An Artifact-based Agent Framework for Adaptive and Reproducible Medical Image Processing

Lianrui Zuo , Yihao Liu , Gaurav Rudravaram , Karthik Ramadass , Aravind R. Krishnan , Michael D. Phillips , Yelena G. Bodien , Mayur B. Patel

show 10 more authors

Paula Trujillo Yency Forero Martinez Stephen A. Deppen Eric L. Grogan Fabien Maldonado Kevin McGann Hudson M. Holmes Laurie E. Cutting Yuankai Huo Bennett A. Landman

This is my paper

Pith reviewed 2026-05-08 02:21 UTC · model gemini-3-flash-preview

classification 💻 cs.AI cs.CVcs.MA

keywords medical imagingworkflow automationautonomous agentsreproducibilityclinical dataartifact contractprovenance

0 comments

The pith

An artifact-based agent framework automates medical image processing by synthesizing dataset-specific workflows while maintaining a deterministic record of every computation.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

Medical image analysis often fails when moved from benchmarks to messy clinical data because processing steps are hard-coded and lack provenance. This paper proposes a system where an autonomous agent selects processing steps based on the specific properties of a dataset and the desired analytical goal. By separating the high-level reasoning from the low-level execution, the framework ensures that every decision is logged and every result can be recreated. This allows researchers to manage technical complexity through a semantic layer while the system handles the underlying computational graph.

Core claim

The authors establish that medical imaging workflows can be made both adaptive and reproducible by introducing a semantic layer called an artifact contract. This contract formalizes the relationship between data inputs, processing rules, and outputs, allowing an agent to assemble valid computational graphs dynamically. Rather than replacing the workflow engine, the agent acts as a configuration synthesizer that maps high-level goals to specific tool chains based on data metadata. This approach successfully handles heterogeneous CT and MRI cohorts by generating tailored pipelines that remain fully auditable and re-executable.

What carries the argument

The Artifact Contract, a formal definition of intermediate and final outputs that enables a goal-conditioned agent to assemble modular processing rules into a deterministic computational graph.

If this is right

Processing pipelines can automatically adjust to variations in image resolution, modality, or anatomical coverage without manual code changes.
Provenance tracking becomes a native feature of the analysis, allowing researchers to audit the exact logic used to generate a clinical finding.
Non-technical users can interact with complex imaging databases using semantic queries that ground natural language in actual data artifacts.
The separation of agent reasoning and local execution allows for privacy-compliant processing where data never leaves the clinical environment.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

This framework could serve as a compiler for clinical guidelines, translating textual medical protocols into executable image-processing pipelines.
The reliance on metadata suggests that the future of medical imaging depends as much on standardized data-characterization tools as it does on the processing algorithms themselves.
If the rule library expands, the agent could potentially optimize workflows for computational efficiency or cost rather than just analytical correctness.

Load-bearing premise

The system assumes that all relevant dataset conditions can be accurately captured as machine-readable metadata that the agent is capable of interpreting.

What would settle it

If a workflow generated by the agent for a new, unseen dataset fails to produce valid artifacts despite the necessary rules being present in the library, the framework's adaptive reasoning would be proven insufficient.

Figures

Figures reproduced from arXiv: 2604.21936 by Aravind R. Krishnan, Bennett A. Landman, Eric L. Grogan, Fabien Maldonado, Gaurav Rudravaram, Hudson M. Holmes, Karthik Ramadass, Kevin McGann, Laurie E. Cutting, Lianrui Zuo, Mayur B. Patel, Michael D. Phillips, Paula Trujillo, Stephen A. Deppen, Yelena G. Bodien, Yency Forero Martinez, Yihao Liu, Yuankai Huo.

**Figure 1.** Figure 1: The typical analytical workflow and operational reality in imaging research. Imaging data originate in hospital and research PACS, where heterogeneous file structures, mixed modalities, and nested archives are common. Extensive curation and processing are often required before most analytical algorithms can be deployed. re-executable [11,14]. Existing workflow engines [4,2] ensure deterministic executio… view at source ↗

**Figure 2.** Figure 2: Overview of the proposed agentic system. User requests are routed to either (1) Knowledge Agent (generic questions), (2) a Semantic Query Agent operating on artifacts A, or (3) a workflow pathway for analytical goals. The Workflow Planning and Assembly Agents construct a configuration C from rule library S and artifacts A, which is executed by a workflow manager to transform dataset D into artifacts A. Wor… view at source ↗

read the original abstract

Medical imaging research is increasingly shifting from controlled benchmark evaluation toward real-world clinical deployment. In such settings, applying analytical methods extends beyond model design to require dataset-aware workflow configuration and provenance tracking. Two requirements therefore become central: \textbf{adaptability}, the ability to configure workflows according to dataset-specific conditions and evolving analytical goals; and \textbf{reproducibility}, the guarantee that all transformations and decisions are explicitly recorded and re-executable. Here, we present an artifact-based agent framework that introduces a semantic layer to augment medical image processing. The framework formalizes intermediate and final outputs through an artifact contract, enabling structured interrogation of workflow state and goal-conditioned assembly of configurations from a modular rule library. Execution is delegated to a workflow executor to preserve deterministic computational graph construction and provenance tracking, while the agent operates locally to comply with most privacy constraints. We evaluate the framework on real-world clinical CT and MRI cohorts, demonstrating adaptive configuration synthesis, deterministic reproducibility across repeated executions, and artifact-grounded semantic querying. These results show that adaptive workflow configuration can be achieved without compromising reproducibility in heterogeneous clinical environments.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

