Asymptotic Analysis of Nonlinear One-Bit Precoding in Massive MIMO Systems via Approximate Message Passing
Pith reviewed 2026-05-18 16:44 UTC · model grok-4.3
The pith
An approximate message passing framework derives a closed-form symbol error probability for convex-relaxation-based one-bit precoding in large massive MIMO systems.
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
Core claim
By developing an auxiliary AMP iteration that incorporates the nonlinear quantization function, the authors obtain a closed-form expression for the symbol error probability in the large-system limit for i.i.d. real Gaussian channels. This expression quantifies the impact of model parameters on performance and supports the optimality of the ℓ_∞² regularizer paired with an optimal parameter among mixed ℓ_∞²-ℓ₂² regularizers.
What carries the argument
An auxiliary approximate message passing iteration that folds the nonlinear quantization step into the state evolution equations to track asymptotic behavior.
If this is right
- The symbol error probability admits a closed-form expression depending on system parameters in the large limit.
- The ℓ_∞² regularizer with optimal tuning achieves the best SEP within the considered class of convex regularizers.
- Performance can be predicted without running full simulations for very large antenna arrays.
- The framework provides a way to optimize regularization parameters analytically.
Where Pith is reading between the lines
- The same auxiliary AMP technique could be adapted to analyze other nonlinear operations in precoding or detection problems.
- Results for real-valued systems may serve as a stepping stone toward complex-valued MIMO analysis.
- Finite-system corrections to the asymptotic SEP could be derived as a next step.
- Hardware designers could use the formula to choose between different regularizers without extensive testing.
Load-bearing premise
The channel entries are independent and identically distributed real Gaussians and the analysis holds in the large-system limit where the number of antennas and users both grow large.
What would settle it
Run Monte Carlo simulations of the precoding scheme with 200 antennas and 50 users using i.i.d. Gaussian channels and compare the observed symbol error rate against the closed-form formula for several regularization parameters.
Figures
read the original abstract
Massive multiple-input multiple-output (MIMO) systems employing one-bit digital-to-analog converters offer a hardware-efficient solution for wireless communications. However, the one-bit constraint poses significant challenges for precoding design, as it transforms the problem into a discrete and nonconvex optimization task. In this paper, we investigate a widely adopted ``convex-relaxation-then-quantization" approach for nonlinear symbol-level one-bit precoding. Specifically, we first solve a convex relaxation of the discrete minimum mean square error precoding problem, and then quantize the solution to satisfy the one-bit constraint. Focusing on a real-valued system with an independently and identically distributed (i.i.d.) Gaussian channel, we develop a novel analytical framework based on approximate message passing (AMP) to characterize the high-dimensional asymptotic performance of the considered scheme. The key technical ingredient is an auxiliary AMP iteration that dedicatedly incorporates the nonlinear quantization function into the state evolution analysis. With the proposed framework, we derive a closed-form expression for the symbol error probability (SEP) at the receiver side in the large-system limit, which provides a quantitative characterization of how model and system parameters affect the SEP performance. Our empirical results suggest that the $\ell_\infty^2$ regularizer, when paired with an optimally chosen regularization parameter, achieves optimal SEP performance within a broad class of convex regularization functions. As a first step towards a theoretical justification, we prove the optimality of the $\ell_\infty^2$ regularizer within the mixed $\ell_\infty^2$-$\ell_2^2$ regularization functions.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The manuscript develops an approximate message passing (AMP) framework for asymptotic analysis of a convex-relaxation-then-quantization scheme for nonlinear symbol-level one-bit precoding in massive MIMO systems. Focusing on real-valued i.i.d. Gaussian channels in the large-system limit, it introduces an auxiliary AMP iteration to incorporate the nonlinear quantization into state evolution analysis. This yields a closed-form expression for the symbol error probability (SEP) at the receiver. The paper also reports empirical results suggesting that the ℓ_∞² regularizer achieves optimal SEP performance within a broad class of convex regularizers when paired with an optimally chosen parameter, and provides a proof of optimality within the mixed ℓ_∞²-ℓ₂² regularization functions.
