Data-Driven Nonconvex Reachability Analysis using Exact Set Propagation

Zhen Zhang , M. Umar B. Niazi , Michelle S. Chong , Karl H. Johansson , Amr Alanwar

Authors on Pith no claims yet

Pith reviewed 2026-05-13 20:34 UTC · model grok-4.3

classification 📡 eess.SY cs.SY

keywords data-driven reachabilityconstrained polynomial zonotopesnonconvex reachable setsexact set propagationmodel set refinementpolynomial dynamics

0 comments

The pith

Constrained polynomial matrix zonotopes enable algebraically exact multiplication with state sets for nonconvex reachability analysis.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper shows how to represent data-consistent models using constrained polynomial matrix zonotopes so that their product with constrained polynomial zonotope state sets can be computed exactly as another constrained polynomial zonotope. This algebraic exactness removes the structural over-approximation that occurs in standard zonotope-based data-driven methods during set propagation. Consequently, reachable sets for unknown systems can be computed without added conservatism and can preserve nonconvex shapes. New data can be used to intersect and tighten the model set online, leading to progressively tighter reachable sets. The framework also extends to polynomial dynamics by providing exact set representations for monomials and their compositions.

Core claim

The central claim is that the multiplication between a constrained polynomial matrix zonotope model set and a constrained polynomial zonotope state set admits an algebraically exact representation as a constrained polynomial zonotope. This enables reachability analysis to proceed entirely within the CPZ representation without propagation-induced over-approximation, even for nonconvex sets. For polynomial systems, exact CPZ representations of monomials and their compositions allow direct set-level propagation without interval arithmetic or relaxations.

What carries the argument

constrained polynomial matrix zonotopes (CPMZs) that represent data-consistent models and permit exact algebraic multiplication with constrained polynomial zonotopes (CPZs) for states

Load-bearing premise

The system dynamics admit an exact polynomial representation that is consistent with observed data, allowing the multiplication to remain algebraic without needing relaxation.

What would settle it

A concrete counterexample with known polynomial dynamics where the computed reachable set after multiplication is strictly larger than the true reachable set, or where the product cannot be expressed exactly as a single CPZ without added terms.

Figures

Figures reproduced from arXiv: 2604.02625 by Amr Alanwar, Karl H. Johansson, Michelle S. Chong, M. Umar B. Niazi, Zhen Zhang.

**Figure 2.** Figure 2: Illustration of the proof of Proposition [PITH_FULL_IMAGE:figures/full_fig_p008_2.png] view at source ↗

**Figure 3.** Figure 3: Projection of Reachable Sets Computed from Input–State Data Using Algorithm [PITH_FULL_IMAGE:figures/full_fig_p014_3.png] view at source ↗

**Figure 4.** Figure 4: Comparative Projection of Reachable Sets from Input–State Data Using Algorithm [PITH_FULL_IMAGE:figures/full_fig_p014_4.png] view at source ↗

**Figure 5.** Figure 5: Projections of reachable sets for a polynomial system. (a) Model-based reachable sets computed using Algorithm [PITH_FULL_IMAGE:figures/full_fig_p015_5.png] view at source ↗

read the original abstract

This paper studies deterministic data-driven reachability analysis for dynamical systems with unknown dynamics and nonconvex reachable sets. Existing deterministic data-driven approaches typically employ zonotopic set representations, for which the multiplication between a zonotopic model set and a zonotopic state set cannot be represented algebraically exactly, thereby necessitating over-approximation steps in reachable-set propagation. To remove this structural source of conservatism, we introduce constrained polynomial matrix zonotopes (CPMZs) to represent data-consistent model sets, and show that the multiplication between a CPMZ model set and a constrained polynomial zonotope (CPZ) state set admits an algebraically exact CPZ representation. This property enables set propagation entirely within the CPZ representation, thereby avoiding propagation-induced over-approximation and even retaining the ability to represent nonconvex reachable sets. Moreover, we develop set-theoretic results that enable the intersection of data-consistent model sets as new data become available, yielding the proposed online refinement scheme that progressively tightens the data-consistent model set and, in turn, the resulting reachable set. Beyond linear systems, we extend the proposed framework to polynomial dynamics and develop additional set-theoretic results that enable both model-based and data-driven reachability analysis within the same algebraic representation. By deriving algebraically exact CPZ representations for monomials and their compositions, reachable-set propagation can be carried out directly at the set level without resorting to interval arithmetic or relaxation-based bounding techniques. Numerical examples for both linear and polynomial systems demonstrate a significant reduction in conservatism compared to state-of-the-art deterministic data-driven reachability methods.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

