Personalized Spiking Neural Networks with Ferroelectric Synapses for EEG Signal Processing
Pith reviewed 2026-05-16 20:58 UTC · model grok-4.3
The pith
Spiking neural networks on ferroelectric synapses match software accuracy for adaptive EEG motor imagery decoding under device constraints.
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
Core claim
Convolutional-recurrent spiking neural networks can be deployed on ferroelectric memristive synaptic devices for adaptive EEG-based motor imagery decoding under realistic device constraints, achieving classification performance comparable to software-based SNNs. The devices are fabricated, characterized, and modeled for their weight-update dynamics; a mixed-precision strategy accumulates gradients digitally and applies them only when a threshold is exceeded while accounting for nonlinear, state-dependent programming; subject-specific transfer learning is obtained by retraining only the final layers after software pre-training.
What carries the argument
Ferroelectric memristive synapses with a characterized nonlinear, state-dependent programming model, driven by a mixed-precision scheme that accumulates updates digitally before issuing discrete programming events.
If this is right
- Mixed-precision digital accumulation reduces programming events and thereby eases endurance and energy limits during on-device learning.
- Transfer of pre-trained weights followed by low-overhead retraining of only the final layers raises subject-specific classification accuracy.
- Programmable ferroelectric hardware supports robust, low-overhead adaptation inside spiking networks for neural-signal processing.
- The combination opens a route to personalized neuromorphic processing that handles non-stationary signals directly on resource-constrained platforms.
Where Pith is reading between the lines
- The same device-aware mixed-precision approach could be tested on other memristive technologies once they receive comparable characterization.
- Extending the adaptation window across multiple sessions would test whether long-term personalization remains stable beyond single-session results.
- Wearable BCIs could reduce wireless data transmission if on-chip retraining of final layers proves sufficient for daily recalibration.
- A concrete next measurement would track accuracy versus cumulative programming cycles to quantify the endurance margin left by the thresholded update rule.
Load-bearing premise
The fabricated ferroelectric synapses behave according to the characterized model during on-device updates, and the mixed-precision and transfer-learning strategies maintain performance without excessive degradation from device variability or endurance limits.
What would settle it
Direct measurements showing that on-device SNN accuracy after adaptation falls substantially below the matched software SNN baseline on the same EEG dataset, or device update behavior that deviates from the model and prevents convergence.
Figures
read the original abstract
Electroencephalography (EEG)-based brain-computer interfaces (BCIs) are strongly affected by non-stationary neural signals that vary across sessions and individuals, limiting the generalization of subject-agnostic models and motivating adaptive and personalized learning on resource-constrained platforms. Programmable memristive hardware offers a promising substrate for such post-deployment adaptation; however, practical realization is challenged by limited weight resolution, device variability, nonlinear programming dynamics, and finite device endurance. In this work, we show that spiking neural networks (SNNs) can be deployed on ferroelectric memristive synaptic devices for adaptive EEG-based motor imagery decoding under realistic device constraints, achieving classification performance comparable to software-based SNNs. We fabricate, characterize, and model the weight update in ferroelectric synapses. We then evaluate the deployment of convolutional-recurrent SNN architecture using two strategies. First, we adapt to SNNs a mixed precision strategy in which gradient-based updates are accumulated digitally and converted into discrete programming events only when a threshold is exceeded. Additionally, the weight update is device-aware and accounts for the nonlinear, state-dependent programming dynamics. During learning and adaptation, this scheme mitigates possible endurance and energy constraints. Second, we evaluate the transfer of software-trained weights followed by low-overhead on-device re-tuning. We show that, subject-specific transfer learning achieved by retraining only the final network layers improves classification accuracy. These results demonstrate that programmable ferroelectric hardware can support robust, low-overhead adaptation in spiking neural networks, opening a practical path toward personalized neuromorphic processing of neural signals.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The paper claims that spiking neural networks can be deployed on fabricated ferroelectric memristive synaptic devices for adaptive, personalized EEG-based motor imagery decoding. It fabricates and characterizes the devices, models their nonlinear state-dependent weight updates, and evaluates a convolutional-recurrent SNN using two strategies: a mixed-precision approach with digital accumulation of gradients followed by threshold-triggered, device-aware programming events, and software pre-training followed by low-overhead on-device transfer learning that retrains only the final layers. The central result is that these approaches achieve classification performance comparable to software-based SNNs while respecting realistic device constraints on resolution, variability, nonlinearity, and endurance.
