HE-LRM: Encrypted Deep Learning Recommendation Models using Fully Homomorphic Encryption

T0 review · 4 major / 6 minor · reviewed 2026-08-06 · deepseek-v4-flash

Challenge this review Re-run · record.json Download PDF Read on arXiv ↗

Pith's one-line read HE-LRM is the first end-to-end FHE DLRM pipeline that keeps embedding tables server-side and runs Criteo-scale recommendation inference in under eight minutes on a CPU.

desk verdict Digit-decomposition embedding lookup is a real advance; missing test AUC and FHE parameter details are load-bearing but fixable gaps. read the letter →

arxiv 2506.18150 v4 pith:CJ7NXYKP submitted 2025-06-22 cs.CR

Karthik Garimella , Austin Ebel , Gabrielle De Micheli , Brandon Reagen This is my paper
classification cs.CR
keywords FullyHomomorphicEncryptionCKKSDLRMprivateinferenceembeddingtablelookupdigitdecompositionblock-diagonalpackingbaby-stepgiant-step
verification ladder T0 review T1 audit T2 compute T3 formal

The pith

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The reading

This paper establishes that deep learning recommendation models (DLRMs), which route categorical inputs through huge embedding tables, can be executed end-to-end under fully homomorphic encryption without exposing the tables. The central move is a client-side digit decomposition of each categorical index into base-$p$ digits, so the expensive one-hot expansion and indicator-function circuit move before encryption and the lookup becomes one encrypted matrix-vector product. A block-diagonal packing places many embedding tables in one ciphertext and works with the baby-step giant-step linear transformation, so the lookup consumes a single multiplicative level and no bootstrap, giving a 56-fold speedup over the prior compressed lookup protocol. On a single-threaded CPU the complete private inference takes about 24 seconds on UCI Heart Disease and 228-489 seconds on the industry-scale Criteo click-prediction task, with hardware projections bringing those latencies to seconds and sub-seconds.

What carries the argument

The load-bearing object is the client-side digit decomposition of an index $i \in \mathbb{Z}_k$ into $\ell$ tokens in $\mathbb{Z}_p$, a deterministic generalization of the Quotient-Remainder trick. Because the mapping depends only on the dimensions of the compressed tables, the client can one-hot encode each decomposed digit and encrypt a single sparse vector without learning anything about table values. The server multiplies that vector by a block-diagonal matrix in which all embedding tables are placed along the diagonal, so one ciphertext can carry simultaneous lookups across many tables. The baby-step giant-step matrix-vector product performs the lookup in one multiplicative level and places the extracted embeddings into contiguous slots, making the output directly compatible with the next encrypted layers.

What would settle it

Compute test AUC on the held-out seventh day of Criteo for each compression threshold and compare against the uncompressed baseline; if the AUC drop at the advertised 59x-31180x compression ratios is not small, the central practical claim collapses. A target check: instrument the FHE trace to verify the embedding lookup uses exactly one multiplicative level and no bootstrap.

Watch

Extended reading notes

Core claim

HE-LRM is the first end-to-end FHE DLRM pipeline in which dense features, sparse features, and the embedding lookup itself all remain encrypted while the embedding tables stay on the server. The paper's discovery is that a deterministic base-$p$ digit decomposition of a categorical token, computable on the client from the public compressed-table dimensions, removes the need for homomorphic one-hot construction and for the encrypted indicator function earlier methods required. The server receives one-hot encodings of the decomposed digits, multiplies them by a block-diagonal matrix of compressed tables using a baby-step giant-step linear transformation, and produces the embedding vectors in contiguous slots that feed directly into the downstream MLP. This design consumes only one multiplicative level for the lookup, requires no bootstrap, and outperforms the prior compressed-table protocol by up to 56x on the reported configurations.

Load-bearing premise

The load-bearing premise is that digit-decomposed tables keep the trained model accurate enough; the paper reports loss curves but does not state test AUC numbers or plaintext baselines, so the practical value of HE-LRM stands or falls on an unstated accuracy retention.

