Energy Aware Wireless System based Software Defined Radio

H. Salman , R. Balatiah , A. Masri , Y.A.S. Dama This is my paper

Pith reviewed 2026-05-24 22:25 UTC · model grok-4.3

classification 📡 eess.SP
keywords energy awaresoftware defined radioadaptive modulationsolar energywireless systemgreen telecommunications
0
0 comments X

The pith

A lab prototype tests an energy-aware wireless system that pairs software-defined radio with solar power and adapts modulation order to battery charge and user preferences.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper implements a laboratory setup for an energy-aware wireless system that integrates software-defined radio with a solar energy power supply. It also proposes an adaptive modulation algorithm that selects the modulation order according to the current state of charge in the solar batteries. The algorithm further allows the system to respond to user choice between a connectivity mode and a quality mode. A sympathetic reader would care because the work directly addresses energy management in wireless links by combining hardware prototyping with a simple decision rule based on available power.

Core claim

The authors implement a lab setup to test an energy aware wireless system based on software defined radio and solar energy power system. In addition, they propose an energy aware adaptive modulation algorithm that considers the state of charge of the solar energy batteries before setting up the modulation order and that adapts to user preferences between the connectivity mode and the quality mode.

What carries the argument

The energy-aware adaptive modulation algorithm that selects modulation order from battery state of charge and switches between connectivity and quality modes according to user input.

If this is right

  • Modulation order drops automatically when solar battery charge falls below a threshold to extend operating time.
  • Users can select connectivity mode to maintain link presence at lower data rates or quality mode to favor higher-order modulation when power allows.
  • Solar integration makes the wireless link responsive to intermittent renewable power without external grid connection.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • If the adaptation rule proves stable, similar logic could be applied to other renewable sources such as wind or vibration harvesting in remote sensor networks.
  • The absence of reported error rates or baseline comparisons leaves open whether the energy savings outweigh any throughput loss in practice.
  • Field trials under real solar variability would test whether the state-of-charge threshold needs seasonal or location-specific tuning.

Load-bearing premise

The laboratory prototype and proposed algorithm deliver meaningful, measurable energy savings and performance trade-offs under realistic conditions.

What would settle it

A side-by-side measurement showing that the adaptive algorithm consumes equal or greater energy than a fixed high-order scheme while delivering no improvement in connectivity uptime or signal quality would falsify the claimed benefit.

read the original abstract

Development of green telecommunication systems is already being considered highly attractive by standard bodies and recently is attracting research attention. While most of the research focuses on modeling and simulation, in this work we implement a lab setup to test an energy aware wireless system based on software defined radio and solar energy power system. In addition, we proposed an energy aware adaptive modulation algorithm that considers the state of charge of the solar energy batteries before setting up the modulation order. Moreover, the algorithm adapts to user preferences between the connectivity mode and the quality mode.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

2 major / 0 minor

Summary. The paper claims to implement a laboratory prototype of an energy-aware wireless system using software-defined radio (SDR) hardware and a solar-energy power system. It additionally proposes an adaptive modulation algorithm that conditions modulation order on battery state-of-charge and on a user-selected preference between connectivity mode and quality mode.

Significance. Demonstrating measurable energy savings through SDR-based adaptive modulation under realistic solar-battery constraints would be of interest to green-communications research. The absence of any power-consumption figures, throughput measurements, battery-discharge curves, or baseline comparisons prevents assessment of whether the claimed savings or trade-offs are realized.

major comments (2)
  1. [Abstract] The abstract states that a lab setup was implemented and an algorithm was proposed, yet the manuscript supplies no power-consumption numbers, throughput figures, modulation-switching thresholds, or comparisons against fixed-modulation or non-solar baselines.
  2. [Results / Experimental Evaluation (missing)] No experimental results section, tables, or figures present quantitative validation of energy savings or algorithm performance under the stated battery-state and user-preference conditions.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the constructive comments. We acknowledge that the submitted manuscript describes the lab prototype and algorithm but does not include the quantitative experimental results needed to evaluate the claimed energy savings and trade-offs. We will revise the manuscript to add these elements.

read point-by-point responses

  1. Referee: [Abstract] The abstract states that a lab setup was implemented and an algorithm was proposed, yet the manuscript supplies no power-consumption numbers, throughput figures, modulation-switching thresholds, or comparisons against fixed-modulation or non-solar baselines.

