Decohered color code and emerging mixed toric code by anyon proliferation: Topological entanglement negativity perspective

Keisuke Kataoka , Yoshihito Kuno , Takahiro Orito , Ikuo Ichinose

Authors on Pith no claims yet

Pith reviewed 2026-05-08 11:48 UTC · model grok-4.3

classification 🪐 quant-ph cond-mat.stat-mechcond-mat.str-el

keywords color codetoric codedecoherencemixed-state topological ordertopological entanglement negativityanyon proliferationstabilizer states

0 comments

The pith

Decoherence via XX operators on red links turns the color code into a mixed state that inherits half its topological properties and emerges as a single toric code.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper investigates decoherence effects on the color code defined on a honeycomb lattice. It demonstrates that XX-type decoherence on red links produces a mixed state retaining half the topological features of the pure color code, including anyon content and logical operators. This leads to an intrinsic mixed-state topological order identified as related to a toric code through a gauging procedure. Topological entanglement negativity serves as the key diagnostic, decreasing from 2 ln 2 to ln 2 at maximum decoherence. Simulations show a smooth crossover with a variance peak, and scaling behavior specific to certain subsystem partitions.

Core claim

For decoherence induced by XX-type operators on red links of the honeycomb lattice, the resulting mixed state inherits half of the topological properties of the color code, including anyon content, logical operators, and topological entanglement structure. Using a gauging procedure for mixed stabilizer states, the emergent phase is identified as closely related to a single toric code. The pure color code has TEN = 2 ln 2, while the maximally decohered state has TEN = ln 2, indicating emergence of a single toric code. Tuning the decoherence strength reveals a smooth crossover in TEN with a pronounced peak in its variance.

What carries the argument

Topological entanglement negativity (TEN) as a probe combined with gauging of mixed stabilizer states to identify the emergent toric code phase.

If this is right

The decohered mixed state possesses the anyon content and logical operators of a single toric code.
TEN exhibits a smooth crossover with a nearly system-size-independent peak in variance as decoherence strength varies.
The negativity shows characteristic scaling only for subsystem partitions matching the triangular lattice of the emergent toric code.
Negativity-based quantities can probe mixed-state topological order generated by decoherence.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

Decoherence channels could be engineered to create other mixed topological phases from known codes.
The variance peak in TEN might signal a transition point between different mixed phases.
Similar anyon proliferation effects may occur in other quantum error correcting codes under targeted noise.

Load-bearing premise

The gauging procedure for mixed stabilizer states correctly identifies the emergent phase as a single toric code without missing additional effects from the decoherence channel.

What would settle it

A direct computation or measurement of the anyon content or logical operators in the maximally decohered state that fails to match those expected for a toric code.

Figures

Figures reproduced from arXiv: 2604.22521 by Ikuo Ichinose, Keisuke Kataoka, Takahiro Orito, Yoshihito Kuno.

**Figure 1.** Figure 1: FIG. 1. Schematic image of color code system. (a) Image of the lattice and the definitions of plaquette site, vertex and length of the system view at source ↗

**Figure 2.** Figure 2: FIG. 2. The color-code system for the analytical calculation of the view at source ↗

**Figure 3.** Figure 3: FIG. 3. The color-code system for the analytical calculation of the view at source ↗

**Figure 5.** Figure 5: FIG. 5. Subsystem complex used for calculation of the TEN. Bound view at source ↗

**Figure 8.** Figure 8: FIG. 8. Setting of the subsystems for the calculation of view at source ↗

**Figure 7.** Figure 7: FIG. 7. (Upper panel) The value of TEN, view at source ↗

**Figure 9.** Figure 9: FIG. 9. (a) Calculations of view at source ↗

read the original abstract

We study how the color code under decoherence gives rise to an intrinsic mixed-state topological order (imTO), which has no counterpart in pure ground states of local gapped Hamiltonians. For decoherence induced by XX-type operators on red links of the honeycomb lattice, we show that the resulting mixed state inherits half of the topological properties of the color code, including anyon content, logical operators, and topological entanglement structure. Using a gauging procedure for mixed stabilizer states, we identify the emergent phase as closely related to a single toric code. We characterize this phase by topological entanglement negativity (TEN) and perform efficient stabilizer-formalism simulations. While the pure color code has ${\rm TEN} = 2 \ln 2$, the maximally decohered state has ${\rm TEN} = \ln 2$, indicating emergence of a single toric code. By tuning the decoherence strength, we find a smooth crossover in TEN accompanied by a pronounced, nearly system-size-independent peak in its variance. We further show that the negativity exhibits characteristic scaling only for subsystem partitions commensurate with the triangular lattice of the emergent toric code. Our results demonstrate that negativity-based quantities provide powerful probes of mixed-state topological order generated by decoherence.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

Targeted XX decoherence on the color code produces a mixed state with toric-code anyon content and TEN halved to ln 2, diagnosed via stabilizer simulations and a variance peak.

