Fast Transformer Inference on ARM-Based HMPSoCs

Transformer models have set new performance standards for machine learning (ML) tasks. However, their resource-intensive deployment on resource-constrained edge devices for cloud-free, on-chip transformer inference remains challenging. The ARM Compute Library (ARM-CL) framework provides low-latency CNN inference on ARM-based edge devices but lacks support for transformer inference. In this work, we implement several new transformer kernels in ARM-CL to support native transformer execution. Our extended ARM-CL achieves up to three times faster transformer inference compared to state-of-the-art CPU/GPU implementations on an ARM-based embedded board. Furthermore, heterogeneous multi-processor system-on-chips (HMPSoCs) powering edge devices provide both embedded CPUs and GPUs. We introduce cooperative CPU-GPU transformer inference, which executes memory-intensive operations on the CPU while utilizing the GPU for highly parallelizable, compute-intensive operations. This cooperative execution, implemented with minimal overhead, further reduces transformer inference latency by up to 15.72% compared to the best single-processor inference on ARM-CL.
