Understanding supernova gravitational waves with protoneutron star asteroseismology
Pith reviewed 2026-05-10 02:14 UTC · model grok-4.3
The pith
Linear analysis of protoneutron star oscillations identifies universal relations with supernova gravitational wave frequencies.
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
Core claim
Systematic examination shows that protoneutron-star oscillation frequencies from linear analysis correspond to the dominant gravitational wave signals in supernova simulations, establishing universal relations independent of model parameters such as progenitor mass and equation of state.
What carries the argument
Protoneutron star asteroseismology, the linear perturbation analysis of oscillation modes in the dense core, matched against nonlinear simulation gravitational wave spectra.
Load-bearing premise
The assumption that linear perturbation frequencies accurately capture the dominant features observed in the full nonlinear gravitational wave signals from simulations.
What would settle it
A mismatch between the oscillation frequencies calculated for a given protoneutron star model and the peak frequencies in its corresponding supernova simulation's gravitational wave output would disprove the correspondence.
Figures
read the original abstract
Supernovae are one of the most promising gravitational wave sources. But, since the system of the supernovae is nearly spherically symmetric, the expected gravitational waves from them are relatively weak, compared to the case of the compact binary mergers. Thus, at least using the current gravitational wave detectors, only the gravitational waves from a supernova that occurred in our galaxy could be detected. To reliably extract information from gravitational waves originating from such a low event rate, thorough preparation is essential. However, because supernova gravitational waves strongly depend on model parameters, such as progenitor mass and the equation of state for dense matter, it may be difficult to extract physical properties even if the gravitational waves are detected. The universal relations between gravitational-wave signals and physical properties, independent of model parameters, are important for solving this difficulty. To discuss such a universal relation, in this article, we systematically examine the protoneutron-star oscillation frequencies with the linear analysis, the so-called asteroseismology, and compare them with the gravitational wave signals in the simulations.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The manuscript claims that universal, model-independent relations between supernova gravitational-wave signals and protoneutron-star physical properties can be established by systematically computing linear oscillation frequencies via asteroseismology on static PNS equilibria and directly comparing them to the dominant features in gravitational-wave spectrograms extracted from nonlinear supernova simulations across varying progenitor masses and equations of state.
Significance. If the quantitative correspondence holds, the result would be significant for gravitational-wave astronomy: it would supply a practical, parameter-free tool for interpreting the rare galactic supernova events detectable by current instruments, mitigating the strong dependence on uncertain microphysics and progenitor structure that otherwise hinders signal interpretation.
major comments (2)
- The central claim rests on the assertion that linear frequencies match the dominant time-dependent GW features; however, the manuscript must supply explicit quantitative comparisons (e.g., frequency differences, overlap integrals, or spectrogram peak alignments) with error estimates across at least several progenitor masses and EOS models, as the abstract supplies none and the skeptic concern about evolving backgrounds, convection, and SASI remains unaddressed by static linear analysis.
- Section on simulation comparison: the universality claim is load-bearing only if the extracted linear modes (f-modes, g-modes, etc.) are shown to correspond to the main peaks without nonlinear mode coupling or stochastic excitation altering the spectrum; without such a demonstration the relations cannot be used to interpret real signals.
minor comments (2)
- Clarify the precise identification procedure for associating a given linear mode with a simulation GW peak, including any windowing or filtering applied to the time series.
- Add a table summarizing the frequency matches, progenitor models, and EOS used, with columns for linear frequency, simulation peak frequency, and relative difference.
Simulated Author's Rebuttal
We thank the referee for their careful reading and constructive comments, which highlight important aspects of our linear asteroseismology approach to supernova gravitational waves. We have revised the manuscript to strengthen the quantitative comparisons and clarify the scope of the static analysis. Our responses to the major comments are provided below.
read point-by-point responses
-
Referee: The central claim rests on the assertion that linear frequencies match the dominant time-dependent GW features; however, the manuscript must supply explicit quantitative comparisons (e.g., frequency differences, overlap integrals, or spectrogram peak alignments) with error estimates across at least several progenitor masses and EOS models, as the abstract supplies none and the skeptic concern about evolving backgrounds, convection, and SASI remains unaddressed by static linear analysis.
Authors: We agree that explicit quantitative metrics improve clarity. The revised manuscript now includes a new table and accompanying text with frequency differences, spectrogram peak alignments, and overlap measures between linear modes and GW features, together with error estimates obtained from multiple analysis windows. These are shown for the full set of progenitors and EOS models considered. On evolving backgrounds, convection, and SASI, we have added a limitations paragraph noting that the static equilibria approximate the early post-bounce phase of dominant GW emission; later-time effects are acknowledged as requiring future nonlinear work but do not alter the reported universal relations for the primary peaks. revision: yes
-
Referee: Section on simulation comparison: the universality claim is load-bearing only if the extracted linear modes (f-modes, g-modes, etc.) are shown to correspond to the main peaks without nonlinear mode coupling or stochastic excitation altering the spectrum; without such a demonstration the relations cannot be used to interpret real signals.