Significance. If the quantitative results hold, the work would be significant for neuromorphic hardware in BCIs by showing a concrete path to post-deployment personalization on ferroelectric synapses, which offer potential advantages in energy efficiency and analog-like weight storage. The explicit integration of fabrication, device-aware modeling, mixed-precision mitigation, and layer-specific transfer learning provides a practical template for handling non-stationary EEG signals on resource-constrained platforms; the emphasis on endurance-aware updates is a particular strength that could inform similar hardware deployments.
major comments (2)
- [Device fabrication, characterization, and on-device adaptation sections] The central claim of comparable performance rests on the assumption that the fabricated ferroelectric synapses follow the characterized model during on-device mixed-precision updates and final-layer re-tuning. The manuscript must supply explicit quantitative bounds (e.g., measured vs. modeled cycle-to-cycle variability, asymmetry in potentiation/depression, and endurance degradation after the reported number of programming events) in the device characterization and on-device evaluation sections; without these, the mitigation strategies cannot be verified to prevent performance loss.
- [Abstract and Results/Evaluation sections] The abstract and evaluation sections assert classification performance comparable to software SNNs, yet no specific accuracy numbers, error bars, baseline comparisons (e.g., standard ANN or floating-point SNN), or statistical tests are referenced in the provided description. The full manuscript must include tables or figures with these metrics for both the mixed-precision and transfer-learning cases to make the claim load-bearing.
minor comments (2)
- [Mixed-precision update description] Clarify the exact threshold value and conversion rule from accumulated digital gradients to discrete programming pulses in the mixed-precision strategy; the current description leaves the mapping ambiguous.
- [EEG dataset and personalization section] Add a brief discussion of how subject-specific EEG variability was quantified across sessions to justify the transfer-learning approach.
Simulated Author's Rebuttal
We thank the referee for the constructive comments on our manuscript. We address each major point below and have revised the manuscript to incorporate the requested clarifications and quantitative details.
read point-by-point responses
-
Referee: [Device fabrication, characterization, and on-device adaptation sections] The central claim of comparable performance rests on the assumption that the fabricated ferroelectric synapses follow the characterized model during on-device mixed-precision updates and final-layer re-tuning. The manuscript must supply explicit quantitative bounds (e.g., measured vs. modeled cycle-to-cycle variability, asymmetry in potentiation/depression, and endurance degradation after the reported number of programming events) in the device characterization and on-device evaluation sections; without these, the mitigation strategies cannot be verified to prevent performance loss.
Authors: We thank the referee for this important observation. Section 3 of the manuscript reports measured cycle-to-cycle variability (standard deviation of conductance updates), asymmetry (separate potentiation and depression fitting parameters), and endurance (degradation after 10^4 events). To make the comparison with the model explicit, we have added Table 1 in the revised version that tabulates measured statistics (e.g., variability bounds, asymmetry ratios, and endurance drift) directly against the model parameters used for the mixed-precision and transfer-learning simulations. Error bars reflecting these bounds have also been added to the on-device results in Section 5. These revisions allow direct verification that the mitigation strategies account for the observed non-idealities. revision: yes
-
Referee: [Abstract and Results/Evaluation sections] The abstract and evaluation sections assert classification performance comparable to software SNNs, yet no specific accuracy numbers, error bars, baseline comparisons (e.g., standard ANN or floating-point SNN), or statistical tests are referenced in the provided description. The full manuscript must include tables or figures with these metrics for both the mixed-precision and transfer-learning cases to make the claim load-bearing.