The paper delivers an algebraically exact CPMZ-CPZ multiplication that removes one source of over-approximation in data-driven reachability, but the gain still hinges on the model set capturing the dynamics exactly.

read the letter

The central advance is the constrained polynomial matrix zonotope that lets multiplication with a constrained polynomial zonotope stay inside the same representation without extra over-approximation. This is a direct fix for the closure problem that forces conservatism in earlier zonotope-based data-driven methods. They also give an online intersection rule that tightens the model set with new data and extend the same machinery to polynomial dynamics with exact monomial handling at the set level. Those pieces are cleanly derived from the set definitions and the numerical examples show visibly smaller reachable sets than the baselines they compare against. That is useful technical progress for anyone who already works with set propagation for safety verification. The limitation is that the exactness property only holds once the data-consistent model set itself is a faithful polynomial representation of the unknown dynamics. For systems whose behavior does not sit exactly inside a low-degree polynomial family, the model set carries its own conservatism before propagation even starts, so the claimed removal of propagation-induced error does not translate into zero extra conservatism overall. The abstract treats the polynomial-dynamics case separately, which suggests the general data-driven claim rests on how well the CPMZ fits arbitrary data without additional relaxation. This work is aimed at people doing deterministic reachability for control systems and robotics. A reader who needs tighter bounds on nonconvex reachable sets will find the new representations and the exact multiplication result worth examining. I would send it to peer review because the algebraic claims are grounded in the set definitions and the numerical evidence is present to check.

Referee Report

2 major / 1 minor

Summary. The paper introduces constrained polynomial matrix zonotopes (CPMZs) to represent data-consistent model sets for deterministic data-driven reachability analysis of systems with unknown dynamics and nonconvex reachable sets. It claims that multiplication between a CPMZ model set and a constrained polynomial zonotope (CPZ) state set admits an algebraically exact CPZ representation, enabling set propagation entirely within the CPZ class without propagation-induced over-approximation. The work also develops intersection-based online refinement of model sets as new data arrive and extends the framework to polynomial dynamics via exact set-theoretic results for monomials and compositions, with numerical examples claimed to show reduced conservatism versus state-of-the-art zonotopic methods.

Significance. If the algebraic exactness property is rigorously established under the paper's conditions, the contribution would be significant for reducing structural conservatism in data-driven reachability, particularly for nonconvex sets and safety-critical applications. The closure under exact multiplication and the online refinement scheme represent clear technical advances over zonotope-based approaches, and the unified treatment of model-based and data-driven polynomial cases is a strength.

major comments (2)

[Abstract] Abstract and central claim: the algebraically exact CPMZ-CPZ multiplication property (and consequent elimination of propagation over-approximation) holds only when the unknown dynamics are exactly captured by a polynomial representation inside the data-consistent CPMZ; for general nonlinear systems this assumption is not automatically satisfied and may embed implicit conservatism in the model set itself, reintroducing the very source of error the method claims to remove. Explicit conditions, error bounds, or data-exclusion rules are needed to substantiate the data-driven claim for arbitrary systems.
[Abstract] Extension to polynomial dynamics: the abstract separates the polynomial-dynamics case, yet the data-driven claim for linear systems still rests on the same exact-capture requirement; without derivations showing how the CPMZ is constructed from data to guarantee exactness (or quantifying the gap), the central non-conservatism result cannot be verified as load-bearing.

minor comments (1)

[Notation] Clarify notation for CPMZ versus CPZ at first use and ensure consistent use of 'algebraically exact' versus 'exact' throughout.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the careful reading and insightful comments on the scope of our exactness claims. We address each major comment below and agree that targeted clarifications will strengthen the manuscript.

read point-by-point responses

Referee: [Abstract] Abstract and central claim: the algebraically exact CPMZ-CPZ multiplication property (and consequent elimination of propagation over-approximation) holds only when the unknown dynamics are exactly captured by a polynomial representation inside the data-consistent CPMZ; for general nonlinear systems this assumption is not automatically satisfied and may embed implicit conservatism in the model set itself, reintroducing the very source of error the method claims to remove. Explicit conditions, error bounds, or data-exclusion rules are needed to substantiate the data-driven claim for arbitrary systems.

