SAAP: An Efficient Spatial-Aware Analytic Partitioning Algorithm of VLSI Netlists for Parallel Routing

Chen Liu , Hongxin Kong , Lang Feng , Wenchao Qian , Wuxi Li

Authors on Pith no claims yet

Pith reviewed 2026-05-15 08:52 UTC · model grok-4.3

classification 💻 cs.ET

keywords VLSI netlist partitioningspatial-aware partitioningparallel routinganalytic partitioningsimulated annealingphysical design

0 comments

The pith

SAAP creates k-way spatially continuous partitions of placed VLSI netlists that achieve several to dozens of times smaller cut sizes than prior methods.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper introduces SAAP, an analytic partitioning algorithm designed for VLSI netlists after placement. It enforces hard spatial constraints to produce continuous regions suitable for parallel routing. Traditional methods often ignore or softly apply spatial data, leading to scattered partitions that hinder parallelism. SAAP combines analytic boundary modeling, regularity-guided simulated annealing, and region embedding to minimize cuts while keeping partitions spatially coherent and timing-friendly. This matters because effective partitioning can substantially speed up the routing phase in complex chip design by allowing independent processing of regions.

Core claim

Given placed netlists, SAAP generates timing-friendly k-way spatially continuous partitions for parallel routing using analytic boundary modeling with regularity-guided simulated annealing and region embedding, providing significantly smaller spatial cut sizes and better continuity than previous state-of-the-art.

What carries the argument

Analytic boundary modeling with regularity-guided simulated annealing and region embedding, which enforces hard spatial constraints to minimize cut sizes in k-way partitions.

If this is right

Partitions exhibit better spatial continuity, reducing the scattering of connections within each region.
Cut sizes are several to dozens of times smaller, improving the efficiency of parallel routing.
The approach remains timing-friendly, avoiding significant increases in timing violations.
Computation is efficient enough for quick generation of multiple partitions.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

This approach could integrate into existing EDA flows to accelerate overall physical design for large-scale chips.
Further work might explore combining SAAP with dynamic load balancing to optimize runtime across varying netlist sizes.
Testing on a broader range of industrial benchmarks could reveal how well spatial continuity translates to actual routing time savings.

Load-bearing premise

Enforcing hard spatial boundaries via analytic modeling and regularity-guided simulated annealing will not increase timing violations or other routing costs enough to offset the parallelism gains.

What would settle it

A side-by-side routing experiment on placed netlists that measures whether SAAP partitions produce higher timing violations or longer total wirelength than non-spatial baselines despite the reported cut-size reductions.

Figures

Figures reproduced from arXiv: 2604.16357 by Chen Liu, Hongxin Kong, Lang Feng, Wenchao Qian, Wuxi Li.

**Figure 2.** Figure 2: The overall flow of SAAP. (1) Grid-Based Layout Formation: Given a placed netlist, the number of required partitions 𝑘, and the balance constraint parameter 𝜀, the first step is to model the layout with grids, such as employing GCells in the router. SAAP carries out partitioning based on the grid layout. To evaluate the effect of a cut, Steiner tree is generated for all nets as pre-routed [PITH_FULL_IMAGE… view at source ↗

**Figure 3.** Figure 3: Example boundaries on the original and grid-based [PITH_FULL_IMAGE:figures/full_fig_p003_3.png] view at source ↗

**Figure 4.** Figure 4: The illustration of the boundary modeling. [PITH_FULL_IMAGE:figures/full_fig_p003_4.png] view at source ↗

**Figure 5.** Figure 5: An example of embedding a partition region to a [PITH_FULL_IMAGE:figures/full_fig_p005_5.png] view at source ↗

**Figure 6.** Figure 6: The cost regression during simulated annealing of [PITH_FULL_IMAGE:figures/full_fig_p005_6.png] view at source ↗

**Figure 8.** Figure 8: This proves that also hMETIS provides the smallest cut [PITH_FULL_IMAGE:figures/full_fig_p006_8.png] view at source ↗

**Figure 7.** Figure 7: The mempool_tile partitioning of (a) 2-way from [PITH_FULL_IMAGE:figures/full_fig_p006_7.png] view at source ↗

read the original abstract

As VLSI designs grow in complexity, partitioning is widely adopted to accelerate physical design through parallel computing. However, traditional hypergraph partitioning methods often degrade in performance when applied to 2D layouts due to spatial constraints. For routers with post-placement locations, a spatial-aware partitioning method fully utilizing placement data is preferable. Existing works can only consider soft spatial constraints, leading to a scattered distribution in one partition. We propose SAAP, an analytic partitioning algorithm enforcing hard spatial constraints while efficiently minimizing cut sizes. It includes analytic boundary modeling with regularity-guided simulated annealing and region embedding. Given placed netlists, it generates timing-friendly k-way spatially continuous partitions for parallel routing. Experiments show that it can quickly provide several to dozens of times smaller spatial cut sizes than previous state-of-the-art, with better spatial continuity.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