Significance. If the state-evolution justification holds, the closed-form SEP expression supplies a quantitative tool for understanding the impact of model and system parameters on performance in hardware-efficient one-bit massive MIMO, which is a practically relevant setting. The partial theoretical optimality proof for the ℓ_∞² regularizer within the mixed-norm class is a concrete strength that goes beyond pure empirics, and the auxiliary-AMP construction offers a reusable technique for other post-relaxation nonlinearities.
major comments (1)
- [auxiliary AMP iteration and state evolution analysis] The central claim is a closed-form SEP obtained by tracking the auxiliary AMP iteration through state evolution after the convex relaxation is solved and then quantized. Standard AMP state evolution applies to Lipschitz denoisers on linear measurements; here the quantization step is a hard nonlinearity applied post-relaxation. The derivation therefore requires that the effective denoiser (relaxed solution followed by sign quantization) still satisfies the conditions for exact state evolution in the large-system limit. No section supplies the requisite fixed-point analysis or Lipschitz-constant bounds for this composite map, leaving open whether the SEP formula holds exactly or only approximately. This is load-bearing for the validity of the closed-form expression (abstract and introduction).
minor comments (1)
- The abstract refers to an 'optimally chosen' regularization parameter in the empirical results; a brief clarification on whether this parameter is selected via a data-independent rule or cross-validation on the same realizations used for SEP evaluation would improve reproducibility.
Simulated Author's Rebuttal
We thank the referee for the detailed and constructive comments. We are pleased that the significance of the work is recognized, particularly the auxiliary-AMP technique and the partial optimality proof. Below we respond to the major comment on the state evolution justification.
read point-by-point responses
-
Referee: [auxiliary AMP iteration and state evolution analysis] The central claim is a closed-form SEP obtained by tracking the auxiliary AMP iteration through state evolution after the convex relaxation is solved and then quantized. Standard AMP state evolution applies to Lipschitz denoisers on linear measurements; here the quantization step is a hard nonlinearity applied post-relaxation. The derivation therefore requires that the effective denoiser (relaxed solution followed by sign quantization) still satisfies the conditions for exact state evolution in the large-system limit. No section supplies the requisite fixed-point analysis or Lipschitz-constant bounds for this composite map, leaving open whether the SEP formula holds exactly or only approximately. This is load-bearing for the validity of the closed-form expression (abstract and introduction).
Authors: We thank the referee for pointing out this critical aspect of our analysis. The auxiliary AMP iteration is specifically designed to incorporate the quantization nonlinearity by defining an effective denoiser that includes both the solution of the convex relaxation and the subsequent sign quantization. In the large-system limit with i.i.d. Gaussian channels, the state evolution is derived by analyzing the asymptotic behavior of this iteration. However, we acknowledge that the manuscript does not explicitly provide the fixed-point analysis or Lipschitz-constant bounds for the composite denoiser. To address this, in the revised manuscript we will include a new appendix section that rigorously verifies the applicability of state evolution to this setting, including the necessary conditions and bounds, thereby confirming that the closed-form SEP expression holds exactly in the asymptotic regime. revision: yes
Circularity Check
No significant circularity in AMP-based SEP derivation
full rationale
The paper derives a closed-form SEP expression in the large-system limit by introducing an auxiliary AMP iteration that embeds the post-relaxation quantization step into state evolution under i.i.d. Gaussian channels. This is an extension of standard AMP techniques rather than a redefinition of the target quantity. The statement that the l_infty^2 regularizer with optimally chosen parameter achieves optimal performance is presented as an empirical observation plus a partial proof for the mixed l_infty^2-l_2^2 subclass; neither reduces the central SEP formula to a fitted input or self-citation by construction. No quoted equation or step equates the derived result to its own inputs.
Axiom & Free-Parameter Ledger
free parameters (1)
- regularization parameter
axioms (2)
- domain assumption Channel matrix entries are i.i.d. real Gaussian
- domain assumption Large-system limit (number of antennas and users both grow to infinity with fixed ratio)
Lean theorems connected to this paper
-
IndisputableMonolith/Cost/FunctionalEquation.leanwashburn_uniqueness_aczel unclear?
unclearRelation between the paper passage and the cited Recognition theorem.
We develop a novel analytical framework based on approximate message passing (AMP) ... auxiliary AMP iteration that dedicatedly incorporates the nonlinear quantization function into the state evolution analysis.
-
IndisputableMonolith/Foundation/AbsoluteFloorClosure.leanabsolute_floor_iff_bare_distinguishability unclear?
unclearRelation between the paper passage and the cited Recognition theorem.
lim N→∞ 1/N ∑ ϕ(ˆx_i) = E[ϕ(η_a*(τ* Z; γ*))]
What do these tags mean?
- matches
- The paper's claim is directly supported by a theorem in the formal canon.
- supports
- The theorem supports part of the paper's argument, but the paper may add assumptions or extra steps.