    Authors: We agree that the current manuscript lacks these quantitative details despite claiming an implementation. In the revised version we will expand the abstract if needed and add a dedicated experimental section reporting measured power consumption of the SDR platform, achieved throughput for each modulation order, the exact battery state-of-charge thresholds used for mode switching, and direct comparisons against fixed-modulation baselines and non-solar power configurations. revision: yes

  2. Referee: [Results / Experimental Evaluation (missing)] No experimental results section, tables, or figures present quantitative validation of energy savings or algorithm performance under the stated battery-state and user-preference conditions.

    Authors: The observation is accurate; the manuscript currently contains only a description of the setup and algorithm without supporting measurements. The revision will introduce an experimental evaluation section containing battery-discharge curves, throughput and energy-consumption data collected under varying state-of-charge levels, and performance under both connectivity and quality user modes, accompanied by tables and figures that enable direct assessment of the algorithm. revision: yes

Circularity Check

0 steps flagged

Implementation report with no derivations or fitted parameters

full rationale

The paper describes a laboratory prototype implementation of an SDR-based wireless system powered by solar energy and proposes a high-level adaptive modulation algorithm conditioned on battery state-of-charge and user mode preference. No equations, derivations, fitted parameters, predictions, or uniqueness theorems appear in the abstract or the described manuscript. The central claims concern what was built and proposed rather than any result derived from prior inputs, so no reduction to self-definition or self-citation occurs.

Axiom & Free-Parameter Ledger

0 free parameters · 0 axioms · 0 invented entities

Abstract-only review; no mathematical model, parameters, or postulates are detailed in the provided text.

pith-pipeline@v0.9.0 · 5613 in / 1031 out tokens · 36313 ms · 2026-05-24T22:25:44.611180+00:00 · methodology

discussion (0)

Sign in with ORCID, Apple, or X to comment. Anyone can read and Pith papers without signing in.

Lean theorems connected to this paper

Citations machine-checked in the Pith Canon. Every link opens the source theorem in the public Lean library.

What do these tags mean?
matches
The paper's claim is directly supported by a theorem in the formal canon.
supports
The theorem supports part of the paper's argument, but the paper may add assumptions or extra steps.
extends
The paper goes beyond the formal theorem; the theorem is a base layer rather than the whole result.
uses
The paper appears to rely on the theorem as machinery.
contradicts
The paper's claim conflicts with a theorem or certificate in the canon.
unclear
Pith found a possible connection, but the passage is too broad, indirect, or ambiguous to say the theorem truly supports the claim.

Reference graph

Works this paper leans on

17 extracted references · 17 canonical work pages

  1. [1]

    Next Generation 5G Wireless Networks: A Comprehensive Survey

    M. Agiwal, Abhishek Roy, and NavratiSaxena, “Next Generation 5G Wireless Networks: A Comprehensive Survey”, IEEE Communications Surveys & Tutorials, Vol. 18, No. 3, Third Quarter 2016

    work page 2016

  2. [2]

    Toward green and soft: A 5G perspective,

    Chih-Lin, C. Rowell, S. Han, Z. Xu, G. Li, and Z. Pan, “Toward green and soft: A 5G perspective,” IEEE Commun. Mag., vol. 52, no. 2, pp. 66–73, Feb. 2014

    work page 2014

  3. [3]

    Understanding 5G: Perspectives on future technological advancements in mobile,

    GSMA Intelligence, “Understanding 5G: Perspectives on future technological advancements in mobile,” White paper, 2014

    work page 2014

  4. [4]

    A survey of green networking research,

    IA. P. Bianzino, C. Chaudet, D. Rossi, and J.-L.Rougier, “A survey of green networking research,” IEEE Commun.Surv.Tuts.,vol. 14, no. 1, pp. 3–20, First Quart. 2012

    work page 2012

  5. [5]

