Recognition: no theorem link
Node-Based Soft-Output Fast Successive Cancellation List Decoding of Polar Codes
Pith reviewed 2026-05-11 01:44 UTC · model grok-4.3
The pith
Polar code list decoders can produce accurate soft outputs while cutting latency and arithmetic operations by using node-based fast methods.
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
Core claim
The SO-FSCL decoder incorporates node-based fast decoding into the soft-output SCL framework after resolving soft-output extraction for special nodes. It functions as an optional add-on to any FSCL decoder, letting the user select hard decisions alone or full soft outputs. Latency analysis shows decoding time steps can drop 81.8 percent with unlimited resources, additions fall 41.3 percent, and comparisons fall 46.4 percent. Bit and frame error rate curves remain nearly identical to standard SO-SCL and superior to prior soft-output polar methods, especially under iterative decoding.
What carries the argument
Node-based fast successive cancellation list decoding with explicit soft-output extraction rules for special nodes.
If this is right
- Decoding time steps fall by 81.8 percent when unlimited parallel resources are available.
- Arithmetic operations decrease by 41.3 percent in additions and 46.4 percent in comparisons.
- Soft-output quality equals that of conventional SO-SCL while exceeding other soft polar decoders in iterative receiver chains.
- Existing FSCL hardware can be reused by simply enabling or disabling the soft-output path.
Where Pith is reading between the lines
- The same node extraction technique might be applied to other list-based decoders to trade latency for richer output information.
- Lower comparison counts could translate directly into reduced switching activity and power in ASIC or FPGA realizations.
- Because the method preserves the original polar code structure, it remains compatible with existing code design tools and rate-matching schemes.
Load-bearing premise
Soft values can be recovered from the fast-decoded special nodes without enough error to erase the performance match with full successive cancellation list.
What would settle it
A side-by-side simulation run at the same list size and channel conditions in which the SO-FSCL frame error rate curve visibly separates from the SO-SCL curve at moderate-to-high SNR.
Figures
read the original abstract
The soft-output successive cancellation list (SO-SCL) decoder provides a methodology for estimating the a-posteriori probability log-likelihood ratios by only leveraging the conventional SCL decoder of polar codes. However, the sequential decoding nature of SCL introduces high decoding latency to SO-SCL. In this paper, we incorporate node-based fast decoding into the SO-SCL framework. After addressing the challenge of soft output extraction in special node decoding, we proposed the soft-output fast SCL (SO-FSCL) decoding algorithm, along with its log-domain implementation and hardware-friendly version. The proposed SO-FSCL decoder can be regarded as an add-on extension to FSCL decoder, enabling us to autonomously choose whether to output only hard decisions like FSCL or to provide additional soft outputs. Latency and complexity analyses demonstrate that SO-FSCL can significantly reduce, for example, decoding time steps by 81.8\% (with unlimited resources), the number of additions by 41.3\%, and the number of comparisons by 46.4\%. Meanwhile, simulation results indicate that SO-FSCL delivers almost the same soft-output performance as SO-SCL, outperforming other soft-output polar decoders, especially in scenarios involving iterative decoding.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The manuscript proposes the soft-output fast successive cancellation list (SO-FSCL) decoder for polar codes by extending the node-based fast SCL (FSCL) framework to also produce soft outputs. After describing how to extract a-posteriori LLRs during special-node (rate-0, rate-1, etc.) decoding, the paper gives a log-domain implementation and a hardware-friendly variant. It claims that SO-FSCL can be used as an optional add-on to plain FSCL, that it reduces decoding time steps by 81.8 % (unlimited resources), additions by 41.3 %, and comparisons by 46.4 % relative to conventional SO-SCL, and that its soft-output error-rate performance is essentially identical to SO-SCL while outperforming other soft-output polar decoders in iterative settings.
Significance. If the complexity accounting is shown to be complete, the work would provide a practical, low-latency route to soft-output list decoding that is directly compatible with existing fast-SCL hardware. The explicit add-on design and the reported latency reductions are potentially useful for iterative receivers.
major comments (2)
- [§5] §5 (Latency and Complexity Analysis): the headline savings (81.8 % time steps, 41.3 % additions, 46.4 % comparisons) are obtained by comparing SO-FSCL against SO-SCL. The text must explicitly demonstrate that the extra LLR-generation operations required inside each special node for every list entry are included in the operation counts; otherwise the per-node cost scales with list size L and the stated percentage reductions cannot be guaranteed for L ≥ 8 or for codes containing many special nodes.
