Charge-Preserving Operations in Quantum Batteries
Pith reviewed 2026-05-18 03:40 UTC · model grok-4.3
The pith
Ergotropy can be internally reorganized in quantum systems without changing its total value.
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
Core claim
The central claim is that ergotropy-preserving operations exist which transform the state of a quantum battery by redistributing its ergotropy between different physical contributions, such as coherence versus population inversion in two-level systems or displacement versus squeezing in Gaussian modes, without any net change in the total extractable work. These operations are accompanied by specific changes in the system's energy and entropy and can be realized using linear optical interactions with an auxiliary system.
What carries the argument
Isoergotropic states and the ergotropy-preserving operations that connect them, which alter the balance between coherent and incoherent ergotropy or between displacement and squeezing contributions while the sum remains constant.
If this is right
- Redistribution of ergotropy between coherence and population inversion occurs in two-level systems with no loss in total value.
- Redistribution between displacement and squeezing occurs in single-mode Gaussian states with no loss in total value.
- Energy and entropy of the system vary in a controlled manner during the transformation.
- Beam-splitter interactions with an auxiliary system provide a physical implementation that preserves total ergotropy.
- These transformations support optimized charging protocols and help mitigate charge loss in open quantum batteries.
Where Pith is reading between the lines
- Similar preservation properties might hold for other measures of quantum resources beyond ergotropy.
- Integrating these operations into charging cycles could improve the efficiency of quantum energy storage devices.
- Extensions to multi-partite or higher-dimensional systems could uncover new ways to manage extractable work in complex quantum networks.
Load-bearing premise
The operations can be implemented using beam-splitter interactions with an auxiliary system without altering the overall extractable work.
What would settle it
A calculation or measurement demonstrating that the total ergotropy changes after applying a beam-splitter interaction to a quantum battery state, or that the component redistribution does not match the predicted isoergotropic mapping, would falsify the central claim.
Figures
read the original abstract
Ergotropy provides a fundamental measure of the extractable work from a quantum system and, consequently, of the maximal useful energy, or charge, stored within it. Understanding how this quantity can be manipulated and transformed efficiently is crucial for advancing quantum energy management technologies. Here, we introduce and formalize the concepts of isoergotropic states and ergotropy-preserving operations, which reorganize the internal structure of ergotropy while keeping its total value unchanged. These ideas are illustrated for both discrete (two-level systems) and continuous-variable systems (single-mode Gaussian states). In each case, we show how ergotropy-preserving operations redistribute the respective coherent-incoherent and displacement-squeezing components. We further examine the thermodynamic exchanges accompanying ergotropy-preserving operations, including variations in energy and entropy, and demonstrate that these transformations can be dynamically implemented through standard beam-splitter-type interactions with an auxiliary system. Finally, we discuss the practical implications of isoergotropic states and operations in optimizing charging protocols and mitigating charge loss in open quantum batteries.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The manuscript introduces and formalizes the concepts of isoergotropic states and ergotropy-preserving operations, which reorganize the internal structure of ergotropy (coherent-incoherent components for two-level systems and displacement-squeezing components for single-mode Gaussian states) while keeping its total value unchanged. These are illustrated on discrete and continuous-variable systems, with analysis of accompanying thermodynamic exchanges in energy and entropy. The work further claims that such operations can be dynamically implemented via standard beam-splitter-type interactions with an auxiliary system and discusses implications for optimizing charging protocols and mitigating charge loss in open quantum batteries.
Significance. If the claims hold, particularly the general dynamical realizability, the introduction of isoergotropic states and ergotropy-preserving operations could provide a useful framework for manipulating ergotropy structure without loss in quantum batteries. The illustrations on TLS and Gaussian states, combined with thermodynamic analysis, offer concrete examples that may aid protocol design in quantum thermodynamics.
major comments (1)
- [Abstract and dynamical implementation discussion] Abstract and dynamical implementation discussion: The claim that ergotropy-preserving operations can be dynamically realized through standard beam-splitter-type interactions with an auxiliary system while preserving total ergotropy is load-bearing for the open-system implications. Preservation requires that any change in Tr(Hρ) is exactly offset by a change in Tr(Hρ_passive). This offset holds automatically only for particular auxiliary states (e.g., vacuum for displacement redistribution); for generic thermal or squeezed auxiliaries the spectrum of the reduced battery state shifts in a way that alters ergotropy. The manuscript should explicitly state the required conditions on the auxiliary and verify them beyond the specific TLS and Gaussian illustrations.
minor comments (2)
- [Definitions section] The formal definitions of isoergotropic states and ergotropy-preserving operations would benefit from explicit mathematical expressions presented early in the text to improve accessibility.