Editorial extensions

If this is right

  • A single-threaded CPU can run an entire encrypted DLRM inference in about 24 seconds on a small health-prediction model and in 228-489 seconds on a Criteo-scale click-prediction model, with bootstrapping the dominant cost in the small model.
  • Embedding tables never leave the server and coded-token mappings do not have to be sent to the client, so the protocol avoids the model-weight leakage inherent in client-side embedding lookups.
  • The 56x lookup speedup over the prior protocol comes from replacing the encrypted indicator function and its bootstraps with a client-side one-hot encoding plus a single-level matrix-vector product.
  • Projected GPU and ASIC execution of the same FHE traces reduces end-to-end latencies to seconds and sub-seconds, respectively, which is the regime needed for production recommender traffic.
  • The same compression and packing primitives bring a GPT-2-scale transformer embedding lookup from hours to minutes and cut the per-generated-token communication rounds down to a small ciphertext upload.

Reading between the lines

Editorial extensions of the paper, not claims the author makes directly.

  • If compressed embeddings hold up on accuracy, the same client-side digit decomposition should transfer to other sparse-index models, such as user-item collaborative filters or graph node embeddings, where table transfer is the bottleneck.
  • The paper's transformer discussion implies a layout mismatch: its row-major contiguous output must be repacked into column-packed ciphertexts for existing attention implementations; closing that gap could make non-interactive encrypted generation practical, which the paper leaves open.
  • Fixing the decomposition base at $p=4$ in the Criteo experiments leaves room for tuning: making $p$ and $\ell$ per-table choices, or learning them during training, could shift the accuracy-versus-compression frontier that the paper only sketches.
  • The cost picture suggests a simple design rule for FHE-friendly recommenders: cap each table's vocabulary near a power of the decomposition base so the one-hot input fits in one or a few ciphertexts; DLRMs that respect this rule are the ones that reach the ~230-second plateau.
Share X Bluesky LinkedIn Reddit HN

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, and a circularity audit.

Referee Report

4 major / 6 minor

Summary. The paper presents HE-LRM, a fully homomorphic encryption (FHE) based inference pipeline for Deep Learning Recommendation Models (DLRMs) that supports both dense and sparse features entirely under encryption. The main technical contributions are a client-side digit-decomposition scheme that compresses large embedding tables into smaller base-p tables, and a block-diagonal multi-embedding packing strategy that allows multiple embedding lookups to be performed in a single SIMD matrix-vector product. The approach is implemented in the open-source Orion FHE framework and evaluated on the UCI Heart Disease and Criteo datasets, reporting 24.22 seconds and roughly 228-489 seconds end-to-end CPU latencies. The paper also discusses extending the embedding-lookup primitives to LLM prefill and generation, arguing that all prior CKKS-based transformer inference works leak embedding tables by performing client-side lookups. The claimed headline result is a 56x speedup over the prior CodedHeLUT approach, enabled by reducing the embedding lookup to a single multiplicative level and avoiding encrypted indicator functions and bootstraps.

Significance. If the results hold, HE-LRM is a meaningful step toward practical private DLRM inference: it is, to my knowledge, the first end-to-end FHE DLRM implementation that keeps embedding tables server-side and performs the entire lookup under encryption, and the reported latencies on standard CPU hardware are substantially better than prior encrypted-lookup baselines. The paper offers a clean, reproducible system contribution: the code is open-sourced, the benchmark numbers are averaged over three runs, and the comparison against CodedHeLUT includes a detailed per-operation breakdown (Table 1) that helps the reader understand where the speedup comes from. The block-diagonal packing observation is also useful beyond DLRMs, and the discussion of LLM embedding costs identifies a real gap in prior FHE-transformer works. However, the significance is tempered by two omissions: no test AUC or plaintext accuracy baseline is reported for the compressed models, and the FHE parameter set is not specified. Both omissions are directly relevant to whether the reported latencies describe a usable deployment-quality model.

