Signal Temporal Logic Motion Planning via Graphs of Convex Sets

T0 review · 2 major / 3 minor · reviewed 2026-05-25 · grok-4.3

Challenge this review Re-run · record.json Download PDF Read on arXiv ↗ Review JSON

Pith's one-line read Coupling timed automata for STL specs with convex decompositions of configuration space turns motion planning into a shortest-path problem over graphs of convex sets that yields smooth Bézier trajectories.

desk verdict The paper turns STL specs into smooth Bézier trajectories by building a timed-automaton and GCS product and solving a shortest-path problem on it, with soundness and polynomial complexity once the automaton and decomposition are already fixed. read the letter →

arxiv 2605.23240 v1 pith:J6HGKJDV submitted 2026-05-22 cs.RO cs.SYeess.SY

Yu Chen , Ancheng Hou , Mingyang Feng , Xiao Yu , Xiang Yin This is my paper · ORCID
classification cs.ROcs.SYeess.SY
keywords signaltemporallogicmotionplanninggraphsofconvexsetstimedautomatabéziersplinesoptimizationrobottrajectories
verification ladder T0 review T1 audit T2 compute T3 formal

The pith

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The reading

The paper develops a planning method for continuous-time robot motions that must satisfy Signal Temporal Logic formulas while obeying smoothness and velocity limits. It converts the STL requirement into a timed automaton and merges it with a convex breakdown of the robot's workspace to create a joint transition system. This system is then modeled as a graph of convex sets whose shortest path encodes both task progress and geometric feasibility. Solving the resulting convex relaxation produces a Bézier spline trajectory that meets all constraints. The approach is shown to be sound and to scale polynomially with dimension once the automaton and decomposition are given.

What carries the argument

The joint transition system obtained by coupling a timed automaton for the STL specification with a convex decomposition of the configuration space, which is then encoded as a graph of convex sets whose shortest-path solution produces the desired Bézier spline.

What would settle it

A computed shortest-path solution in the GCS that produces a Bézier trajectory violating the original STL formula or the velocity bounds.

Watch

Extended reading notes

Core claim

An STL specification is represented by a timed automaton, which is coupled with a convex decomposition of the configuration space to form a joint transition system encoding both task progress and region occupancy. Based on this joint transition system, the STL motion-planning problem is reformulated as a shortest-path problem over a GCS, whose solution induces a smooth Bézier-spline trajectory satisfying the STL specification, smoothness requirements, and velocity bounds. The formulation is sound and the convex relaxation scales polynomially with the configuration-space dimension and the Bézier degree once the timed automaton and convex decomposition are fixed.

Load-bearing premise

The timed automaton correctly captures the STL specification and the convex decomposition accurately represents the configuration space and its connectivity.

Editorial extensions

If this is right

  • The induced Bézier trajectory satisfies the STL specification, required smoothness, and velocity bounds.
  • Once the automaton and decomposition are fixed, the convex relaxation scales polynomially with configuration-space dimension and Bézier degree.
  • A compact timed-automaton construction is available for an expressive STL fragment via dedicated templates and Boolean composition.
  • The method produces executable trajectories on benchmarks, a 3-D quadrotor, a 30-DoF humanoid, and a physical UR-3 arm.

Reading between the lines

Editorial extensions of the paper, not claims the author makes directly.

  • The same joint-system construction could be reused for other temporal logics that admit timed-automaton encodings.
  • If convex decompositions can be updated online, the polynomial scaling opens a route to receding-horizon STL planning.
  • The quality of the initial convex decomposition directly limits both feasibility and path optimality.
  • Hardware experiments indicate that the resulting splines are directly usable as low-level references without further smoothing.
Share X Bluesky LinkedIn Reddit HN

Signed reviews

No signed human review yet.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit.

Referee Report

2 major / 3 minor

Summary. The paper proposes combining timed automata for STL specifications with graphs of convex sets (GCS) derived from a convex decomposition of configuration space. The STL planning problem is recast as a shortest-path problem on the resulting GCS; its solution yields a smooth Bézier-spline trajectory satisfying the STL formula, velocity bounds, and smoothness requirements. Soundness of the formulation is claimed, and computational complexity is shown to be polynomial in configuration-space dimension and Bézier degree once the timed automaton and convex decomposition are fixed. A compact timed-automaton construction for an expressive STL fragment is also given, supported by numerical experiments on low-dimensional cases, a 3-D quadrotor, a 30-DoF humanoid, and a UR-3 hardware demonstration.