- [Illustrations and figures] Any figures showing redistribution of coherent/incoherent or displacement/squeezing components should include clear labels distinguishing the reorganized parts from the total ergotropy.
Simulated Author's Rebuttal
We thank the referee for the careful reading and constructive feedback on our manuscript. We address the single major comment below, agreeing where appropriate and outlining the revisions that will be made.
read point-by-point responses
-
Referee: Abstract and dynamical implementation discussion: The claim that ergotropy-preserving operations can be dynamically realized through standard beam-splitter-type interactions with an auxiliary system while preserving total ergotropy is load-bearing for the open-system implications. Preservation requires that any change in Tr(Hρ) is exactly offset by a change in Tr(Hρ_passive). This offset holds automatically only for particular auxiliary states (e.g., vacuum for displacement redistribution); for generic thermal or squeezed auxiliaries the spectrum of the reduced battery state shifts in a way that alters ergotropy. The manuscript should explicitly state the required conditions on the auxiliary and verify them beyond the specific TLS and Gaussian illustrations.
Authors: We agree with the referee that the dynamical realizability claim requires careful qualification, as ergotropy preservation under beam-splitter interactions is not automatic for arbitrary auxiliary states. In the current manuscript the explicit constructions and numerical illustrations are restricted to auxiliary states (vacuum for the Gaussian case and the appropriate ground-state equivalent for the TLS case) for which the required offset between ΔTr(Hρ) and ΔTr(Hρ_passive) holds exactly, so that only the internal coherent/incoherent or displacement/squeezing decomposition is redistributed. We will revise the relevant sections (including the abstract and the dynamical-implementation discussion) to state these conditions explicitly: the auxiliary must be prepared in a state whose spectrum, after the unitary interaction, ensures that any energy change in the battery is precisely compensated by a change in its passive energy. We will also add a short general argument showing why the vacuum (or ground) choice satisfies the condition and note that generic thermal or squeezed auxiliaries generally violate it, thereby limiting the open-system implications to the auxiliary states we have verified. These changes will be incorporated in the revised version. revision: yes
Circularity Check
No significant circularity detected
full rationale
The paper defines isoergotropic states and ergotropy-preserving operations directly from the established ergotropy functional (energy minus passive energy), then illustrates redistribution of coherent/incoherent or displacement/squeezing components on TLS and Gaussian states. Dynamical realization is asserted via explicit beam-splitter unitaries with an auxiliary mode. No quoted step reduces a claimed prediction or uniqueness result to a fitted parameter, self-definition, or load-bearing self-citation chain; the constructions remain independent of the target claims and rely on standard quantum-optical interactions rather than tautological renaming or imported ansätze.
Axiom & Free-Parameter Ledger
axioms (1)
- standard math Standard quantum mechanics and thermodynamics apply to the description of ergotropy in two-level and Gaussian states.
invented entities (2)
-
isoergotropic states
no independent evidence
-
ergotropy-preserving operations
no independent evidence
Lean theorems connected to this paper
-
IndisputableMonolith/Cost/FunctionalEquation.leanwashburn_uniqueness_aczel unclear?
unclearRelation between the paper passage and the cited Recognition theorem.
Ergotropy R[ρ̂]:=Tr[(ρ̂−ρ̂p)Ĥ] ... isoergotropic states ... ergotropy-preserving operations ... beam-splitter-type interactions
-
IndisputableMonolith/Foundation/AlphaCoordinateFixation.leanJ_uniquely_calibrated_via_higher_derivative unclear?
unclearRelation between the paper passage and the cited Recognition theorem.
