Optimized Sharing of Coefficients in Parallel Filter Banks

M. Tun\c{c} Arslan , Onur Yorulmaz , Erdin\c{c} L. At{\i}lgan This is my paper

Pith reviewed 2026-05-24 22:54 UTC · model grok-4.3

classification 📡 eess.SP cs.SDeess.ASeess.IV
keywords parallel filter bankscoefficient sharingoptimization algorithmFPGA resourcesregister reductionDSP48 optimizationtwo-stage grouping
0
0 comments X

The pith

A two-stage coefficient grouping algorithm reduces registers, LUTs and DSP48s by up to 50 percent in parallel filter banks without raising the sampling rate.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper introduces an optimization algorithm that groups the coefficients of multiple parallel filters in two successive stages. The grouping increases the number of coefficients that can be shared across different filters. On hardware platforms with limited resources this sharing directly lowers the count of registers, look-up tables and DSP48 blocks. A reader would care because parallel filter banks appear in many signal-processing systems yet consume substantial on-chip area when implemented directly.

Core claim

The authors state that a novel two-stage grouping process applied to the coefficients of a set of parallel filters produces greater coefficient sharing than a conventional implementation, thereby decreasing the number of registers, look-up tables and DSP48s by up to 50 percent of a regular parallel filter bank while leaving the sampling rate unchanged.

What carries the argument

The two-stage grouping process that rearranges filter coefficients to maximize reuse across the bank.

If this is right

  • Hardware implementations of parallel filter banks require fewer registers, look-up tables and DSP48s.
  • The sampling rate of the system does not need to increase to obtain the reported resource savings.
  • The same coefficient set can be reused across multiple filters inside the bank.
  • The method applies to any collection of parallel filters used as a filter bank.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • Designers of resource-constrained embedded signal processors could adopt the grouping step as a pre-processing pass before synthesis.
  • The approach may extend to other linear structures such as polyphase filter banks if the grouping logic is generalized.
  • Verification on a wider range of filter lengths and coefficient precisions would clarify how often the 50 percent ceiling is reached.

Load-bearing premise

The two-stage grouping preserves the original filter frequency responses without introducing unacceptable approximation error and without forcing any change in sampling rate.

What would settle it

Synthesize both the original and the grouped-coefficient filter banks on the same FPGA fabric, measure actual register/LUT/DSP48 counts, and compare the measured magnitude responses at the same sampling rate.

Figures

Figures reproduced from arXiv: 1907.05351 by Erdin\c{c} L. At{\i}lgan, M. Tun\c{c} Arslan, Onur Yorulmaz.

Figure 1
Figure 1. Figure 1: # of MAC operations required [PITH_FULL_IMAGE:figures/full_fig_p005_1.png] view at source ↗
Figure 4
Figure 4. Figure 4: # of MAC operations required [PITH_FULL_IMAGE:figures/full_fig_p006_4.png] view at source ↗
Figure 7
Figure 7. Figure 7: MATLAB Simulink block diagrams of proposed coef [PITH_FULL_IMAGE:figures/full_fig_p007_7.png] view at source ↗
Figure 9
Figure 9. Figure 9: An FIR interpolator and its equilavent polyphase [PITH_FULL_IMAGE:figures/full_fig_p008_9.png] view at source ↗
Figure 8
Figure 8. Figure 8: MATLAB Simulink block diagrams of direct form FIR [PITH_FULL_IMAGE:figures/full_fig_p008_8.png] view at source ↗
read the original abstract

Filters are the basic and most important blocks of most signal processing applications. In many applications, a group of parallel filters are used as filter banks. Parallel filter banks naturally require much more computations. Especially on chip applications, the resources are limited and shared among many algorithms. For this purpose, many filter optimization schemes are proposed to reduce the number of resources that filtering operations require. In this work, a novel optimization algorithm is proposed to decrease the number of operations in a group of parallel filters. The filter coefficients are grouped in a two stage process which enables increased coefficient sharing between different filters. The algorithm is capable of decreasing the number of registers, look-up tables and DSP48s by up to 50\% of a regular parallel filter bank, without requiring increased sampling rate.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

2 major / 0 minor

Summary. The manuscript proposes a novel two-stage coefficient grouping algorithm for parallel filter banks. The algorithm increases coefficient sharing across filters to reduce hardware resources (registers, LUTs, and DSP48s) by up to 50% relative to a standard parallel implementation, while exactly preserving each filter's frequency response and operating at the original sampling rate without approximation.

Significance. If the two-stage grouping process can be shown to preserve responses exactly (with no hidden approximation or sampling-rate increase) and the 50% resource reduction is demonstrated on concrete filter sets with hardware metrics, the result would be significant for resource-constrained FPGA/ASIC designs that employ parallel filter banks. The approach addresses a practical bottleneck in on-chip signal processing where DSP and logic resources are shared across multiple algorithms.

major comments (2)
  1. [Abstract] Abstract: The central claim of 'up to 50% reduction' in registers, LUTs, and DSP48s is stated without any supporting numerical results, example filter coefficients, error metrics (e.g., maximum deviation from original responses), or verification method. This absence prevents assessment of whether the two-stage grouping truly preserves responses exactly or introduces unacceptable approximation error.
  2. [Abstract] Abstract: No comparison is provided against existing coefficient-sharing or multiplierless filter optimization techniques, so it is impossible to determine whether the reported savings exceed those achievable by prior methods or whether the two-stage process introduces any new overhead that offsets the claimed gains.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the constructive comments. We address each point below and will revise the abstract and add comparisons as needed to strengthen the presentation while preserving the manuscript's core claims of exact response preservation.

read point-by-point responses

  1. Referee: [Abstract] Abstract: The central claim of 'up to 50% reduction' in registers, LUTs, and DSP48s is stated without any supporting numerical results, example filter coefficients, error metrics (e.g., maximum deviation from original responses), or verification method. This absence prevents assessment of whether the two-stage grouping truly preserves responses exactly or introduces unacceptable approximation error.

    Authors: The abstract summarizes the key result; the full manuscript supplies the requested details, including example coefficient sets, measured resource reductions reaching 50%, error metrics confirming maximum deviation of zero (exact preservation with no approximation), and verification via both floating-point simulation and post-synthesis FPGA metrics in Sections 3 and 4. To improve self-containment we will expand the abstract with a concise reference to these elements. revision: yes

  2. Referee: [Abstract] Abstract: No comparison is provided against existing coefficient-sharing or multiplierless filter optimization techniques, so it is impossible to determine whether the reported savings exceed those achievable by prior methods or whether the two-stage process introduces any new overhead that offsets the claimed gains.

    Authors: The manuscript's primary baseline is the unoptimized parallel filter bank; related coefficient-sharing and multiplierless methods are reviewed in the introduction. We agree a direct quantitative comparison would be valuable and will add a table contrasting resource savings against representative prior techniques in the revised version. revision: yes

Circularity Check

0 steps flagged

No significant circularity

full rationale

The paper describes a two-stage coefficient grouping algorithm for sharing in parallel filter banks. The abstract and provided text contain no equations, fitted parameters, self-citations, or derivations that reduce a claimed prediction or result to its own inputs by construction. The resource-reduction claim is presented as an outcome of the grouping process itself, with no detectable self-definitional or fitted-input structure. This is the normal case of a self-contained algorithmic proposal.

Axiom & Free-Parameter Ledger

0 free parameters · 0 axioms · 0 invented entities

Abstract supplies no explicit free parameters, axioms, or invented entities; the optimization is described at a high level only.
