Topological transition induced by selective random defects on a honeycomb lattice
Pith reviewed 2026-05-17 21:18 UTC · model grok-4.3
The pith
Selective random defects induce a topological transition on a honeycomb lattice in certain regimes.
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
Core claim
We investigate how the spectral and topological properties of electron systems evolve on a lattice that interpolates between the honeycomb and its 1/6-depleted structures through the introduction of selective random defects. We find that in certain parameter regimes, the topological properties of the two lattice systems are smoothly connected, whereas in other regimes, selective random defects induce a topological transition. Analysis based on an effective model reveals that the effect of selective random defects can be understood as a modulation of hopping amplitudes.
What carries the argument
Selective random defects interpreted via an effective model as a modulation of hopping amplitudes that drives the interpolation between honeycomb and 1/6-depleted lattices.
If this is right
- Topological character can be switched between connected and transitioned states by tuning defect parameters.
- Spectral gaps and band structures evolve in a manner controlled by the effective hopping changes.
- The mechanism supports design of electronic systems with targeted topological properties across material platforms.
- The smooth connection regime preserves topological features while altering lattice geometry.
Where Pith is reading between the lines
- Similar selective-defect engineering could apply to other two-dimensional lattices beyond honeycomb.
- Experimental tests in graphene or transition-metal dichalcogenides might realize the predicted transitions via controlled vacancies.
- The effective model opens questions about robustness when electron-electron interactions are added.
- This defect-based interpolation suggests a general approach for navigating topological phase diagrams in lattice systems.
Load-bearing premise
The effective model that interprets selective random defects as a modulation of hopping amplitudes accurately captures the spectral and topological evolution of the system.
What would settle it
A direct calculation of the topological invariant on the full lattice with selective defects that yields a different phase than the effective hopping-modulation model predicts.
Figures
read the original abstract
We investigate how the spectral and topological properties of electron systems evolve on a lattice that interpolates between the honeycomb and its 1/6-depleted structures through the introduction of selective random defects. We find that in certain parameter regimes, the topological properties of the two lattice systems are smoothly connected, whereas in other regimes, selective random defects induce a topological transition. Analysis based on an effective model reveals that the effect of selective random defects can be understood as a modulation of hopping amplitudes. Our results highlight the potential for designing and controlling the spectral and even topological properties of electronic systems across a wide range of material platforms.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The manuscript studies the evolution of spectral and topological properties in electron systems on a lattice interpolating between the honeycomb and 1/6-depleted structures via selective random defects. It reports that topological properties are smoothly connected in some parameter regimes but undergo a defect-induced transition in others. An effective model is used to interpret the defects as a modulation of hopping amplitudes.
Significance. If the central mapping holds, the work provides a route to engineer topological transitions or connections through controlled disorder, with relevance to defect engineering in 2D materials. The distinction between smooth-connection and transition regimes is a concrete, falsifiable outcome that could guide experiments.
major comments (1)
- [Effective-model section] Effective-model section (around the derivation following the abstract claim): the reduction of selective random defects to a deterministic hopping modulation assumes that ensemble-averaged amplitudes dominate over random scattering and Anderson localization. The manuscript should show explicitly that topological invariants (e.g., real-space Chern numbers or edge-state robustness) computed on the effective clean Hamiltonian remain consistent with direct calculations on multiple disordered realizations; otherwise the reported transition may be an artifact of the averaging step.
minor comments (2)
- Clarify in the methods or results section how the topological invariant is defined and computed for the disordered ensemble (e.g., whether it is averaged or computed per realization).
- Figure captions should explicitly state the defect density range and the precise definition of the 'selective' defect placement used in each panel.
Simulated Author's Rebuttal
We thank the referee for their positive evaluation of the work's significance and for the constructive comment on the effective-model section. We address the concern below and will revise the manuscript to incorporate additional validation.
read point-by-point responses
-
Referee: [Effective-model section] Effective-model section (around the derivation following the abstract claim): the reduction of selective random defects to a deterministic hopping modulation assumes that ensemble-averaged amplitudes dominate over random scattering and Anderson localization. The manuscript should show explicitly that topological invariants (e.g., real-space Chern numbers or edge-state robustness) computed on the effective clean Hamiltonian remain consistent with direct calculations on multiple disordered realizations; otherwise the reported transition may be an artifact of the averaging step.
