WATSON: Leveraging Data Watchpoints for Shadow Stack Protection on Embedded Systems

Xi Tan , Sagar Mohan , Ziming Zhao
Authors on Pith no claims yet

Pith reviewed 2026-05-12 01:30 UTC · model grok-4.3

classification 💻 cs.CR
keywords shadow stackembedded systemscontrol-flow integritydata watchpointsARM Cortex-Mreturn address protectionIoT securitymemory safety
0
0 comments X

The pith

Data watchpoints can be configured to write-protect shadow stacks, delivering system-wide return-address defense on embedded processors with under 8 percent overhead.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper seeks to prove that standard hardware data watchpoints, already present on most embedded CPUs, can enforce write protection on a shadow stack and thereby stop control-flow hijacks that target return addresses. Existing shadow-stack schemes for these devices either leave interrupts unprotected, impose high slowdowns, or require security extensions that many chips lack. If the approach holds, it would give practical control-flow integrity to memory-unsafe firmware on typical IoT hardware without extra silicon or large runtime costs.

Core claim

WATSON configures the address-matching logic inside the data watchpoint unit to trap any write that targets the shadow-stack memory region. This hardware check prevents an attacker from overwriting stored return addresses even when the processor is handling interrupts or exceptions. The resulting protection works on ARM Cortex-M devices, adds 7.33 percent slowdown on BEEBS and 1.81 percent on CoreMark-Pro, shows negligible cost on real applications and exception paths, and increases code size by at most 2.11 percent while remaining compatible with compiler forward-edge CFI.

What carries the argument

Data watchpoint unit configured to match the shadow-stack address range and block write attempts to it.

If this is right

  • Return-address overwrites aimed at the shadow stack are blocked by the hardware watchpoint trap.
  • Runtime overhead stays below 8 percent on standard embedded benchmark suites.
  • Exception and interrupt handling incur no measurable extra cost.
  • Worst-case code-size growth remains under 2.11 percent.
  • The protection composes directly with existing compiler forward-edge integrity passes.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • Architectures that expose similar address-matching debug units could adopt the same protection pattern with little redesign.
  • Developers could share watchpoint resources between security and debugging by adding a lightweight arbitration layer.
  • The technique opens a route to combine shadow-stack protection with other low-level hardware monitors already present on the chip.

Load-bearing premise

That data watchpoints can be reserved exclusively for shadow-stack protection without conflicts from other debug uses or across varied embedded applications and interrupt handlers.

What would settle it

A working control-flow hijack that overwrites a return address inside the protected shadow-stack region without triggering a watchpoint fault, or a benchmark run showing the watchpoint configuration itself produces unacceptable slowdown or compatibility breakage.

Figures

Figures reproduced from arXiv: 2605.08604 by Sagar Mohan, Xi Tan, Ziming Zhao.

Figure 1
Figure 1. Figure 1: WATSON Workflow: Components specific to WATSON are highlighted in green. A. Design Goals WATSON has several security and functional design goals. G1. Return address integrity. WATSON should ensure that return instructions always return to a legal address stored by the function prologue. G2. Interrupt-aware algorithm. WATSON should prevent po￾tential malicious exception handlers from compromising the system… view at source ↗
Figure 2
Figure 2. Figure 2: (b) shows, we use the compact shadow stack, which condenses the size of the shadow stack to store only the return addresses instead of duplicating the whole program main stack used by the parallel shadow stack. A challenge of using the compact shadow stack is that it requires maintaining a shadow stack pointer (ssp) to access the last entry on the shadow stack, which can be expen￾sive [41]. One method is t… view at source ↗
Figure 3
Figure 3. Figure 3: Code instrumentation for accessing comparator registers and [PITH_FULL_IMAGE:figures/full_fig_p005_3.png] view at source ↗
Figure 4
Figure 4. Figure 4: WATSON Code instrumentation for function prologue and epilogue. range, referred to ss_size, by either defining a mask register associated with ss_start (for ARMv7-M) or configuring an additional comparator to store the shadow stack’s ending address (for ARMv8-M). This range is predefined and remains static throughout the system’s operation. Third, to activate the write protection, WATSON i) enables write t… view at source ↗
Figure 6
Figure 6. Figure 6: shows that the function prologue phase incurs approximately 21 CPU cycles, with AW, USS, and ASSP accounting for 28.57%, 19.05%, and 14.29% of this overhead, respectively. The function epilogue takes 16 CPU cycles, with ASSP being the dominant contributor at 43.75%. This is expected, as the epilogue phase only requires read access to the shadow stack and does not involve changing WATSON configurations. The… view at source ↗
read the original abstract