- [§6] §6 (Simulation Results): the claim that SO-FSCL delivers “almost the same soft-output performance as SO-SCL” is central to the paper’s value proposition. The section should report the exact list size, code lengths, and number of Monte-Carlo trials together with any observed FER/BER gap (or confidence intervals) so that readers can judge whether the performance loss is negligible under the same conditions used for the complexity tables.
minor comments (2)
- [Abstract] The abstract states the reductions “for example”; adding the precise code length, rate, and list size used for those figures would make the claim immediately verifiable.
- [Figures 4–6 and Algorithm 2] Figure captions and the hardware-friendly pseudocode should explicitly label which blocks are new relative to the FSCL baseline so that the incremental cost of the soft-output path is visually clear.
Simulated Author's Rebuttal
We thank the referee for the constructive comments. We address each major comment below and will revise the manuscript to improve clarity on these points.
read point-by-point responses
-
Referee: [§5] §5 (Latency and Complexity Analysis): the headline savings (81.8 % time steps, 41.3 % additions, 46.4 % comparisons) are obtained by comparing SO-FSCL against SO-SCL. The text must explicitly demonstrate that the extra LLR-generation operations required inside each special node for every list entry are included in the operation counts; otherwise the per-node cost scales with list size L and the stated percentage reductions cannot be guaranteed for L ≥ 8 or for codes containing many special nodes.
Authors: We thank the referee for this observation. In our complexity model for SO-FSCL, the LLR-generation operations inside each special node are performed independently for every list entry and have been included in the addition and comparison counts used to derive the reported savings. These per-list costs are part of the node-specific operation formulas that scale with L. To address the request for explicit demonstration, we will revise Section 5 to add a breakdown (including equations) showing how these operations are accounted for within the totals, confirming that the percentage reductions hold under the evaluated conditions. revision: yes
-
Referee: [§6] §6 (Simulation Results): the claim that SO-FSCL delivers “almost the same soft-output performance as SO-SCL” is central to the paper’s value proposition. The section should report the exact list size, code lengths, and number of Monte-Carlo trials together with any observed FER/BER gap (or confidence intervals) so that readers can judge whether the performance loss is negligible under the same conditions used for the complexity tables.
Authors: We agree that explicit reporting of these parameters strengthens the performance claims. We will revise Section 6 to state the exact list size, code lengths, and number of Monte-Carlo trials used in the simulations. We will also quantify the observed FER/BER gaps between SO-FSCL and SO-SCL (which are negligible) and include confidence intervals or variance notes to allow readers to assess the closeness of the curves under the same conditions as the complexity analysis. revision: yes
Circularity Check
No significant circularity detected in the SO-FSCL derivation.
full rationale
The paper presents SO-FSCL as an algorithmic extension to FSCL that incorporates soft-output extraction for special nodes, supported by separate latency/complexity analyses (e.g., time-step reductions) and simulation comparisons to SO-SCL. No load-bearing step reduces by construction to a self-citation, fitted parameter renamed as prediction, or self-definitional equivalence; the central claims rest on explicit modifications to the decoding tree and external empirical validation rather than internal redefinition of inputs.
Axiom & Free-Parameter Ledger
axioms (1)
- domain assumption Standard assumptions of memoryless channels and known polar code construction used in all SCL decoding literature.