Authors: We have expanded the simulation comparison section with eigenfunction-based mode identification and quantitative overlap integrals between linear frequencies and the dominant spectrogram peaks. While nonlinear coupling and stochastic excitation cannot be ruled out entirely in the underlying simulations, the data show that the main peaks align with the linear f- and g-modes to within the stated uncertainties across models, preserving the universality. We have clarified that the relations serve as a practical interpretive tool for bulk properties, with explicit caveats regarding more complex nonlinear dynamics. revision: partial
Circularity Check
No circularity: linear frequencies compared to independent external simulations
full rationale
The paper computes protoneutron-star oscillation frequencies via linear perturbation analysis (asteroseismology) on static equilibria and compares them directly to gravitational-wave signals extracted from separate nonlinear supernova simulations. No derivation step reduces the target universal relations to a fit or self-definition; the claimed relations emerge (or fail to emerge) from this cross-check across progenitor masses and EOS. The correspondence assumption is an empirical hypothesis, not a tautology, and no self-citation chain or ansatz smuggling is invoked to force the result.
Axiom & Free-Parameter Ledger
axioms (1)
- domain assumption Linear perturbation theory is sufficient to capture the dominant oscillation modes of protoneutron stars relevant to gravitational-wave emission.
Reference graph
Works this paper leans on
-
[1]
Abbott B. P.et al. (LIGO Scientific and Virgo Collaborations), Phys. Rev. Lett. 119, 161101 (2017)
2017
-
[2]
Abbott B. P.et al. (LIGO Scientific and Virgo Collaborations), Astrophys. J.848, L12 (2017)
2017
-
[3]
D., Class
Ott C. D., Class. Quant. Grav.26, 063001 (2009)
2009
-
[4]
Abdikamalov E., Pagliaroli G., Radice D.,Handbook of Gravitational Wave Astronomy(Springer, Singapore, 2022), pp. 1
2022
-
[5]
Szczepa´ nczyk M., Zanolin M., Galaxies10, 70 (2022)
2022
-
[6]
L., Fujii M
Arimoto M., Asada H., Cherry M. L., Fujii M. S., Fukazawa Y., Harada A., Hayama K. et al., Prog. Theor. Exp. Phys.2023, 10A103 (2023)
2023
- [7]
- [8]
-
[9]
J.766, 43 (2013)
M¨ uller B., Janka H.-T., Marek A., Astrophys. J.766, 43 (2013)
2013
-
[10]
A., Font J
Cerd´ a-Dur´ an P., DeBrye N., Aloy M. A., Font J. A., Obergaulinger M., Astrophys. J. Lett.779, L18 (2013)
2013
-
[11]
Kuroda T., Kotake K., Takiwaki T., Astrophys. J. Lett.829, L14 (2016)
2016
-
[12]
J.861, 10 (2018)
Morozova V., Radice D., Burrows A., Vartanyan D., Astrophys. J.861, 10 (2018)
2018
-
[13]
Jakobus P., M¨ uller B., Heger A., Zha S., Powell J., Motornenko A., Steinheimer J., Stoecker H., Phys. Rev. Lett.131, 191201 (2023)
2023
-
[14]
E., Lentz E
Mezzacappa A., Marronetti P., Landfield R. E., Lentz E. J., Hix W. R., Harris J. A., Bruenn S. W., Blondin J. M., Messer O. E. B., Casanova J., Kronzer L. L., Physical Review D107, 043008 (2023)
2023
-
[15]
Vartanyan D., Burrows A., Wang T., Coleman M. S. B., White C. J., Phys. Rev. D107, 103015 (2023)
2023
-
[16]
Torres-Forn´ e A., Cerd´ a-Dur´ an P., Passamonti A., Font J. A., Mon. Not. R. Astron. Soc.474, 5272 (2018)
2018
-
[17]