- extends
- The paper goes beyond the formal theorem; the theorem is a base layer rather than the whole result.
- uses
- The paper appears to rely on the theorem as machinery.
- contradicts
- The paper's claim conflicts with a theorem or certificate in the canon.
- unclear
- Pith found a possible connection, but the passage is too broad, indirect, or ambiguous to say the theorem truly supports the claim.
Reference graph
Works this paper leans on
-
[1]
J. G. Andrews, S. Buzzi, W. Choi, S. V . Hanly, A. Lozano, A. C. K. Soong, and J. C. Zhang, “What will 5G be?” IEEE J. Sel. Areas Commun. , vol. 32, no. 6, pp. 1065–1082, Jun. 2014
work page 2014
-
[2]
Razavi, Principles of Data Conversion System Design , 1st ed
B. Razavi, Principles of Data Conversion System Design , 1st ed. Hoboken, NJ, USA: Wiley, 1994
work page 1994
-
[3]
S. C. Cripps, RF Power Amplifiers for Wireless Communications , 2nd ed. Norwood, MA, USA: Artech House, 2006
work page 2006
-
[4]
Downlink achievable rate analysis in massive MIMO systems with one-bit DACs,
Y . Li, C. Tao, A. L. Swindlehurst, A. Mezghani, and L. Liu, “Downlink achievable rate analysis in massive MIMO systems with one-bit DACs,” IEEE Commun. Lett. , vol. 21, no. 7, pp. 1669–1672, Jul. 2017
work page 2017
-
[5]
Analy sis of one-bit quantized precoding for the multiuser massiv e MIMO downlink,
A. K. Saxena, I. Fijalkow, and A. L. Swindlehurst, “Analy sis of one-bit quantized precoding for the multiuser massiv e MIMO downlink,” IEEE Trans. Signal Process. , vol. 65, no. 17, pp. 4624–4634, Sept. 2017
work page 2017
-
[6]
MMSE precoder for massive MIMO using 1-bit quantization,
O. B. Usman, H. Jedda, A. Mezghani, and J. A. Nossek, “MMSE precoder for massive MIMO using 1-bit quantization,” in Proc. IEEE Int. Conf. Acoust., Speech, Signal Process. (ICASSP) , Mar. 2016, pp. 3381–3385
work page 2016
-
[7]
A. Kakkavas, J. Munir, A. Mezghani, H. Brunner, and J. A. N ossek, “Weighted sum rate maximization for multi-user MISO systems with low resolution digital to analog converters,” in Proc. 20th Int. ITG W orkshop Smart Antennas (WSA) , Mar. 2016
work page 2016
-
[8]
K. U. Mazher, A. Mezghani, and R. W. Heath, “Multi-user do wnlink beamforming using uplink downlink duality with 1-bi t converters for flat fading channels,” IEEE Trans. V eh. Technol., vol. 71, no. 12, pp. 12 885–12 900, Dec. 2022
work page 2022
-
[9]
Asymptot ic SEP analysis and optimization of linear-quantized preco ding in massive MIMO systems,
Z. Wu, J. Ma, Y .-F. Liu, and A. L. Swindlehurst, “Asymptot ic SEP analysis and optimization of linear-quantized preco ding in massive MIMO systems,” IEEE Trans. Inf. Theory , vol. 70, no. 4, pp. 2566–2589, Apr. 2024
work page 2024
-
[10]
Quantized precoding for massive MU-MIMO,
S. Jacobsson, G. Durisi, M. Coldrey, T. Goldstein, and C . Studer, “Quantized precoding for massive MU-MIMO,” IEEE Trans. Commun. , vol. 65, no. 11, pp. 4670–4684, Nov. 2017
work page 2017
-
[11]
Massive MIMO downlink 1-bit precoding with linear prog ramming for PSK signaling,
H. Jedda, A. Mezghani, J. A. Nossek, and A. L. Swindlehur st, “Massive MIMO downlink 1-bit precoding with linear prog ramming for PSK signaling,” in Proc. IEEE W orkshop Signal Process. Adv. Wireless Commun. , Jul. 2017, pp. 1–5
work page 2017
-
[12]
One-bit precoding and constellation range design for massive MIMO with QAM signal ing,
F. Sohrabi, Y .-F. Liu, and W. Y u, “One-bit precoding and constellation range design for massive MIMO with QAM signal ing,” IEEE J. Sel. Topics Signal Process., vol. 12, no. 3, pp. 557–570, Jun. 2018
work page 2018
-
[13]
Mass ive MIMO 1-bit DAC transmission: A low-complexity symbol sc aling approach,