Reference graph
Works this paper leans on
-
[1]
Soft-output fast successive-cancellation list decoder for polar codes,
L. Shen, Y . Wu, Y . Xu, X. You, X. Gao, and W. Zhang, “Soft-output fast successive-cancellation list decoder for polar codes,” inProc. IEEE Wireless Commun. Netw. Conf. (WCNC), Milan, Italy, Mar. 2025, pp. 1–6
work page 2025
-
[2]
E. Arıkan, “Channel polarization: A method for constructing capacity- achieving codes for symmetric binary-input memoryless channels,”IEEE Trans. Inf. Theory, vol. 55, no. 7, pp. 3051–3073, Jul. 2009
work page 2009
-
[3]
I. Tal and A. Vardy, “List decoding of polar codes,”IEEE Trans. Inf. Theory, vol. 61, no. 5, pp. 2213–2226, May 2015
work page 2015
-
[4]
CRC-aided decoding of polar codes,
K. Niu and K. Chen, “CRC-aided decoding of polar codes,”IEEE Commun. Lett., vol. 16, no. 10, pp. 1668–1671, Sep. 2012
work page 2012
-
[5]
LLR-based successive cancellation list decoding of polar codes,
A. Balatsoukas-Stimming, M. B. Parizi, and A. Burg, “LLR-based successive cancellation list decoding of polar codes,”IEEE Trans. Signal Process., vol. 63, no. 19, pp. 5165–5179, Oct. 2015. [6]NR; Multiplexing and channel coding, 3GPP Technical Speification (TS) 38.212 V17.3.0 (Release 17), 2022
work page 2015
-
[6]
Channel coding toward 6G: Technical overview and outlook,
M. Rowshan, M. Qiu, Y . Xie, X. Gu, and J. Yuan, “Channel coding toward 6G: Technical overview and outlook,”IEEE Open J. Commun. Soc., vol. 5, pp. 2585–2685, Apr. 2024
work page 2024
-
[7]
Physical layer signal processing for XR communications and systems,
Y . Wu, M. Xu, G. Zhai, and W. Zhang, “Physical layer signal processing for XR communications and systems,”Sci. China Inf. Sci., vol. 67, no. 12, Nov. 2024, Art. no. 221301
work page 2024
-
[8]
A simplified successive- cancellation decoder for polar codes,
A. Alamdar-Yazdi and F. R. Kschischang, “A simplified successive- cancellation decoder for polar codes,”IEEE Commun. Lett., vol. 15, no. 12, pp. 1378–1380, Dec. 2011
work page 2011
-
[9]
Fast polar decoders: Algorithm and implementation,
G. Sarkis, P. Giard, A. Vardy, C. Thibeault, and W. J. Gross, “Fast polar decoders: Algorithm and implementation,”IEEE J. Sel. Areas Commun., vol. 32, no. 5, pp. 946–957, May 2014
work page 2014
-
[10]
Fast successive-cancellation decoding of polar codes: Identification and decoding of new nodes,
M. Hanif and M. Ardakani, “Fast successive-cancellation decoding of polar codes: Identification and decoding of new nodes,”IEEE Commun. Lett., vol. 21, no. 11, pp. 2360–2363, Nov. 2017
work page 2017
-
[11]
Generalized fast decoding of polar codes,
C. Condo, V . Bioglio, and I. Land, “Generalized fast decoding of polar codes,” inProc. IEEE Global Commun. Conf. (GLOBECOM), Abu Dhabi, United Arab Emirates, Dec. 2018, pp. 1–6
work page 2018
-
[12]
Threshold-based fast successive-cancellation decoding of polar codes,
H. Zhenget al., “Threshold-based fast successive-cancellation decoding of polar codes,”IEEE Trans. Commun., vol. 69, no. 6, pp. 3541–3555, Jun. 2021
work page 2021
-
[13]
Fast successive- cancellation decoding of polar codes with sequence nodes,
Y . Lu, M.-M. Zhao, M. Lei, and M.-J. Zhao, “Fast successive- cancellation decoding of polar codes with sequence nodes,”IEEE Trans. Green Commun. Netw., vol. 8, no. 1, pp. 118–133, Mar. 2024
work page 2024
-
[14]
Fast list decoders for polar codes,
