Reciprocal Beyond Diagonal Reconfigurable Intelligent Surface: Distributed Scattering Matrix Design and MIMO Beamforming via Fractional Programming and Manifold Optimization
Pith reviewed 2026-05-20 15:52 UTC · model grok-4.3
The pith
Fractional programming designs MIMO beamforming weights for reciprocal BD-RIS that decompose into independent power-constrained sub-beamformers.
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
Core claim
The proposed fractional programming approach, based on the equivalent channel incorporating a reciprocal BD-RIS parameterized by existing scattering matrix design methods, yields optimized MIMO BF weights that decompose the transmit beamformer into multiple sum-rate maximization sub-beamformers, each satisfying an independent power-constraint, allowing optimal handling of distributed MIMO-BF scenarios and outperforming existing BD-RIS-aided schemes when combined with RBD-RIS scattering matrices.
What carries the argument
Fractional programming framework applied to the equivalent channel of the reciprocal BD-RIS, which produces MIMO beamforming weights that decompose into independent sum-rate maximization sub-beamformers for distributed power constraints.
If this is right
- The proposed SRM-MIMO-BF framework is independent of the specific scattering matrix design.
- The approach extends the BD-RIS-aided system model to the CF-mMIMO setting with a corresponding beamforming matrix.
- Simulation results show outperformance over SotA schemes employing existing MIMO-BF techniques.
- Distributed MIMO-BF scenarios can be optimally handled due to the decomposition into independent power-constrained sub-beamformers.
Where Pith is reading between the lines
- Tailored beamforming can unlock additional gains from advanced RIS designs in large-scale networks.
- Joint optimization of scattering matrices and beamformers might yield improvements beyond the sequential design approach.
- The method could apply to other types of reconfigurable surfaces in wireless systems.
Load-bearing premise
That parameterizing a reciprocal BD-RIS with existing scattering matrix designs forms an equivalent channel that can be directly used in a fractional programming framework to produce MIMO beamforming weights decomposable into independent power-constrained sum-rate maximization sub-beamformers.
What would settle it
Running the proposed method against existing MIMO-BF techniques in the same BD-RIS setup and finding no sum-rate improvement in simulations would challenge the claim.
Figures
read the original abstract
We consider the optimization of beyond diagonal reconfigurable intelligent surface (BD-RIS)-aided multi-user (MU) cell-free (CF)-massive multiple-input multiple-output (mMIMO) systems, where the propagation environment design achieved scattering matrix optimization is complemented by developing an efficient base station (BS) beamforming (BF) scheme that effectively exploits the latter ``engineered'' channel. In particular, we describe a fractional programming (FP) method, which based on the equivalent channel incorporating a reciprocal BD-RIS (RBD-RIS) parameterized by existing scattering matrix design methods, yielding the correspondingly optimized multiple-input multiple-output (MIMO) BF weights. The proposed approach decomposes the transmit (TX) beamformer into multiple sum-rate maximization (SRM) sub-beamformers, each satisfying an independent power-constraint, such that distributed MIMO-BF scenarios can be optimally handled. Although the proposed SRM-MIMO-BF framework is independent of the specific scattering matrix design, extending the BD-RIS-aided system model to the CF-mMIMO setting requires the design of a corresponding beamforming matrix. In this context, this work investigates the impact of beamforming in reconfigurable intelligent surface (RIS)-aided systems. Simulation results demonstrate that the proposed method for designing the MIMO-BF weights, when combined with the previously developed design of reciprocal BD-RIS (RBD-RIS) scattering matrices, outperforms existing BD-RIS-aided state-of-the-art (SotA) schemes employing existing MIMO-BF techniques, indicating that the whole contribution is more than the sum of the parts.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The paper considers the optimization of beyond diagonal reconfigurable intelligent surface (BD-RIS)-aided multi-user cell-free massive MIMO systems. It develops a fractional programming (FP) method for MIMO beamforming weights based on an equivalent channel that incorporates a reciprocal BD-RIS (RBD-RIS) parameterized by existing scattering matrix design methods. The approach decomposes the transmit beamformer into multiple sum-rate maximization sub-beamformers with independent power constraints for distributed scenarios. Simulations are presented to show that combining this beamforming method with previously developed RBD-RIS scattering matrix designs outperforms existing BD-RIS-aided state-of-the-art schemes using conventional MIMO beamforming techniques.
