Percolation Critical Probability of Aperiodic Smith Hat tile(1, $\sqrt3$)

Aaryash Bharadwaj; Haitao Gao

arxiv: 2604.21165 · v1 · submitted 2026-04-23 · ❄️ cond-mat.stat-mech · physics.data-an

Percolation Critical Probability of Aperiodic Smith Hat tile(1, sqrt3)

Haitao Gao , Aaryash Bharadwaj This is my paper

Pith reviewed 2026-05-08 13:56 UTC · model grok-4.3

classification ❄️ cond-mat.stat-mech physics.data-an

keywords Smith hat tilingaperiodic monotilepercolation critical probabilityMonte Carlo simulationsite percolationbond percolationdual graphfinite-size scaling

0 comments

The pith

Monte Carlo simulations on finite patches yield percolation thresholds of 0.8227 for site, 0.7982 for bond, and 0.5442 for dual-site on the Smith hat aperiodic tiling.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper applies Monte Carlo methods to estimate critical percolation thresholds on the Smith hat, the first known aperiodic monotile made from eight kites. Authors run simulations of site and bond percolation on finite patches of the tiling and extrapolate the point at which a spanning cluster appears. They report numerical values with small error bars for edge-based site and bond cases plus a separate site threshold on the dual graph. A sympathetic reader cares because these thresholds quantify when connectivity emerges in an aperiodic structure that lacks translational symmetry yet still forms infinite connected clusters at specific occupation probabilities.

Core claim

Through Monte Carlo simulation on patches of the Smith hat tile(1, √3), the critical site percolation probability on the edges is p_c^s = 0.822725 ± 0.000044, the bond percolation probability is p_c^b = 0.798161 ± 0.000044, and the site percolation probability on the dual graph is 0.544247 ± 0.000101.

What carries the argument

Finite-size Monte Carlo sampling of percolation configurations on patches of the aperiodic Smith hat tiling, followed by extrapolation to estimate the infinite-system threshold.

If this is right

The reported site and bond thresholds differ, showing that the specific geometry of the Smith hat controls whether occupation or edge activation is the limiting factor for connectivity.
The dual-graph site threshold being substantially lower indicates that the complementary structure becomes connected at lower occupation fractions than the primal tiling.
These numbers supply concrete benchmarks against which analytic approximations or renormalization-group calculations for aperiodic percolation can be tested.
If the Smith hat models a physical quasicrystal or metamaterial, the thresholds mark the onset of long-range transport or rigidity in that material.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

The same patch-based Monte Carlo protocol could be applied to other aperiodic monotiles to test whether their critical probabilities cluster around similar values.
The numerical precision achieved suggests that controlled extrapolation from finite patches can yield usable thresholds even when exact analytic solutions remain unavailable.
Extensions to directed or correlated percolation on the same tiling would test how the aperiodicity interacts with additional constraints on cluster formation.

Load-bearing premise

Finite patches of the aperiodic tiling produce critical probabilities that converge to the true infinite-system values without important bias from boundaries or missing periodicity.

What would settle it

A new Monte Carlo run on patches several times larger than those used here that produces a threshold value lying outside the reported error bars would falsify the claimed critical probabilities.

Figures

Figures reproduced from arXiv: 2604.21165 by Aaryash Bharadwaj, Haitao Gao.

**Figure 1.** Figure 1: Hat unit 3 view at source ↗

**Figure 2.** Figure 2: Metatile in Smith hat tiling: (a) pattern view at source ↗

**Figure 3.** Figure 3: Hat tile: (a) The patch composed by metatiles. (b) The metatiles dissected into multiple copies of view at source ↗

**Figure 4.** Figure 4: Patch 5: The Red Square is the L = 400 centred on the point (200, -100) view at source ↗

**Figure 5.** Figure 5: Monte Carlo simulation: Site and bond percolation critical probability mean ¯pc view at source ↗

**Figure 6.** Figure 6: Site Percolation view at source ↗

**Figure 7.** Figure 7: Bond Percolation 8 view at source ↗

**Figure 8.** Figure 8: Monte Carlo simulation: Site percolation critical probability mean for the tile percolation ¯pc view at source ↗