major comments (4)
  1. [§6.2 and Table 2] The central practical claim that aggressively compressed DLRMs remain accurate is not supported by any reported test AUC or plaintext baseline. Section 6.2 states only that "more compressed models exhibit slightly higher loss" and that "SiLU models consistently show lower test AUC," and Figure 9 shows training curves, not test AUC values. Table 2 reports compression ratios up to 31180x, but no accuracy is attached to any row. Please report test AUC (and ideally a confidence interval) for each compression threshold in Table 2, for both the ReLU and SiLU variants, together with the AUC of an uncompressed baseline DLRM. Without these numbers, the 56x speedup and the end-to-end latencies in Figure 10 may be achieved on models whose accuracy is below the threshold required for practical deployment.
  2. [§6.1 and §6.3] The FHE parameter set is not specified beyond the statement "we choose an FHE parameter set that enables bootstrapping while maintaining 128-bit security." The latency, level budget, and bootstrap count reported in Section 6.3 and Table 1 all depend on the ring degree N, the chain of coefficient moduli, the scaling factor, and the number of levels reserved for bootstrapping. Please report the concrete parameters (e.g., N, modulus bit lengths, scaling factor, and the estimated security level) used for each reported latency. Without this, the results are not reproducible and the comparison in Table 1 cannot be checked.
  3. [Abstract, §5.1, and Figure 6] The 56x speedup is attributed in the abstract to "client-side digit decomposition," but the comparison in Figure 6 and Table 1 bundles at least two distinct optimizations: eliminating the encrypted indicator function through client-side one-hot encoding, and replacing CodedHeLUT's TableMult with a double-hoisted BSGS linear transformation. The text acknowledges the BSGS substitution, but the headline claim would be clearer if the speedup were decomposed, e.g., by reporting CodedHeLUT with and without the BSGS substitution. This matters because a reader may otherwise credit the entire 56x to the digit-decomposition compression scheme alone.
  4. [§6.4 and Figure 11] The GPU and ASIC latency projections are presented in the abstract and conclusion as concrete outcomes ("can reduce end-to-end latencies to seconds and even sub-seconds"), but they are obtained by feeding Orion's static trace into Cheddar's primitive-level GPU microbenchmarks and Osiris's ASIC cost model, not by running the end-to-end HE-LRM pipeline on those backends. Please state explicitly in Section 6.4 that these are model-based projections, not measured end-to-end results, and report the key assumptions of the Osiris cost model (e.g., array dimensions, clock frequency, memory bandwidth) that drive the sub-second ASIC estimate.
minor comments (6)
  1. [Abstract and §6.3] The abstract reports Criteo latencies of "228 to 489 seconds," and Section 6.3 discusses models around 230 seconds for the highly compressed configurations, while the conclusion says "489 seconds." Please clarify which configuration produces the 489-second number and which produces the 228-second number, so the range is unambiguous.
  2. [Figure 9] The caption of Figure 9 reads "Uncompressed (33M rows)" repeated three times; this looks like a placeholder and should be replaced with the actual compression-ratio labels for each curve.
  3. [§6.3] The UCI model is said to use the "x2 activation function rather than ReLU," but x2 is not defined or motivated in the text; please explain what this activation is and how it was chosen.
  4. [§6.2] The text says the digit-decomposition strategy is implemented with base p=4 for Criteo, but it does not say how p or the embedding-table threshold are chosen per configuration, nor whether the UCI experiments use the same p. Please specify the exact p and threshold for each row of Table 2.
  5. [§5.1] The claim that the client "knows the size of the compressed embedding tables, which is encompassed by our threat model" deserves a sentence clarifying why revealing table dimensions and the base p does not leak information about the learned embeddings themselves; this would preempt a natural security question from readers.
  6. [Table 1] The comparison in Table 1 is helpful, but it should state whether the CodedHeLUT timings are taken from the original paper or reimplemented in the authors' framework, and, if reimplemented, how the reimplementation was validated against the original results.

