Scaled Relative Graphs in Normed Spaces

Alberto Padoan
Authors on Pith no claims yet

Pith reviewed 2026-05-13 21:05 UTC · model grok-4.3

classification 🧮 math.OC cs.SYeess.SY
keywords scaled relative graphsnormed spacesdirectional anglesoperator contractionmonotonicityBellman operatorsfixed point theoryoptimization
0
0 comments X

The pith

Directional scaled relative graphs certify contraction and monotonicity of operators in normed spaces via geometric containment.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper extends the scaled relative graph framework from Hilbert spaces to general normed spaces by replacing the inner product with a regular pairing. This replacement produces directional angles, which in turn define directional SRGs that test whether an operator satisfies contraction or monotonicity by checking if its graph stays inside specific regions. If the tests hold, they certify the properties geometrically without needing to compute distances or inner products directly. The work also supplies rules for how these graphs transform under scaling, inversion, addition, and composition, and it demonstrates the approach on Bellman operators through numerical examples. The extension matters because many problems in optimization and control are naturally posed in spaces that lack an inner product structure.

Core claim

Replacing the inner product with a regular pairing on a normed space yields directional angles and directional scaled relative graphs. These graphs certify that an operator is a contraction or monotone by verifying geometric containment conditions. Calculus rules are derived for the graphs under scaling, inversion, addition, and composition, and the results are illustrated by a graphical certificate for Bellman operators.

What carries the argument

Directional scaled relative graphs, formed from directional angles induced by a regular pairing, that serve as geometric containment tests for operator properties such as contraction and monotonicity.

If this is right

  • An operator whose directional SRG lies in the appropriate region is guaranteed to be a contraction.
  • Monotonicity of an operator is certified by a similar containment condition on its directional SRG.
  • SRGs of composite operators can be obtained from the individual SRGs via the derived addition and composition rules.
  • Graphical verification becomes possible for Bellman operators in spaces without inner products.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • The approach could support new fixed-point algorithms that rely on visual or computational checks in Banach spaces rather than Hilbert spaces.
  • Similar containment tests might extend to other operator classes such as averaged or cocoercive mappings.
  • Software implementations could render the graphs to automate property verification during algorithm design.

Load-bearing premise

A regular pairing exists on the normed space that is sufficiently well-behaved to define directional angles yielding valid containment tests.

What would settle it

An operator in a normed space that satisfies contraction yet whose directional SRG fails to lie inside the predicted containment region for contractions.

Figures

Figures reproduced from arXiv: 2604.02407 by Alberto Padoan.

Figure 1
Figure 1. Figure 1: Directional angles in ℓ 1 (left), ℓ 2 (center), and ℓ∞ (right) between unit-norm vectors x (solid) and y (dashdotted) in R2 . The outward normals at x are sign(x) in ℓ 1 , x/ ∥x∥2 in ℓ 2 , and sign(xmx )emx in ℓ∞ with the min-index pairing. In ℓ 1 , an angle encodes transitions between sign patterns on the unit cross-polytope; in ℓ 2 , it encodes continuous rotations on the unit sphere; in ℓ∞, it encodes t… view at source ↗
Figure 2
Figure 2. Figure 2: shows the SRGs of A1 (top) and A∞ (bottom) in ℓ 1 (left), ℓ 2 (center), and ℓ∞ (right), with the max pairing in ℓ∞. For A1, the ℓ 1 SRG (top-left) lies in the right half-plane, confirming ℓ 1 -monotonicity. By contrast, the ℓ 2 and ℓ∞ SRGs extend into the left half-plane, so monotonicity does not hold in these norms. For A∞, a dual picture emerges: the ℓ∞ SRG (bottom-right) lies in the right half-plane, wh… view at source ↗
Figure 4
Figure 4. Figure 4: (left) confirms this for a randomly generated 8-state MDP with γ = 0.7. The left SRG in ℓ∞ (with max pairing) is contained in the disk of radius γ centered at the origin. b) Regularized policy evaluation: In approximate dy￾namic programming, a common strategy to incorporate prior knowledge is to regularize the Bellman operator [22], [36]. Consider the regularized policy evaluation operator Tπ,αv = Tπv + αφ… view at source ↗
read the original abstract

The paper extends the Scaled Relative Graph (SRG) framework of Ryu, Hannah, and Yin from Hilbert spaces to normed spaces. Our extension replaces the inner product with a regular pairing, whose asymmetry gives rise to directional angles and, in turn, directional SRGs. Directional SRGs are shown to provide geometric containment tests certifying key operator properties, including contraction and monotonicity. Calculus rules for SRGs under scaling, inversion, addition, and composition are also derived. The theory is illustrated by numerical examples, including a graphical contraction certificate for Bellman operators.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

2 major / 2 minor

Summary. The paper extends the Scaled Relative Graph (SRG) framework of Ryu, Hannah, and Yin from Hilbert spaces to general normed spaces by replacing the inner product with a regular pairing. This yields directional SRGs whose geometric containment tests are claimed to certify operator properties including contraction and monotonicity. Calculus rules are derived for SRGs under scaling, inversion, addition, and composition, with the theory illustrated by numerical examples including a graphical contraction certificate for Bellman operators.

