arxiv: 2604.15202 · v1 · submitted 2026-04-16 · 💻 cs.RO · cs.AI· math.OC

Benchmarking Classical Coverage Path Planning Heuristics on Irregular Hexagonal Grids for Maritime Coverage Scenarios

Carlos S. Sep\'ulveda , Gonzalo A. Ruz This is my paper

Pith reviewed 2026-05-10 10:47 UTC · model grok-4.3

classification 💻 cs.RO cs.AImath.OC

keywords coverage path planningirregular hexagonal gridsWarnsdorff heuristicHamiltonian pathsmaritime surveillancebenchmarkingresidual degreegraph traversal

0 comments

The pith

A Warnsdorff heuristic variant with index-based tie-breaking and terminal-inclusive residual degree reaches 79 percent success on Hamiltonian coverage paths for irregular hexagonal grids.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper sets up a large-scale, reproducible test of classical deterministic heuristics for single-vehicle coverage path planning on irregular hexagonal graphs. These graphs come from synthetic areas chosen to reflect maritime surveillance, search-and-rescue, and monitoring needs, with 10,000 instances that include compact, elongated, and bottlenecked shapes. It reports that heuristics using shortest-path reconnection solve the relaxed task of visiting every cell (allowing revisits) almost every time, yet only one specific Warnsdorff variant produces zero-revisit Hamiltonian tours in 79 percent of cases. A reader would care because maritime missions often prize paths without wasted revisits, and the work shows that small, previously under-reported choices in how a heuristic counts remaining neighbors can shift success rates by large margins on sparse geometric graphs.

Core claim

The benchmark evaluates 17 heuristics drawn from seven families on 10,000 Hamiltonian-feasible irregular hexagonal instances. Exact depth-first search verifies that every instance admits a Hamiltonian tour. Among the heuristics, the strongest performer is a Warnsdorff rule variant that applies an index-based tie-breaker together with a residual-degree policy that continues to count the designated endpoint until the final move; this combination yields 79.0 percent Hamiltonian success. The paper states that the dominant design factor is not the tie-breaker itself but the precise definition of residual degree when the endpoint is reserved until last. Heuristics without this policy produce far-f

What carries the argument

The terminal-inclusive residual-degree policy inside a Warnsdorff rule: when choosing the next cell, the heuristic counts the number of unvisited neighbors for every candidate while still treating the tour endpoint as unavailable until the final step, then breaks remaining ties by cell index.

If this is right

Heuristics that reconnect via shortest paths reliably achieve complete coverage but almost never produce zero-revisit tours.
The way residual degree is defined when the endpoint is held in reserve affects performance more than the choice of tie-breaker alone on graphs that contain bottlenecks.
All 10,000 released instances are Hamiltonian-feasible, so any heuristic failure is due to the heuristic rather than to the absence of a solution.
The benchmark supplies a fixed, publicly described testbed that future heuristic designers can use to isolate the effect of individual implementation choices.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

Designers of new coverage planners for maritime robots could adopt the terminal-inclusive residual-degree rule as a baseline before introducing learned components or backtracking.
The performance gap between relaxed coverage and strict Hamiltonian tours suggests that hybrid methods that switch from heuristic search to limited exact search near the end might close the remaining 21 percent without prohibitive compute cost.
Because the instances span compact, elongated, and irregular morphologies, the same residual-degree policy might transfer to other sparse grid types such as triangular or square lattices used in different coverage domains.
The emphasis on under-reported implementation details implies that published pseudocode for classical heuristics should always specify how the final cell is treated during degree calculations.

Load-bearing premise

The synthetic maritime-motivated areas and the generated irregular hexagonal graphs capture the structural bottlenecks and connectivity patterns that real-world maritime coverage missions would present.

What would settle it

Running the same Warnsdorff variant on a new collection of irregular hexagonal graphs extracted from actual satellite imagery of coastlines or archipelagos and obtaining a Hamiltonian success rate clearly below or above 79 percent.

Figures

Figures reproduced from arXiv: 2604.15202 by Carlos S. Sep\'ulveda, Gonzalo A. Ruz.