Significance. If validated, the results would indicate that the proposed beamforming optimization provides meaningful gains when paired with reciprocal BD-RIS designs in cell-free mMIMO settings. The decomposition property is particularly valuable for distributed implementations. The framework's claimed independence from the specific scattering matrix design is a notable strength, as it allows modular use with various RBD-RIS parameterizations. Credit is due for addressing the combined optimization of environment and beamforming in this context.
major comments (2)
- [Simulation results] Simulation results section: The central performance claim of outperformance over SotA schemes rests on the reported simulations, but the manuscript provides no details on channel models, system parameters (number of antennas, RIS elements, users), Monte Carlo runs, or statistical measures such as error bars. This makes it difficult to assess the robustness of the gains and is load-bearing for the headline result.
- [FP method] FP framework and decomposition (around the equivalent channel parameterization): While the updates and reduction to independent per-sub-beamformer SRM problems under separate power constraints are derived, a more explicit convergence analysis or optimality guarantee when the RBD-RIS scattering matrix is held fixed from prior designs would strengthen the theoretical support for the distributed CF-mMIMO case.
minor comments (2)
- [Abstract] The abstract is dense and could more explicitly separate the new beamforming contribution from the reliance on previously developed scattering matrix designs to clarify the incremental novelty.
- [Notation and system model] Notation consistency: Ensure uniform usage of BD-RIS versus RBD-RIS and define all acronyms at first use in the main text.
Simulated Author's Rebuttal
We thank the referee for the positive assessment of our work and the constructive comments, which help improve the clarity and rigor of the manuscript. We address each major comment point by point below.
read point-by-point responses
-
Referee: [Simulation results] Simulation results section: The central performance claim of outperformance over SotA schemes rests on the reported simulations, but the manuscript provides no details on channel models, system parameters (number of antennas, RIS elements, users), Monte Carlo runs, or statistical measures such as error bars. This makes it difficult to assess the robustness of the gains and is load-bearing for the headline result.
Authors: We agree that additional details on the simulation setup are necessary to ensure reproducibility and to allow readers to properly evaluate the robustness of the reported gains. In the revised version, we will expand the Simulation Results section with a new subsection that explicitly specifies the channel models (including path-loss exponents and fading distributions), all system parameters (e.g., number of BS antennas M, RIS elements N, users K, and cell-free BS count), the number of Monte Carlo realizations, and statistical measures such as error bars or standard deviations on the plotted curves. revision: yes
-
Referee: [FP method] FP framework and decomposition (around the equivalent channel parameterization): While the updates and reduction to independent per-sub-beamformer SRM problems under separate power constraints are derived, a more explicit convergence analysis or optimality guarantee when the RBD-RIS scattering matrix is held fixed from prior designs would strengthen the theoretical support for the distributed CF-mMIMO case.
Authors: We appreciate this observation. Because the RBD-RIS scattering matrix is obtained from prior designs and then held fixed, the equivalent channel seen by the beamformer is constant during the FP iterations. The quadratic transform underlying our FP approach therefore inherits the standard convergence guarantees to a stationary point of the sum-rate maximization problem under per-sub-beamformer power constraints. The decomposition into independent SRM sub-problems follows directly from the separability of the power constraints and does not alter these guarantees. Nevertheless, to make this explicit, we will add a short convergence subsection in the revised manuscript that recalls the relevant FP properties and notes their applicability to the fixed-scattering-matrix, distributed CF-mMIMO setting. revision: yes
Circularity Check
Minor self-citation for evaluation but core FP derivation and decomposition are independent
full rationale
The paper states that the SRM-MIMO-BF framework is independent of the specific scattering matrix design and derives the fractional programming updates plus the decomposition into independent power-constrained SRM sub-beamformers directly from the equivalent channel. Performance results combine the new BF weights with a previously developed RBD-RIS parameterization, but this is presented as an application rather than a definitional reduction; the mathematical steps stand alone and do not reduce to the prior design by construction. Self-citation appears in the combined claim but is not load-bearing for the central derivation, which remains self-contained against external benchmarks.
Axiom & Free-Parameter Ledger
axioms (2)
- domain assumption An equivalent channel can be formed by parameterizing a reciprocal BD-RIS using existing scattering matrix design methods.