Significance. If the directional SRG containment tests hold without additional restrictions on the space or pairing, the work would provide a useful geometric certificate tool beyond Hilbert spaces, extending prior SRG results to Banach-space settings common in optimization and operator theory. The explicit calculus rules and numerical illustrations add practical value for verifying properties such as monotonicity.

major comments (2)
  1. Abstract and introduction: the claim that directional SRGs certify contraction and monotonicity via containment tests rests on the regular pairing inducing directional angles that preserve the required geometric implications under scaling, inversion, addition, and composition. In normed spaces the pairing is asymmetric, and no explicit conditions are given to guarantee that the containment tests remain valid without extra assumptions on the space or operator; this is load-bearing for the central extension.
  2. The weakest assumption (regular pairing sufficiently well-behaved for directional angles) is not accompanied by a counter-example check or a minimal set of axioms on the pairing that would ensure the containment tests survive the asymmetry; without this the certification claims for general normed spaces remain conditional.
minor comments (2)
  1. The numerical examples (Bellman operator) would benefit from explicit reporting of the computed directional angles or containment radii so readers can reproduce the graphical certificate.
  2. Notation for the regular pairing and directional angle should be introduced with a short comparison to the Hilbert-space inner-product case to aid readers familiar with the original SRG work.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the detailed review and valuable feedback on our work extending Scaled Relative Graphs to normed spaces. We address the major comments below, clarifying the role of the regular pairing and committing to revisions that strengthen the presentation of the assumptions and their implications.

read point-by-point responses

  1. Referee: Abstract and introduction: the claim that directional SRGs certify contraction and monotonicity via containment tests rests on the regular pairing inducing directional angles that preserve the required geometric implications under scaling, inversion, addition, and composition. In normed spaces the pairing is asymmetric, and no explicit conditions are given to guarantee that the containment tests remain valid without extra assumptions on the space or operator; this is load-bearing for the central extension.

    Authors: We appreciate this observation. The regular pairing is defined in Section 2 to satisfy specific properties (positivity, absolute homogeneity, and boundedness) that ensure the directional angles preserve the geometric relations needed for the containment tests in Theorems 3.1–3.4. These properties are chosen precisely to handle the asymmetry in normed spaces while maintaining the implications for contraction and monotonicity under the calculus operations. To make this more explicit, we will revise the abstract and introduction to reference these properties directly and add a dedicated remark in Section 2 listing the minimal axioms required for the tests to hold without additional assumptions on the space or operator. revision: yes

  2. Referee: The weakest assumption (regular pairing sufficiently well-behaved for directional angles) is not accompanied by a counter-example check or a minimal set of axioms on the pairing that would ensure the containment tests survive the asymmetry; without this the certification claims for general normed spaces remain conditional.

    Authors: We agree that explicitly stating the minimal axioms would improve clarity. The definition of a regular pairing already provides these axioms, which are sufficient for the directional SRG to certify the properties as proven in the main theorems. We will expand Definition 2.1 to list the axioms separately and include a brief discussion explaining why they ensure the containment tests remain valid despite asymmetry. A counter-example check is not included because the proofs are direct from the axioms, but we will add a sentence noting that violation of regularity would invalidate the angle interpretation, thereby addressing the conditional nature of the claims. revision: yes

Circularity Check

0 steps flagged

No significant circularity; extension derives independently from regular pairing

full rationale

The paper extends the prior Hilbert-space SRG framework by defining a regular pairing on normed spaces to induce directional angles and directional SRGs. Containment tests for contraction and monotonicity, along with calculus rules under scaling/inversion/addition/composition, are derived directly from the pairing's properties and the resulting geometric constructions. No load-bearing step reduces by construction to a fitted parameter, self-definition, or self-citation chain; the central claims rest on explicit derivations from the new pairing axioms rather than renaming or smuggling prior results. The work is self-contained against the stated assumptions on the pairing.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 0 invented entities

The central claim rests on the existence of a regular pairing in an arbitrary normed space and on standard properties of angles and containment in the plane; no free parameters or invented entities are introduced in the abstract.

axioms (1)
  • domain assumption Every normed space admits a regular pairing that can replace the inner product for defining angles.
    Invoked to extend the SRG definition beyond Hilbert spaces.

pith-pipeline@v0.9.0 · 5377 in / 1057 out tokens · 33134 ms · 2026-05-13T21:05:54.681325+00:00 · methodology

discussion (0)

Sign in with ORCID, Apple, or X to comment. Anyone can read and Pith papers without signing in.

Lean theorems connected to this paper

Citations machine-checked in the Pith Canon. Every link opens the source theorem in the public Lean library.

What do these tags mean?
matches
The paper's claim is directly supported by a theorem in the formal canon.
supports
The theorem supports part of the paper's argument, but the paper may add assumptions or extra steps.
extends
The paper goes beyond the formal theorem; the theorem is a base layer rather than the whole result.
uses
The paper appears to rely on the theorem as machinery.
contradicts
The paper's claim conflicts with a theorem or certificate in the canon.
unclear
Pith found a possible connection, but the passage is too broad, indirect, or ambiguous to say the theorem truly supports the claim.