**Figure 1.** Figure 1: Representative instances from each morphological family showing the hexagonal tessellation with base node ( [PITH_FULL_IMAGE:figures/full_fig_p003_1.png] view at source ↗

**Figure 2.** Figure 2: * Warnsdorff-EP (FAIL) [PITH_FULL_IMAGE:figures/full_fig_p006_2.png] view at source ↗

read the original abstract

Coverage path planning on irregular hexagonal grids is relevant to maritime surveillance, search and rescue and environmental monitoring, yet classical methods are often compared on small ad hoc examples or on rectangular grids. This paper presents a reproducible benchmark of deterministic single-vehicle coverage path planning heuristics on irregular hexagonal graphs derived from synthetic but maritime-motivated areas of interest. The benchmark contains 10,000 Hamiltonian-feasible instances spanning compact, elongated, and irregular morphologies, 17 heuristics from seven families, and a common evaluation protocol covering Hamiltonian success, complete-coverage success, revisits, path length, heading changes, and CPU latency. Across the released dataset, heuristics with explicit shortest-path reconnection solve the relaxed coverage task reliably but almost never produce zero-revisit tours. Exact Depth-First Search confirms that every released instance is Hamiltonian-feasible. The strongest classical Hamiltonian baseline is a Warnsdorff variant that uses an index-based tie-break together with a terminal-inclusive residual-degree policy, reaching 79.0% Hamiltonian success. The dominant design choice is not tie-breaking alone, but how the residual degree is defined when the endpoint is reserved until the final move. This shows that underreported implementation details can materially affect performance on sparse geometric graphs with bottlenecks. The benchmark is intended as a controlled testbed for heuristic analysis rather than as a claim of operational optimality at fleet scale.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

This paper provides a solid benchmark dataset and protocol for coverage heuristics on irregular hexagonal grids, highlighting key implementation details in classical methods.

read the letter

This paper provides a large, controlled benchmark for classical single-vehicle coverage path planning on irregular hexagonal grids. It includes 10,000 Hamiltonian-feasible instances generated from synthetic maritime-motivated areas, with exact DFS verification for each one. The work compares 17 heuristics across seven families using a uniform set of metrics: Hamiltonian success, complete coverage, revisits, path length, heading changes, and CPU time. The standout result is that a specific Warnsdorff variant, using index-based tie-breaking and a terminal-inclusive residual-degree policy, achieves 79% Hamiltonian success. The paper notes that the way residual degree is defined when holding the endpoint for last makes the biggest difference. This is done well. The scale and reproducibility are strengths, and the authors position it clearly as a testbed rather than an operational solution. Releasing the dataset supports further work by others. Soft spots are limited. The instances are synthetic, which means they may miss some real-world maritime features like dynamic conditions or sensor noise. The paper acknowledges this by not claiming generalization, so the limitation is not overstated. Since it's purely empirical benchmarking with no fitted models or circular claims, the evidence holds up. This paper is for robotics researchers focused on path planning for coverage tasks, particularly in maritime settings. Readers who need baselines or a standard test set for irregular grids will find it practical. It deserves a serious referee. The careful setup and verifiable results make it a useful contribution for the community. I would recommend sending this to peer review.

Referee Report

0 major / 3 minor

Summary. The paper claims to provide a reproducible benchmark of 17 classical coverage path planning heuristics on 10,000 Hamiltonian-feasible irregular hexagonal graphs derived from synthetic maritime-motivated areas of interest. Using a uniform multi-metric protocol (Hamiltonian success, coverage success, revisits, path length, heading changes, CPU time) and exact DFS verification of feasibility for every instance, it identifies a Warnsdorff variant with index-based tie-breaking and terminal-inclusive residual-degree policy as the strongest baseline at 79.0% Hamiltonian success, attributing performance differences primarily to the residual-degree definition rather than tie-breaking alone. The work is explicitly framed as a controlled testbed rather than an operational claim.