Significance. If the soundness result holds, the work supplies a scalable, convex-optimization-based route to continuous-time STL motion planning that produces executable smooth trajectories for high-DoF systems. The explicit conditioning on fixed automata and decompositions, together with the polynomial scaling claim for the GCS relaxation, distinguishes the contribution from prior discrete or sampling-based STL planners and could influence practical deployment in robotics tasks with temporal requirements.

major comments (2)
  1. [Abstract / complexity analysis] Abstract and § on complexity: the polynomial scaling statement is explicitly conditioned on the timed automaton and convex decomposition already being fixed; the manuscript should state the explicit dependence of GCS size (hence solve time) on the number of automaton states and regions so that the overall complexity claim is unambiguous.
  2. [Soundness section] The soundness argument rests on the product construction correctly lifting discrete transitions to continuous-time STL satisfaction via Bézier segments; the manuscript should supply the precise lemma showing that satisfaction of the timed-automaton acceptance condition plus region occupancy implies STL satisfaction over the entire continuous trajectory (including at segment boundaries).
minor comments (3)
  1. [Preliminaries / joint transition system] Notation for the joint transition system (states, transitions, labels) should be introduced with a single compact diagram or table early in the paper to aid readability.
  2. [Experiments] The hardware experiment on the UR-3 arm would benefit from a brief description of the low-level controller used to track the Bézier trajectory and any observed tracking error.
  3. [Method] Bézier degree appears as a tunable parameter; a short discussion of its effect on both feasibility and computational cost would strengthen the presentation.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the detailed and constructive report. The two major comments are addressed point-by-point below. Both can be resolved by targeted additions and clarifications that strengthen the presentation without altering the technical claims.

read point-by-point responses

  1. Referee: [Abstract / complexity analysis] Abstract and § on complexity: the polynomial scaling statement is explicitly conditioned on the timed automaton and convex decomposition already being fixed; the manuscript should state the explicit dependence of GCS size (hence solve time) on the number of automaton states and regions so that the overall complexity claim is unambiguous.

    Authors: We agree that an explicit statement of the dependence improves clarity. The GCS is constructed with one vertex per pair (automaton state, convex region), so its size is linear in |Q| × |R|. In the revision we will add this relation immediately after the existing conditioning sentence in both the abstract and the complexity section, making the overall scaling unambiguous while preserving the polynomial claim in dimension and degree once |Q| and |R| are fixed. revision: yes

  2. Referee: [Soundness section] The soundness argument rests on the product construction correctly lifting discrete transitions to continuous-time STL satisfaction via Bézier segments; the manuscript should supply the precise lemma showing that satisfaction of the timed-automaton acceptance condition plus region occupancy implies STL satisfaction over the entire continuous trajectory (including at segment boundaries).

    Authors: The current soundness argument sketches the lifting via the product construction and Bézier interpolation, but does not isolate the required implication as a standalone lemma. We will insert a concise lemma (with a short proof) that states: if a trajectory satisfies the timed-automaton acceptance condition and each Bézier segment lies entirely inside its assigned convex region, then the continuous-time signal satisfies the original STL formula at every time, including segment boundaries. This addition will be placed in the soundness subsection. revision: yes

Circularity Check

0 steps flagged · score 0.0 of 10

Derivation is self-contained with no circular reductions

full rationale

The paper conditions its polynomial scaling result on the timed automaton and convex decomposition already being fixed, then reformulates the planning problem as a GCS shortest-path instance whose solution induces a Bézier trajectory. Soundness follows from the standard product construction between the automaton and the decomposition. No equations or claims reduce by construction to fitted parameters, self-definitions, or load-bearing self-citations; the central claims remain independent of the paper's own inputs once the precondition is granted. This is the normal case of a compositional method built on prior automata and optimization primitives.