Authors: We agree that the algebraic exactness of CPMZ-CPZ multiplication presupposes that the true dynamics lie within the polynomial class represented by the CPMZ. Our framework is developed specifically for linear and polynomial systems, where this inclusion holds by construction: the data-consistent CPMZ is defined to contain every linear (or polynomial) model that exactly reproduces the observed trajectories. For general nonlinear systems outside this class the method is not claimed, and any implicit conservatism would indeed arise from model mismatch rather than propagation. We will revise the abstract to state the scope explicitly and add a short paragraph in the introduction clarifying the exact-capture assumption together with a reference to the data-consistency definition in Section 3. revision: yes
Referee: [Abstract] Extension to polynomial dynamics: the abstract separates the polynomial-dynamics case, yet the data-driven claim for linear systems still rests on the same exact-capture requirement; without derivations showing how the CPMZ is constructed from data to guarantee exactness (or quantifying the gap), the central non-conservatism result cannot be verified as load-bearing.

Authors: The explicit construction of the data-consistent CPMZ from input-output data is derived in Section 3.1 for the linear case and extended in Section 5 for polynomial dynamics. The resulting CPMZ is the smallest set (in the chosen generator representation) that contains every model whose input-output behavior is identical to the collected data; hence the true linear model is guaranteed to lie inside the set whenever the system is linear. Because the subsequent multiplication with a CPZ state set is shown to be algebraically exact (Theorem 1), no additional over-approximation is introduced during propagation. We will insert a concise summary of this construction and the exact-capture guarantee into the abstract and add a remark quantifying that the only source of conservatism is the data-consistent enclosure itself. revision: partial

Circularity Check

0 steps flagged

No circularity: core property follows from explicit algebraic definitions of new set representations

full rationale

The paper introduces constrained polynomial matrix zonotopes (CPMZs) and constrained polynomial zonotopes (CPZs) as new set representations and proves that their multiplication admits an algebraically exact CPZ representation by direct construction from those definitions. This enables exact propagation without over-approximation. The extension to polynomial dynamics similarly derives exact representations for monomials and compositions via algebraic operations at the set level. No steps reduce a claimed prediction or uniqueness result to a fitted parameter, self-citation chain, or prior ansatz by the same authors; the data-consistent model set is an explicit modeling choice whose exactness is an assumption rather than a derived output. The derivation is therefore self-contained and independent of its inputs.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 2 invented entities

The central claim rests on the algebraic closure properties of the newly defined constrained polynomial matrix zonotopes and constrained polynomial zonotopes; these are introduced in the paper rather than taken from prior literature.

axioms (1)

standard math Standard set-theoretic operations on zonotopes and polynomial zonotopes remain valid when extended to the constrained polynomial matrix version.
Invoked when claiming exact representation after multiplication.

invented entities (2)

constrained polynomial matrix zonotope (CPMZ) no independent evidence
purpose: Represent data-consistent model sets so that multiplication with state sets is algebraically exact.
New object defined in the paper to remove the structural source of conservatism in zonotope multiplication.
constrained polynomial zonotope (CPZ) no independent evidence
purpose: Exact representation of reachable sets after propagation through CPMZ models.
Introduced as the target representation that preserves nonconvexity and exactness.

pith-pipeline@v0.9.0 · 5594 in / 1374 out tokens · 37084 ms · 2026-05-13T20:34:12.098765+00:00 · methodology

discussion (0)

Lean theorems connected to this paper

Citations machine-checked in the Pith Canon. Every link opens the source theorem in the public Lean library.

IndisputableMonolith/Foundation/RealityFromDistinction.lean reality_from_one_distinction unclear

?

unclear
Relation between the paper passage and the cited Recognition theorem.

exact set propagation... avoiding propagation-induced over-approximation

What do these tags mean?

matches: The paper's claim is directly supported by a theorem in the formal canon.
supports: The theorem supports part of the paper's argument, but the paper may add assumptions or extra steps.
extends: The paper goes beyond the formal theorem; the theorem is a base layer rather than the whole result.
uses: The paper appears to rely on the theorem as machinery.
contradicts: The paper's claim conflicts with a theorem or certificate in the canon.
unclear: Pith found a possible connection, but the passage is too broad, indirect, or ambiguous to say the theorem truly supports the claim.