R(p,C)=R_inc(p)+R_coh(p,C) ... f_μ̄(ξ,N)=|μ̄|²−(N+½)[cosh(2|ξ|)−1]
What do these tags mean?
- matches
- The paper's claim is directly supported by a theorem in the formal canon.
- supports
- The theorem supports part of the paper's argument, but the paper may add assumptions or extra steps.
- extends
- The paper goes beyond the formal theorem; the theorem is a base layer rather than the whole result.
- uses
- The paper appears to rely on the theorem as machinery.
- contradicts
- The paper's claim conflicts with a theorem or certificate in the canon.
- unclear
- Pith found a possible connection, but the passage is too broad, indirect, or ambiguous to say the theorem truly supports the claim.
Reference graph
Works this paper leans on
-
[1]
Iso-Rrealization via POVM Iso-Roperations can also be realized through selec- tive measurements (POVM elements). A single selective measurement is sufficient to realize an isoergotropic op- eration that maps an incoherent two-level system active state to any other state within the same isoergotropic family. Indeed, consider the incoherent active state ˆϱ¯...
-
[2]
This construction realizes the isoergotropic mappingq7→1−qby a thermal auxil- iary system plus a global unitary and a fixed postprocess- ing unitary ˆV. Note that the mappingq7→1−qcannot be implemented deterministically by local operations and classical communications (LOCC) [88] forq∈(0,1): for q < 1 2 it generally increases entanglement (e.g., the con- ...
-
[3]
Iso-Rrealization via selective Gaussian measurements Let the input be an arbitrary element of the isoer- gotropic family ˆρ¯µ(µ, ξ, N) = ˆU(µ, ξ) ˆπ(N)ˆU †(µ, ξ),(55) with ˆU(µ, ξ) = ˆD(µ) ˆS(ξ),ˆπ(N) = P n≥0 pn(N)|n⟩ ⟨n| and pn(N) = N n (N+ 1) n+1 .(56) The eigenvectors ofˆρ¯µ(µ, ξ, N)are ˆU(µ, ξ)|n⟩with eigen- valuesp n(N). In particular the principal e...
work page 2021
-
[4]
J. Roßnagel, S. T. Dawkins, K. N. Tolazzi, O. Abah, E.Lutz, F.Schmidt-Kaler,andK. Singer,A single-atom heat engine, Science352, 325 (2016)
work page 2016
-
[5]
J.P.Peterson, T.B.Batalhao, M.Herrera, A.M.Souza, R. S. Sarthour, I. S. Oliveira, and R. M. Serra, Experi- mental characterization of a spin quantum heat engine, Phys. Rev. Lett.123, 240601 (2019)
work page 2019
-
[6]
J. Klatzow, J. N. Becker, P. M. Ledingham, C. Weinzetl, K. T. Kaczmarek, D. J. Saunders, J. Nunn, I. A. Walm- sley, R. Uzdin, and E. Poem, Experimental demonstra- tion of quantum effects in the operation of microscopic heat engines, Phys. Rev. Lett.122, 110601 (2019)
work page 2019
-
[7]
X. Nie, X. Zhu, K. Huang, K. Tang, X. Long, Z. Lin, Y. Tian, C. Qiu, C. Xi, X. Yang,et al., Experimental realizationofaquantumrefrigeratordrivenbyindefinite causal orders, Phys. Rev. Lett.129, 100603 (2022)
work page 2022
-
[8]
G. Manzano, G.-L. Giorgi, R. Fazio, and R. Zambrini, Boosting the performance of small autonomous refrig- erators via common environmental effects, New Journal of Physics21, 123026 (2019)
work page 2019
-
[9]
A.H.A.Malavazi, B.Ahmadi, P.Mazurek,andA.Man- darino, Detuning effects for heat-current control in quantum thermal devices, Phys. Rev. E109, 064146 (2024)
work page 2024
-
[10]