Torres-Forn´ e A., Cerd´ a-Dur´ an P., Passamonti A., Obergaulinger M., Font J. A., Mon. Not. R. Astron. Soc.482, 3967 (2019). REFERENCES23
2019
-
[18]
A., Phys
Torres-Forn´ e A., Cerd´ a-Dur´ an P., Obergaulinger M., M¨ uller B., Font J. A., Phys. Rev. Lett.123, 051102 (2019)
2019
-
[19]
Sotani H., Kuroda T., Takiwaki T., Kotake K., Phys. Rev. D99, 123024 (2019)
2019
-
[20]
Sotani H., Takiwaki T., Mon. Not. R. Astron. Soc.498, 3503 (2020)
2020
-
[21]
Sotani H., Takiwaki T., Togashi H., Phys. Rev. D104, 123009 (2021)
2021
-
[22]
A., Maturana-Russel P., Torres-Forn´ e A., Obergaulinger M., Cerd´ a- Dur´ an P., Christensen N., Font J
Bizouard M. A., Maturana-Russel P., Torres-Forn´ e A., Obergaulinger M., Cerd´ a- Dur´ an P., Christensen N., Font J. A., Meyer R., Phys. Rev. D103, 063006 (2021)
2021
-
[23]
E., Fr¨ ohlich C., Miller J
Wolfe N. E., Fr¨ ohlich C., Miller J. M., Torres-Forn´ e A., Cerd´ a-Dur´ an P., Astrophys. J.954, 161 (2023)
2023
-
[24]
A., Obergaulinger M., Maturana-Russel P., A
Bruel T., Bizouard M. A., Obergaulinger M., Maturana-Russel P., A. Torres- Forn´ e, Cerd´ a-Dur´ an P., Christensen N., Font J. A., Meyer R., Phys. Rev. D107, 083029 (2023)
2023
-
[25]
Sotani H., M¨ uller B., Takiwaki T., Phys. Rev. D109, 123021 (2024)
2024
-
[26]
Sotani H., M¨ uller B., Takiwaki T., Phys. Rev. D112, 083018 (2025)
2025
-
[27]
W., Ott C
Murphy J. W., Ott C. D., Burrows A., Astrophys. J. 707, 1173 (2009)
2009
-
[28]
Andresen H., M¨ uller B., M¨ uller E., Janka H.-T., Mon. Not. R. Astron. Soc.468, 2032 (2017)
2032
-
[29]
Andresen H., M¨ uller E., Janka H.-T., Summa A., Gill K., Zanolin M., Mon. Not. R. Astron. Soc.486, 2238 (2019)
2019
-
[30]
J.901, 108 (2020)
Vartanyan D., Burrows A., Astrophys. J.901, 108 (2020)
2020
-
[31]
D., Schmidt B
Kokkotas K. D., Schmidt B. G., Living Rev. Relativity2, 2 1999
1999
-
[32]
Andersson N., Universe7, 97 (2021)
2021
-
[33]
D., Phys
Andersson N., Kokkotas K. D., Phys. Rev. Lett.77, 4134 (1996)
1996
-
[34]
Andersson N., Kokkotas K. D., Mon. Not. R. Astron. Soc.299, 1059 (1998)
1998
-
[35]
W., Watts A
Steiner A. W., Watts A. L., Phys. Rev. Lett.103, 181101 (2009)
2009
-
[36]
G., Hooker J., Li B
Gearheart M., Newton W. G., Hooker J., Li B. -A., Mon. Not. R. Astron. Soc. 418, 2343 (2011)
2011
-
[37]
Sotani H., Nakazato K., Iida K., Oyamatsu K., Phys. Rev. Lett.108, 201101 (2012)
2012
-
[38]
Sotani H., Iida K., Oyamatsu K., Mon. Not. R. Astron. Soc.489, 3022 (2019)
2019
-
[39]
D., Stergioulas N., Astron
Sotani H., Kokkotas K. D., Stergioulas N., Astron. Astrophys.676, A65 (2023)
2023
-
[40]
Sotani H., Universe10, 231 (2024)
2024
-
[41]
Sotani H., Kohri K., Harada T., Phys. Rev. D69, 084008 (2004)
2004
-
[42]
Sotani H., Yasutake N., Maruyama T., Tatsumi T., Phys. Rev. D83024014 (2011)
2011
-
[43]
Passamonti A., Andersson N., Mon. Not. R. Astron. Soc.419, 638 (2012)
2012
-
[44]
D., Gaertig E., Kokkotas K
Doneva D. D., Gaertig E., Kokkotas K. D., Kr¨ uger C., Phys. Rev. D88, 044052 (2013). REFERENCES24
2013
-
[45]
J., Ho W
Kr¨ uger C. J., Ho W. C. G., Andersson N., Phys. Rev. D92, 063009 (2015)
2015
-
[46]
Sotani H., Phys. Rev. D107, 123025 (2023)
2023
-
[47]
Sotani H., Sumiyoshi K., Phys. Rev. D100, 083008 (2019)
2019
-
[48]
L., Teukolsky S
Shapiro S. L., Teukolsky S. A.,Black Holes, White Dwarfs, and Neutron Stars: The Physics of Compact Objects(Wiley-Interscience, New York, 1983)
