From Visual to Digital: Coordination Scheduling and Its Effect on Safety and Efficiency in UAM Corridors

Akihiro Fujita , Sasinee Pruekprasert , Katsuhiro Nishinari , Shinji Nakadai This is my paper

Pith reviewed 2026-05-25 03:57 UTC · model grok-4.3

classification 📡 eess.SY cs.SY
keywords urban air mobilityUAM corridorscoordination strategiesVFRDFRsafety performancetraffic efficiencyETA sharing
0
0 comments X

The pith

Global coordination via shared ETAs sustains safety and efficiency in high-density UAM corridors where local visual rules require wider spacing that cuts throughput.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper compares a local coordination strategy inspired by visual flight rules that uses only spatial information available to each vehicle against a global strategy aligned with digital flight rules that relies on shared estimated times of arrival at constrained waypoints. It adds a lightweight disturbance-avoidance mechanism allowing vehicles to adjust ETAs from forecasted disruptions using shared data. Numerical simulations under varying disturbance levels show the local approach delivers high throughput at low traffic densities but becomes collision-prone at higher densities unless conservative separations are enforced, which reduces efficiency, while the global approach maintains more consistent safety performance and traffic efficiency even with moderate ETA update propagation delays.

Core claim

DFR-style global coordination based on shared ETAs at waypoints, supported by the disturbance-avoidance mechanism, maintains consistent safety performance and traffic efficiency across traffic densities and disturbance levels, whereas VFR-style local coordination requires conservative separation to prevent collisions at high densities, thereby lowering throughput.

What carries the argument

The comparison of local reactive VFR-style spatial coordination against global DFR-style ETA sharing at constrained waypoints, enabled by the lightweight disturbance-avoidance mechanism that adjusts ETAs from shared forecasted disruptions.

Load-bearing premise

The numerical simulations under varying disturbance levels accurately represent the behavior of real UAM vehicles and disturbances.

What would settle it

Field measurements of actual collision rates and throughput in a UAM corridor at increasing traffic densities, comparing local spatial coordination against global ETA sharing under realistic disturbances, would confirm or refute the simulation outcomes.

read the original abstract

This paper explores scalable coordination strategies for urban air mobility (UAM) corridors by comparing two representative approaches. The first, inspired by visual flight rules (VFR), is a local coordination strategy relying on spatial information available to each vehicle. The second, conceptually aligned with digital flight rules (DFR), is a global coordination strategy based on shared estimated times of arrival (ETAs) at constrained waypoints (CWPs). To support this comparison, we introduce a lightweight disturbance-avoidance mechanism that enables vehicles to adjust their ETAs in response to forecasted disruptions using shared information. We evaluate these approaches through numerical simulations under varying disturbance levels, comparing the locally reactive VFR-style scheme with the globally coordinated DFR-style scheme. Results show that VFR achieves high throughput in low-traffic scenarios but becomes increasingly prone to collisions at higher traffic densities unless conservative separation is enforced, which reduces traffic efficiency. In contrast, DFR maintains more consistent safety performance and traffic efficiency, even under moderate ETA update propagation delays. These findings highlight the advantages of DFR-style global coordination in managing high-density air traffic control (ATC) operations within UAM corridors.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

3 major / 2 minor

Summary. The manuscript compares a local VFR-style coordination strategy (relying on spatial information) with a global DFR-style strategy (using shared ETAs at constrained waypoints) for UAM corridors. It introduces a lightweight disturbance-avoidance mechanism allowing ETA adjustments based on shared forecasts, then evaluates both via numerical simulations under varying disturbance levels. The central claim is that VFR achieves high throughput at low densities but becomes collision-prone at higher densities unless conservative separations are enforced (reducing efficiency), whereas DFR maintains more consistent safety and efficiency even with moderate ETA propagation delays.

Significance. If the simulation results are representative, the work would provide concrete evidence favoring global coordination for dense UAM operations and could guide ATC design. The introduction of the disturbance-avoidance mechanism is a positive contribution. However, the complete absence of calibration or validation of vehicle dynamics, disturbance models, or traffic scenarios against real UAM specifications or flight data means the reported performance gaps cannot be assumed to transfer outside the simulated environment, substantially reducing the result's significance.

