arxiv: 2511.22316 · v2 · submitted 2025-11-27 · 💻 cs.LG

Outlier Smoothing with Closed-Form Rotations for W4A4 Large Language Model Quantization

Jinying Xiao , Bin Ji , Shasha Li , XiaoDong Liu , Ma Jun , Chao Wang , Wei Li , Ye Zhong

show 3 more authors

Xuan Xie Nyima Tashi Jie Yu

This is my paper

Pith reviewed 2026-05-17 04:08 UTC · model grok-4.3

classification 💻 cs.LG

keywords LLM quantizationoutlier smoothingclosed-form rotationsGivens rotationsW4A4 quantizationSingleQuantactivation outliersquantization speedup

0 comments

The pith

SingleQuant smooths activation outliers with closed-form Givens rotations to enable single-pass W4A4 LLM quantization.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper establishes that existing quantization approaches suffer from convergence failures because straight-through estimators on Stiefel manifolds create non-smooth gradients and noise during joint optimization and truncation. SingleQuant instead performs all outlier handling in one forward pass by building two fixed rotation matrices, ART to pull extreme activation values inward and URT to spread the remaining values into a more uniform shape. Both matrices are assembled from Givens rotations whose dimensions and angles are chosen once by closed-form formulas rather than learned or calibrated on data. A reader should care because the method removes the long training loop and still reports higher average task scores on models from 7B to 70B parameters. The concrete payoff shown is a 1400-fold reduction in quantization time for LLaMA-2-13B together with a 0.57 percent gain over the strongest baseline.

Core claim

SingleQuant is a single-pass quantization framework that decouples from gradient optimization and truncation by constructing Alignment Rotation Transformation (ART) and Uniformity Rotation Transformation (URT) as matrices of strictly formulated Givens rotations with predetermined dimensions and rotation angles. ART smooths outlier values through closed-form optimal rotations while URT reshapes distributions via geometric mapping, eliminating the non-smoothness and gradient noise that previously obstructed high-fidelity quantized LLM development.

What carries the argument

Alignment Rotation Transformation (ART) and Uniformity Rotation Transformation (URT), two matrices of closed-form Givens rotations with fixed dimensions and angles that perform outlier smoothing and geometric redistribution of activations.

If this is right

Quantization of LLaMA-2-13B completes 1400 times faster than the best baseline while raising average task performance by 0.57 percent.
The same single-pass procedure scales to 7B–70B models and improves results across multiple tasks without extra training.
Elimination of STE-induced gradient noise on manifolds removes the main source of convergence pathology in prior joint optimization schemes.
Because rotations are fully determined in advance, no calibration dataset or iterative solver is needed at quantization time.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

Hardware implementations could precompute the rotation matrices once and apply them with simple matrix multiplies, further amplifying the reported speed advantage.
The fixed-angle construction may extend to other bit-width targets or to weight-only quantization if the same outlier statistics appear.
If the method works on additional model families, it would simplify on-device deployment pipelines by removing the need for per-model hyperparameter search.
A direct comparison of outlier histograms before and after ART/URT on held-out models would provide an independent check of the smoothing claim.

Load-bearing premise

Predetermined closed-form rotations with strictly fixed dimensions and angles in ART and URT are assumed to smooth every relevant activation outlier across diverse LLMs without introducing new distortions or requiring any data-dependent adjustment.

What would settle it

A new LLM on which the fixed rotations leave activation ranges larger than competing methods or produce lower task accuracy than the chosen baseline after the single pass would falsify the claim.

read the original abstract

Large Language Models (LLMs) quantization facilitates deploying LLMs in resource-limited settings, but existing methods that combine incompatible gradient optimization and quantization truncation lead to serious convergence pathology. This prolongs quantization time and degrades LLMs' task performance. Our studies confirm that Straight-Through Estimator (STE) on Stiefel manifolds introduce non-smoothness and gradient noise, obstructing optimization convergence and blocking high-fidelity quantized LLM development despite extensive training. To tackle the above limitations, we propose SingleQuant, a single-pass quantization framework that decouples from quantization truncation, thereby eliminating the above non-smoothness and gradient noise factors. Specifically, SingleQuant constructs Alignment Rotation Transformation (ART) and Uniformity Rotation Transformation (URT) targeting distinct activation outliers, where ART achieves smoothing of outlier values via closed-form optimal rotations, and URT reshapes distributions through geometric mapping. Both matrices comprise strictly formulated Givens rotations with predetermined dimensions and rotation angles, enabling promising LLMs task performance within a short time. Experimental results demonstrate SingleQuant's superiority over the selected baselines across diverse tasks on 7B-70B LLMs. To be more precise, SingleQuant enables quantized LLMs to achieve higher task performance while necessitating less time for quantization. For example, when quantizing LLaMA-2-13B, SingleQuant achieves 1,400$\times$ quantization speedup and increases +0.57\% average task performance compared to the selected best baseline.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

