Comparative Evaluation of Memory Technologies for Synaptic Crossbar Arrays- Part 2: Design Knobs and DNN Accuracy Trends

Jeffry Victor , Chunguang Wang , Sumeet K. Gupta This is my paper

Pith reviewed 2026-05-23 22:15 UTC · model grok-4.3

classification 💻 cs.ET cs.LG
keywords synaptic crossbar arraysmemory technologiesDNN accuracyFeFETReRAMin-memory computinghardware non-idealitiesdesign knobs
0
0 comments X

The pith

FeFET is best suited for large synaptic crossbar arrays due to its small layout height and high state distinguishability, with ReRAM matching it on higher bit-slices and complex datasets.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

This paper compares the impact of design choices like array size and bit-slice on DNN accuracy for four memory technologies in crossbar arrays. It evaluates how partial wordline activation and custom ADC levels mitigate non-idealities at the 7nm node. FeFET emerges as preferable for large arrays, while ReRAM performs similarly under more challenging conditions. Accuracy improvements reach over 30 percent with the proposed circuit techniques.

Core claim

Compared to the other technologies, FeFET, by virtue of its small layout height and high distinguishability of its memory states, is best suited for large arrays. For higher bit-slices and a more complex dataset (ResNet-50 with Cifar-100) we found that ReRAM matches the performance of FeFET. PWA increases accuracy by up to 32.56% while custom ADC reference levels yield up to 31.62% accuracy enhancement.

What carries the argument

Evaluation of array size, bit-slice number, partial wordline activation (PWA), and custom ADC reference levels on 8T SRAM, FeFET, ReRAM, and SOT-MRAM crossbars for DNN inference accuracy.

If this is right

  • FeFET is preferred for large arrays over SRAM, ReRAM, and SOT-MRAM.
  • ReRAM matches FeFET performance at higher bit-slices with ResNet-50 on CIFAR-100.
  • PWA can improve accuracy by up to 32.56%.
  • Custom ADC reference levels can improve accuracy by up to 31.62%.
  • The technologies respond differently to these accuracy-enhancing techniques.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • Designers of in-memory computing hardware may favor FeFET when scaling array sizes.
  • Testing these findings on additional DNN models could confirm the trends.
  • The results highlight the importance of co-optimizing circuit solutions with memory technology choice.
  • Future work might explore power or latency implications of these choices.

Load-bearing premise

The device compact models and circuit simulations at the 7 nm node accurately capture all relevant hardware non-idealities and their quantitative impact on end-to-end DNN inference accuracy.

What would settle it

Fabrication and measurement of 7nm crossbar arrays with these technologies showing reversed accuracy rankings or no benefit from PWA would disprove the claims.

read the original abstract

Crossbar memory arrays have been touted as the workhorse of in-memory computing (IMC)-based acceleration of Deep Neural Networks (DNNs), but the associated hardware non-idealities limit their efficacy. To address this, cross-layer design solutions that reduce the impact of hardware non-idealities on DNN accuracy are needed. In Part 1 of this paper, we established the co-optimization strategies for various memory technologies and their crossbar arrays, and conducted a comparative technology evaluation in the context of IMC robustness. In this part, we analyze various design knobs such as array size and bit-slice (number of bits per device) and their impact on the performance of 8T SRAM, ferroelectric transistor (FeFET), Resistive RAM (ReRAM) and spin-orbit-torque magnetic RAM (SOT-MRAM) in the context of inference accuracy at 7nm technology node. Further, we study the effect of circuit design solutions such as Partial Wordline Activation (PWA) and custom ADC reference levels that reduce the hardware non-idealities and comparatively analyze the response of each technology to such accuracy enhancing techniques. Our results on ResNet-20 (with CIFAR-10) show that PWA increases accuracy by up to 32.56% while custom ADC reference levels yield up to 31.62% accuracy enhancement. We observe that compared to the other technologies, FeFET, by virtue of its small layout height and high distinguishability of its memory states, is best suited for large arrays. For higher bit-slices and a more complex dataset (ResNet-50 with Cifar-100) we found that ReRAM matches the performance of FeFET.