U. N. Ekanayake, S. D. Gunapala, and M. Premaratne, Engineeredcommonenvironmentaleffectsonmultitran- sistor systems, Phys. Rev. B107, 075440 (2023)
work page 2023
-
[11]
A. Rajapaksha, S. D. Gunapala, and M. Premaratne, Enhanced thermal rectification in coupled qutrit–qubit quantum thermal diode, APL Quantum1, 046123 (2024)
work page 2024
-
[12]
P. R. Dieguez, V. F. Lisboa, and R. M. Serra, Thermal devices powered by generalized measurements with in- definite causal order, Phys. Rev. A107, 012423 (2023)
work page 2023
-
[13]
R. Alicki and M. Fannes, Entanglement boost for ex- tractable work from ensembles of quantum batteries, Phys. Rev. E87, 042123 (2013)
work page 2013
-
[14]
A. Camposeo, T. Virgili, F. Lombardi, G. Cerullo, D. Pisignano, and M. Polini, Quantum batteries: A materials science perspective, Advanced Materials37, 2415073 (2025). 17
work page 2025
-
[15]
F. Campaioli, S. Gherardini, J. Q. Quach, M. Polini, and G. M. Andolina, Colloquium: Quantum batteries, Rev. Mod. Phys.96, 031001 (2024)
work page 2024
- [16]
-
[17]
H.-Y. Yang, H.-L. Shi, Q.-K. Wan, K. Zhang, X.-H. Wang, and W.-L. Yang, Optimal energy storage in the tavis-cummings quantum battery, Phys. Rev. A109, 012204 (2024)
work page 2024
- [18]
-
[19]
F.-Q. Dou and F.-M. Yang, Superconducting transmon qubit-resonator quantum battery, Phys. Rev. A107, 023725 (2023)
work page 2023
-
[20]
F.-M. Yang and F.-Q. Dou, Resonator-qutrit quantum battery, Phys. Rev. A109, 062432 (2024)
work page 2024
- [21]
-
[22]
I. Maillette de Buy Wenniger, S. E. Thomas, M. Maffei, S. C. Wein, M. Pont, N. Belabas, S. Prasad, A. Harouri, A. Lemaître, I. Sagnes, N. Somaschi, A. Auffèves, and P. Senellart, Experimental analysis of energy transfers between a quantum emitter and light fields, Phys. Rev. Lett.131, 260401 (2023)
work page 2023
-
[23]
A. Rojo-Francàs, F. Isaule, A. C. Santos, B. Juliá-Díaz, and N. T. Zinner, Stable collective charging of ultracold- atom quantum batteries, Phys. Rev. A110, 032205 (2024)
work page 2024
-
[24]
J. Q. Quach, K. E. McGhee, L. Ganzer, D. M. Rouse, B. W. Lovett, E. M. Gauger, J. Keeling, G. Cerullo, D. G. Lidzey, and T. Virgili, Superabsorption in an or- ganic microcavity: Toward a quantum battery, Science advances8, 3160 (2022)
work page 2022
-
[25]
J. Joshi and T. S. Mahesh, Experimental investigation of a quantum battery using star-topology nmr spin sys- tems, Phys. Rev. A106, 042601 (2022)
work page 2022
-
[26]
C. Cruz, M. F. Anka, M. S. Reis, R. Bachelard, and A. C. Santos, Quantum battery based on quantum dis- cord at room temperature, Quantum Science and Tech- nology7, 025020 (2022)
work page 2022
-
[27]
L.Q.Galvão, A.C.dasNeves, M.F.Anka,andC.Cruz, Simulating work extraction in a dinuclear quantum bat- tery using a variational quantum algorithm, Phys. Rev. E111, 064119 (2025)
work page 2025
- [28]
- [29]
- [30]
-
[31]
V. Shaghaghi, V. Singh, G. Benenti, and D. Rosa, Mi- cromasers as quantum batteries, Quantum Science and Technology7, 04LT01 (2022)
work page 2022
-
[32]
V. Shaghaghi, V. Singh, M. Carrega, D. Rosa, and G. Benenti, Lossy micromaser battery: Almost pure states in the jaynes–cummings regime, Entropy25, 430 (2023)
work page 2023
-
[33]