Circularity Check

0 steps flagged · score 1.0 of 10

No significant circularity: HE-LRM's central claims are measured benchmarks and comparisons against an external baseline, not derivations from fitted inputs or self-cited theorems.

full rationale

The paper's central claims are empirical and externally grounded. The 56x speedup is a measured comparison against CodedHeLUT, a prior published algorithm from a different group, reported as detailed component timings in Table 1 and Figure 6. The end-to-end latencies on UCI and Criteo are benchmark measurements on a single-threaded CPU, not quantities obtained by definition from the method's own construction. No parameter is fitted to reproduce a target latency or accuracy, so the fitted-input-called-prediction pattern does not apply. The digit-decomposition compression is explicitly presented as a generalization of the Quotient-Remainder method from Shi et al. [58], and the compressed embedding tables are trained end-to-end, so the method does not define its target in terms of the FHE pipeline. The paper does cite prior work by the same authors: Orion [22] is the integration framework, and Osiris [23] supplies the ASIC cost model for projected latencies. These are infrastructure and projection tools rather than load-bearing derivations of the measured results; the CPU measurements and the external CodedHeLUT comparison stand independently. The acknowledged absence of test AUC values and plaintext baselines in Section 6.2 is a real evaluation weakness, but it is an omission of evidence, not a circular step, and the paper does not claim accuracy follows from the FHE construction. The appended limitation in Section 7.4, where the authors state they do not train compressed LLM embeddings in this work and instead identify the problem and demonstrate tractability, further shows that the authors do not disguise assumptions as derived results. Overall, no circular step can be exhibited with a specific equation or fitted-parameter reduction, so the circularity score is low despite minor self-citation.

Assumptions & free parameters 3 free parameters · 4 assumptions · 0 invented entities

The core of the paper is an engineering optimization, so the ledger is short. The genuinely hand-chosen numbers (base p, compression thresholds, FHE parameters) are evaluation choices, not fitted predictions. The main unproven assumption is accuracy preservation, which is asserted qualitatively rather than demonstrated numerically.

free parameters (3)
  • base p for digit decomposition = 4 (Criteo)
    Section 6.2: 'we implement our digit decomposition strategy (with base p=4) in the CAFE framework for Criteo.' The choice affects compression ratio and one-hot input length; no sweep or justification is given.
  • compression thresholds = 500, 5000, 50000, 500000, 5000000 rows
    Table 2: thresholds determine which tables are compressed and the resulting compression ratio (31180x down to 12.18x). These are hand-chosen evaluation points, not fitted to data.
  • FHE parameter set = not specified
    Section 6.1: 'we choose an FHE parameter set that enables bootstrapping while maintaining 128-bit security' but no ring dimension, level budget, or scaling parameters are given; latencies depend on these.
assumptions (4)
  • domain assumption CKKS is IND-CPA secure under the RingLWE hardness assumption.
    Section 2.1; the privacy guarantee of the whole pipeline rests on this standard cryptographic assumption.
  • domain assumption The client is allowed to know the compressed embedding table dimensions (p, l per feature).
    Section 3 (threat model) states the client knows the input dimensionality; Section 5.1 notes the client must know the compressed table sizes to compute the digit decomposition. If model architecture is sensitive, this leaks structural information.
  • ad hoc to paper Digit-decomposed embeddings preserve DLRM accuracy.
    This is the paper's own design claim; supported only by unquantified training curves in Section 6.2 and no test AUC numbers.
  • standard math BSGS matrix-vector product is correct and implemented per Orion [22].
    Used in Section 5.2; correctness relies on the published Orion linear-transform algorithm.

how reviews work

0 comments
Cite this review

Pith. "Pith review of HE-LRM: Encrypted Deep Learning Recommendation Models using Fully Homomorphic Encryption." pith.science (2026). https://pith.science/paper/CJ7NXYKP

@misc{pith2026250618150,
  author       = {Pith},
  title        = {Pith review of: HE-LRM: Encrypted Deep Learning Recommendation Models using Fully Homomorphic Encryption},
  year         = {2026},
  howpublished = {\url{https://pith.science/paper/CJ7NXYKP}},
  note         = {Machine review of arXiv:2506.18150}
}
abstract