SingleQuant swaps gradient optimization for fixed Givens rotations in outlier smoothing, delivering claimed speedups but resting on unproven assumptions about fixed angles working across layers.

read the letter

The key takeaway is that this paper offers a single-pass W4A4 quantization approach called SingleQuant that replaces iterative optimization with two closed-form transformations, ART and URT, built from predetermined Givens rotations to smooth and reshape activation outliers. It directly targets the convergence problems the authors link to Straight-Through Estimator noise on Stiefel manifolds. On LLaMA-2-13B they report a 1400x quantization speedup and a 0.57% average task gain over their chosen best baseline, which would matter for practical deployment if it holds up. The decoupling from gradient steps is the clearest novelty here, and it avoids the training overhead that slows down other methods. The fixed angles and dimensions make the process fast and deterministic, which is a practical plus for reproducibility. The paper does a reasonable job framing the problem and showing experimental superiority on 7B-70B models across tasks. The stress-test point about predetermined dimensions and angles not matching varying outlier positions is a real concern worth watching. If outlier channels shift substantially by layer or model, the fixed rotations could leave residual issues or introduce new distortions without any data-dependent fix. The abstract gives no derivation for why those specific angles are optimal or closed-form, and the lack of error analysis or detailed baseline specs makes it hard to judge how solid the gains actually are. The circularity burden looks low since the rotations are not fitted to final numbers, but that does not replace the need for evidence that the choices generalize. This work is aimed at engineers and researchers who need fast, non-iterative quantization for resource-limited LLM inference. Readers focused on practical speedups rather than theoretical guarantees would get the most from it. It deserves a serious referee because the core idea is distinct and addresses a documented bottleneck, even though the methods and robustness sections would likely need expansion. I would recommend sending it to peer review.

Referee Report

3 major / 2 minor

Summary. The paper proposes SingleQuant, a single-pass W4A4 quantization framework for LLMs that decouples from gradient-based optimization on Stiefel manifolds by using two closed-form transformations: Alignment Rotation Transformation (ART) to smooth activation outliers and Uniformity Rotation Transformation (URT) to reshape distributions. Both are constructed from strictly formulated Givens rotations with predetermined dimensions and angles. The method claims to eliminate non-smoothness and gradient noise from STE, enabling 1400× faster quantization and +0.57% higher average task performance on LLaMA-2-13B versus the best selected baseline, with similar gains reported across 7B–70B models.

Significance. If the fixed, data-independent Givens rotations in ART and URT provably or empirically smooth outliers across layers and models without introducing new distortions, the approach would represent a meaningful advance in efficient LLM quantization by removing the need for iterative optimization and delivering both speed and accuracy improvements.

major comments (3)

[Methods section describing ART/URT] The central claim that predetermined dimensions and angles in the Givens rotations of ART and URT are 'closed-form optimal' and sufficient to smooth all relevant outliers (without data-dependent adjustment) is load-bearing but unsupported by derivation or robustness analysis. The abstract and methods description provide no explicit construction or proof that these fixed choices align with varying outlier channel positions across layers or models (e.g., LLaMA-2-13B vs. 70B variants).
[Experimental results on LLaMA-2-13B] Table or figure reporting the LLaMA-2-13B result: the 1,400× speedup and +0.57% average task performance gain versus the 'selected best baseline' cannot be evaluated without the exact baseline methods, their hyper-parameters, quantization time measurements, and statistical details (error bars, number of runs). This undermines verification of the empirical superiority claim.
[Results and discussion] No sensitivity study or ablation is presented showing that the fixed rotation angles remain effective when outlier locations shift (as is common across layers in 7B–70B models). If residual outliers persist, both the convergence benefit and the reported performance edge would be compromised.

minor comments (2)

The abstract refers to 'the selected best baseline' without naming the methods; the main text should explicitly list all compared quantization approaches (e.g., GPTQ, AWQ, etc.) and their configurations.
[Methods] Notation for the Givens rotation parameters (dimensions, angles) should be introduced with explicit equations rather than descriptive text only.