Significance. If the results hold, this supplies a large-scale, released, and exactly verified testbed that enables systematic, reproducible analysis of heuristic behavior on sparse geometric graphs containing bottlenecks and irregular morphologies. Credit is due for the 10,000-instance scale, exact DFS confirmation of Hamiltonian feasibility on every instance, the uniform multi-metric protocol, and the explicit release of the dataset, all of which strengthen the empirical foundation and support future heuristic development in coverage planning.

minor comments (3)

[Abstract, §3] Abstract and §3: the phrase 'synthetic but maritime-motivated areas of interest' is used without a concise summary of the generation parameters (e.g., elongation ratios, bottleneck widths); a one-sentence description or pointer to the precise generation procedure would improve immediate readability.
[§4.3, Table 2] §4.3 and Table 2: the comparison of Warnsdorff variants would be clearer if the residual-degree policies were enumerated in a small table alongside their respective Hamiltonian success rates, making the claim that 'the dominant design choice is ... how the residual degree is defined' directly verifiable at a glance.
[Figure 4, §5] Figure 4 and §5: axis labels and legend entries for the 17 heuristics are occasionally abbreviated; expanding the legend or adding a short key in the caption would reduce the need to cross-reference the text while interpreting the performance distributions.

Simulated Author's Rebuttal

0 responses · 0 unresolved

We thank the referee for the positive summary, recognition of the benchmark scale, exact DFS verification, uniform protocol, and dataset release, as well as the recommendation for minor revision. The work is framed strictly as a reproducible testbed for heuristic analysis on irregular hexagonal graphs.

Circularity Check

0 steps flagged

No significant circularity: purely empirical benchmarking

full rationale

The paper is a reproducible empirical benchmark that generates 10,000 Hamiltonian-feasible irregular hexagonal instances, verifies feasibility via exact DFS on every instance, and measures performance of 17 heuristics under a fixed protocol. No mathematical derivations, fitted parameters, predictions, or ansatzes appear; all reported outcomes (Hamiltonian success rates, revisits, etc.) are direct computations on the released dataset. Central claims rest on these measurements rather than any self-referential reduction or self-citation chain. The study is self-contained against external benchmarks.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 0 invented entities

The work relies on standard graph theory concepts such as Hamiltonian paths and residual degree without introducing new free parameters, ad hoc axioms, or invented entities beyond the synthetic instance generator.

axioms (1)

domain assumption All generated instances are Hamiltonian-feasible
Confirmed via exact Depth-First Search to ensure heuristics are evaluated only on solvable graphs.

pith-pipeline@v0.9.0 · 5549 in / 1247 out tokens · 26332 ms · 2026-05-10T10:47:37.935015+00:00 · methodology

discussion (0)

Reference graph

Works this paper leans on

18 extracted references · 2 canonical work pages

[1]

Coverage for robotics–a survey of recent results,

H. Choset, “Coverage for robotics–a survey of recent results,”Annals of mathematics and artificial intelligence, vol. 31, no. 1, pp. 113–126, 2001

2001
[2]

A survey on coverage path planning for robotics,

E. Galceran and M. Carreras, “A survey on coverage path planning for robotics,”Robotics and Autonomous systems, vol. 61, pp. 1258–1276, 2013

2013
[3]

Survey on coverage path planning with unmanned aerial vehicles,

T. M. Cabreira, L. B. Brisolara, and R. F. Paulo, “Survey on coverage path planning with unmanned aerial vehicles,”Drones, vol. 3, pp. 1–38, 3 2019

2019
[4]

Coverage path planning methods focusing on energy efficient and cooperative strategies for unmanned aerial vehicles,

G. Fevgas, T. Lagkas, V . Argyriou, and P. Sarigiannidis, “Coverage path planning methods focusing on energy efficient and cooperative strategies for unmanned aerial vehicles,”Sensors, vol. 22, 2 2022

2022
[5]

Multi-uav coverage path planning based on hexagonal grid decomposition in maritime search and rescue,

S.-W. Cho, J.-H. Park, H.-J. Park, and S. Kim, “Multi-uav coverage path planning based on hexagonal grid decomposition in maritime search and rescue,”Mathematics, vol. 10, no. 1, p. 83, 2021

2021
[6]

Coverage path planning for multiple unmanned aerial vehicles in maritime search and rescue operations,