SAAP adds hard spatial constraints to placed-netlist partitioning and reports large cut-size reductions, but the routing and timing results are missing.

read the letter

SAAP is a new analytic partitioning method that enforces hard spatial boundaries on placed VLSI netlists instead of the soft constraints used before. It does this with analytic boundary modeling, regularity-guided simulated annealing, and region embedding to produce k-way spatially continuous partitions meant for parallel routing. That combination looks like a real step past the prior literature the abstract cites. The experiments claim several-to-dozens-of-times smaller spatial cut sizes and better continuity, which would be useful if they hold up for large chips. The paper is clear on the algorithm and the spatial metrics it optimizes. The main gap is that the reported results stop at cut size and continuity. There are no numbers on post-partition routing runs for critical-path delay, total wirelength, or congestion. Hard boundaries can easily create longer nets or boundary hotspots that hurt timing or routability more than the parallelism helps, so the “timing-friendly” claim rests on an untested assumption. This work is for EDA researchers and tool builders who already work on physical design partitioning and parallel routing. Someone in that narrow area would find the technique and the spatial improvements worth looking at. I would send it to peer review. The idea is concrete, the experiments are presented in a form that can be checked, and referees can ask for the missing routing data.

Referee Report

1 major / 0 minor

Summary. The paper proposes SAAP, an analytic partitioning algorithm for placed VLSI netlists that enforces hard spatial constraints via analytic boundary modeling, regularity-guided simulated annealing, and region embedding. It claims to generate k-way spatially continuous partitions that are timing-friendly for parallel routing, achieving several-to-dozens-of-times smaller spatial cut sizes than prior state-of-the-art methods along with improved spatial continuity.

Significance. If validated, the approach could meaningfully advance parallel physical design flows by better exploiting post-placement geometry to reduce inter-partition cuts while preserving locality, potentially improving scalability for large netlists in routing and other downstream steps.

major comments (1)

[Abstract / Experiments] The claim that partitions are 'timing-friendly' is load-bearing for the central contribution yet unsupported by the reported experiments, which (per the abstract) evaluate only spatial cut sizes and continuity. No post-partition routing runs measuring critical-path delay, total wirelength, congestion, or timing-violation counts are described, leaving open the possibility that hard spatial boundaries increase intra-region detours or boundary congestion enough to offset the parallelism gains.

Simulated Author's Rebuttal

1 responses · 0 unresolved

We thank the referee for the constructive comment on the validation of our timing-related claims. We address the point directly below.

read point-by-point responses

Referee: [Abstract / Experiments] The claim that partitions are 'timing-friendly' is load-bearing for the central contribution yet unsupported by the reported experiments, which (per the abstract) evaluate only spatial cut sizes and continuity. No post-partition routing runs measuring critical-path delay, total wirelength, congestion, or timing-violation counts are described, leaving open the possibility that hard spatial boundaries increase intra-region detours or boundary congestion enough to offset the parallelism gains.

Authors: We agree that the manuscript does not include post-partition routing runs or direct measurements of critical-path delay, wirelength, congestion, or timing violations. The reported experiments are limited to spatial cut size and continuity because these are the primary optimization targets of SAAP and serve as the most direct proxies for the inter-partition communication cost that dominates timing impact in parallel routing flows. Smaller spatial cuts reduce the number of nets requiring cross-partition synchronization, while spatial continuity keeps each region compact and thereby limits long detours. We nevertheless recognize that hard boundaries could introduce unmeasured congestion or detour effects. In the revised manuscript we will add a short discussion subsection (in the experiments or conclusions section) that explicitly states the proxy relationship, acknowledges the absence of end-to-end routing data, and notes that full routing and timing evaluations remain future work. This revision clarifies the scope of the current claims without altering the experimental results. revision: partial

Circularity Check

0 steps flagged

No significant circularity in SAAP algorithmic derivation

full rationale

The paper presents SAAP as a new procedure combining analytic boundary modeling, regularity-guided simulated annealing, and region embedding to enforce hard spatial constraints on placed netlists. Claims of smaller spatial cut sizes and better continuity rest on the explicit algorithm steps and direct experimental measurements rather than any reduction of outputs to fitted inputs or self-citations by construction. No self-definitional loops, renamed predictions, or load-bearing self-citation chains appear in the derivation.

Axiom & Free-Parameter Ledger

0 free parameters · 0 axioms · 0 invented entities

Insufficient detail in abstract to enumerate free parameters, axioms, or invented entities; the method appears to rely on standard optimization techniques plus placement data as input.