A pragmatic architectural take on medical imaging workflows that balances pipeline flexibility with strict reproducibility using a metadata-driven agent.

read the letter

This paper addresses a problem anyone working with clinical imaging cohorts knows well: the constant tension between needing a rigid, reproducible pipeline and needing to tweak that pipeline because every dataset has its own quirks. The win here is the 'artifact-based agent framework.' It separates the decision-making—choosing which tool to use for a specific scan—from the actual execution.

What is actually new is the 'artifact contract.' Instead of just chaining scripts, they define a semantic layer where the agent looks at metadata to decide the next step. This allows the system to be 'adaptive' (e.g., choosing different segmentation parameters for different CT protocols) while remaining 'reproducible' because the agent’s logic is recorded and the execution is handled by a deterministic workflow manager. The authors tested this on real CT and MRI cohorts rather than clean benchmarks, which gives the results some teeth.

The soft spot is the reliance on the 'rule library' and metadata quality. As the stress-test notes, the agent isn't actually 'intelligent' in a clinical sense; it is a rule-following engine. If your DICOM headers are messy or your rules are shallow, the agent will confidently and reproducibly generate a scientifically invalid result—like applying a non-contrast brain mask to a contrast-enhanced scan just because the file dimensions matched. The framework ensures the process is auditable and repeatable, but it doesn't inherently guarantee the scientific validity of the synthesized workflow.

That said, this is a solid piece of systems engineering for the medical AI community. It provides a formal structure for something that is usually handled with fragile, undocumented shell scripts. It is a useful read for anyone building large-scale imaging pipelines who needs to satisfy both data scientists and clinical auditors.

I recommend sending this to peer review. It’s a clear, well-reasoned contribution to the infrastructure of the field.

Referee Report

3 major / 3 minor

Summary. This paper introduces an agent-based framework for medical image processing designed to balance adaptability and reproducibility. The architecture separates the decision-making 'Agent' from a deterministic 'Executor'. The Agent uses a 'Rule Library' and 'Artifact Contracts'—a set of metadata specifications for inputs and outputs—to synthesize computational graphs tailored to specific dataset characteristics. The authors argue that by formalizing the intermediate states of a workflow as artifacts, they can achieve goal-conditioned configuration while maintaining an immutable provenance record through the executor. The framework is evaluated on CT organ segmentation and MRI brain tumor segmentation tasks using clinical datasets.

Significance. The paper addresses a critical bottleneck in clinical imaging: the high overhead of manually configuring pipelines for heterogeneous data. The primary strength is the formalization of the 'Artifact Contract', which provides a machine-readable interface between modular imaging tools. By decoupling the reasoning (Agent) from the execution (Executor), the work offers a pathway to use large language models or rule-based systems in clinical environments without sacrificing the auditability of the final execution graph. The inclusion of real-world clinical cohorts rather than just curated benchmarks is a significant strength that demonstrates the system's practical utility in handling varied metadata.

major comments (3)

[§2.2, 'Artifact Contract'] The Artifact Contract definition focuses heavily on technical metadata (file formats, dimensions, voxel spacing). However, it lacks a mechanism for clinical semantic validation. For instance, the contract as described does not seem to prevent the Agent from applying a rule designed for non-contrast CT to a contrast-enhanced artifact if both share the same technical dimensions. The authors should clarify how the framework ensures 'scientific' validity versus merely 'execution' validity, or explicitly define the scope of the Agent's reasoning as limited to technical compatibility.
[§4.1, Table 1 / Performance Comparison] The evaluation demonstrates that the Agent can successfully synthesize a valid path, but it lacks a comparison against a fixed, 'one-size-fits-all' baseline. To support the claim of 'adaptive configuration synthesis' as a benefit, the results should show that the Agent's dataset-specific adaptation outperforms a standard static pipeline (e.g., a default nnU-Net configuration) across the heterogeneous cohorts tested.
[§3.3, 'Reproducibility'] The paper claims deterministic reproducibility, yet the Agent's decision-making process (choosing from the Rule Library) appears to happen outside the workflow executor. If the Agent's selection logic is updated or contains stochastic components (e.g., if using an LLM-based agent as hinted in the discussion), the 'same' input could result in different execution graphs over time. The authors must specify if the Agent's state and rule-set versions are captured in the provenance metadata to ensure the entire pipeline, not just the resulting DAG, is reproducible.

minor comments (3)

[§2.3] The 'Rule Library' is described as modular, but the manuscript does not provide the scale of these libraries. Please clarify the number of rules used in the CT vs. MRI experiments to give the reader a sense of the search space complexity.
[Figure 2] The notation for 'Artifact Flow' is slightly ambiguous; use distinct arrow styles or colors to differentiate between metadata interrogation (Agent-Artifact) and data movement (Executor-Artifact).
[§5.2] The discussion mentions privacy constraints. It would be helpful to explicitly state whether the Artifact Contracts ever contain Protected Health Information (PHI) or if they are strictly limited to non-identifying technical headers.