Fully Homomorphic Encryption (FHE) enables computation directly on encrypted data and privacy-preserving neural inference in the cloud. Existing solutions focus on models with dense inputs (e.g., CNNs and MLPs). Recommendation models (e.g., DLRM) pose a different challenge: sparse categorical inputs require private lookups into large embedding tables, which must be implemented using FHE's restrictive operators. Naive lookups incur significant communication and memory costs; prior work proposes compressing embedding tables at the expense of introducing large server-side compute costs (i.e., indicator function) and revealing embedding-table structure. We present HE-LRM, a performance optimized solution for executing recommendation with FHE. First, we develop an embedding compression technique using client-side digit decomposition that achieves 56$\times$ speedup over the state-of-the-art. Next, we propose a multi-embedding packing strategy that enables ciphertext SIMD-parallel lookups across multiple tables. We integrate HE-LRM into the open-source Orion FHE framework to demonstrate end-to-end encrypted DLRM inference. We evaluate HE-LRM on UCI (health prediction) and Criteo (click prediction), achieving inference latencies of 24 seconds on UCI and 228 to 489 seconds, respectively, on a single-threaded CPU. Finally, we show how GPU and ASIC FHE acceleration can reduce end-to-end latencies to seconds and even sub-seconds. Our code can be found at https://github.com/baahl-nyu/orion/tree/criteo-helrm.

Figures

Figures reproduced from arXiv: 2506.18150 by the authors.

Figure 1
Figure 1. Prior FHE inference protocols perform embedding [PITH_FULL_IMAGE:figures/full_fig_p001_1.png] view at source ↗
Figure 2
Figure 2. Architecture of a Deep Learning Recommendation [PITH_FULL_IMAGE:figures/full_fig_p002_2.png] view at source ↗
Figure 3
Figure 3. Latencies (single-threaded) of primitive homomor [PITH_FULL_IMAGE:figures/full_fig_p003_3.png] view at source ↗
Figures from the paper (11 more)
Figure 4
Figure 4. Figure 4: Embedding table sizes (number of rows) for each [PITH_FULL_IMAGE:figures/full_fig_p005_4.png]
Figure 5
Figure 5. Figure 5: Prior work [68] compressed embedding lookup with k rows and an embedding dimension of size d = 3. The client must store the coded token mapping of size k ×ℓ locally. Prior work performs this compressed lookup homomorphically by utilizing pℓ slots per ciphertext and per…
Figure 6
Figure 6. Figure 6: Comparison of encrypted embedding lookups using a fixed set of FHE parameters for different settings of [PITH_FULL_IMAGE:figures/full_fig_p007_6.png]
Figure 7
Figure 7. Figure 7: Client-side base-p digit decomposition maps the token “cat” (14) to coded tokens (2,3). case is to simply encrypt each compressed index separately and perform the methods discussed before. However, this method would require one CKKS ciphertext per embedding table and m…
Figure 8
Figure 8. Figure 8: Block-diagonal packing of embedding tables, which [PITH_FULL_IMAGE:figures/full_fig_p008_8.png]
Figure 9
Figure 9. Figure 9: Training curves and performance trade-offs for com [PITH_FULL_IMAGE:figures/full_fig_p009_9.png]
Figure 10
Figure 10. Figure 10: End-to-end (aggregate) FHE latency of a single [PITH_FULL_IMAGE:figures/full_fig_p009_10.png]
Figure 11
Figure 11. Figure 11: Projected GPU [14] and ASIC [23] for the SiLU￾based DLRMs. even GPU acceleration provides roughly 200× speedup over CPU, bringing previously impractical runtimes from minutes down to seconds. We examine these speedups across differ￾ent compression ratios to understand…
Figure 12
Figure 12. Figure 12: A state-of-the-art ciphertext-plaintext matrix [PITH_FULL_IMAGE:figures/full_fig_p011_12.png]
Figure 13
Figure 13. Figure 13: LLM Embedding latency using our block-diagonal [PITH_FULL_IMAGE:figures/full_fig_p012_13.png]
Figure 14
Figure 14. Figure 14: The HE-LRM architecture. Beginning from the [PITH_FULL_IMAGE:figures/full_fig_p015_14.png]