    Greening the optical backbone network: A traffic engineering approach,

    M. Xia, M. Tornatore, Y. Zhang, P. Chowdhury, C. U. Martel, and B. Mukherjee, “Greening the optical backbone network: A traffic engineering approach,” in Proc. IEEE Int. Conf. Commun., 2010

    work page 2010

  6. [6]

    Energy-cost aware hybrid power system for off-grid base stations under green cellular networks,

    A. Jahid, Md. Hossain, “Energy-cost aware hybrid power system for off-grid base stations under green cellular networks,” 3rd International Conference on Electrical Information and Communication Technology (EICT), 2017

    work page 2017

  7. [7]

    RF Wireless Power Transfer: Regreening Future Networks,

    H. Tran, G. Kaddoum, “RF Wireless Power Transfer: Regreening Future Networks,” IEEE Potentials , vol. 37, issue. 2, March-April 2018

    work page 2018

  8. [8]

    SATRC Report on Green Telecommunication,

    SATRC Working Group on Policy and Regulation, “SATRC Report on Green Telecommunication,” Adopted by 13th meeting of South Asian Telecommunication Regulator's council 18-20 April 2012, Kathmandu , Nepal

    work page 2012

  9. [9]

    Yearly Electrical report -2011,

    Jordan Telecom Company, “Yearly Electrical report -2011,” Yearly report from technical department , 2011

    work page 2011

  10. [10]

    Green Reconfigurable Radio Systems,

    A. Dejonghe, B. Bougard, S. Pollin, J. Craninckx,A. Bourdoux, L. Perre, F. Catthoor, “Green Reconfigurable Radio Systems,” IEEE Signal Processing Magazine, vol. 24, issue. 3, pp. 90 - 101, May 2007

    work page 2007

  11. [11]

    SATCOM link adaptive configuration design in radio frequency interference environment,

    G. Wang, D. Shen and G. Chen, “SATCOM link adaptive configuration design in radio frequency interference environment,” IEEE Aerospace Conference, 2017

    work page 2017

  12. [12]

    On the Energy Consumption of M-PSK Modulation Schemes under Fading Channels,

    N. Wu, X. Wang, H. Dai, H. Zhao, “On the Energy Consumption of M-PSK Modulation Schemes under Fading Channels,” IEEE/CIC International Conference on Communications in China (ICCC), 2013

    work page 2013

  13. [13]

    https://www.ettus.com/content/files/07495_Ettus_N200- 210_DS_Flyer_HR_1.pdf,

    Ettus Research, URL: , “ https://www.ettus.com/content/files/07495_Ettus_N200- 210_DS_Flyer_HR_1.pdf,” Accessed 18.3.2018

    work page 2018

  14. [14]

    Control of solar system's battery voltage based on state of charge estimation (SOC),

    A. Hajizadeh, A. Shahirinia, S. Arabameri, D. C Yu, “Control of solar system's battery voltage based on state of charge estimation (SOC),” IEEE International conference on Renewable Energy Research and Application (ICRERA), 2014

    work page 2014

  15. [15]

    A novel online adaptive fast simple state of charge estimation for Lithium Ion batteries

    F. Poloei, A. Bakhshai, Y.Liu, "A novel online adaptive fast simple state of charge estimation for Lithium Ion batteries", Renewable Energy Research and Applications (ICRERA) IEEE 6th International Conference on, 2017

    work page 2017

  16. [16]

    A review on sizing methodologies of photovoltaic array and storage battery in a standalone photovoltaic system,

    T. Khatib, I. A. Ibrahim, A. Mohamed, “A review on sizing methodologies of photovoltaic array and storage battery in a standalone photovoltaic system,” Elsevier, Energy Conversion and Management 120 (2016) 430–448

    work page 2016

  17. [17]

    Sizing of a standalone photovoltaic/battery system at minimum cost for remote housing electrification in Sohar, Oman,

    H. A. Kazema, T. Khatib, K. Sopian, “Sizing of a standalone photovoltaic/battery system at minimum cost for remote housing electrification in Sohar, Oman,” Elsevier, Energy and Buildings 61 (2013) 108–115. Fig. 8. Battery state of charge for different USRP N200 system gains. Consumption Current (A) Transmitter Gain (dB)0 510 15 20 25 30 1.81.851.91.952 11...

    work page 2013
