Lie Group Formulation of Recursive Dynamics Algorithms of Higher Order for Floating-Base Robots

Ahmed Ali , Chiara Gabellieri , Antonio Franchi This is my paper

Pith reviewed 2026-05-08 08:42 UTC · model grok-4.3

classification 💻 cs.RO cs.SYeess.SY
keywords lie group dynamicsfloating base robotshigher order derivativesrecursive algorithmsnewton-eulerarticulated body inertiaaerial manipulatorquadratic complexity
0
0 comments X

The pith

Recursive Lie-group algorithms enable higher-order dynamics computation for floating-base robots at quadratic cost.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper develops procedures for computing higher-order time derivatives of the Lie-group Newton-Euler, articulated-body inertia, and hybrid dynamics algorithms for floating-base tree robots. These recursions are collected into closed-form equations of motion that preserve an admissible Coriolis matrix satisfying passivity and keep the articulated inertia tensor unchanged across derivatives. The methods are demonstrated on a 12-DoF aerial manipulator with analytical expressions for the first derivative and numerical evaluation up to the fifth order. A sympathetic reader would care because this provides an efficient way to obtain the higher derivatives required for advanced control, optimization, and simulation in robotics, avoiding the exponential cost of automatic differentiation.

Core claim

We describe recursive procedures to compute the higher-order time derivatives of the Lie-group Newton-Euler, Articulated-Body Inertia, and hybrid dynamics algorithms for floating-base trees. The resulting recursions are collected into closed-form equations of motion, identifying an admissible Coriolis matrix satisfying the passivity property and showing that the articulated inertia tensor remains unchanged across all time derivatives. Application to a 12-DoF aerial manipulator yields analytical geometric forward and inverse dynamics along with their first time derivatives, while numerical simulations evaluate these dynamics up to fifth order. Benchmarks demonstrate quadratic computational成本

What carries the argument

Recursive higher-order extensions of the Lie-group Newton-Euler and Articulated-Body Inertia algorithms using spatial twists for SE(3) base and tree joints.

If this is right

  • The dynamics algorithms can be extended to arbitrary derivative orders via recursion.
  • The articulated inertia tensor is invariant under time differentiation of any order.
  • An admissible Coriolis matrix satisfying passivity exists for the closed-form equations at each order.
  • Analytical expressions for first-order derivatives are derivable for systems like the 12-DoF aerial manipulator.
  • Computation up to fifth order is practical and scales quadratically in cost.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • This could support derivative-based methods in real-time robot control and motion planning that were previously computationally prohibitive.
  • The invariance of the inertia tensor across orders may simplify the analysis of energy properties or stability in higher-order dynamic systems.
  • Similar recursive structures could be adapted for robots with different topologies or additional constraints.
  • The quadratic scaling suggests these algorithms are suitable for integration into optimization frameworks requiring multiple derivatives.

Load-bearing premise

The higher-order recursive procedures can be collected into closed-form equations of motion while preserving an admissible Coriolis matrix that satisfies passivity and leaving the articulated inertia tensor unchanged across derivatives.

What would settle it

Computing the fifth-order dynamics for the 12-DoF aerial manipulator and verifying that the articulated inertia tensor matches the base case while the Coriolis matrix satisfies passivity, alongside confirming quadratic computation time scaling.

read the original abstract

In this paper, we describe procedures for computing higher-order time derivatives of the Lie-group Newton-Euler, Articulated-Body Inertia, and hybrid dynamics algorithms for floating-base trees, where the base configuration evolves on SE(3) and the attached mechanism is an open kinematic tree with configuration on the (n1+n2)-dimensional manifold T^{n1} \times R^{n2}, using spatial representation of twists. After presenting the algorithms, we collect the resulting recursions into closed-form equations of motion, identifying an admissible Coriolis matrix satisfying the passivity property, and showing that the articulated inertia tensor remains unchanged across all time derivatives. We then apply the developed methods to a 12-DoF aerial manipulator to derive analytical expressions for its geometric forward and inverse dynamics along with their first time derivatives whereas the numerical simulations successfully evaluate these dynamics up to fifth order. Finally, to demonstrate their practical utility, we benchmark the proposed extensions and show that, in the considered tests, their computational cost scales quadratically with the derivative order, whereas the automatic-differentiation baseline exhibits exponential scaling.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