S. W. Cho, H. J. Park, H. Lee, D. H. Shim, and S. Y . Kim, “Coverage path planning for multiple unmanned aerial vehicles in maritime search and rescue operations,”Computers and Industrial Engineering, vol. 161, 11 2021

2021
[7]

Rectangular and hexagonal grids used for observation, experiment and simulation in ecology,

C. P. Birch, S. P. Oom, and J. A. Beecham, “Rectangular and hexagonal grids used for observation, experiment and simulation in ecology,” Ecological modelling, vol. 206, no. 3-4, pp. 347–359, 2007

2007
[8]

Uav coverage using hexagonal tessellation,

E. Kadioglu, C. Urtis, and N. Papanikolopoulos, “Uav coverage using hexagonal tessellation,” in27th Mediterranean Conference on Control and Automation, MED 2019 - Proceedings. Institute of Electrical and Electronics Engineers Inc., 7 2019, pp. 37–42

2019
[9]

A comprehensive review of coverage path planning in robotics using classical and heuristic algorithms,

C. S. Tan, R. Mohd-Mokhtar, and M. R. Arshad, “A comprehensive review of coverage path planning in robotics using classical and heuristic algorithms,”IEEE Access, vol. 9, pp. 119 310–119 342, 2021

2021
[10]

Spanning-tree based coverage of contin- uous areas by a mobile robot,

Y . Gabriely and E. Rimon, “Spanning-tree based coverage of contin- uous areas by a mobile robot,”Annals of mathematics and artificial intelligence, vol. 31, no. 1, pp. 77–98, 2001

2001
[11]

Revisiting boustrophedon coverage path planning as a generalized traveling salesman problem,

R. B ¨ahnemann, N. Lawrance, J. J. Chung, M. Pantic, R. Siegwart, and J. Nieto, “Revisiting boustrophedon coverage path planning as a generalized traveling salesman problem,” inField and Service Robotics: Results of the 12th International Conference. Springer, 2021, pp. 277– 290

2021
[12]

Multi-robot coverage path planning using hexagonal segmentation for geophysical surveys,

H. Azp ´urua, G. M. Freitas, D. G. Macharet, and M. F. Campos, “Multi-robot coverage path planning using hexagonal segmentation for geophysical surveys,”Robotica, vol. 36, pp. 1144–1166, 8 2018

2018
[13]

von Warnsdorf,Des R ¨osselsprunges einfachste und allgemeinste L¨osung

H. von Warnsdorf,Des R ¨osselsprunges einfachste und allgemeinste L¨osung. Verhagen, 1823
[14]

A method for finding hamilton paths and knight’s tours,

I. Pohl, “A method for finding hamilton paths and knight’s tours,” Communications of the ACM, vol. 10, no. 7, pp. 446–449, 1967

1967
[15]

Hamilton circuits in hexagonal grid graphs

K. Islam, H. Meijer, Y . N. Rodr ´ıguez, D. Rappaport, and H. Xiao, “Hamilton circuits in hexagonal grid graphs.” inCCCG, 2007, pp. 85– 88

2007
[16]

Rl4co: an extensive reinforcement learning for combinatorial optimization benchmark,

F. Berto, C. Hua, J. Park, L. Luttmann, Y . Ma, F. Bu, J. Wang, H. Ye, M. Kim, S. Choiet al., “Rl4co: an extensive reinforcement learning for combinatorial optimization benchmark,” inProceedings of the 31st ACM SIGKDD Conference on Knowledge Discovery and Data Mining V . 2, 2025, pp. 5278–5289

2025
[17]

Irregular hexagonal aoi coverage path planning benchmark dataset,

C. S. Sep ´ulveda and G. A. Ruz, “Irregular hexagonal aoi coverage path planning benchmark dataset,” 2026. [Online]. Available: https: //doi.org/10.5281/zenodo.19477858

work page doi:10.5281/zenodo.19477858 2026
[18]

Benchmark figures and instance visualizations for the irregular hexagonal aoi cpp benchmark,

——, “Benchmark figures and instance visualizations for the irregular hexagonal aoi cpp benchmark,” 2026. [Online]. Available: https://doi.org/10.5281/zenodo.19547071

work page doi:10.5281/zenodo.19547071 2026
