Design and Modeling of a HASEL Actuator-Based Micro Parallel Robot

Agustin Feregrino (UMLP; Alexis Lef\`evre (UMLP; ENSMM; FEMTO-ST); Nelson Cisneros (UMLP; Yann Le Gorrec (UMLP; Yongxin Wu (UMLP

arxiv: 2604.25337 · v1 · submitted 2026-04-28 · 🧮 math.OC

Design and Modeling of a HASEL Actuator-Based Micro Parallel Robot

Agustin Feregrino (UMLP , ENSMM , FEMTO-ST) , Nelson Cisneros (UMLP , Alexis Lef\`evre (UMLP , Yongxin Wu (UMLP , Yann Le Gorrec (UMLP This is my paper

Pith reviewed 2026-05-07 15:51 UTC · model grok-4.3

classification 🧮 math.OC

keywords HASEL actuatormicro parallel robotport-Hamiltonian modelnonlinear dynamicsgrey-box estimationsoft roboticskinematics3PS topology

0 comments

The pith

A port-Hamiltonian model with forward and inverse kinematics captures the nonlinear dynamics of a HASEL-actuated 3-DOF micro parallel robot.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper designs and prototypes a three-degree-of-freedom micro parallel robot driven by three HASEL soft actuators arranged in a 3PS topology, with a compliant interface serving as a spherical joint. It develops a port-Hamiltonian model that incorporates the mechanism's forward kinematics to represent the nonlinear dynamic behavior and applies inverse kinematics to determine the actuator displacements required for target platform motions. Parameters in this model are identified from experimental data using nonlinear grey-box estimation, producing a compact representation intended for controller design. This modeling step matters because HASEL actuators introduce compliance and electrostatic actuation that standard rigid-body models cannot handle directly.

Core claim

The authors fabricate a prototype with three base-integrated HASEL actuators and track platform motion via an XY laser system. They formulate a port-Hamiltonian model augmented by forward kinematics to describe the system's nonlinear dynamics and employ inverse kinematics to map desired platform poses to actuator lengths. Nonlinear grey-box estimation then tunes the model parameters against measured trajectories, delivering a control-oriented dynamic description of the soft-actuated parallel mechanism.

What carries the argument

The port-Hamiltonian model integrated with the robot's forward kinematics and inverse kinematics, with parameters fitted by nonlinear grey-box estimation to match observed behavior.

If this is right

The identified model supplies the actuator displacements needed to achieve commanded platform motions via inverse kinematics.
The compact port-Hamiltonian representation supports the design of nonlinear controllers for the robot.
Experimental validation on the laser-tracked prototype confirms that the model reproduces the observed dynamic response.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

The same port-Hamiltonian-plus-kinematics structure may transfer to other parallel robots that use compliant or soft actuators.
Improved dynamic models of this type could enable higher-precision trajectory tracking in micro-manipulation applications.
The approach suggests that electrostatic soft actuators can be incorporated into existing port-Hamiltonian control frameworks without requiring entirely new formalisms.

Load-bearing premise

The compliant interface behaves exactly like a spherical joint and the port-Hamiltonian model with kinematics contains no major unmodeled effects that would invalidate its use for control.

What would settle it

A direct comparison in which simulated platform trajectories from the model deviate substantially from laser-tracked experimental positions under identical actuator inputs would falsify the claim that the model accurately captures the nonlinear dynamics.

Figures

Figures reproduced from arXiv: 2604.25337 by Agustin Feregrino (UMLP, Alexis Lef\`evre (UMLP, ENSMM, FEMTO-ST), Nelson Cisneros (UMLP, Yann Le Gorrec (UMLP, Yongxin Wu (UMLP.

**Figure 1.** Figure 1: a) Top view HASEL actuator schematic design view at source ↗

**Figure 2.** Figure 2: 3PS prototype showing the integrated antenna view at source ↗

**Figure 3.** Figure 3: Left: Forward kinematics; Right: Inverse kinematics view at source ↗

**Figure 4.** Figure 4: Overall experimental setup 4.2 Nonlinear Grey-Box Identification The dynamics of each HASEL actuator were represented using a nonlinear ordinary differential equation (ODE) model, as described by (5). The adopted grey-box model included nine parameters: (i) electrical parameters (R0, R1, R2) representing equivalent resistances and C1 denoting the effective capacitance; (ii) mechanical parameters K, Kb an… view at source ↗

**Figure 5.** Figure 5: Parameter identification results. (a–c) Experimen view at source ↗

**Figure 6.** Figure 6: Validation results under ω = 11 rad/s. (a–c) Experimental vs. simulated vertical displacements hi(t); (d) Reconstructed tip trajectory obtained via FKM. apply the framework to biomedical and microscale robotic systems. REFERENCES Acome, E., Mitchell, S., Morrissey, T., Emmett, M., Benjamin, C., King, M., Radakovitz, M., and Keplinger, C. (2018). Hydraulically amplified self-healing electrostatic actuator… view at source ↗

read the original abstract

This paper presents the mechatronic design, dynamic modeling, and experimental validation of a three-degree-of-freedom (3-DOF) micro parallel robot featuring a prismatic-spherical (3PS) topology actuated by three Hydraulically Amplified Self-Healing Electrostatic (HASEL) actuators. Each soft actuator provides the prismatic motion of an individual limb, while a compliant interface to the moving platform functions as a spherical joint. A prototype incorporating three base-integrated HASEL actuators was fabricated, and the platform motion was measured using an XY laser-tracking system. For control purposes, a port-Hamiltonian (PH) model, combined with the mechanism's forward kinematics (FKM), is developed to capture the robot's nonlinear dynamic behavior, whereas the inverse kinematics (IKM) is employed to estimate the required actuator displacements. Model parameters were identified using nonlinear grey-box (NLGB) estimation, yielding a compact and control-oriented representation suitable for subsequent controller design.