1 major / 2 minor

Summary. The paper describes recursive procedures for higher-order time derivatives of Lie-group Newton-Euler, ABA, and hybrid dynamics algorithms for floating-base trees on SE(3) with tree mechanisms. The recursions are collected into closed-form equations, with an admissible Coriolis matrix for passivity and invariance of the articulated inertia tensor. Analytical expressions up to first derivatives are given for a 12-DoF aerial manipulator, numerical evaluations to fifth order, and benchmarks show quadratic cost scaling with derivative order versus exponential for automatic differentiation.

Significance. This contribution is significant for robotics as it enables efficient computation of higher-order dynamics derivatives using recursive methods rather than costly automatic differentiation. The quadratic scaling demonstrated in benchmarks is particularly valuable for real-time applications. The work credits the extension of established algorithms with Lie-group structure, provides concrete analytical results, and includes numerical validation, making the claims falsifiable and the methods reproducible in principle. The proof of inertia invariance and passivity-preserving Coriolis matrix add theoretical strength without introducing free parameters.

major comments (1)
  1. [Numerical evaluation] The manuscript reports successful numerical evaluation of the dynamics up to fifth order but does not provide error bounds or full verification details against independent calculations. This is important for substantiating the higher-order results and the quadratic scaling claim in the benchmarks.
minor comments (2)
  1. [Configuration description] The manifold is specified as T^{n1} × R^{n2} without defining n1 and n2 in the aerial manipulator example, which could be clarified for readers.
  2. [Benchmark results] Including the specific automatic differentiation library and hardware specifications used in the timing comparisons would enhance reproducibility.

Simulated Author's Rebuttal

1 responses · 0 unresolved

We thank the referee for the positive assessment of the manuscript and the recommendation for minor revision. We address the major comment below and will incorporate the suggested improvements.

read point-by-point responses

  1. Referee: [Numerical evaluation] The manuscript reports successful numerical evaluation of the dynamics up to fifth order but does not provide error bounds or full verification details against independent calculations. This is important for substantiating the higher-order results and the quadratic scaling claim in the benchmarks.

    Authors: We agree that the original manuscript would benefit from explicit error bounds and more detailed verification against independent calculations. While the numerical simulations in the paper successfully compute the dynamics up to fifth order, we did not include quantitative error analysis or comparisons in the submitted version. In the revised manuscript, we will add a dedicated verification subsection that compares the recursive higher-order derivatives to finite-difference approximations (with multiple step sizes) and reports the resulting error norms and observed convergence orders. This will directly substantiate the accuracy of the fifth-order results and support the quadratic scaling benchmarks. revision: yes

Circularity Check

0 steps flagged

No significant circularity; derivation extends established recursive Lie-group dynamics independently

full rationale

The paper presents explicit recursive procedures for higher-order derivatives of the Lie-group Newton-Euler, ABA, and hybrid algorithms on SE(3) floating-base trees, then collects them into closed-form equations while preserving an admissible Coriolis matrix and proving invariance of the articulated inertia tensor. These steps follow directly from differentiating the base recursions (which are taken as given from prior literature) without any reduction to fitted parameters, self-definitions, or unverified self-citations. The analytic expressions for the 12-DoF aerial manipulator and the quadratic-vs-exponential benchmark timings are independent numerical/analytical outputs, not forced by construction from the inputs. No enumerated circularity pattern applies.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 0 invented entities

The central claim rests on standard Lie-group properties of SE(3) and the product manifold for joints, plus the existence of recursive factorizations that extend to arbitrary order without introducing new fitted quantities.

axioms (1)
  • domain assumption Base configuration evolves on SE(3) and joints on T^{n1} × R^{n2} with spatial twist representation
    Explicitly stated as the configuration space for floating-base trees.

pith-pipeline@v0.9.0 · 5499 in / 1115 out tokens · 64416 ms · 2026-05-08T08:42:03.863570+00:00 · methodology