Simulated Author's Rebuttal

3 responses · 0 unresolved

We thank the referee for the thoughtful and constructive comments on our manuscript. We address each major comment point by point below, providing clarifications based on the existing work and proposing targeted revisions to improve clarity and completeness.

read point-by-point responses

Referee: [Methods section describing ART/URT] The central claim that predetermined dimensions and angles in the Givens rotations of ART and URT are 'closed-form optimal' and sufficient to smooth all relevant outliers (without data-dependent adjustment) is load-bearing but unsupported by derivation or robustness analysis. The abstract and methods description provide no explicit construction or proof that these fixed choices align with varying outlier channel positions across layers or models (e.g., LLaMA-2-13B vs. 70B variants).

Authors: The methods section formulates ART and URT explicitly as products of Givens rotations with fixed dimensions and angles chosen to target the dominant activation outlier channels observed in transformer layers. These choices derive from the geometric properties of rotation matrices that align extreme values toward the mean without requiring per-layer optimization. While the current text emphasizes the closed-form construction, we agree that an expanded derivation would better substantiate optimality. In the revision we will add a dedicated subsection deriving the angle selection from the expected channel-wise variance patterns and include a brief robustness argument based on the consistency of outlier statistics across the evaluated model scales. revision: yes
Referee: [Experimental results on LLaMA-2-13B] Table or figure reporting the LLaMA-2-13B result: the 1,400× speedup and +0.57% average task performance gain versus the 'selected best baseline' cannot be evaluated without the exact baseline methods, their hyper-parameters, quantization time measurements, and statistical details (error bars, number of runs). This undermines verification of the empirical superiority claim.

Authors: We acknowledge that the current experimental presentation would benefit from greater detail to enable direct verification. The reported 1,400× speedup is measured against the strongest-performing baseline from the set of compared methods, using identical hardware and the same calibration dataset. In the revised manuscript we will expand the experimental section to list the precise baseline implementations, all hyper-parameters, wall-clock quantization times, and statistical summaries including standard deviations over three independent runs with different random seeds. revision: yes
Referee: [Results and discussion] No sensitivity study or ablation is presented showing that the fixed rotation angles remain effective when outlier locations shift (as is common across layers in 7B–70B models). If residual outliers persist, both the convergence benefit and the reported performance edge would be compromised.

Authors: Our main results already span 7B–70B models whose layers exhibit distinct outlier channel shifts, and SingleQuant maintains consistent gains without per-layer retuning. Nevertheless, we agree that an explicit sensitivity analysis would strengthen the robustness claim. We will add an ablation subsection that perturbs the fixed angles around the predetermined values and reports performance on representative layers from LLaMA-2-13B and LLaMA-2-70B, thereby directly demonstrating stability under moderate outlier location variation. revision: yes

Circularity Check

0 steps flagged

No circularity: closed-form predetermined rotations derived independently of performance metrics

full rationale

The paper's core derivation for ART and URT relies on strictly formulated Givens rotations with predetermined dimensions and rotation angles presented as closed-form optimal solutions. These are constructed mathematically without reference to fitted parameters from the target LLM task performance or quantization outcomes. The reported gains (e.g., 1400× speedup and +0.57% on LLaMA-2-13B) are positioned as empirical results from applying these fixed transformations, not as quantities that define or force the rotations by construction. No self-citation chains, ansatz smuggling, or renaming of known results appear as load-bearing steps in the abstract or described framework. The method is self-contained against external benchmarks via its decoupling from STE-based optimization.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 2 invented entities

The central claim rests on the existence of closed-form optimal rotations that can be constructed from standard Givens matrices with fixed dimensions and angles; no data-fitted parameters are mentioned, but the effectiveness of the transformations is postulated without independent verification outside the reported experiments.

axioms (1)

standard math Givens rotations form an orthogonal transformation that can achieve optimal alignment or uniformity mappings when dimensions and angles are predetermined.
Invoked when constructing ART for outlier smoothing and URT for distribution reshaping.

invented entities (2)

Alignment Rotation Transformation (ART) no independent evidence
purpose: Smoothing of outlier values via closed-form optimal rotations
Newly introduced transformation targeting distinct activation outliers.
Uniformity Rotation Transformation (URT) no independent evidence
purpose: Reshaping distributions through geometric mapping
Newly introduced to complement ART for overall uniformity.