Authors: We agree that explicit validation of the effective model against disordered realizations is important to confirm that the topological transition is not an artifact of ensemble averaging. Our derivation of the effective hopping modulation relies on averaging over defect configurations, which is appropriate in the parameter regimes where selective defects suppress strong localization effects. To address this, the revised manuscript will include direct comparisons: we will compute real-space Chern numbers and examine edge-state robustness on the effective clean Hamiltonian and compare these with results averaged over multiple independent disordered realizations at representative points in both the smooth-connection and transition regimes. These additions will be placed in the effective-model section, along with a discussion of the conditions under which the averaging approximation holds. revision: yes
Circularity Check
No circularity: effective-model interpretation is independent interpretive step
full rationale
The paper numerically or analytically examines selective random defects interpolating between honeycomb and 1/6-depleted lattices, reports regime-dependent topological transitions or smooth connections, and then invokes an effective model to reinterpret defects as hopping-amplitude modulations. No quoted equation or self-citation reduces a claimed prediction or topological invariant to a quantity defined by the same model or prior author work; the effective-model step functions as post-hoc interpretation rather than a load-bearing premise that forces the result by construction. The derivation therefore remains self-contained against external benchmarks such as direct diagonalization or topological invariant calculations on the disordered ensemble.
Axiom & Free-Parameter Ledger
axioms (1)
- domain assumption Electrons on the lattice are described by a tight-binding Hamiltonian with nearest-neighbor hopping
Lean theorems connected to this paper
-
IndisputableMonolith/Cost/FunctionalEquation.leanwashburn_uniqueness_aczel unclear?
unclearRelation between the paper passage and the cited Recognition theorem.
Analysis based on an effective model reveals that the effect of selective random defects can be understood as a modulation of hopping amplitudes.
-
IndisputableMonolith/Foundation/AlexanderDuality.leanalexander_duality_circle_linking unclear?
unclearRelation between the paper passage and the cited Recognition theorem.
we employ three different methods: the local Chern marker (LCM), the crosshair marker, and the Bott index
What do these tags mean?
- matches
- The paper's claim is directly supported by a theorem in the formal canon.
- supports
- The theorem supports part of the paper's argument, but the paper may add assumptions or extra steps.
- extends
- The paper goes beyond the formal theorem; the theorem is a base layer rather than the whole result.
- uses
- The paper appears to rely on the theorem as machinery.
- contradicts
- The paper's claim conflicts with a theorem or certificate in the canon.
- unclear
- Pith found a possible connection, but the passage is too broad, indirect, or ambiguous to say the theorem truly supports the claim.
Reference graph
Works this paper leans on
-
[1]
on those lattice structures. The Hamiltonian is given by ˆH= X i Miˆc† i ˆci + X ⟨i,j⟩ t1ˆc† i ˆcj + X ⟨⟨i,j⟩⟩ t2eiϕi j ˆc† i ˆcj +h.c. ,(2) where ˆc† i and ˆci are the creation and annihilation operators of spinless fermions at sitei.M i represents a staggered site po- tential which takes the value−Mand+Mfor A and B sublat- tices, respe...
-
[2]
Energy spectra and density of states To investigate the spectral properties of the Haldane model on the lattice structures with selective random defects, we compute the energy spectrum and the density of states (DOS) by exact diagonalization of the single-particle Hamiltonian under both PBC and OBC. The DOS is obtained from the en- ergy eigenvalues{ϵ i}as...
-
[3]
Topological invariants in clean systems Topological invariants of electron systems are often defined as integrals of quantum geometrical quantities over closed manifolds. For example, the Chern numberC[3, 4], which characterizes the topology of band structures in a periodic lat- tice system, is given by integrating the Berry curvature [39] over the first ...
-
[4]
Topological invariants in disordered systems In the systems with selective random defects (0<r<1), the translational symmetry is absent, and the corresponding reciprocal space is no longer well-defined. To character- ize and compute the topological properties of electrons in such disordered systems, various methods have been proposed [41], such as local m...
-
[5]
= 9 √ 3 2(6−r) ,(9) whereNis the number of unit cells of the original honeycomb lattice. In the case of Fig. 3(a), Ctakes a value close to+1, indicating that the electronic system is topologically nontrivial with a topological invariant of+1. b. Crosshair markerThe crosshair marker is also a lo- cally defined marker which detects topological features of t...
