Design Space Exploration for ReRAM-based Architectures to Address Scaling Non-idealities

Ching-Yi Lin , Sahil Shah This is my paper

Pith reviewed 2026-05-10 00:23 UTC · model grok-4.3

classification 📡 eess.SY cs.SY
keywords ReRAMin-memory computingdesign space explorationnon-idealitiesscalingenergy efficiencyIMCparameter extraction
0
0 comments X

The pith

A parameter-extraction testbench lets designers optimize ReRAM array size, ADC resolution, and frequency without exhaustive simulations.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper develops a framework that extracts modeling parameters from a small number of representative transistor-level simulations and uses them to predict performance across many possible ReRAM-based in-memory computing architectures. This matters because larger arrays reduce the relative cost of DACs and ADCs but increase parasitics and non-idealities, and current practice requires slow iterative full simulations at the early design stage. The method is demonstrated on two cases that seek to maximize energy efficiency measured in TOPs per watt while staying inside given power and error budgets.

Core claim

A specialized testbench extracts parameters from limited transistor-level simulations; these parameters then accurately predict the behavior of arbitrary ReRAM IMC architectures, enabling selection of optimal array size, ADC resolution, and system frequency that maximize energy efficiency under power and error constraints.
