cTreeBalls: a fast 3-point correlation function code for clustering measurements

Alejandro Aviles; Eladio Moreno; Gustavo Niz; Mario A. Rodriguez-Meza

arxiv: 2604.08855 · v1 · submitted 2026-04-10 · 🌌 astro-ph.IM · astro-ph.CO

cTreeBalls: a fast 3-point correlation function code for clustering measurements

Mario A. Rodriguez-Meza , Eladio Moreno , Alejandro Aviles , Gustavo Niz This is my paper

Pith reviewed 2026-05-10 17:41 UTC · model grok-4.3

classification 🌌 astro-ph.IM astro-ph.CO

keywords 3-point correlation functionclustering statisticsHEALPixtree algorithmsoctreeLSSTlarge-scale structurecosmology software

0 comments

The pith

cTreeBalls computes three-point correlation functions for more than 200 million HEALPix pixels in under 10 minutes on one node.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper presents cTreeBalls, a Python and C package that applies octree and kd-tree algorithms to measure two- and three-point clustering statistics from large astronomical catalogs. It shows that the code can handle full-sky simulations with over 200 million points fast enough to support practical analysis of next-generation survey data. A reader would care because three-point correlations provide additional cosmological information beyond two-point statistics, yet they have been computationally prohibitive for the volumes expected from surveys such as LSST. The package adds flexible input and output handling, configuration via external files, and logging to make the method usable in large collaborations.

Core claim

cTreeBalls builds upon octree and kd-tree algorithms to calculate (2,3)-point clustering statistics, achieving the measurement of three-point correlations for more than 200 million HEALPix pixels (a full-sky simulation with Nside = 4096) in less than 10 minutes on a single high-performance computing node. This performance enables feasible analysis for the upcoming LSST data. The code supplies a user-friendly interface for catalog input and result output, supports methods for two-point clustering in periodic boxes, and is configured through external parameter files with enhanced logging and exception handling.

What carries the argument

Octree and kd-tree algorithms that accelerate the counting of triplet and pair separations in large point sets while respecting HEALPix pixelation.

If this is right

Three-point correlation measurements become practical for full LSST-scale catalogs on modest hardware.
Two-point clustering methods for periodic boxes are supplied as a complementary tool within the same package.
Users can configure runs through external parameter files and track execution with built-in logging.
The interface supports flexible catalog input and output formats suitable for collaboration pipelines.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

The reported scaling suggests the code could be used to generate large numbers of mock realizations for covariance estimation of three-point functions.
Similar tree structures might accelerate related statistics such as marked correlations or void-galaxy cross-correlations on the same datasets.
Adoption in existing cosmology analysis frameworks could lower the barrier to including three-point information in parameter constraints.

Load-bearing premise

The tree-based counting correctly preserves the statistical properties of the input catalogs, including HEALPix pixelation and periodic boundaries, without introducing numerical biases or artifacts.

What would settle it

A side-by-side comparison of cBalls results against a brute-force three-point function calculation on an identical catalog of a few thousand points, revealing statistically significant differences in any correlation bin.

read the original abstract

cTreeBalls (cBalls for short) is a Python/C package useful to measure (2,3)-point clustering statistics. cBalls can efficiently calculate 3-point correlations of more than 200 million HEALPix pixels ( a full sky simulation with Nside = 4096) in less than 10 minutes on a single high-performance computing node, enabling a feasible analysis for the upcoming LSST data. It builds upon octree (Barnes & Hut, 1986) and kd-tree algorithms (Bentley, 1975), and supplies a user-friendly interface with flexible input/output (I/O) of catalogue data and measurement results, with the built program configurable through external parameter files and tracked through enhanced logging and warning/exception handling. For completeness and complementarity, methods for measuring two-point clustering statistics for periodic boxes are also included in the package. cTreeBalls was developed for its use in the Dark Energy Science Collaboration (DESC) of the Rubin Observatory Legacy Survey of Space and Time (LSST).

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

cTreeBalls packages standard tree algorithms into a usable 3PCF tool for LSST-scale HEALPix maps, but the speed claims rest on unshown accuracy checks.

read the letter

The core contribution is an engineering package that applies the 1986 Barnes-Hut octree and 1975 kd-tree methods to 3-point correlation measurements on very large catalogs. The practical payoff they advertise is running the 3PCF on a full-sky Nside=4096 HEALPix map with over 200 million pixels in under 10 minutes on one node, which would make this statistic feasible for LSST/DESC work where brute force is impossible. They also include 2PCF routines for periodic boxes and supply a Python/C interface with parameter files, logging, and flexible I/O, which matches what survey analysts actually need day to day. That part looks like a useful, targeted implementation rather than a new algorithm. The main gap is that the abstract states the performance number without any accompanying verification: no timing tables against baselines, no error budgets from the tree opening-angle criterion, and no tests showing that the triple counts on HEALPix pixels match an exact estimator on smaller maps. Tree codes always trade a controllable bias for speed, and for cosmology that bias has to stay below the sample variance; without those numbers the central claim is hard to evaluate. The stress-test concern about unquantified approximation errors therefore stands on the information given. This is a tool paper aimed at people who already run large-scale structure measurements and need faster 3PCF code. A reading group focused on survey pipelines would get value from trying the implementation once the code is public. It deserves peer review if the authors add the missing benchmark and accuracy sections; the underlying methods are established, so the refereeing should focus on whether the delivered performance and fidelity are documented clearly enough for others to adopt it.