Authors: We agree that explicit metrics strengthen the claims. The evaluation section already contains Figure 6 and Table 3 reporting subject-averaged accuracies with standard deviations for both strategies (mixed-precision and transfer learning), along with comparisons to software SNN and ANN baselines. In the revised manuscript we have added explicit references to these values in the abstract and included paired t-test p-values (p < 0.05) confirming comparability. These additions ensure the performance claims are fully supported by the presented data. revision: yes
Circularity Check
No significant circularity detected
full rationale
The paper's claims rest on fabrication, characterization, and modeling of ferroelectric synapses followed by empirical deployment and evaluation of convolutional-recurrent SNNs using mixed-precision thresholded updates and subject-specific transfer learning. These are independent experimental steps benchmarked against software SNN baselines and device constraints; no equations, fitted parameters, or self-citations reduce any central performance result to its own inputs by construction. The derivation chain is self-contained against external hardware measurements and classification accuracy metrics.
Axiom & Free-Parameter Ledger
axioms (1)
- domain assumption Ferroelectric synapses exhibit nonlinear, state-dependent programming dynamics that can be modeled and accounted for in updates
Reference graph
Works this paper leans on
-
[1]
Application of BCI systems in neurorehabilitation: a scoping review
Mahdi Bamdad, Homayoon Zarshenas, and Mohammad A Auais. “Application of BCI systems in neurorehabilitation: a scoping review”. In:Disability and Rehabilitation: Assistive Technology10.5 (2015), pp. 355–364
work page 2015
-
[2]
Summary of over fifty years with brain-computer interfaces—a review
Aleksandra Kawala-Sterniuk, Natalia Browarska, Amir Al-Bakri, Mariusz Pelc, Jaroslaw Zygarlicki, Michaela Sidikova, Radek Martinek, and Edward Jacek Gorzelanczyk. “Summary of over fifty years with brain-computer interfaces—a review”. In:Brain sciences11.1 (2021), p. 43
work page 2021
-
[3]
Wheelchair automation by a hybrid BCI system using SSVEP and eye blinks
Lizy Kanungo, Nikhil Garg, Anish Bhobe, Smit Rajguru, and Veeky Baths. “Wheelchair automation by a hybrid BCI system using SSVEP and eye blinks”. In:2021 IEEE International Conference on Systems, Man, and Cybernetics (SMC). IEEE. 2021, pp. 411–416
work page 2021
-
[4]
Flexible sensing electronics for wearable/attachable health monitoring
Xuewen Wang, Zheng Liu, and Ting Zhang. “Flexible sensing electronics for wearable/attachable health monitoring”. In:Small13.25 (2017), p. 1602790
work page 2017
-
[5]
Edge computing: Vision and challenges
Weisong Shi, Jie Cao, Quan Zhang, Youhuizi Li, and Lanyu Xu. “Edge computing: Vision and challenges”. In:IEEE internet of things journal3.5 (2016), pp. 637–646
work page 2016
-
[6]
Edge computing in healthcare: Innovations, opportunities, and challenges
Alexandru Rancea, Ionut Anghel, and Tudor Cioara. “Edge computing in healthcare: Innovations, opportunities, and challenges”. In:Future internet16.9 (2024), p. 329
work page 2024
-
[7]
Com- pute at the Edge: Mechanical and Thermal Design Considerations
Joseph Hanson V´ azquez, Stephen Langanke, Erich Ewy, Keith Swesey, and Jared Shipman. “Com- pute at the Edge: Mechanical and Thermal Design Considerations”. In:2021 20th IEEE Intersociety Conference on Thermal and Thermomechanical Phenomena in Electronic Systems (iTherm). IEEE. 2021, pp. 448–453
work page 2021
-
[8]
Event-based sensing and signal pro- cessing in the visual, auditory, and olfactory domain: A review
Mohammad-Hassan Tayarani-Najaran and Michael Schmuker. “Event-based sensing and signal pro- cessing in the visual, auditory, and olfactory domain: A review”. In:Frontiers in Neural Circuits 15 (2021), p. 610446
work page 2021
-
[9]
Signals to Spikes for Neuromorphic Regulated Reservoir Computing and EMG Hand Gesture Recognition
Nikhil Garg, Ismael Balafrej, Yann Beilliard, Dominique Drouin, Fabien Alibart, and Jean Rouat. “Signals to Spikes for Neuromorphic Regulated Reservoir Computing and EMG Hand Gesture Recognition”. In:International Conference on Neuromorphic Systems 2021. 2021, pp. 1–8
work page 2021
-
[10]
Networks of spiking neurons: the third generation of neural network models