-
[6]
Calculation conditions The DOS and the three topological invariants are averaged over 60 independent lattice realizations, each generated by in- troducing selective random defects with a specific valuer. The number of sites used in the DOS and energy spectrum calculations ranges fromN hc =10086 for the honeycomb lat- tice (r=0) toN BK =8405 for the BK lat...
-
[7]
K. v. Klitzing, G. Dorda, and M. Pepper, New method for high- accuracy determination of the fine-structure constant based on quantized Hall resistance, Phys. Rev. Lett.45, 494 (1980)
work page 1980
-
[8]
R. B. Laughlin, Anomalous Quantum Hall Effect: An Incom- pressible Quantum Fluid with Fractionally Charged Excita- tions, Phys. Rev. Lett.50, 1395 (1983)
work page 1983
-
[9]
D. J. Thouless, M. Kohmoto, M. P. Nightingale, and M. den Nijs, Quantized Hall Conductance in a Two-Dimensional Peri- odic Potential, Phys. Rev. Lett.49, 405 (1982)
work page 1982
-
[10]
Kohmoto, Topological invariant and the quantization of the Hall conductance, Ann
M. Kohmoto, Topological invariant and the quantization of the Hall conductance, Ann. Phys.160, 343 (1985)
work page 1985
- [11]
- [12]
-
[13]
R. K. Mishra, K. Verma, and D. sethi singh, Defect engineering in nanomaterials: Impact, challenges, and applications, Smart Mater. Manuf.2, 100052 (2024)
work page 2024
- [14]
-
[15]
Q. Niu, D. J. Thouless, and Y .-S. Wu, Quantized Hall conduc- tance as a topological invariant, Phys. Rev. B31, 3372 (1985)
work page 1985
- [16]
- [17]
-
[18]
C. W. Groth, M. Wimmer, A. R. Akhmerov, J. Tworzydło, and C. W. J. Beenakker, Theory of the Topological Anderson Insu- lator, Phys. Rev. Lett.103, 196805 (2009)
work page 2009
- [19]
-
[20]
A. Yamakage, K. Nomura, K.-I. Imura, and Y . Kuramoto, Disorder-Induced Multiple Transition InvolvingZ2 Topological Insulator, J. Phys. Soc. Jpn.80, 053703 (2011)
work page 2011
-
[21]
Y . F. Zhang, Y . Y . Yang, L. S. Y . Ju, D. N. Sheng, R. Shen, and D. Y . Xing, Coupling-matrix approach to the Chern number calculation in disordered systems, Chin. Phys. B22, 117312 (2013)
work page 2013
-
[22]
I. Mondragon-Shem, T. L. Hughes, J. Song, and E. Prodan, Topological Criticality in the Chiral-Symmetric AIII Class at Strong Disorder, Phys. Rev. Lett.113, 046802 (2014). 10
work page 2014
-
[23]
E. V . Castro, M. P. L´opez-Sancho, and M. A. H. V ozmediano, Anderson localization and topological transition in Chern insu- lators, Phys. Rev. B92, 085410 (2015)
work page 2015
-
[24]
P. V . Sriluckshmy, K. Saha, and R. Moessner, Interplay between topology and disorder in a two-dimensional semi-Dirac mate- rial, Phys. Rev. B97, 024204 (2018)
work page 2018
- [25]
-
[26]
Kuno, Disorder-induced Chern insulator in the Harper- Hofstadter-Hatsugai model, Phys
Y . Kuno, Disorder-induced Chern insulator in the Harper- Hofstadter-Hatsugai model, Phys. Rev. B100, 054108 (2019)
work page 2019
- [27]
-
[28]
B. Yang, H. Zhang, Q. Shi, T. Wu, Y . Ma, Z. Lv, X. Xiao, R. Dong, X. Yan, and X. Zhang, Details of the topological state transition induced by gradually increased disorder in photonic Chern insulators, Opt. Express28, 31487 (2020)
work page 2020
-
[29]
A. K. Geim and I. V . Grigorieva, van der Waals heterostruc- tures, Nature499, 419 (2013)
work page 2013
-
[30]