Referee Report

2 major / 2 minor

Summary. The manuscript introduces cTreeBalls (cBalls), a Python/C package implementing octree (Barnes & Hut 1986) and kd-tree (Bentley 1975) algorithms to compute 2- and 3-point correlation functions. It claims that the code can evaluate the 3PCF on catalogs exceeding 200 million HEALPix pixels (full-sky Nside=4096 simulation) in under 10 minutes on a single HPC node, thereby enabling feasible 3PCF analyses for LSST DESC data; periodic-box 2PCF methods are included for completeness.

Significance. If the performance and accuracy claims hold, the package would provide a practical tool for large-scale 3PCF measurements required by LSST cosmology, where brute-force approaches are prohibitive. The user-friendly interface, external parameter files, and enhanced logging are practical strengths for collaboration use. The work directly addresses a computational bottleneck in the field.

major comments (2)

[Abstract] Abstract: the central performance claim (200 M+ HEALPix pixels, Nside=4096, <10 min) is presented without any accompanying benchmarks, timing tables, baseline comparisons to existing 3PCF codes, or error budgets. Because the implementation relies on tree opening-angle or multipole-acceptance criteria, the absence of quantified approximation error (or tests against exact counts on smaller maps) makes it impossible to judge whether the measured correlations remain statistically faithful at the precision needed for LSST.
[Implementation] Implementation section (description of HEALPix handling): no explicit statement is given of how pixel weights, spherical geometry, or periodic-boundary conditions are incorporated into the tree traversal, nor is there a test demonstrating that the tree approximation preserves the input catalog's statistical properties without introducing measurable bias in the triple counts.

minor comments (2)

The package name is introduced as both 'cTreeBalls' and 'cBalls'; consistent usage throughout the text and documentation would improve clarity.
A short table or figure summarizing wall-clock times, memory usage, and accuracy metrics on a range of catalog sizes would make the performance results easier to evaluate.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for their careful and constructive review of our manuscript. The comments identify key areas where additional detail and validation would strengthen the presentation. We address each major comment below and have revised the manuscript to incorporate the requested clarifications and supporting material.

read point-by-point responses

Referee: [Abstract] Abstract: the central performance claim (200 M+ HEALPix pixels, Nside=4096, <10 min) is presented without any accompanying benchmarks, timing tables, baseline comparisons to existing 3PCF codes, or error budgets. Because the implementation relies on tree opening-angle or multipole-acceptance criteria, the absence of quantified approximation error (or tests against exact counts on smaller maps) makes it impossible to judge whether the measured correlations remain statistically faithful at the precision needed for LSST.

Authors: We agree that the abstract states the performance claim without embedding the supporting evidence. The full manuscript contains timing results and validation tests in the Results and Validation sections; however, these were not sufficiently highlighted or cross-referenced from the abstract. In the revised version we will add an explicit performance subsection that includes timing tables, direct comparisons against existing 3PCF codes (e.g., TreeCorr and Corrfunc), and quantified approximation-error budgets. We have already performed and will now report tests that compare tree-approximated triple counts against exact brute-force results on smaller HEALPix maps (Nside ≤ 512). These tests show that, for the adopted opening-angle criteria, the relative error in the 3PCF remains below 0.1 % across the scales relevant to LSST analyses, which is adequate for the statistical precision required. The abstract will be updated to reference this new subsection. revision: yes
Referee: [Implementation] Implementation section (description of HEALPix handling): no explicit statement is given of how pixel weights, spherical geometry, or periodic-boundary conditions are incorporated into the tree traversal, nor is there a test demonstrating that the tree approximation preserves the input catalog's statistical properties without introducing measurable bias in the triple counts.

Authors: We accept that the current Implementation section lacks sufficient detail on these points. The revised manuscript will expand this section to describe: (i) how HEALPix pixel weights are propagated to internal tree nodes during construction and traversal, (ii) the use of great-circle angular distances (or equivalent HEALPix-native metrics) for all pair and triple evaluations on the sphere, and (iii) the separate treatment of periodic-boundary conditions that applies only to the included 2PCF box routines. In addition, we will insert a dedicated validation subsection that compares tree-approximated triple counts against exact enumeration on controlled test catalogs. These comparisons confirm that, once the opening-angle tolerance is fixed, the tree algorithm introduces no additional systematic bias in the binned 3PCF beyond the controlled approximation error already quantified. The new text will make these aspects explicit and reproducible. revision: yes

Circularity Check

0 steps flagged

No circularity: direct implementation of established external algorithms

full rationale

The paper describes a software package implementing known octree (Barnes & Hut 1986) and kd-tree (Bentley 1975) algorithms for 2PCF/3PCF measurements on HEALPix maps. No mathematical derivations, parameter fittings, or predictions appear in the provided text. Performance claims are presented as empirical benchmarks rather than derived results. All cited methods are external and predate the work; no self-citation chains or self-definitional reductions are present. The derivation chain is therefore self-contained as a straightforward coding of prior algorithms.

Axiom & Free-Parameter Ledger

0 free parameters · 0 axioms · 0 invented entities

This is a software implementation paper with no theoretical derivation, so the ledger contains no free parameters, axioms, or invented entities.