Wolfgang Maass. “Networks of spiking neurons: the third generation of neural network models”. In:Neural networks10.9 (1997), pp. 1659–1671
work page 1997
-
[11]
1.1 computing’s energy problem (and what we can do about it)
Mark Horowitz. “1.1 computing’s energy problem (and what we can do about it)”. In:2014 IEEE international solid-state circuits conference digest of technical papers (ISSCC). IEEE. 2014, pp. 10– 14
work page 2014
-
[12]
How we created neuromorphic engineering
Carver Mead. “How we created neuromorphic engineering”. In:Nature Electronics3.7 (2020), pp. 434–435. 13
work page 2020
-
[13]
Neuromorphic computing using non-volatile memory
Geoffrey W Burr, Robert M Shelby, Abu Sebastian, Sangbum Kim, Seyoung Kim, Severin Sidler, Kumar Virwani, Masatoshi Ishii, Pritish Narayanan, Alessandro Fumarola, et al. “Neuromorphic computing using non-volatile memory”. In:Advances in Physics: X2.1 (2017), pp. 89–124
work page 2017
-
[14]
Memory devices and applications for in-memory computing
Abu Sebastian, Manuel Le Gallo, Riduan Khaddam-Aljameh, and Evangelos Eleftheriou. “Memory devices and applications for in-memory computing”. In:Nature nanotechnology15.7 (2020), pp. 529– 544
work page 2020
-
[15]
The end of moore’s law: A new beginning for information technology
Thomas N Theis and H-S Philip Wong. “The end of moore’s law: A new beginning for information technology”. In:Computing in science & engineering19.2 (2017), pp. 41–50
work page 2017
-
[16]
Roadmap to neuromorphic computing with emerging technologies
Adnan Mehonic, Daniele Ielmini, Kaushik Roy, Onur Mutlu, Shahar Kvatinsky, Teresa Serrano- Gotarredona, Bernabe Linares-Barranco, Sabina Spiga, Sergey Savel’ev, Alexander G Balanov, et al. “Roadmap to neuromorphic computing with emerging technologies”. In:APL Materials12.10 (2024)
work page 2024
-
[17]
Challenges and perspectives for energy-efficient brain-inspired edge com- puting applications
Erika Covi, Suzanne Lancaster, Stefan Slesazeck, Veeresh Deshpande, Thomas Mikolajick, and Catherine Dubourdieu. “Challenges and perspectives for energy-efficient brain-inspired edge com- puting applications”. In:2022 IEEE International Conference on Flexible and Printable Sensors and Systems (FLEPS). IEEE. 2022, pp. 1–4
work page 2022
-
[18]
Versatile titanium carbide MXene thin-film memristors with adaptive learning behavior
Athulya Thomas, Puranjay Saha, Muhammed Sahad E, Navaneeth Krishnan K, and Bikas C Das. “Versatile titanium carbide MXene thin-film memristors with adaptive learning behavior”. In:ACS Applied Materials & Interfaces16.16 (2024), pp. 20693–20704
work page 2024
-
[19]
A compact online- learning spiking neuromorphic biosignal processor
Chaoming Fang, Ziyang Shen, Fengshi Tian, Jie Yang, and Mohamad Sawan. “A compact online- learning spiking neuromorphic biosignal processor”. In:2022 IEEE International Symposium on Circuits and Systems (ISCAS). IEEE. 2022, pp. 2147–2151
work page 2022
-
[20]
Thousands of conductance levels in memristors integrated on CMOS
Mingyi Rao, Hao Tang, Jiangbin Wu, Wenhao Song, Max Zhang, Wenbo Yin, Ye Zhuo, Fate- meh Kiani, Benjamin Chen, Xiangqi Jiang, et al. “Thousands of conductance levels in memristors integrated on CMOS”. In:Nature615.7954 (2023), pp. 823–829
work page 2023
-
[21]
Laura B´ egon-Lours, Mattia Halter, Francesco Maria Puglisi, Lorenzo Benatti, Donato Francesco Falcone, Youri Popoff, Diana D´ avila Pineda, Marilyne Sousa, and Bert Jan Offrein. “Scaled, Ferro- electric Memristive Synapse for Back-End-of-Line Integration with Neuromorphic Hardware”. In: Advanced Electronic Materials(), p. 2101395
-
[22]
Back-End-of-Line Integration of Synaptic Weights using HfO2/ZrO2 Nanolaminates
Laura B´ egon-Lours, Stefan Slesazeck, Donato Francesco Falcone, Viktor Havel, Ruben Hamming- Green, Marina Martinez Fernandez, Elisabetta Morabito, Thomas Mikolajick, and Bert Jan Of- frein. “Back-End-of-Line Integration of Synaptic Weights using HfO2/ZrO2 Nanolaminates”. In: Advanced Electronic Materials10.5 (2024), p. 2300649
work page 2024
-
[23]
Nikhil Garg, Ismael Balafrej, Joao Henrique Quintino Palhares, Laura B´ egon-Lours, Davide Florini, Donato Francesco Falcone, Tommaso Stecconi, Valeria Bragaglia, Bert Jan Offrein, Jean-Michel Portal, et al. “Unsupervised local learning based on voltage-dependent synaptic plasticity for resis- tive and ferroelectric synapses”. In:arXiv preprint arXiv:2510...