1983
-
[49]
Sotani H., Nishimura N., Naito T., Prog. Theor. Exp. Phys.2022, 041D01 (2022)
2022
-
[50]
Sotani H., Ota S., Phys. Rev. D106, 103005 (2022)
2022
-
[51]
Demorest P., Pennucci T., Ransom S., Roberts M., Hessels J., Nature467, 1081 (2010)
2010
-
[52]
J.915, L12 (2021)
Fonseca E.et al., Astrophys. J.915, L12 (2021)
2021
-
[53]
Ransom, S., et al., Astrophys
Saffer A., Fonseca, E. Ransom, S., et al., Astrophys. J. 983, L20 (2025)
2025
-
[54]
W., Beleznay M., Filippenko A
Romani R. W., Beleznay M., Filippenko A. V., Brink T. G., Zheng W., Astrophys. J. 996, 101 (2026)
2026
-
[55]
K., Leung P
Tsui L. K., Leung P. T., Mon. Not. R. Astron. Soc.357, 1029 (2005)
2005
-
[56]
Sotani H., Kumar B., Phys. Rev. D104, 123002 (2021)
2021
-
[57]
Sotani H., Phys. Rev. D113, 023017 (2026)
2026
-
[58]
S., Kanakis-Pegios A., Moustakidis Ch
Laskos-Patkos P., Koliogiannis P. S., Kanakis-Pegios A., Moustakidis Ch. C., Universe8, 395 (2022)
2022
-
[59]
Lozano N., Tran V., Jaikumar P., Galaxies 10, 79 (2022)
2022
-
[60]
Kumar A., Thakur P., Sinha M., Mon. Not. Roy. Astron. Soc.530, 501 (2024)
2024
-
[61]
K., Chatterjee D., Phys
Barman N., Pradhan B. K., Chatterjee D., Phys. Rev. D111, 023017 (2025)
2025
-
[62]
Kumar D., Karan A., Verma A., Mishra H., Mallick R., Phys. Rev. C111, 055805 (2025)
2025
-
[63]
F., Schulze H.-J., Phys
Zheng Z.-Y., Sun T.-T., Chen H., Wei J.-B., Zheng X.-P., Burgio G. F., Schulze H.-J., Phys. Rev. D112, 063015 (2025)
2025
-
[64]
H., Phys
Guha A., Sen D., Gil H., Togashi H.,Hyun C. H., Phys. Rev. D112, 103045 (2025)
2025
-
[65]
Sen D., J. Phys. G48, 025201 (2021)
2021
-
[66]
Barba-Gonz´ alez D., Albertus C., P´ erez-Garc´ ıa M.´A., Mon. Not. Roy. Astron. Soc. 528, 3498 (2024)
2024
-
[67]
Tsiopelas S., Sedrakian A., Oertel M., Eur. Phys. J. A60, 127 (2024)
2024
-
[68]
C49, 054102 (2025)
Wu X., Chu, P.-C., Ju, M., Liu, H., Chinese Phys. C49, 054102 (2025)
2025
-
[69]
H., Symmetry17, 445 (2025)
Togashi H., Sen D., Gil H., Hyun C. H., Symmetry17, 445 (2025)
2025
-
[70]
Kunkel S., Wystub S., Schaffner-Bielich J., Phys. Rev. C111, 035807 (2025)
2025
-
[71]
M., Astrophys
Burrows A., Lattimer J. M., Astrophys. J.307, 178 (1986)
1986
-
[72]
J., Lattimer J
Prakash M., Bombaci I., Prakash M., Ellis P. J., Lattimer J. M., Knorren R., Phys. Rept.280, 1 (1997). REFERENCES25
1997
-
[73]
A., Reddy S., Prakash M., Lattimer J
Pons J. A., Reddy S., Prakash M., Lattimer J. M., Miralles J. A., Astrophys. J. 513, 780 (1999)
1999
-
[74]
Y., Yakovlev D
Gnedin O. Y., Yakovlev D. G., Potekhin A. Y., Monthly Notices of the Royal Astronomical Society324, 725 (2001)
2001
-
[75]
G., Pethick C
Yakovlev D. G., Pethick C. J., Annual Review of Astronomy and Astrophysics 42, 169 (2004)
2004
-
[76]
Astrophys.396, 361 (2002)
Rampp M., Janka H.-T., Astron. Astrophys.396, 361 (2002)
2002
-
[77]
Astrophys
Marek A., Dimmelmeier H., Janka H.-T., Mu¨ uller E., Buras R., Astron. Astrophys. 445, 273 (2006)
2006
-
[78]
Takiwaki T., Kotake K., Suwa Y., Mon. Not. Roy. Astron. Soc.461, L112 (2016)
2016
-
[79]
et al., J
O’Connor E. et al., J. Phys. G45, 104001 (2018)
2018
-
[80]
J.853, 170 (2018)
Kotake K., Takiwaki T., Fischer T., Nakamura K., Mart´ ınez-Pinedo G., Astrophys. J.853, 170 (2018)
2018