M.-L. Hu, T. Gao, and H. Fan, Efficient wireless charg- ing of a quantum battery, Phys. Rev. A111, 042216 (2025)
work page 2025
-
[34]
G. M. Andolina, D. Farina, A. Mari, V. Pellegrini, V. Giovannetti, and M. Polini, Charger-mediated en- ergy transfer in exactly solvable models for quantum batteries, Phys. Rev. B98, 205423 (2018)
work page 2018
- [35]
-
[36]
F. C. Binder, S. Vinjanampathy, K. Modi, and J. Goold, Quantacell: powerful charging of quantum batteries, New Journal of Physics17, 075015 (2015)
work page 2015
-
[37]
Y.-Y. Zhang, T.-R. Yang, L. Fu, and X. Wang, Powerful harmonic charging in a quantum battery, Phys. Rev. E 99, 052106 (2019)
work page 2019
-
[38]
Çakmak, Ergotropy from coherences in an open quantum system, Phys
B. Çakmak, Ergotropy from coherences in an open quantum system, Phys. Rev. E102, 042111 (2020)
work page 2020
-
[39]
D. Ferraro, M. Campisi, G. M. Andolina, V. Pellegrini, and M. Polini, High-power collective charging of a solid- state quantum battery, Phys. Rev. Lett.120, 117702 (2018)
work page 2018
-
[40]
F. Campaioli, F. A. Pollock, F. C. Binder, L. Céleri, J. Goold, S. Vinjanampathy, and K. Modi, Enhancing the charging power of quantum batteries, Phys. Rev. Lett.118, 150601 (2017)
work page 2017
- [41]
-
[42]
F.-Q. Dou, H. Zhou, and J.-A. Sun, Cavity heisenberg- spin-chain quantum battery, Phys. Rev. A106, 032212 (2022)
work page 2022
- [43]
-
[44]
J.-Y. Gyhm, D. Šafránek, and D. Rosa, Quantum charg- ing advantage cannot be extensive without global oper- ations, Phys. Rev. Lett.128, 140501 (2022)
work page 2022
-
[45]
L. F. C. de Moraes, A. C. Duriez, A. Saguia, A. C. San- tos, and M. S. Sarandy, Quantum battery supercharging via counter-diabatic dynamics, Quantum Science and Technology9, 045033 (2024)
work page 2024
-
[46]
X. Zhang and M. Blaauboer, Enhanced energy transfer in a dicke quantum battery, Frontiers in Physics10, 1097564 (2023)
work page 2023
-
[47]
F. Mazzoncini, V. Cavina, G. M. Andolina, P. A. Erd- man, and V. Giovannetti, Optimal control methods for quantum batteries, Phys. Rev. A107, 032218 (2023)
work page 2023
-
[48]
R. R. Rodríguez, B. Ahmadi, G. Suárez, P. Mazurek, S. Barzanjeh, and P. Horodecki, Optimal quantum con- trol of charging quantum batteries, New Journal of Physics26, 043004 (2024)
work page 2024
-
[49]
C.-K. Hu, J. Qiu, P. J. P. Souza, J. Yuan, Y. Zhou, L. Zhang, J. Chu, X. Pan, L. Hu, J. Li, Y. Xu, Y. Zhong, S. Liu, F. Yan, D. Tan, R. Bachelard, C. J. Villas-Boas, A. C. Santos, and D. Yu, Optimal charging of a su- perconducting quantum battery, Quantum Science and Technology7, 045018 (2022)
work page 2022
-
[50]
M.-L. Hu, T. Gao, and H. Fan, Enhancing the charging performance of an atomic quantum battery, Advanced Quantum Technologies , e00422 (2025). 18
work page 2025
- [51]
-
[52]
F. Pirmoradian and K. Molmer, Aging of a quantum battery, Phys. Rev. A100, 043833 (2019)
work page 2019
-
[53]
A. C. Santos, Quantum advantage of two-level batter- ies in the self-discharging process, Phys. Rev. E103, 042118 (2021)
work page 2021
-
[54]
C. A. Downing and M. S. Ukhtary, Hyperbolic enhance- ment of a quantum battery, Phys. Rev. A109, 052206 (2024)