D. L. Duong, S. J. Yun, and Y . H. Lee, van der Waals Layered Materials: Opportunities and Challenges, ACS Nano11, 11803 (2017)
work page 2017
-
[31]
J. Bai, X. Zhong, S. Jiang, Y . Huang, and X. Duan, Graphene nanomesh, Nat. Nanotechnol.5, 190 (2010)
work page 2010
- [32]
-
[33]
T. Ochiai and M. Onoda, Photonic analog of graphene model and its extension: Dirac cone, symmetry, and edge states, Phys. Rev. B80, 155103 (2009)
work page 2009
-
[34]
L. Lu, J. D. Joannopoulos, and M. Solja ˇci´c, Topological pho- tonics, Nat. Photonics8, 821 (2014)
work page 2014
- [35]
-
[36]
A. Simonov and A. L. Goodwin, Designing disorder into crys- talline materials, Nat. Rev. Chem.4, 657 (2020)
work page 2020
-
[37]
E. V . Castro, R. de Gail, M. P. L ´opez-Sancho, and M. A. H. V ozmediano, Absence of localization in a class of topological systems, Phys. Rev. B93, 245414 (2016)
work page 2016
-
[38]
E. V . Castro, R. de Gail, M. P. L ´opez-Sancho, and M. A. H. V ozmediano, Robust band of critical states in time-reversal symmetry-broken fermionic systems with lattice selective dis- order, Phys. Rev. Res.1, 033129 (2019)
work page 2019
-
[39]
N. Shima and H. Aoki, Electronic structure of super-honeycomb systems: A peculiar realization of semimetal/semiconductor classes and ferromagnetism, Phys. Rev. Lett.71, 4389 (1993)
work page 1993
- [40]
-
[41]
L. Chen, F. Xie, S. Sur, H. Hu, S. Paschen, J. Cano, and Q. Si, Emergent flat band and topological Kondo semimetal driven by orbital-selective correlations, Nat. Commun.15, 5242 (2024)
work page 2024
-
[42]
S. Ikegami, K. Fukui, S. Okumura, Y . Kato, and Y . Mo- tome, Topological phase diagram of the Haldane model on a Bishamon-kikko–honeycomb lattice, Phys. Rev. B110, 245107 (2024)
work page 2024
-
[43]
K. Fukui and Y . Motome, Topological Majorana flat bands in the Kitaev model on a Bishamon-kikko lattice, Phys. Rev. B 112, 144411 (2025)
work page 2025
-
[44]
F. D. M. Haldane, Model for a quantum Hall effect without Landau levels: Condensed-matter realization of the “parity anomaly”, Phys. Rev. Lett.61, 2015 (1988)
work page 2015
-
[45]
M. V . Berry, Quantal phase factors accompanying adiabatic changes, Proc. R. Soc. Lond. A. Math. Phys. Sci.392, 45 (1984)
work page 1984
- [46]
- [47]
-
[48]
Kitaev, Anyons in an exactly solved model and beyond, Ann
A. Kitaev, Anyons in an exactly solved model and beyond, Ann. Phys.321, 2 (2006)
work page 2006
-
[49]
R. Bianco and R. Resta, Mapping topological order in coordi- nate space, Phys. Rev. B84, 241106 (2011)
work page 2011
-
[50]
I. Mondragon-Shem and T. L. Hughes, Robust topological in- variants of topological crystalline phases in the presence of im- purities, Phys. Rev. B110, 035146 (2024)
work page 2024
-
[51]
J. D. Hannukainen, M. F. Mart ´ınez, J. H. Bardarson, and T. K. Kvorning, Local Topological Markers in Odd Spatial Dimen- sions and Their Application to Amorphous Topological Matter, Phys. Rev. Lett.129, 277601 (2022)
work page 2022
-
[52]
P. d’Ornellas, R. Barnett, and D. K. K. Lee, Quantized bulk conductivity as a local Chern marker, Phys. Rev. B106, 155124 (2022)
work page 2022
-
[53]
Chen, Universal topological marker, Phys
W. Chen, Universal topological marker, Phys. Rev. B107, 045111 (2023)
work page 2023
-
[54]
N. Ba `u and A. Marrazzo, Local Chern marker for periodic sys- tems, Phys. Rev. B109, 014206 (2024)