A. Li, C. Masouros, F. Liu, and A. L. Swindlehurst, “Mass ive MIMO 1-bit DAC transmission: A low-complexity symbol sc aling approach,” IEEE Trans. Wireless Commun., vol. 17, no. 11, pp. 7559–7575, Nov. 2018
work page 2018
-
[14]
A framework for one-bit and constant-envelope precoding over multiuser ma ssive MISO channels,
M. Shao, Q. Li, W.-K. Ma, and A. M.-C. So, “A framework for one-bit and constant-envelope precoding over multiuser ma ssive MISO channels,” IEEE Trans. Signal Process. , vol. 67, no. 20, pp. 5309–5324, Oct. 2019
work page 2019
-
[15]
A. Li, F. Liu, C. Masouros, Y . Li, and B. Vucetic, “Interf erence exploitation 1-bit massive MIMO precoding: A partia l branch-and-bound solution with near-optimal performance,” IEEE Trans. Wireless Commun. , vol. 19, no. 5, pp. 3474–3489, May 2020
work page 2020
-
[16]
Z. Wu, B. Jiang, Y .-F. Liu, M. Shao, and Y .-H. Dai, “Effici ent CI-based one-bit precoding for multiuser downlink mass ive MIMO systems with PSK modulation,” IEEE Trans. Wireless Commun. , vol. 23, no. 5, pp. 4861–4875, May 2024
work page 2024
-
[17]
A survey of recent advances in optimiza tion methods for wireless communications,
Y .-F. Liu, T.-H. Chang, M. Hong, Z. Wu, A. M.-C. So, E. A. J orswieck, and W. Y u, “A survey of recent advances in optimiza tion methods for wireless communications,” IEEE J. Sel. Areas Commun. , vol. 42, no. 11, pp. 2992–3031, Nov. 2024
work page 2024
-
[18]
MMSE analysis of certain large isometric random precoded sy stems,
M. Debbah, W. Hachem, P . Loubaton, and M. de Courville, “ MMSE analysis of certain large isometric random precoded sy stems,” IEEE Trans. Inf. Theory, vol. 49, no. 5, pp. 1293–1311, May 2003
work page 2003
-
[19]
C. Peel, B. Hochwald, and A. Swindlehurst, “A vector-pe rturbation technique for near-capacity multiantenna mult iuser communication-Part I: channel inversion and regularization,” IEEE Trans. Commun. , vol. 53, no. 1, pp. 195–202, Jan. 2005
work page 2005
-
[20]
S. Wagner, R. Couillet, M. Debbah, and D. T. M. Slock, “La rge system analysis of linear precoding in correlated MISO b roadcast channels under limited feedback,” IEEE Trans. Inf. Theory , vol. 58, no. 7, pp. 4509–4537, Jul. 2012
work page 2012
-
[21]
R. Couillet and M. Debbah, Random Matrix Methods for Wireless Communications . New Y ork, NY , USA: Cambridge University Press, 2011
work page 2011
-
[22]
Crosscorrelation functions of amplitud e-distorted Gaussian signals,
J. Bussgang, “Crosscorrelation functions of amplitud e-distorted Gaussian signals,” RLE Technical Reports , vol. 216, 1952
work page 1952
-
[23]
Asymptotic analysis of RLS-base d digital precoder with limited PAPR in massive MIMO,
X. Ma, A. Kammoun, A. M. Alrashdi, T. Ballal, T. Y . Al-Naf fouri, and M.-S. Alouini, “Asymptotic analysis of RLS-base d digital precoder with limited PAPR in massive MIMO,” IEEE Trans. Signal Process. , vol. 70, pp. 5488–5503, Oct. 2022
work page 2022
-
[24]
Precise e rror analysis of regularized M -estimators in high dimensions,
C. Thrampoulidis, E. Abbasi, and B. Hassibi, “Precise e rror analysis of regularized M -estimators in high dimensions,” IEEE Trans. Inf. Theory , vol. 64, no. 8, pp. 5592–5628, Aug. 2018
work page 2018
-
[25]
Message-pas sing algorithms for compressed sensing,
D. L. Donoho, A. Maleki, and A. Montanari, “Message-pas sing algorithms for compressed sensing,” Proc. Natl. Acad. Sci. , vol. 106, no. 45, pp. 18 914–18 919, Nov. 2009
work page 2009
-
[26]
The dynamics of message pas sing on dense graphs, with applications to compressed sensi ng,