- domain assumption The decomposition of the transmit beamformer into multiple SRM sub-beamformers each satisfying an independent power constraint optimally handles distributed MIMO-BF scenarios.
Lean theorems connected to this paper
-
IndisputableMonolith/Cost/FunctionalEquation.leanwashburn_uniqueness_aczel unclear?
unclearRelation between the paper passage and the cited Recognition theorem.
We describe a fractional programming (FP) method, which based on the equivalent channel incorporating a reciprocal BD-RIS (RBD-RIS) parameterized by existing scattering matrix design methods, yielding the correspondingly optimized multiple-input multiple-output (MIMO) BF weights. The proposed approach decomposes the transmit (TX) beamformer into multiple sum-rate maximization (SRM) sub-beamformers
-
IndisputableMonolith/Foundation/AlexanderDuality.leanalexander_duality_circle_linking unclear?
unclearRelation between the paper passage and the cited Recognition theorem.
a novel method to design reciprocal BD-RIS (RBD-RIS) scattering matrices was proposed, whereby the challenging problem of maximizing the system’s sum-rate while incorporating a reciprocal structure that enforces both unitary and symmetry constraints was addressed under a manifold optimization framework
What do these tags mean?
- matches
- The paper's claim is directly supported by a theorem in the formal canon.
- supports
- The theorem supports part of the paper's argument, but the paper may add assumptions or extra steps.
- extends
- The paper goes beyond the formal theorem; the theorem is a base layer rather than the whole result.
- uses
- The paper appears to rely on the theorem as machinery.
- contradicts
- The paper's claim conflicts with a theorem or certificate in the canon.
- unclear
- Pith found a possible connection, but the passage is too broad, indirect, or ambiguous to say the theorem truly supports the claim.
Reference graph
Works this paper leans on
-
[1]
Reconfigurable intelligent surfaces: A signal pro- cessing perspective with wireless applications,
E. Bj ¨ornson, H. Wymeersch, B. Matthiesen, P. Popovski, L. Sanguinetti, and E. de Carvalho, “Reconfigurable intelligent surfaces: A signal pro- cessing perspective with wireless applications,”IEEE Signal Processing Magazine, vol. 39, no. 2, pp. 135–158, 2022
work page 2022
-
[2]
Reconfigurable intelligent surfaces: Principles and opportunities,
Y . Liu, X. Liu, X. Mu, T. Hou, J. Xu, M. D. Renzo, and N. Al-Dhahir, “Reconfigurable intelligent surfaces: Principles and opportunities,”IEEE Commun. Surveys Tuts., vol. 23, no. 3, pp. 1546–1577, 2021
work page 2021
-
[3]
Closed-form global optimization of beyond diagonal reconfigurable intelligent surfaces,
M. Nerini, S. Shen, and B. Clerckx, “Closed-form global optimization of beyond diagonal reconfigurable intelligent surfaces,”IEEE Transactions on Wireless Communications, 2023
work page 2023
-
[4]
Fractional programming and manifold optimization for reciprocal BD-RIS scattering matrix design,
M. Fidanovski, I. A. M. Sandoval, K. R. R. Ranasinghe, G. T. F. de Abreu, E. Bj ¨ornson, and B. Clerckx, “Fractional programming and manifold optimization for reciprocal BD-RIS scattering matrix design,”
-
[5]
Available: https://arxiv.org/abs/2511.07683
[Online]. Available: https://arxiv.org/abs/2511.07683
work page internal anchor Pith review arXiv
-
[6]
M. Fidanovski, I. A. M. Sandoval, H. S. Rou, G. T. F. de Abreu, and E. Bj ¨ornson, “Reciprocal beyond-diagonal reconfigurable intelligent surface (BD-RIS): Scattering matrix design via manifold optimization,”
-
[7]
Available: https://arxiv.org/abs/2509.20246
[Online]. Available: https://arxiv.org/abs/2509.20246
-
[8]
