Micro-Transfer Printing of Lithium Niobate on 200 mm Silicon Photonics: A High-Speed Heterogeneous Wafer-Scale Platform

The rapid growth of artificial intelligence (AI) and other data center applications is driving the demand for photonic interconnects that combine high-speed with low energy consumption, making scalability a critical requirement. Micro-transfer printing (MTP) has emerged as a promising technique for the wafer-scale heterogeneous integration of thin film lithium niobate (TFLN) onto silicon photonics (SiPho) platforms. Here, we demonstrate heterogeneous SiPho TFLN integration across four full 200 mm wafers with a 3sigma placement accuracy down to 420 nm and a printing yield of larger than 95percentage. Low insertion loss less than 2 dB over 600 phase modulators (300 amplitude modulators) is achieved. A half wave voltage of 4 V in push pull configuration, and high-speed modulation with a bandwith larger than 70 GHz is demonstrated on a subset of tested devices.