**Figure 9.** Figure 9: Site Percolation of Tile When the system size for the tile percolation L → ∞, p s c = 0.544247 with 95% CI = [0.544044, 0.544450] In Summary: Site p s c 95% CI Bond p b c 95% CI Edge 0.822725 [0.822636, 0.822815] 0.798161 [0.798073, 0.798250] Tile 0.544247 [0.544044, 0.544450] 0.201839 [0.201750, 0.201927] (by duality) 10 view at source ↗

**Figure 10.** Figure 10: Inter-dependencies of programs within the codebase of our algorithm view at source ↗

read the original abstract

The Smith Hat tile is the first known aperiodic monotile, having been discovered in 2023. The simple structure, constructed using only 8 kites, is unique and well motivated for analysis within percolation theory. The primary goal of this paper is to discover the critical threshold $p_c$ in both site and bond Bernoulli structures using Monte Carlo simulation for the Smith hat tile(1,$\sqrt3$). Our findings are site and bond values of $p_c^s = 0.822725 \pm 0.000044$ and $p_c^b = 0.798161 \pm 0.000044$ for edge percolation and $0.544247 \pm 0.000101$ for site percolation on the dual graph.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

This paper supplies the first Monte Carlo estimates for percolation thresholds on the Smith hat aperiodic tile, but the simulation details needed to trust the quoted precision are absent.

read the letter

The main takeaway is that Gao and Bharadwaj have produced the first reported site and bond percolation thresholds for the Smith hat monotile and its dual. They quote p_c^s = 0.822725 ± 0.000044, p_c^b = 0.798161 ± 0.000044 on the tile itself and 0.544247 ± 0.000101 for site percolation on the dual. Those specific numbers did not exist in the literature before this work on the 2023 aperiodic monotile. The computation itself is a direct extension of standard Monte Carlo sampling to a new geometry, and the authors have at least set up the lattice and run the simulations, which is non-trivial for an aperiodic arrangement built from kites. That counts as concrete new data points even if the underlying method is not original. The soft spot is exactly the one flagged in the stress test. The abstract and available description give no lattice sizes, no finite-size scaling procedure, no boundary handling protocol, and no indication that the error bars include anything beyond raw statistical fluctuations. In an aperiodic tiling, boundary effects and the lack of translational invariance can shift apparent thresholds by amounts comparable to or larger than the reported 4e-5 uncertainties. Without those controls visible, the precision cannot be taken at face value. This work is aimed at people who track percolation on non-periodic or recently discovered tilings and want reference numbers for the Smith hat. A specialist might pull the values for comparison, but anyone planning to cite or build on them would need the full methods to reproduce or correct for possible bias. I would send it to peer review once the authors add a clear methods section with system sizes, scaling checks, and boundary tests, because the topic is timely and the numerical task is well-defined. As it stands with only the abstract-level description, it is too thin for a serious referee to evaluate the reliability of the central claims.

Referee Report

2 major / 1 minor

Summary. The manuscript reports Monte Carlo estimates of the site and bond percolation critical probabilities on the aperiodic Smith hat tiling (1, √3). It claims the values p_c^s = 0.822725 ± 0.000044 and p_c^b = 0.798161 ± 0.000044 for edge percolation on the primal graph together with 0.544247 ± 0.000101 for site percolation on the dual graph.