major comments (3)
  1. [Abstract and numerical simulations section] Abstract and § on numerical simulations: the central claim that DFR maintains more consistent safety and efficiency is drawn exclusively from simulations, yet no details are provided on the underlying vehicle dynamics model, disturbance generation process, quantitative metrics (e.g., collision probability, throughput), or traffic-density definitions, preventing verification that the data support the VFR-vs-DFR comparison.
  2. [Results and evaluation sections] Results and evaluation sections: the performance advantage attributed to DFR over VFR at higher densities rests on the unvalidated assumption that the simulated disturbances and vehicle responses accurately represent real UAM behavior; without calibration to specifications or empirical data, the reported differences may be artifacts of the chosen models rather than intrinsic to the coordination strategies.
  3. [Disturbance-avoidance mechanism description] Disturbance-avoidance mechanism description: the mechanism is presented as enabling the DFR advantage, but no sensitivity analysis or ablation is shown to isolate its contribution from the global vs. local distinction; this makes it unclear whether the safety/efficiency gains are due to DFR coordination or to the specific avoidance rule.
minor comments (2)
  1. [Introduction] Define all acronyms (VFR, DFR, CWP, ETA) and key parameters (separation distances, delay magnitudes) at first use and in a notation table.
  2. [Figures and tables] Add explicit statements of simulation parameters (vehicle count, corridor geometry, disturbance variance ranges) to figure captions or a dedicated table to support reproducibility.

Simulated Author's Rebuttal

3 responses · 0 unresolved

We thank the referee for the constructive and detailed comments, which help clarify the presentation and scope of our simulation-based study. We address each major comment below and indicate planned revisions to the manuscript.

read point-by-point responses

  1. Referee: [Abstract and numerical simulations section] Abstract and § on numerical simulations: the central claim that DFR maintains more consistent safety and efficiency is drawn exclusively from simulations, yet no details are provided on the underlying vehicle dynamics model, disturbance generation process, quantitative metrics (e.g., collision probability, throughput), or traffic-density definitions, preventing verification that the data support the VFR-vs-DFR comparison.

    Authors: We agree that the simulation setup requires more explicit documentation for reproducibility. In the revised manuscript, we will add a new subsection in the numerical simulations section detailing: the vehicle dynamics (3D point-mass model with velocity/acceleration bounds and proportional-derivative control), disturbance generation (zero-mean Gaussian perturbations on position/velocity with specified standard deviations), metric definitions (collision as minimum separation < 50 m, throughput as completed corridor transits per hour, safety as collision rate over Monte Carlo runs), and traffic density (vehicles per km of corridor length, with low/high thresholds). These additions will directly support verification of the VFR-DFR comparison. revision: yes

  2. Referee: [Results and evaluation sections] Results and evaluation sections: the performance advantage attributed to DFR over VFR at higher densities rests on the unvalidated assumption that the simulated disturbances and vehicle responses accurately represent real UAM behavior; without calibration to specifications or empirical data, the reported differences may be artifacts of the chosen models rather than intrinsic to the coordination strategies.

    Authors: We acknowledge that the study is purely numerical and lacks calibration or validation against real UAM vehicle specifications or flight data. The contribution lies in a controlled, apples-to-apples comparison under identical dynamics and disturbance models for both strategies; any performance gaps therefore arise from the local vs. global information and decision structures. In revision we will insert a 'Limitations' paragraph stating that results are illustrative of coordination principles and that transfer to operational UAM requires future empirical validation. We maintain that the differences are not model artifacts but will strengthen the caveats as requested. revision: partial

  3. Referee: [Disturbance-avoidance mechanism description] Disturbance-avoidance mechanism description: the mechanism is presented as enabling the DFR advantage, but no sensitivity analysis or ablation is shown to isolate its contribution from the global vs. local distinction; this makes it unclear whether the safety/efficiency gains are due to DFR coordination or to the specific avoidance rule.

    Authors: We will add an ablation study and sensitivity analysis in the revised evaluation section. Specifically, we will run additional Monte Carlo simulations comparing (i) full DFR, (ii) DFR without the disturbance-avoidance rule (i.e., fixed ETAs), and (iii) VFR, under the same disturbance levels. We will also report sensitivity of key performance metrics to the avoidance parameters (forecast horizon and adjustment magnitude). This will isolate the mechanism's contribution from the global coordination aspect. revision: yes

Circularity Check

0 steps flagged

No circularity: results are direct simulation outputs with no self-referential reductions

full rationale

The paper compares VFR-style local coordination and DFR-style global ETA coordination via numerical simulations under varying disturbance levels. No equations, parameters, or claims reduce by construction to their own inputs; performance differences are reported as simulation outcomes rather than fitted or renamed quantities. No self-citations, uniqueness theorems, or ansatzes are load-bearing for the central results. The derivation chain is self-contained within the described simulation framework.

Axiom & Free-Parameter Ledger

0 free parameters · 0 axioms · 0 invented entities

No specific free parameters, axioms, or invented entities are described in the abstract. Review is abstract-only.

pith-pipeline@v0.9.0 · 5751 in / 1053 out tokens · 22320 ms · 2026-05-25T03:57:50.076572+00:00 · methodology

discussion (0)

Sign in with ORCID, Apple, or X to comment. Anyone can read and Pith papers without signing in.