work page 2024
-
[55]
A. C. Santos, B. Çakmak, S. Campbell, and N. T. Zin- ner, Stable adiabatic quantum batteries, Phys. Rev. E 100, 032107 (2019)
work page 2019
-
[56]
M. T. Mitchison, J. Goold, and J. Prior, Charging a quantum battery with linear feedback control, Quantum 5, 500 (2021)
work page 2021
-
[57]
J. Liu, D. Segal, and G. Hanna, Loss-free excitonic quantum battery, The Journal of Physical Chemistry C123, 18303 (2019)
work page 2019
- [58]
-
[59]
J. Q. Quach and W. J. Munro, Using dark states to charge and stabilize open quantum batteries, Phys. Rev. Appl.14, 024092 (2020)
work page 2020
-
[60]
M. Carrega, A. Crescente, D. Ferraro, and M. Sassetti, Dissipative dynamics of an open quantum battery, New Journal of Physics22, 083085 (2020)
work page 2020
-
[61]
Barra, Dissipative charging of a quantum battery, Phys
F. Barra, Dissipative charging of a quantum battery, Phys. Rev. Lett.122, 210601 (2019)
work page 2019
- [62]
-
[63]
W.-L. Song, H.-B. Liu, B. Zhou, W.-L. Yang, and J.- H. An, Remote charging and degradation suppression for the quantum battery, Phys. Rev. Lett.132, 090401 (2024)
work page 2024
-
[64]
S.-Y. Bai and J.-H. An, Floquet engineering to reacti- vate a dissipative quantum battery, Phys. Rev. A102, 060201 (2020)
work page 2020
-
[65]
F. Zhao, F.-Q. Dou, and Q. Zhao, Quantum battery of interacting spins with environmental noise, Phys. Rev. A103, 033715 (2021)
work page 2021
-
[66]
S. Gherardini, F. Campaioli, F. Caruso, and F. C. Binder, Stabilizing open quantum batteries by sequen- tial measurements, Phys. Rev. Res.2, 013095 (2020)
work page 2020
-
[67]
A. H. Malavazi, R. Sagar, B. Ahmadi, and P. R. Dieguez, Two-time weak-measurement protocol for er- gotropy protection in open quantum batteries, PRX En- ergy4, 023011 (2025)
work page 2025
-
[68]
A. E. Allahverdyan, R. Balian, and T. M. Nieuwen- huizen, Maximal work extraction from finite quantum systems, Europhysics Letters67, 565 (2004)
work page 2004
-
[69]
M. Łobejko, The tight second law inequality for coher- ent quantum systems and finite-size heat baths, Nature Communications12, 918 (2021)
work page 2021
- [70]
-
[71]
R. Castellano, R. Nery, K. Simonov, and D. Farina, Par- allel ergotropy: Maximum work extraction via paral- lel local unitary operations, Phys. Rev. A111, 012212 (2025)
work page 2025
- [72]
-
[73]
G. Di Bello, D. Farina, D. Jansen, C. Perroni, V. Cataudella, and G. De Filippis, Local ergotropy and its fluctuations across a dissipative quantum phase tran- sition, arXiv:2408.02655 (2024)
-
[74]
R. Castellano, D. Farina, V. Giovannetti, and A. Acin, Extended local ergotropy, Phys. Rev. Lett.133, 150402 (2024)
work page 2024
-
[75]
G. Francica, F. C. Binder, G. Guarnieri, M. T. Mitchi- son, J. Goold, and F. Plastina, Quantum coherence and ergotropy, Phys. Rev. Lett.125, 180603 (2020)
work page 2020
- [76]
- [77]
-
[78]
Z. Niu, Y. Wu, Y. Wang, X. Rong, and J. Du, Exper- imental investigation of coherent ergotropy in a single spin system, Phys. Rev. Lett.133, 180401 (2024)
work page 2024
- [79]
-
[80]
A. Serafini,Quantum Continuous Variables: A Primer of Theoretical Methods(CRC Press, Boca Raton, FL, 2017)
work page 2017