G. Sarkis, P. Giard, A. Vardy, C. Thibeault, and W. J. Gross, “Fast list decoders for polar codes,”IEEE J. Sel. Areas Commun., vol. 34, no. 2, pp. 318–328, Feb. 2016
work page 2016
-
[15]
Fast and flexible successive- cancellation list decoders for polar codes,
S. A. Hashemi, C. Condo, and W. J. Gross, “Fast and flexible successive- cancellation list decoders for polar codes,”IEEE Trans. Signal Process., vol. 65, no. 21, pp. 5756–5769, Nov. 2017
work page 2017
-
[16]
Fast successive-cancellation-based decoders of polar codes,
M. H. Ardakani, M. Hanif, M. Ardakani, and C. Tellambura, “Fast successive-cancellation-based decoders of polar codes,”IEEE Trans. Commun., vol. 67, no. 7, pp. 4562–4574, Jul. 2019
work page 2019
-
[17]
Y . Ren, A. T. Kristensen, Y . Shen, A. Balatsoukas-Stimming, C. Zhang, and A. Burg, “A sequence repetition node-based successive cancellation list decoder for 5G polar codes: Algorithm and implementation,”IEEE Trans. Signal Process., vol. 70, pp. 5592–5607, 2022
work page 2022
-
[18]
Fast list decoding of high- rate polar codes,
Y . Lu, M.-M. Zhao, M. Lei, and M.-J. Zhao, “Fast list decoding of high- rate polar codes,”IEEE Trans. Commun., vol. 73, no. 1, pp. 22–38, Jan. 2025. 15
work page 2025
-
[19]
J. Dai, K. Niu, and J. Lin, “Polar-coded MIMO systems,”IEEE Trans. Veh. Technol., vol. 67, no. 7, pp. 6170–6184, Jul. 2018
work page 2018
-
[20]
Achieving near-capacity on a multiple-antenna channel,
B. M. Hochwald and S. ten Brink, “Achieving near-capacity on a multiple-antenna channel,”IEEE Trans. Commun., vol. 51, no. 3, pp. 389–399, Mar. 2003
work page 2003
-
[21]
Quasi-cyclic generalized LDPC codes with low error floors,
G. Liva, W. E. Ryan, and M. Chiani, “Quasi-cyclic generalized LDPC codes with low error floors,”IEEE Trans. Commun., vol. 56, no. 1, pp. 49–57, Jan. 2008
work page 2008
-
[22]
GLDPC-PC codes: Channel coding toward 6G communications,
L. Shen, Y . Wu, Y . Xu, X. You, X. Gao, and W. Zhang, “GLDPC-PC codes: Channel coding toward 6G communications,”IEEE Commun. Mag., vol. 63, no. 10, pp. 165–171, Oct. 2025
work page 2025
-
[23]
P. Elias, “Error-free coding,”Trans. IRE Prof. Group Inf. Theory, vol. 4, no. 4, pp. 29–37, Sep. 1954
work page 1954
-
[24]
Code-aided channel estimation in LDPC-coded MIMO systems,
B. Shi, Y . Wu, P. Yuan, D. W. K. Ng, X.-G. Xia, and W. Zhang, “Code-aided channel estimation in LDPC-coded MIMO systems,”IEEE Wireless Commun. Lett., vol. 13, no. 2, pp. 491–495, Feb. 2024
work page 2024
-
[25]
Optimal decoding of linear codes for minimizing symbol error rate (corresp.),
L. Bahl, J. Cocke, F. Jelinek, and J. Raviv, “Optimal decoding of linear codes for minimizing symbol error rate (corresp.),”IEEE Trans. Inf. Theory, vol. 20, no. 2, pp. 284–287, Mar. 1974
work page 1974
-
[26]
A performance comparison of polar codes and Reed-Muller codes,
E. Arıkan, “A performance comparison of polar codes and Reed-Muller codes,”IEEE Commun. Lett., vol. 12, no. 6, pp. 447–449, Jun. 2008
work page 2008
-
[27]
Low-complexity soft-output decoding of polar codes,
U. U. Fayyaz and J. R. Barry, “Low-complexity soft-output decoding of polar codes,”IEEE J. Sel. Areas Commun., vol. 32, no. 5, pp. 958–966, May 2014
work page 2014
-
[28]
Early stopping criteria for energy-efficient low-latency belief-propagation polar code decoders,