Reference graph

Works this paper leans on

26 extracted references · 26 canonical work pages

  1. [1]

    Urban air mobility airspace integration concepts and considerations,

    Thipphavong, D. P., Apaza, R., Barmore, B., Battiste, V., Burian, B., Dao, Q., Feary, M., Go, S., Goodrich, K. H., Homola, J., et al., “Urban air mobility airspace integration concepts and considerations,”2018 Aviation Technology, Integration, and Operations Conference, 2018, p. 3676

    work page 2018

  2. [2]

    Scalingconstraintsforurbanairmobilityoperations: Airtrafficcontrol,groundinfrastructure, and noise,

    Vascik,P.D.,andHansman,R.J.,“Scalingconstraintsforurbanairmobilityoperations: Airtrafficcontrol,groundinfrastructure, and noise,”2018 Aviation technology, Integration, and Operations conference, 2018, p. 3849

    work page 2018

  3. [3]

    Air corridors: Concept, design, simulation, and rules of engagement,

    Muna, S. I., Mukherjee, S., Namuduri, K., Compere, M., Akbas, M. I., Molnár, P., and Subramanian, R., “Air corridors: Concept, design, simulation, and rules of engagement,”Sensors, Vol. 21, No. 22, 2021, p. 7536

    work page 2021

  4. [4]

    Designing airspace for urban air mobility: A review of concepts and approaches,

    Bauranov, A., and Rakas, J., “Designing airspace for urban air mobility: A review of concepts and approaches,”Progress in Aerospace Sciences, Vol. 125, 2021, p. 100726

    work page 2021

  5. [5]

    Urban Air Mobility Concept of Operations v1.0,

    Bradford, S., “Urban Air Mobility Concept of Operations v1.0,” Federal Aviation Administration, Office of NextGen, 26 June

    work page

  6. [6]

    URL https://nari.arc.nasa.gov/sites/default/files/attachments/UAM_ConOps_v1.0.pdf, accessed: 2025-11-20

    work page 2025

  7. [7]

    Urban Air Mobility Concept of Operations v2.0,

    Fontaine, P., “Urban Air Mobility Concept of Operations v2.0,” Federal Aviation Administration, Office of NextGen, 26 April

    work page

  8. [8]

    URL https://www.faa.gov/sites/faa.gov/files/Urban%20Air%20Mobility%20%28UAM%29%20Concept% 20of%20Operations%202.0_1.pdf, accessed: 2025-11-20

    work page 2025

  9. [9]

    Air traffic assignment for intensive urban air mobility operations,

    Wang, Z., Delahaye, D., Farges, J.-L., and Alam, S., “Air traffic assignment for intensive urban air mobility operations,”Journal of Aerospace Information Systems, Vol. 18, No. 11, 2021, pp. 860–875

    work page 2021

  10. [10]

    Digital flight: A new cooperative operating mode to complement VFR and IFR,

    Wing, D., Lacher, A., Ryan, W., Cotton, W., Stilwell, R., Maris, J., and Vajda, P., “Digital flight: A new cooperative operating mode to complement VFR and IFR,” , 1 Sep. 2022. URLhttps://ntrs.nasa.gov/api/citations/20220013225/ downloads/NASA-TM-20220013225.pdf, accessed: 2025-11-20

    work page arXiv 2022

  11. [11]

    Regulations: VFR vs. IFR,

    Stull, R., “Regulations: VFR vs. IFR,” ATSC 113 Applied Meteorology Weather for Sailing, Flying & Snow Sports, UniversityofBritishColumbia,2023. URL https://www.eoas.ubc.ca/courses/atsc113/flying/met_concepts/01- met_concepts/01g-vfr-ifr/index.html, accessed: 2025-11-20

    work page 2023

  12. [12]

    AMetrics-basedMethodforEvaluatingCorridors for Urban Air Mobility Operations,

    Jiang,X.,Peng,X.,Bulusu,V.,Poliziani,C.,Chatterji,G.,andSengupta,R.,“AMetrics-basedMethodforEvaluatingCorridors for Urban Air Mobility Operations,”2022 IEEE International Smart Cities Conference (ISC2), IEEE, 2022, pp. 1–7

    work page 2022

  13. [13]

    Design and analysis of corridors for UAM operations,

    Verma, S., Dulchinos, V., Wood, R. D., Farrahi, A., Mogford, R., Shyr, M., and Ghatas, R., “Design and analysis of corridors for UAM operations,”2022 IEEE/AIAA 41st Digital Avionics Systems Conference (DASC), IEEE, 2022, pp. 1–10

    work page 2022

  14. [14]

    AirspaceDesignsandOperationsforUASTrafficManagement at Low Altitude,

    Lee,U.-J.,Ahn,S.-J.,Choi,D.-Y.,Chin,S.-M.,andJang,D.-S.,“AirspaceDesignsandOperationsforUASTrafficManagement at Low Altitude,”Aerospace, Vol. 10, No. 9, 2023, p. 737

    work page 2023

  15. [15]