read the letter

The paper shows that applying XX decoherence specifically to red links on the honeycomb lattice turns the color code into a mixed state that keeps half the original topological features, including anyon types and logical operators, and maps to a single toric code under their gauging procedure. In the strong-decoherence limit the topological entanglement negativity drops from 2 ln 2 to ln 2, and they see a system-size-independent peak in the variance of TEN at the crossover point. The negativity also scales properly only when the subsystem cut respects the emergent triangular lattice of the toric code. These are the concrete results from their stabilizer-formalism runs. The work is useful because it gives an explicit mechanism and a workable numerical diagnostic for how decoherence can create mixed-state order that has no pure-state parent. The simulations are efficient and the scaling checks add a useful consistency test. The gauging step for mixed stabilizer states is the part that carries the main claim, and while the abstract presents it as direct, the full paper would need to spell out the lattice partitioning and any assumptions about the channel to make the mapping fully transparent. The “intrinsic” label is reasonable for this setup but could be tightened by showing why the same halved order cannot appear in a closed Hamiltonian. Overall the numerics and the specific example are solid enough to stand on their own. This is for people already working on open-system topological phases or mixed-state order; a reader outside that niche will find the technical details heavy. It deserves a serious referee because the results are specific, the method is reproducible in principle, and the variance peak plus lattice-commensurate scaling give something concrete to check rather than just a new definition.

Referee Report

0 major / 3 minor

Summary. The manuscript studies decoherence of the color code on the honeycomb lattice via XX-type operators acting on red links. It claims that the resulting mixed state exhibits an intrinsic mixed-state topological order (imTO) that inherits half the topological properties of the pure color code, including anyon content, logical operators, and entanglement structure. A gauging procedure for mixed stabilizer states is used to identify the emergent phase as closely related to a single toric code. Topological entanglement negativity (TEN) is computed via stabilizer simulations, yielding TEN = 2 ln 2 for the pure color code and TEN = ln 2 for the maximally decohered state; a smooth crossover with a nearly system-size-independent variance peak is reported, together with partition-dependent scaling of the negativity.

Significance. If the central claims hold, the work advances the understanding of decoherence-induced intrinsic mixed-state topological order, which lacks a pure-state counterpart. Strengths include the exact TEN values (2 ln 2 to ln 2), the use of efficient stabilizer-formalism simulations to obtain concrete numerical results, the system-size-independent variance peak, and the demonstration that negativity scaling appears only for partitions commensurate with the emergent toric-code lattice. These provide falsifiable, negativity-based diagnostics for anyon proliferation in mixed topological phases and have implications for topological quantum error correction under decoherence.

minor comments (3)

[Gauging procedure] The gauging procedure for mixed stabilizer states is load-bearing for the phase identification; the main text should include an explicit step-by-step construction (or a clear reference to prior work) showing how the anyon content is halved and how the logical operators are inherited, including any assumptions on the decoherence channel.
[Numerical results] The abstract and results section report a 'nearly system-size-independent' variance peak in TEN; please add the specific system sizes simulated, the number of samples, error bars or statistical uncertainties, and the precise criterion used to identify the peak location.
[Topological entanglement negativity] The claim that negativity exhibits characteristic scaling 'only for subsystem partitions commensurate with the triangular lattice' would benefit from an explicit definition of the partitions used and a brief discussion of why incommensurate partitions fail to show the scaling.

Simulated Author's Rebuttal

0 responses · 0 unresolved

We thank the referee for their positive assessment of our manuscript and the recommendation for minor revision. The referee's summary accurately captures our central results on decoherence-induced intrinsic mixed-state topological order in the color code, the emergence of a single toric code, and the use of topological entanglement negativity as a diagnostic. We appreciate the recognition of the strengths, including the exact TEN values, stabilizer simulations, system-size-independent variance peak, and partition-dependent scaling. As no specific major comments were raised in the report, we will incorporate minor improvements in the revised version.

Circularity Check

0 steps flagged

No significant circularity; derivation relies on direct stabilizer simulations and independent gauging

full rationale

The paper's central results follow from explicit stabilizer-formalism simulations of the XX-decohered color code on the honeycomb lattice, followed by a gauging map applied to the resulting mixed stabilizer state and direct computation of topological entanglement negativity (TEN) for chosen partitions. The reduction from pure color code TEN = 2 ln 2 to maximal-decoherence TEN = ln 2 is obtained by evaluating the negativity formula on the decohered density matrix; it is not obtained by fitting a parameter or by renaming an input. The gauging procedure is invoked as a standard tool for mixed stabilizer states rather than a self-citation whose validity depends on the present work. No self-definitional loop, fitted-input-as-prediction, or ansatz-smuggled-via-citation appears in the derivation chain. The lattice-partition dependence of the negativity scaling is likewise a direct numerical observation, not a tautology.

Axiom & Free-Parameter Ledger

1 free parameters · 2 axioms · 0 invented entities

The central claim rests on the standard definition of the color code, the validity of the mixed-state gauging map, and the interpretation of TEN as a faithful probe of mixed topological order.

free parameters (1)

decoherence strength
Tuned continuously to observe the smooth crossover and variance peak in TEN.

axioms (2)

domain assumption The color code on the honeycomb lattice supports the stated anyon content and logical operators.
Standard background for topological stabilizer codes.
domain assumption Topological entanglement negativity correctly diagnoses the inherited topological order in the mixed state.
Central diagnostic used throughout the work.