Simulated Author's Rebuttal

3 responses · 0 unresolved

We thank the referee for their constructive feedback and for highlighting the significance of our Artifact-based Agent Framework in clinical imaging. We appreciate the recognition of the 'Artifact Contract' as a key innovation for decoupling reasoning from execution. We have addressed the referee's concerns regarding semantic validation, performance baselines, and the reproducibility of the synthesis process itself through revisions in Sections 2.2, 3.3, and 4.1.

read point-by-point responses

Referee: [§2.2, 'Artifact Contract'] The Artifact Contract definition focuses heavily on technical metadata... It lacks a mechanism for clinical semantic validation... The authors should clarify how the framework ensures 'scientific' validity versus merely 'execution' validity.

Authors: The referee is correct that our initial description focused on technical metadata necessary for low-level execution. However, the Artifact Contract's metadata field is designed to be extensible to clinical semantics. In the revised manuscript, we have clarified that the 'artifact_type' and 'metadata' fields are intended to encompass clinical attributes such as contrast phase, anatomical region, and sequence type. We have added a paragraph in Section 2.2 describing 'Semantic Rules' within the Rule Library that specifically check these clinical tags (e.g., ensuring a 'contrast-enhanced' tag is present before invoking a specific segmentation rule). This ensures that the Agent reasoning encompasses scientific validity in addition to technical compatibility. revision: yes
Referee: [§4.1, Table 1 / Performance Comparison] The evaluation... lacks a comparison against a fixed, 'one-size-fits-all' baseline. To support the claim of 'adaptive configuration synthesis' as a benefit, the results should show that the Agent's dataset-specific adaptation outperforms a standard static pipeline.

Authors: We agree that a static baseline is necessary to quantify the benefit of adaptivity. We have updated Table 1 and Section 4.1 to include a 'Static Baseline' comparison. In our tests on the CT organ segmentation task, we compare the Agent-synthesized pipeline against a fixed pre-processing pipeline (standardized resampling and intensity scaling based on the aggregate dataset mean). The results demonstrate that the Agent’s ability to detect and adapt to varying voxel spacings and manufacturer-specific metadata leads to a statistically significant improvement in segmentation accuracy (DSC) compared to the static baseline, particularly in the heterogeneous 'Clinical Cohort B'. revision: yes
Referee: [§3.3, 'Reproducibility'] The paper claims deterministic reproducibility, yet the Agent's decision-making process... appears to happen outside the workflow executor... The authors must specify if the Agent's state and rule-set versions are captured in the provenance metadata.

Authors: This is an important point regarding the scope of reproducibility. In the original manuscript, provenance focused on the execution of the computational graph. We have now revised Section 3.3 and our implementation to include 'Synthesis Provenance.' This ensures that the version of the Rule Library, the Agent's internal state (e.g., hyper-parameters), and any external model identifiers (for LLM-based reasoning) are captured as metadata in the final Artifact. This ensures that the entire lifecycle—from initial data ingestion to the final synthesized execution—is fully auditable and reproducible. We have clarified that if the Agent's logic is updated, it is treated as a new version of the synthesis engine, which is explicitly recorded in the provenance trace. revision: yes

Circularity Check

0 steps flagged

No significant circularity: Results are functional verifications of a self-contained system architecture.

full rationale

The framework's primary claims—reproducibility and adaptive synthesis—are established through the integration of a deterministic execution engine and a structured rule library. Reproducibility is an inherited property of the chosen executor (e.g., Snakemake), and the agent's 'adaptive' success is a verification that the rule library successfully covers the metadata variants present in the test cohorts. While the system's performance is a direct consequence of these authored inputs (rules and contracts), this represents a successful functional verification of the software architecture rather than a circular scientific derivation. The 'adaptive configuration' is a traversal of a search space defined by the authors; while limited by that library, its successful synthesis is an implementation result rather than a logical fallacy. The authors do not invoke unverified 'uniqueness theorems' or rely on load-bearing self-citations to justify the framework's validity, and the evaluation on real-world clinical data serves as an empirical check of the system's utility.

Axiom & Free-Parameter Ledger

0 free parameters · 2 axioms · 1 invented entities

The framework rests on the availability of high-quality metadata and the human-authored rules that the agent uses to select processing steps.

axioms (2)

domain assumption DICOM/Metadata Reliability
The agent relies on accurate metadata (e.g., image orientation, sequence type) to make informed configuration decisions.
domain assumption Modular Rule Sufficiency
It is assumed that the problem domain can be decomposed into a library of rules that are sufficient for the agent to assemble a valid workflow for most clinical variations.

invented entities (1)

Artifact Contract no independent evidence
purpose: A semantic layer that defines the properties and expected state of imaging data at each stage of a pipeline.
This is a conceptual construct introduced by the authors to enable agent-based reasoning.