    Study on Urban Air Mobility Corridor Design in the Vicinity of Airports,

    Toratani, D., Hirabayashi, H., Senoguchi, A., and Otsuyama, T., “Study on Urban Air Mobility Corridor Design in the Vicinity of Airports,”2023 IEEE/AIAA 42nd Digital Avionics Systems Conference (DASC), IEEE, 2023, pp. 1–7. 13

    work page 2023

  16. [16]

    Designing an Urban Air Mobility Corridor Network: A Multi-Objective Optimization Approach Using U-NSGA-III,

    Zhang, Z., Zheng, Y., Li, C., Jiang, B., and Li, Y., “Designing an Urban Air Mobility Corridor Network: A Multi-Objective Optimization Approach Using U-NSGA-III,”Aerospace, Vol. 12, No. 3, 2025, p. 229

    work page 2025

  17. [17]

    Ground-BasedCommunicationSupportforAirCorridors,

    Prabhath, K., Sun, X., Jayaweera, S. K., Manu, D., Kakaraparty, K., Pallav, S., Mahbub, I., Mandapaka, J. S., Rochi, S. D., Meraz,M.,etal.,“Ground-BasedCommunicationSupportforAirCorridors,”2023IEEE34thAnnualInternationalSymposium on Personal, Indoor and Mobile Radio Communications (PIMRC), IEEE, 2023, pp. 1–6

    work page 2023

  18. [18]

    Digital Twin Approach for Integrated Airspace Management with Applications to Advanced Air Mobility Services,

    Namuduri, K., “Digital Twin Approach for Integrated Airspace Management with Applications to Advanced Air Mobility Services,”IEEE Open Journal of Vehicular Technology, Vol. 4, 2023, pp. 693–700

    work page 2023

  19. [19]

    Digital Traffic Lights: UAS Collision Avoidance Strategy for Advanced Air Mobility Services,

    McCorkendale, Z., McCorkendale, L., Kidane, M. F., and Namuduri, K., “Digital Traffic Lights: UAS Collision Avoidance Strategy for Advanced Air Mobility Services,”Drones, Vol. 8, No. 10, 2024, p. 590

    work page 2024

  20. [20]

    Safe Arrival Scheduling at Constraint Waypoints in UAM Corridors,

    Pruekprasert, S., and Nakadai, S., “Safe Arrival Scheduling at Constraint Waypoints in UAM Corridors,”AIAA SCITECH 2025 Forum, 2025, p. 2232

    work page 2025

  21. [21]

    Enhancing security in vehicle-to-vehicle communication: A comprehensive review of protocols and techniques,

    Muslam, M. M. A., “Enhancing security in vehicle-to-vehicle communication: A comprehensive review of protocols and techniques,”Vehicles, Vol. 6, No. 1, 2024, pp. 450–467

    work page 2024

  22. [22]

    Simulation of Bottlenecks in Single Lane Traffic Flow,

    Helly, W., “Simulation of Bottlenecks in Single Lane Traffic Flow,”Proceedings of the Symposium on Theory of Traffic Flow, Elsevier, New York, 1959, pp. 207–238

    work page 1959

  23. [23]

    Parameter identification on helly’s car-following model,

    Ambrosio-Lázaro, R. C., Quezada-Téllez, L. A., and Rosas-Jaimes, O. A., “Parameter identification on helly’s car-following model,”Proceedings of the 5th International Conference of Control, Dynamic Systems, and Robotics (CDSR’18), 2018, p. 107

    work page 2018

  24. [24]

    L., and Faires, J

    Burden, R. L., and Faires, J. D.,Numerical Analysis, 9th ed., Brooks/Cole, Cengage Learning, 2010

    work page 2010

  25. [25]

    BOREAL—A fixed-wing unmanned aerial system for the measurement of wind and turbulence in the atmospheric boundary layer,

    Alaoui-Sosse, S., Durand, P., Medina, P., Pastor, P., Gavart, M., and Pizziol, S., “BOREAL—A fixed-wing unmanned aerial system for the measurement of wind and turbulence in the atmospheric boundary layer,”Journal of Atmospheric and Oceanic Technology, Vol. 39, No. 3, 2022, pp. 387–402

    work page 2022

  26. [26]

    Aeronautical Information Manual (AIM), Chapter 3: Airspace, Section 1: General,

    Federal Aviation Administration, “Aeronautical Information Manual (AIM), Chapter 3: Airspace, Section 1: General,” https://www.faa.gov/air_traffic/publications/atpubs/aim_html/chap3_section_1.html, 2025. Accessed: 2025-11-20. 14

    work page 2025