B. Yuan and K. K. Parhi, “Early stopping criteria for energy-efficient low-latency belief-propagation polar code decoders,”IEEE Trans. Signal Process., vol. 62, no. 24, pp. 6496–6506, Dec. 2014
work page 2014
-
[29]
Belief propaga- tion list decoding of polar codes,
A. Elkelesh, M. Ebada, S. Cammerer, and S. ten Brink, “Belief propaga- tion list decoding of polar codes,”IEEE Commun. Lett., vol. 22, no. 8, pp. 1536–1539, Aug. 2018
work page 2018
-
[30]
SCAN list decoding of polar codes,
C. Pillet, C. Condo, and V . Bioglio, “SCAN list decoding of polar codes,” inProc. IEEE Int. Conf. Commun. (ICC), Dublin, Ireland, Jun. 2020, pp. 1–6
work page 2020
-
[31]
Soft list decoding of polar codes,
L. Xiang, Y . Liu, Z. B. K. Egilmez, R. G. Maunder, L.-L. Yang, and L. Hanzo, “Soft list decoding of polar codes,”IEEE Trans. Veh. Technol., vol. 69, no. 11, pp. 13 921–13 926, Nov. 2020
work page 2020
-
[32]
A soft-input soft-output polar decoding algorithm for turbo-detection in MIMO-aided 5G new radio,
Z. B. K. Egilmez, L. Xiang, R. G. Maunder, and L. Hanzo, “A soft-input soft-output polar decoding algorithm for turbo-detection in MIMO-aided 5G new radio,”IEEE Trans. Veh. Technol., vol. 71, no. 6, pp. 6454–6468, Jun. 2022
work page 2022
-
[33]
An efficient soft-input soft- output decoder for polar codes in MIMO iterative detection system,
A. Fominykh, A. Frolov, and K. Qin, “An efficient soft-input soft- output decoder for polar codes in MIMO iterative detection system,” in Proc. IEEE Wireless Commun. Netw. Conf. (WCNC), Glasgow, United Kingdom, Mar. 2023, pp. 1–6
work page 2023
-
[34]
Belief propagation decoding for short-length codes based on sparse Tanner graph,
Z. Li, Y . Shen, Y . Ren, Y . Huang, X. You, and C. Zhang, “Belief propagation decoding for short-length codes based on sparse Tanner graph,”IEEE Commun. Lett., vol. 28, no. 5, pp. 969–973, May 2024
work page 2024
-
[35]
Fast-SCAN decoding of polar codes,
C. Pillet, C. Condo, and V . Bioglio, “Fast-SCAN decoding of polar codes,” inProc. 11th Int. Symp. Topics Coding (ISTC), Montreal, Canada, Aug. 2021, pp. 1–5
work page 2021
-
[36]
Fast iterative soft-output list decoding of polar codes,
Y . Shen, W. Zhou, Y . Huang, Z. Zhang, X. You, and C. Zhang, “Fast iterative soft-output list decoding of polar codes,”IEEE Trans. Signal Process., vol. 70, pp. 1361–1376, 2022
work page 2022
-
[37]
Near-optimum decoding of product codes: Block turbo codes,
R. M. Pyndiah, “Near-optimum decoding of product codes: Block turbo codes,”IEEE Trans. Commun., vol. 46, no. 8, pp. 1003–1010, Aug. 1998
work page 1998
-
[38]
Practical product code construction of polar codes,
C. Condo, V . Bioglio, H. Hafermann, and I. Land, “Practical product code construction of polar codes,”IEEE Trans. Signal Process., vol. 68, pp. 2004–2014, 2020
work page 2004
-
[39]
M. C. Cos ¸kun, “Precoded polar product codes,” inProc. IEEE Int. Symp. Inf. Theory (ISIT), Athens, Greece, Jul. 2024, pp. 3368–3373
work page 2024
-
[40]
Upgrade error detection to prediction with GRAND,
K. Galligan, P. Yuan, M. M ´edard, and K. R. Duffy, “Upgrade error detection to prediction with GRAND,” inProc. IEEE Global Commun. Conf. (GLOBECOM), Kuala Lumpur, Malaysia, Dec. 2023, pp. 1818– 1823
work page 2023
-
[41]
Soft-output (SO) GRAND and iterative decoding to outperform LDPC codes,
P. Yuan, M. M ´edard, K. Galligan, and K. R. Duffy, “Soft-output (SO) GRAND and iterative decoding to outperform LDPC codes,”IEEE Trans. Wireless Commun., vol. 24, no. 4, pp. 3386–3399, Apr. 2025