Assumptions & free parameters 1 free parameters · 2 assumptions · 0 invented entities

The approach rests on domain assumptions from automata theory and convex geometry without new free parameters or invented entities beyond standard choices such as Bézier degree.

free parameters (1)
  • Bézier degree
    Chosen as input to the polynomial scaling analysis; not fitted to data but affects trajectory smoothness.
assumptions (2)
  • domain assumption The configuration space admits a fixed convex decomposition.
    Invoked to form the joint transition system and enable polynomial scaling once fixed.
  • domain assumption The timed automaton faithfully encodes the STL specification.
    Central to coupling task progress with region occupancy in the transition system.

how reviews work

0 comments
Cite this review

Pith. "Pith review of Signal Temporal Logic Motion Planning via Graphs of Convex Sets." pith.science (2026). https://pith.science/paper/J6HGKJDV

@misc{pith2026260523240,
  author       = {Pith},
  title        = {Pith review of: Signal Temporal Logic Motion Planning via Graphs of Convex Sets},
  year         = {2026},
  howpublished = {\url{https://pith.science/paper/J6HGKJDV}},
  note         = {Machine review of arXiv:2605.23240}
}
abstract

This paper investigates continuous-time motion planning under Signal Temporal Logic (STL) specifications. The goal is to generate smooth robot trajectories that satisfy high-level logical and timing requirements while respecting low-level motion constraints. To this end, we propose an efficient framework that combines timed-automata reasoning with graphs of convex sets (GCS). An STL specification is first represented by a timed automaton, which is then coupled with a convex decomposition of the configuration space to form a joint transition system encoding both task progress and region occupancy. Based on this joint transition system, the STL motion-planning problem is reformulated as a shortest-path problem over a GCS, whose solution induces a smooth B\'ezier-spline trajectory satisfying the STL specification, smoothness requirements, and velocity bounds. We establish the soundness of the proposed formulation and analyze its computational complexity, showing that, once the timed automaton and convex decomposition are fixed, the convex relaxation scales polynomially with the configuration-space dimension and the B\'ezier degree. We further develop a compact timed-automaton construction for an expressive STL fragment using dedicated templates and Boolean composition. Numerical experiments on low-dimensional benchmarks, a $3$-D quadrotor, a $30$-DoF humanoid, and a hardware experiment on a UR-3 robot arm demonstrate that the proposed method efficiently solves complex STL motion-planning problems and produces smooth executable trajectories.

Figures

Figures reproduced from arXiv: 2605.23240 by the authors.

Figure 1
Figure 1. Timed automata for φ1U[a,b]φ2 and G[a,b]φ. Dashed states are accepting states. Here R1 = Rφ1 , R2 = Rφ1∧φ2 . (a) Case of F[a,b]G[c,d]φ. (b) Case of G[a,b]F[c,d]φ [PITH_FULL_IMAGE:figures/full_fig_p011_1.png] view at source ↗
Figure 2
Figure 2. Timed automata for F[a,b]G[c,d]φ and G[a,b]F[c,d]φ. Dashed states are accepting states. Here R1 = Rφ, R2 = R¬φ The intuition behind these templates is as follows. For F[a,b]φ, the automaton enters a φ-enforcing state at some time within [a, b]. For G[a,b]φ, the automaton enters the φ￾enforcing state no later than a and leaves it no earlier than b. For φ1U[a,b]φ2, the state s0 enforces φ1 until a switching time in [a… view at source ↗
Figure 3
Figure 3. Benchmarks and computed trajectories of each method for a [PITH_FULL_IMAGE:figures/full_fig_p014_3.png] view at source ↗
Figures from the paper (4 more)
Figure 4
Figure 4. Figure 4: Results for the 3-D quadrotor experiment. motion planning. The first baseline is the piecewise-linear (PWL) method in [25], which computes a piecewise-linear path satisfying the STL task and assumes the availability of a tracking controller for execution. The second ba…
Figure 5
Figure 5. Figure 5: Visualization of the humanoid STL task. The left panel shows the annotated target regions, and the right panel shows [PITH_FULL_IMAGE:figures/full_fig_p016_5.png]
Figure 6
Figure 6. Figure 6: Visualization of the hardware experiment under the STL task. The left panel shows the hardware setup, where the green [PITH_FULL_IMAGE:figures/full_fig_p017_6.png]
Figure 7
Figure 7. Figure 7: The TA for Φˆ a run ρ1 of A1. Indeed, right transitions do not change the first component and, because C1 ∩ C2 = ∅, they do not reset any clock in C1. Therefore, the clock valuations and guards along the remaining left transitions are exactly those of a valid run of A1…