E. Bj ¨ornson, M. Bengtsson, and B. Ottersten, “Optimal multiuser trans- mit beamforming: A difficult problem with a simple solution structure [lecture notes],”IEEE Signal Processing Magazine, vol. 31, no. 4, pp. 142–148, 2014
work page 2014
-
[9]
Convex optimization-based beamforming,
A. B. Gershman, N. D. Sidiropoulos, S. Shahbazpanahi, M. Bengtsson, and B. Ottersten, “Convex optimization-based beamforming,”IEEE Signal Processing Magazine, vol. 27, no. 3, pp. 62–75, 2010
work page 2010
-
[10]
L. C. Godara,Handbook of antennas in wireless communications. CRC press, 2018
work page 2018
-
[11]
Channel estimation and beamforming for beyond diagonal reconfigurable intelligent surfaces,
H. Li, S. Shen, Y . Zhang, and B. Clerckx, “Channel estimation and beamforming for beyond diagonal reconfigurable intelligent surfaces,” IEEE Transactions on Signal Processing, vol. 72, pp. 3318–3332, 2024
work page 2024
-
[12]
H. Li, S. Shen, and B. Clerckx, “Beyond diagonal reconfigurable intelli- gent surfaces: A multi-sector mode enabling highly directional full-space wireless coverage,”IEEE Journal on Selected Areas in Communications, vol. 41, no. 8, pp. 2446–2460, 2023
work page 2023
-
[13]
Enhancing ISAC network throughput using beyond diagonal RIS,
Z. Liu, Y . Liu, S. Shen, Q. Wu, and Q. Shi, “Enhancing ISAC network throughput using beyond diagonal RIS,”IEEE Wireless Communications Letters, vol. 13, no. 6, pp. 1670–1674, 2024
work page 2024
-
[14]
Transmitter side beyond-diagonal RIS for mmwave integrated sensing and communications,
K. Chen and Y . Mao, “Transmitter side beyond-diagonal RIS for mmwave integrated sensing and communications,” in2024 IEEE 25th International Workshop on Signal Processing Advances in Wireless Communications (SPA WC), 2024, pp. 951–955
work page 2024
-
[15]
Y . Zhou, Y . Liu, H. Li, Q. Wu, S. Shen, and B. Clerckx, “Optimizing power consumption, energy efficiency, and sum-rate using beyond diagonal RIS—a unified approach,”IEEE Transactions on Wireless Communications, vol. 23, no. 7, pp. 7423–7438, 2024
work page 2024
-
[16]
H. Li, S. Shen, and B. Clerckx, “Beyond diagonal reconfigurable intelligent surfaces: From transmitting and reflecting modes to single- , group-, and fully-connected architectures,”IEEE Transactions on Wireless Communications, vol. PP, pp. 1–1, 01 2022
work page 2022
-
[17]
CVX: Matlab software for disciplined convex programming, version 2.1,
M. Grant and S. Boyd, “CVX: Matlab software for disciplined convex programming, version 2.1,” https://cvxr.com/cvx, Mar. 2014
work page 2014
-
[18]
Optimization of beyond diagonal RIS: A universal framework applicable to arbitrary architectures,
Z. Wu and B. Clerckx, “Optimization of beyond diagonal RIS: A universal framework applicable to arbitrary architectures,” 2024. [Online]. Available: https://arxiv.org/abs/2412.15965
-
[19]
A low-complexity beamforming design for beyond-diagonal RIS aided multi-user networks,
T. Fang and Y . Mao, “A low-complexity beamforming design for beyond-diagonal RIS aided multi-user networks,”IEEE Communications Letters, vol. 28, no. 1, pp. 203–207, 2024
work page 2024
-
[20]
Beamform- ing design for multi-sector BD-RIS assisted FL with aircomp,
X. Xu, Y . Ju, Z. Li, X. Hou, L. Liu, S. Mumtaz, and C. Wu, “Beamform- ing design for multi-sector BD-RIS assisted FL with aircomp,” in2025 IEEE Wireless Communications and Networking Conference (WCNC), 2025, pp. 1–6
work page 2025
-
[21]
Massive MIMO is a reality—what is next?: Five promising research directions for antenna arrays,
E. Bj ¨ornson, L. Sanguinetti, H. Wymeersch, J. Hoydis, and T. L. Marzetta, “Massive MIMO is a reality—what is next?: Five promising research directions for antenna arrays,”Digital Signal Processing, vol. 94, pp. 3–20, 2019, special Issue on Source Localization in TO BE SUBMITTED TO THE IEEE TRANSACTIONS ON WIRELESS COMMUNICATIONS, 2026 12 Massive MIMO. [...