work page 2025
-
[42]
Soft-output guessing codeword decoding,
K. R. Duffy, P. Yuan, J. Griffin, and M. M ´edard, “Soft-output guessing codeword decoding,”IEEE Commun. Lett., vol. 29, no. 2, pp. 328–332, Feb. 2025
work page 2025
-
[43]
Near-optimal generalized decoding of polar-like codes,
P. Yuan, K. R. Duffy, and M. M ´edard, “Near-optimal generalized decoding of polar-like codes,” inProc. IEEE Int. Symp. Inf. Theory (ISIT), Athens, Greece, Jul. 2024, pp. 2939–2944
work page 2024
-
[44]
Soft-output successive cancellation list decoding,
——, “Soft-output successive cancellation list decoding,”IEEE Trans. Inf. Theory, vol. 71, no. 2, pp. 1007–1017, Feb. 2025
work page 2025
-
[45]
P. Trifonov and V . Miloslavskaya, “Polar subcodes,”IEEE J. Sel. Areas Commun., vol. 34, no. 2, pp. 254–266, Feb. 2016
work page 2016
-
[46]
A fast polar code list decoder architecture based on sphere decoding,
S. A. Hashemi, C. Condo, and W. J. Gross, “A fast polar code list decoder architecture based on sphere decoding,”IEEE Trans. Circuits Syst. I, Reg. Papers, vol. 63, no. 12, pp. 2368–2380, Dec. 2016
work page 2016
-
[47]
Beta-expansion: A theoretical framework for fast and recursive construction of polar codes,
G. Heet al., “Beta-expansion: A theoretical framework for fast and recursive construction of polar codes,” inProc. IEEE Global Commun. Conf. (GLOBECOM), Singapore, Dec. 2017, pp. 1–6
work page 2017
-
[48]
Efficient design and decoding of polar codes,
P. Trifonov, “Efficient design and decoding of polar codes,”IEEE Trans. Commun., vol. 60, no. 11, pp. 3221–3227, Nov. 2012
work page 2012
-
[49]
I. Tal and A. Vardy, “How to construct polar codes,”IEEE Trans. Inf. Theory, vol. 59, no. 10, pp. 6562–6582, Oct. 2013
work page 2013
-
[50]
Linearly approximated log-MAP algo- rithms for turbo decoding,
J.-F. Cheng and T. Ottosson, “Linearly approximated log-MAP algo- rithms for turbo decoding,” inProc. IEEE Veh. Technol. Conf. (VTC- Spring), Tokyo, Japan, May 2000, pp. 2252–2256
work page 2000
-
[51]
From sequential decoding to channel polarization and back again,
E. Arıkan, “From sequential decoding to channel polarization and back again,”arXiv: 1908.09594, 2019
-
[52]
A comparison of optimal and sub-optimal MAP decoding algorithms operating in the log domain,
P. Robertson, E. Villebrun, and P. Hoeher, “A comparison of optimal and sub-optimal MAP decoding algorithms operating in the log domain,” in Proc. IEEE Int. Conf. Commun. (ICC), vol. 2, Seattle, W A, USA, Jun. 1995, pp. 1009–1013
work page 1995
-
[53]
C. Studer, S. Fateh, and D. Seethaler, “ASIC implementation of soft- input soft-output MIMO detection using MMSE parallel interference cancellation,”IEEE J. Solid-State Circuits, vol. 46, no. 7, pp. 1754– 1765, Jul. 2011
work page 2011
-
[54]
From product codes to structured generalized LDPC codes,
M. Lentmaier, G. Liva, E. Paolini, and G. Fettweis, “From product codes to structured generalized LDPC codes,” inProc. 5th Int. ICST Conf. Commun. Netw. China, Beijing, China, Aug. 2010, pp. 1–8
work page 2010
-
[55]
GLDPC codes based on polar constraints and their near-optimal decoding,
B. Shi, Y . Wu, Y . Xu, X. Gao, X. You, and W. Zhang, “GLDPC codes based on polar constraints and their near-optimal decoding,” inProc. IEEE Global Commun. Conf. (GLOBECOM), Taipei, Taiwan, Dec. 2025, pp. 1–6
work page 2025