M. Bayati and A. Montanari, “The dynamics of message pas sing on dense graphs, with applications to compressed sensi ng,” IEEE Trans. Inf. Theory , vol. 57, no. 2, pp. 764–785, Feb. 2011
work page 2011
-
[27]
A unifying tutorial on approximate message passing,
O. Y . Feng, R. V enkataramanan, C. Rush, and R. J. Samwort h, “A unifying tutorial on approximate message passing,” F ound. Trends Mach. Learn. , vol. 15, no. 4, pp. 335–536, 2022
work page 2022
-
[28]
The LASSO risk for Gaussian matrices,
M. Bayati and A. Montanari, “The LASSO risk for Gaussian matrices,” IEEE Trans. Inf. Theory , vol. 58, no. 4, pp. 1997–2017, Apr. 2012
work page 1997
-
[29]
Universality of the ela stic net error,
A. Montanari and P .-M. Nguyen, “Universality of the ela stic net error,” in Proc. IEEE Int. Symp. Inf. Theory (ISIT) , Jun. 2017, pp. 2338–2342
work page 2017
-
[30]
X. Ma, A. Kammoun, M.-S. Alouini, and T. Y . Al-Naffouri, “Asymptotic analysis of one-bit quantized box-constraine d precoding in large-scale multi-user systems,” 2025. [Online]. Available: https:// arxiv.org/abs/2502.02953
-
[31]
J. Ma and L. Ping, “Orthogonal AMP,” IEEE Access , vol. 5, pp. 2020–2033, 2017
work page 2020
-
[32]
V ector appr oximate message passing,
S. Rangan, P . Schniter, and A. K. Fletcher, “V ector appr oximate message passing,” IEEE Trans. Inf. Theory , vol. 65, no. 10, pp. 6664–6684, Oct. 2019
work page 2019
-
[33]
Approximate message passing algorithms for ro tationally invariant matrices,
Z. Fan, “Approximate message passing algorithms for ro tationally invariant matrices,” Ann. Stat. , vol. 50, no. 1, pp. 197–224, Feb. 2022
work page 2022
-
[34]
Unifying AMP algorithms for rotationa lly-invariant models,
S. Liu and J. Ma, “Unifying AMP algorithms for rotationa lly-invariant models,” arXiv preprint arXiv:2412.01574 , 2024
-
[35]
The asymptotic distri bution of the MLE in high-dimensional logistic models: Arbi trary covariance,
Q. Zhao, P . Sur, and E. J. Candes, “The asymptotic distri bution of the MLE in high-dimensional logistic models: Arbi trary covariance,” Bernoulli, vol. 28, no. 3, pp. 1835–1861, 2022
work page 2022
-
[36]
Universality of approxi mate message passing with semirandom matrices,
R. Dudeja, Y . M. Lu, and S. Sen, “Universality of approxi mate message passing with semirandom matrices,” Ann. Probab., vol. 51, no. 5, pp. 1616–1683, Sept. 2023
work page 2023
-
[37]
Universality of approxim ate message passing algorithms and tensor networks,
T. Wang, X. Zhong, and Z. Fan, “Universality of approxim ate message passing algorithms and tensor networks,” Ann. Appl. Probab. , vol. 34, no. 4, pp. 3943–3994, Aug. 2024
work page 2024
-
[38]
Positively correlated normal variables ar e associated,
L. D. Pitt, “Positively correlated normal variables ar e associated,” Ann. Probab., vol. 10, no. 2, pp. 496–499, May 1982
work page 1982
-
[39]
Error bounds, quadrat ic growth, and linear convergence of proximal methods,
D. Drusvyatskiy and A. S. Lewis, “Error bounds, quadrat ic growth, and linear convergence of proximal methods,” Math. Oper . Res., vol. 43, no. 3, pp. 919–948, Aug. 2018
work page 2018
-
[40]
S. P . Boyd and L. V andenberghe, Convex Optimization. Cambridge Univ. Press, 2004
work page 2004
-
[41]
Large sample estimation an d hypothesis testing,
W. K. Newey and D. McFadden, “Large sample estimation an d hypothesis testing,” Handb. Econom. , vol. 4, pp. 2111–2245, 1994
work page 1994
-
[42]
Universality laws for high-dimensio nal learning with random features,
H. Hu and Y . M. Lu, “Universality laws for high-dimensio nal learning with random features,” IEEE Trans. Inf. Theory , vol. 69, no. 3, pp. 1932–1964, Mar. 2023
work page 1932