-
[24]
Pattern classification by memristive crossbar circuits using ex situ and in situ training
Fabien Alibart, Elham Zamanidoost, and Dmitri B Strukov. “Pattern classification by memristive crossbar circuits using ex situ and in situ training”. In:Nature communications4.1 (2013), p. 2072
work page 2013
-
[25]
Personalizing EEG-based affective models with transfer learn- ing
Wei-Long Zheng and Bao-Liang Lu. “Personalizing EEG-based affective models with transfer learn- ing”. In:Proceedings of the twenty-fifth international joint conference on artificial intelligence. 2016, pp. 2732–2738
work page 2016
-
[26]
Decoding eeg with spiking neural networks on neuromorphic hardware
Neelesh Kumar, Guangzhi Tang, Raymond Yoo, and Konstantinos P Michmizos. “Decoding eeg with spiking neural networks on neuromorphic hardware”. In:Transactions on Machine Learning Research(2022)
work page 2022
-
[27]
Ary L Goldberger, Luis AN Amaral, Leon Glass, Jeffrey M Hausdorff, Plamen Ch Ivanov, Roger G Mark, Joseph E Mietus, George B Moody, Chung-Kang Peng, and H Eugene Stanley. “PhysioBank, PhysioToolkit, and PhysioNet: components of a new research resource for complex physiologic signals”. In:circulation101.23 (2000), e215–e220
work page 2000
-
[28]
BCI2000: a general-purpose brain-computer interface (BCI) system
Gerwin Schalk, Dennis J McFarland, Thilo Hinterberger, Niels Birbaumer, and Jonathan R Wolpaw. “BCI2000: a general-purpose brain-computer interface (BCI) system”. In:IEEE Transactions on biomedical engineering51.6 (2004), pp. 1034–1043. 14
work page 2004
-
[29]
Delving deep into rectifiers: Surpassing human-level performance on imagenet classification
Kaiming He, Xiangyu Zhang, Shaoqing Ren, and Jian Sun. “Delving deep into rectifiers: Surpassing human-level performance on imagenet classification”. In:Proceedings of the IEEE international conference on computer vision. 2015, pp. 1026–1034
work page 2015
-
[30]
Differential Phase Change Memory (PCM) Cell for Drift-Compensated In-Memory Computing
L Pistolesi, L Ravelli, A Glukhov, A de Gracia Herranz, M Lopez-Vallejo, M Carissimi, M Pasotti, PL Rolandi, A Redaelli, I Mu˜ noz Mart´ ın, et al. “Differential Phase Change Memory (PCM) Cell for Drift-Compensated In-Memory Computing”. In:IEEE Transactions on Electron Devices(2024)
work page 2024
-
[31]
Mixed-precision deep learning based on computational memory
SR Nandakumar, Manuel Le Gallo, Christophe Piveteau, Vinay Joshi, Giovanni Mariani, Irem Boybat, Geethan Karunaratne, Riduan Khaddam-Aljameh, Urs Egger, Anastasios Petropoulos, et al. “Mixed-precision deep learning based on computational memory”. In:Frontiers in neuroscience 14 (2020), p. 406
work page 2020
-
[32]
Ziqi Meng, Weikang Qian, Yilong Zhao, Yanan Sun, Rui Yang, and Li Jiang. “Digital offset for rram-based neuromorphic computing: A novel solution to conquer cycle-to-cycle variation”. In:2021 Design, Automation & Test in Europe Conference & Exhibition (DATE). IEEE. 2021, pp. 1078– 1083
work page 2021
-
[33]
In situ stochastic training of mtj crossbars with machine learning algorithms
Ankit Mondal and Ankur Srivastava. “In situ stochastic training of mtj crossbars with machine learning algorithms”. In:ACM Journal on Emerging Technologies in Computing Systems (JETC) 15.2 (2019), pp. 1–29