work page 2019
-
[22]
Cooperative beamforming for RIS-aided cell-free massive MIMO networks,
X. Ma, D. Zhang, M. Xiao, C. Huang, and Z. Chen, “Cooperative beamforming for RIS-aided cell-free massive MIMO networks,”IEEE Transactions on Wireless Communications, vol. 22, no. 11, pp. 7243– 7258, 2023
work page 2023
-
[23]
Distributed distortion-aware beamforming designs for cell-free mMIMO systems,
M. Liu, M. Li, R. Liu, and Q. Liu, “Distributed distortion-aware beamforming designs for cell-free mMIMO systems,”IEEE Journal of Selected Topics in Signal Processing, 2025
work page 2025
-
[24]
Decentralized cooperative beamforming for BDRIS-assisted cell-free MIMO OFDM systems,
K. D. Katsanos and G. C. Alexandropoulos, “Decentralized cooperative beamforming for BDRIS-assisted cell-free MIMO OFDM systems,”
-
[25]
Available: https://arxiv.org/abs/2601.13201
[Online]. Available: https://arxiv.org/abs/2601.13201
-
[26]
Extendable carrier synchronization for distributed beamforming in wireless sensor networks,
S. Shi, S. Zhu, X. Gu, and R. Hu, “Extendable carrier synchronization for distributed beamforming in wireless sensor networks,” in2016 Inter- national Wireless Communications and Mobile Computing Conference (IWCMC), 2016, pp. 298–303
work page 2016
-
[27]
Spread spectrum based energy efficient collaborative communication in wireless sensor networks,
A. Ghani, H. Naqvi, M. S. Ramzan, M. Khattak, I. Khan, and A. Irshad, “Spread spectrum based energy efficient collaborative communication in wireless sensor networks,”PLOS ONE, vol. 11, p. e0159069, 07 2016
work page 2016
-
[28]
Limiting liability with positioning to minimize negative health effects of cellular phone towers,
J. Pearce, “Limiting liability with positioning to minimize negative health effects of cellular phone towers,”Environmental Research, vol. 181, p. 108845, 2020. [Online]. Available: https://www.sciencedirect. com/science/article/pii/S0013935119306425
work page 2020
-
[29]
Mobile phone infrastructure regulation in europe: Scientific challenges and human rights protection,
C. Roda and S. Perry, “Mobile phone infrastructure regulation in europe: Scientific challenges and human rights protection,”Environmental Science and Policy, vol. 37, pp. 204–214, 2014. [Online]. Available: https://www.sciencedirect.com/science/article/pii/S146290111300186X
work page 2014
-
[30]
Fractional programming for communication system design,
K. Shen, “Fractional programming for communication system design,” Ph.D. dissertation, Stanford University, 2018, ph.D. dissertation, available online. [Online]. Available: https://kaimingshen.github.io/doc/ shen thesis.pdf
work page 2018
-
[31]
Fractional programming for communication systems—part I: Power control and beamforming,
K. Shen and W. Yu, “Fractional programming for communication systems—part I: Power control and beamforming,”IEEE Transactions on Signal Processing, vol. 66, no. 10, pp. 2616–2630, May 2018
work page 2018
-
[32]
Fractional programming for communication systems—part II: Uplink scheduling via matching,
——, “Fractional programming for communication systems—part II: Uplink scheduling via matching,”IEEE Transactions on Signal Pro- cessing, vol. 66, no. 10, pp. 2631–2644, 2018
work page 2018
-
[33]
Sum-rate max- imization and leakage minimization for multi-user cell-free massive MIMO systems,
I. Sandoval, K. Ando, O. Taghizadeh, and G. Abreu, “Sum-rate max- imization and leakage minimization for multi-user cell-free massive MIMO systems,”IEEE Access, vol. PP, pp. 1–1, 01 2023
work page 2023
-
[34]
Further advancements for E-UTRA physical layer aspects,
3GPP, “Further advancements for E-UTRA physical layer aspects,” 3rd Generation Partnership Project (3GPP), Technical Report TR 36.814, Mar. 2017
work page 2017
-
[35]
UL-DL duality for cell-free massive MIMO with per-AP power and information constraints,
L. Miretti, R. L. G. Cavalcante, E. Bj ¨ornson, and S. Sta ´nczak, “UL-DL duality for cell-free massive MIMO with per-AP power and information constraints,”IEEE Transactions on Signal Processing, vol. 72, pp. 1750– 1765, 2024
work page 2024
