

  18. [18]

    Voltage stability enhancement by reactive power changes based on voltage stability index PTSI,

    M. C. Ziegler and M. Wolter, “Voltage stability enhancement by reactive power changes based on voltage stability index PTSI,”

  19. [19]

    Volt- age stability index based on multi-bus reactive power loading,

    P. M. Munyao, J. T. Agee, and R. Tiako, “Volt- age stability index based on multi-bus reactive power loading,” in2021 IEEE PES/IAS Pow- erAfrica, Nairobi, Kenya: IEEE, Aug. 23, 2021, pp. 1–5.doi:10 . 1109 / PowerAfrica52236 . 2021.9543435

    work page arXiv 2021

  20. [20]

    Comprehensive configura- tion method for static and dynamic reactive power compensation of multi-voltage level ur- ban power grid,

    Y. Song et al., “Comprehensive configura- tion method for static and dynamic reactive power compensation of multi-voltage level ur- ban power grid,” in2023 13th International Conference on Power and Energy Systems (ICPES), Chengdu, China: IEEE, Dec. 8, 2023, 11 pp. 57–63.doi:10.1109/ICPES59999.2023. 10400102

    work page doi:10.1109/icpes59999.2023 2023

  21. [21]

    Sizing of a reactive power compensation device for a 300mw grid con- nected wind plant,

    Jayasudha, V. K H, M. G. Nair, J. K. Pisini, and A. Thomas, “Sizing of a reactive power compensation device for a 300mw grid con- nected wind plant,” in2025 2nd International Conference On Multidisciplinary Research and Innovations in Engineering (MRIE), Guru- gram, India: IEEE, Jul. 30, 2025, pp. 399–404. doi:10.1109/MRIE66930.2025.11156630

    work page doi:10.1109/mrie66930.2025.11156630 2025

  22. [22]

    A novel reactive power compensation scheme of UHV AC transmission line,

    J. Zhang, Z. Chen, K. Gao, and A. Yan, “A novel reactive power compensation scheme of UHV AC transmission line,” in2009 Asia- Pacific Power and Energy Engineering Confer- ence, Wuhan, China: IEEE, Mar. 2009, pp. 1– 4.doi:10.1109/APPEEC.2009.4918102

    work page doi:10.1109/appeec.2009.4918102 2009

  23. [23]

    Discussion and research- ing on dynamic reactive power planning,

    L. Du and F. Cheng, “Discussion and research- ing on dynamic reactive power planning,” in 2010 Asia-Pacific Power and Energy Engineer- ing Conference, Chengdu, China: IEEE, 2010, pp. 1–4.doi:10.1109/APPEEC.2010.5448774

    work page doi:10.1109/appeec.2010.5448774 2010

  24. [24]

    Dynamic reactive power allocation strategy for AC/DC system based on quantum genetic algorithm,

    Y. Li et al., “Dynamic reactive power allocation strategy for AC/DC system based on quantum genetic algorithm,” in2020 Chinese Automa- tion Congress (CAC), Shanghai, China: IEEE, Nov. 6, 2020, pp. 1949–1954

    2020

  25. [25]

    Active compensation of reactive power via STATCOM analysis,

    V. K. Satyamsetti, A. Michaelides, and A. Hadjiantonis, “Active compensation of reactive power via STATCOM analysis,”IET Confer- ence Proceedings, vol. 2020, no. 5, pp. 121–126, Jun. 2, 2021.doi:10.1049/icp.2021.1252

    work page doi:10.1049/icp.2021.1252 2020

  26. [26]

    Research on the suppression function of reactive power compensation device based on harmonic source detection,

    Z. Kang, Y. Luo, J. An, and Y. Feng, “Research on the suppression function of reactive power compensation device based on harmonic source detection,” in2025 4th International Confer- ence on Power System and Power Engineer- ing (PSPE), Zhenjiang, China: IEEE, Sep. 19, 2025, pp. 188–192.doi:10.1109/PSPE66589. 2025.11296395

    work page doi:10.1109/pspe66589 2025

  27. [27]

    Q-V curve interpretations of energy measures for voltage security,

    T. J. Overbye, I. Dobson, and C. L. DeMarco, “Q-V curve interpretations of energy measures for voltage security,” vol. 9, no. 1, pp. 331–340, Feb. 1994.doi:10.1109/59.317593 [28]PowerFactory DIg SILENT, version 2025 SP3 (x64). [Online]. Available:https : / / www . digsilent.de/en/powerfactory.html

    work page doi:10.1109/59.317593 1994

  28. [28]

    Dynamic IEEE test sys- tems for transient analysis,

    P. Demetriou, M. Asprou, J. Quiros-Tortos, and E. Kyriakides, “Dynamic IEEE test sys- tems for transient analysis,”IEEE Systems Journal, vol. 11, no. 4, pp. 2108–2117, Dec. 2017.doi:10.1109/JSYST.2015.2444893

    work page doi:10.1109/jsyst.2015.2444893 2017

  29. [29]

    The creation and validation of load time series for synthetic electric power sys- tems,

    H. Li, J. H. Yeo, A. L. Bornsheuer, and T. J. Overbye, “The creation and validation of load time series for synthetic electric power sys- tems,”IEEE Transactions on Power Systems, vol. 36, no. 2, pp. 961–969, Mar. 2021.doi: 10.1109/TPWRS.2020.3018936

    work page doi:10.1109/tpwrs.2020.3018936 2021

  30. [30]

    A practical method for the direct analysis of tran- sient stability,

    T. Athay, R. Podmore, and S. Virmani, “A practical method for the direct analysis of tran- sient stability,”IEEE Transactions on Power Apparatus and Systems, vol. PAS-98, no. 2, pp. 573–584, Mar. 1979.doi:10.1109/TPAS. 1979.319407 12

    work page doi:10.1109/tpas 1979