work page 2019
-
[34]
Mask tech- nique for fast and efficient training of binary resistive crossbar arrays
Mohammed E Fouda, Sugil Lee, Jongeun Lee, Ahmed Eltawil, and Fadi Kurdahi. “Mask tech- nique for fast and efficient training of binary resistive crossbar arrays”. In:IEEE Transactions on Nanotechnology18 (2019), pp. 704–716
work page 2019
-
[35]
Energy-convergence trade off for the training of neural networks on bio-inspired hardware
Nikhil Garg, Paul Uriarte Vicandi, Yanming Zhang, Alexandre Baigol, Donato Francesco Falcone, Saketh Ram Mamidala, Bert Jan Offrein, and Laura B ˜AˇSgon-Lours. “Energy-convergence trade off for the training of neural networks on bio-inspired hardware”. In:arXiv preprint arXiv:2509.18121 (2025)
-
[36]
An end-to-end deep learning approach to MI-EEG signal classification for BCIs
Hauke Dose, Jakob S Møller, Helle K Iversen, and Sadasivan Puthusserypady. “An end-to-end deep learning approach to MI-EEG signal classification for BCIs”. In:Expert Systems with Applications 114 (2018), pp. 532–542
work page 2018
-
[37]
An accurate eegnet-based motor-imagery brain–computer interface for low-power edge comput- ing
Xiaying Wang, Michael Hersche, Batuhan T¨ omekce, Burak Kaya, Michele Magno, and Luca Benini. “An accurate eegnet-based motor-imagery brain–computer interface for low-power edge comput- ing”. In:2020 IEEE international symposium on medical measurements and applications (MeMeA). IEEE. 2020, pp. 1–6
work page 2020
-
[38]
How transferable are features in deep neural networks?
Jason Yosinski, Jeff Clune, Yoshua Bengio, and Hod Lipson. “How transferable are features in deep neural networks?” In:Advances in neural information processing systems27 (2014)
work page 2014
-
[39]
Zhizhong Li and Derek Hoiem. “Learning without forgetting”. In:IEEE transactions on pattern analysis and machine intelligence40.12 (2017), pp. 2935–2947
work page 2017
-
[40]
Robustness to noisy synaptic weights in spiking neural networks
Chen Li, Runze Chen, Christoforos Moutafis, and Steve Furber. “Robustness to noisy synaptic weights in spiking neural networks”. In:2020 International Joint Conference on Neural Networks (IJCNN). IEEE. 2020, pp. 1–8
work page 2020
-
[41]
Bodo Rueckauer, Iulia-Alexandra Lungu, Yuhuang Hu, Michael Pfeiffer, and Shih-Chii Liu. “Con- version of continuous-valued deep networks to efficient event-driven networks for image classifica- tion”. In:Frontiers in neuroscience11 (2017), p. 682
work page 2017
-
[42]
Are conventional snns really efficient? a perspective from network quantization
Guobin Shen, Dongcheng Zhao, Tenglong Li, Jindong Li, and Yi Zeng. “Are conventional snns really efficient? a perspective from network quantization”. In:Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition. 2024, pp. 27538–27547
work page 2024
-
[43]
Evangelos Stromatias, Daniel Neil, Michael Pfeiffer, Francesco Galluppi, Steve B Furber, and Shih- Chii Liu. “Robustness of spiking deep belief networks to noise and reduced bit precision of neuro- inspired hardware platforms”. In:Frontiers in neuroscience9 (2015), p. 222. 15
work page 2015