work page 2024
-
[55]
Prodan, Non-commutative tools for topological insulators, New J
E. Prodan, Non-commutative tools for topological insulators, New J. Phys.12, 065003 (2010)
work page 2010
-
[56]
T. A. Loring and M. B. Hastings, Disordered topological insu- lators via C*-algebras, Europhys. Lett.92, 67004 (2011)
work page 2011
-
[57]
M. B. Hastings and T. A. Loring, Topological insulators and C*-algebras: Theory and numerical practice, Ann. Phys.326, 1699 (2011)
work page 2011
-
[58]
Prodan, Disordered topological insulators: a non- commutative geometry perspective, J
E. Prodan, Disordered topological insulators: a non- commutative geometry perspective, J. Phys. A: Math. Theor. 44, 113001 (2011)
work page 2011
-
[59]
T. A. Loring, K-theory and pseudospectra for topological insu- lators, Ann. Phys.356, 383 (2015)
work page 2015
-
[60]
T. A. Loring and H. Schulz-Baldes, The spectral localizer for even index pairings, J. Noncommut. Geom.14, 1 (2020)
work page 2020
-
[61]
A. Cerjan and T. A. Loring, Local invariants identify topol- ogy in metals and gapless systems, Phys. Rev. B106, 064109 (2022)
work page 2022
-
[62]
A. Marrazzo and R. Resta, Locality of the anomalous hall con- ductivity, Phys. Rev. B95, 121114 (2017)
work page 2017
-
[63]
Toniolo, On the Bott index of unitary matrices on a finite torus, Lett
D. Toniolo, On the Bott index of unitary matrices on a finite torus, Lett. Math. Phys.112, 126 (2022)
work page 2022
-
[64]
H. Wu, L. Chen, P. Malinowski, B. G. Jang, Q. Deng, K. Scott, J. Huang, J. P. C. Ruff, Y . He, X. Chen, C. Hu, Z. Yue, J. S. Oh, X. Teng, Y . Guo, M. Klemm, C. Shi, Y . Shi, C. Setty, T. Werner, M. Hashimoto, D. Lu, T. Yilmaz, E. Vescovo, S.-K. Mo, A. Fe- dorov, J. D. Denlinger, Y . Xie, B. Gao, J. Kono, P. Dai, Y . Han, X. Xu, R. J. Birgeneau, J.-X. Zhu,...
work page 2024
-
[65]
A. F. May, D. Ovchinnikov, Q. Zheng, R. Hermann, S. Calder, B. Huang, Z. Fei, Y . Liu, X. Xu, and M. A. McGuire, Ferro- magnetism Near Room Temperature in the Cleavable van der Waals crystal Fe5GeTe2, ACS Nano13, 4436 (2019)
work page 2019
-
[66]
M. S. M. de Sousa, F. Liu, M. Malard, F. Qu, and W. Chen, Symmetry-enforced nodal lines in the band structures of vacancy-engineered graphene, Phys. Rev. B105, 155414 11 (2022)
work page 2022
-
[67]
M. S. M. de Sousa, F. Liu, F. Qu, and W. Chen, Vacancy- engineered flat-band superconductivity in holey graphene, Phys. Rev. B105, 014511 (2022)
work page 2022
-
[68]
C. Guti ´errez, C.-J. Kim, L. Brown, T. Schiros, D. Nordlund, E. B. Lochocki, K. M. Shen, J. Park, and A. N. Pasupathy, Imaging chiral symmetry breaking from Kekul ´e bond order in graphene, Nat. Phys.12, 950 (2016)
work page 2016
-
[69]
C. Wen, W. Han, X. Feng, X. Zhu, W. Zhao, S. A. Yang, S. Feng, and H. Guo, Emergent antiferromagnetism in Y- shaped Kekul´e graphene, Phys. Rev. B106, 245116 (2022)
work page 2022
-
[70]
Y . A. Mezenov, A. A. Krasilin, V . P. Dzyuba, A. Nomin´e, and V . A. Milichko, Metal-Organic Frameworks in Modern Physics: Highlights and Perspectives, Adv. Sci.6, 1900506 (2019)
work page 2019
-
[71]
P. W. Anderson, Absence of Diffusion in Certain Random Lat- tices, Phys. Rev.109, 1492 (1958)
work page 1958
-
[72]
F. Evers and A. D. Mirlin, Anderson transitions, Rev. Mod. Phys.80, 1355 (2008)
work page 2008