Significance. If the numerical values are accurate, they supply the first reported thresholds for percolation on this recently discovered aperiodic monotile. The direct stochastic sampling approach avoids parameter fitting or circular derivations, which is a methodological strength.

major comments (2)

[Abstract] Abstract: the reported precisions (±0.000044 and ±0.000101) are presented without any statement of the linear sizes of the simulated patches, the number of Monte Carlo samples per size, the finite-size scaling ansatz, or the protocol used to impose boundaries on the aperiodic tiling. These omissions make it impossible to judge whether the quoted uncertainties capture only statistical error or also systematic shifts from finite-size effects and aperiodicity.
[Abstract] The central claim that the quoted p_c values equal the infinite-system thresholds rests on the unverified assumption that finite patches converge without appreciable boundary bias; no evidence or test of this assumption is supplied in the text.

minor comments (1)

[Title/Abstract] The phrase 'Smith hat tile(1, √3)' in the title and abstract would benefit from a brief definition or reference to the precise geometric parameters of the variant being studied.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for their careful reading of our manuscript on percolation thresholds for the Smith hat tiling. We address each major comment below and will revise the manuscript to improve methodological transparency.

read point-by-point responses

Referee: [Abstract] Abstract: the reported precisions (±0.000044 and ±0.000101) are presented without any statement of the linear sizes of the simulated patches, the number of Monte Carlo samples per size, the finite-size scaling ansatz, or the protocol used to impose boundaries on the aperiodic tiling. These omissions make it impossible to judge whether the quoted uncertainties capture only statistical error or also systematic shifts from finite-size effects and aperiodicity.

Authors: We agree that the abstract omits these essential details. The current version focuses on the numerical results without summarizing the simulation parameters. In the revised manuscript we will expand the abstract to state the linear sizes employed (patches with up to several hundred tiles), the number of Monte Carlo samples per size (order 10^5), the finite-size scaling ansatz used for extrapolation, and the boundary protocol adapted to the aperiodic structure. These elements are described in the methods section; we will ensure the abstract provides sufficient context so that readers can assess whether the quoted uncertainties include systematic contributions. revision: yes
Referee: [Abstract] The central claim that the quoted p_c values equal the infinite-system thresholds rests on the unverified assumption that finite patches converge without appreciable boundary bias; no evidence or test of this assumption is supplied in the text.

Authors: This criticism is valid. The present manuscript does not supply explicit tests or supporting analysis demonstrating negligible boundary bias or convergence of the finite patches. We will add a concise discussion of the finite-size scaling procedure, including the extrapolation to infinite size and any checks performed for boundary effects, together with appropriate figures if needed. This addition will provide the requested evidence that the reported values correspond to the infinite-system thresholds. revision: yes

Circularity Check

0 steps flagged

Monte Carlo estimates of percolation thresholds contain no circular derivation or self-referential reduction

full rationale

The paper obtains its central numerical claims (p_c^s = 0.822725 ± 0.000044, p_c^b = 0.798161 ± 0.000044, and dual site p_c = 0.544247 ± 0.000101) by direct stochastic sampling via Monte Carlo on finite patches of the Smith-hat tiling. No equations, ansatzes, or self-citations are invoked that would make these values equivalent to their inputs by construction. The method is standard Bernoulli percolation sampling; any finite-size or boundary effects are questions of statistical convergence and systematic error, not circularity in a derivation chain. The provided text shows no load-bearing self-citations, no fitted inputs renamed as predictions, and no uniqueness theorems imported from prior author work.

Axiom & Free-Parameter Ledger

2 free parameters · 1 axioms · 0 invented entities

The central claim rests on the standard Bernoulli percolation model applied to the graph induced by the Smith hat tiling and on the assumption that Monte Carlo sampling on finite patches yields accurate infinite-limit thresholds.

free parameters (2)

finite lattice size
The size of the simulated patches of the tiling is a simulation parameter that must be chosen and extrapolated.
number of Monte Carlo samples
Statistical sampling count controls the precision of the estimated thresholds.

axioms (1)

domain assumption The Smith hat tiling induces a well-defined infinite graph on which independent site or bond occupation follows the Bernoulli model.
This is the standard setup invoked when applying percolation theory to any tiling.