Embedded and Internet-of-Things (IoT) devices play a critical role in modern life. Their software and firmware, often developed in memory-unsafe languages like C, are susceptible to memory safety vulnerabilities that can lead to control-flow hijacking attacks. Shadow stack is a defense mechanism against control-flow hijacking that targets return addresses. However, existing shadow stack solutions for embedded systems have the following limitations. First, they lack system-wide protection, particularly for interrupts and exceptions. Second, they introduce high performance overhead. Third, they depend on security extensions like a trusted execution environment, which are not universally available on embedded devices. Finally, they rely on hardware features that have inherent configurable constraints, which pose compatibility challenges when integrating security mechanisms that require similar hardware support. To overcome these limitations, we present WATSON, an efficient and effective shadow stack solution. It leverages a standard hardware debug unit named data watchpoints for shadow stack protection on embedded systems. To prevent unauthorized access to the shadow stack, WATSON leverages the address-matching features of the debug unit to enforce the write protection of the shadow stack. Additionally, WATSON is compatible with compiler options to enforce forward-edge control-flow integrity. We implemented a prototype of WATSON on the ARM CortexM architecture, and the concept also applies to other platforms. The introduced overhead is 7.33% and 1.81% on BEEBS and CoreMark-Pro benchmarks, respectively. We also evaluate WATSON on exception handling and two real-world applications, observing negligible performance overhead and a worst-case code size overhead of 2.11%. Furthermore, our security evaluation demonstrates that WATSON effectively prevents attacks.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

2 major / 2 minor

Summary. The paper presents WATSON, a shadow stack mechanism for embedded systems that uses the data watchpoint (DWT) features of the ARM Cortex-M debug unit to enforce write protection on a shadow stack region via address matching. It claims system-wide coverage (including interrupts/exceptions), compatibility with compiler-enforced forward-edge CFI, low overhead (7.33% on BEEBS, 1.81% on CoreMark-Pro), negligible overhead on exception handling and two real-world applications, worst-case code-size overhead of 2.11%, and effective prevention of control-flow hijacking attacks, all without requiring TEEs or non-standard hardware extensions.

Significance. If the central claims hold, WATSON would provide a practical defense against return-address corruption on resource-constrained embedded and IoT devices that lack TEE support, using only ubiquitous debug hardware. The concrete benchmark numbers, exception-handling measurements, and attack-prevention evaluation constitute a strength; the approach avoids self-referential parameter fitting and grounds the design in standard Cortex-M DWT comparators.

major comments (2)
  1. [§3 and §4] §3 (Design) and §4 (Implementation): the claim of exclusive DWT configuration for shadow-stack write protection is load-bearing for both the reported overhead figures and the 'no special extensions' assertion. The manuscript does not describe how the four DWT comparators are reserved, how state is saved/restored on debugger attachment or concurrent profiling, or how the protection handler distinguishes legitimate instrumented writes (e.g., via PC range check) from unauthorized ones when interrupts or other debug features are active.
  2. [§5] §5 (Evaluation): the security evaluation and overhead measurements (Table 2, BEEBS/CoreMark-Pro rows) assume uncontended DWT resources. No experiment or analysis is provided for the case in which a pre-existing watchpoint or range comparator is already in use, which would either disable protection or require additional context-switch overhead, directly affecting the 'negligible on real-world applications' and 'system-wide' claims.
minor comments (2)
  1. [Abstract] The abstract states that 'the concept also applies to other platforms' but supplies no concrete mapping or constraints for architectures whose debug units differ in comparator count or range semantics.
  2. [Figure 3] Figure 3 (or equivalent architecture diagram) would benefit from an explicit call-out of the DWT comparator allocation and the exact exception vector that invokes the protection handler.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the constructive and detailed feedback. The comments identify important clarifications needed in the design and evaluation sections. We address each point below and will revise the manuscript accordingly.

read point-by-point responses

  1. Referee: [§3 and §4] §3 (Design) and §4 (Implementation): the claim of exclusive DWT configuration for shadow-stack write protection is load-bearing for both the reported overhead figures and the 'no special extensions' assertion. The manuscript does not describe how the four DWT comparators are reserved, how state is saved/restored on debugger attachment or concurrent profiling, or how the protection handler distinguishes legitimate instrumented writes (e.g., via PC range check) from unauthorized ones when interrupts or other debug features are active.

    Authors: We acknowledge the need for greater detail on DWT resource management. WATSON configures the four DWT comparators exclusively at boot for shadow-stack write protection by setting address-match comparators and enabling the corresponding watchpoint events; this is performed once in the initialization routine before any application code runs. On debugger attachment, standard Cortex-M debug behavior disables or overrides DWT settings, and WATSON restores the protection configuration upon detachment via the debug monitor exception path. The protection handler distinguishes authorized writes by checking that the faulting PC lies within the pre-defined range of instrumented call sites (a simple bounds check on the PC value read from the exception frame); unauthorized writes trigger the full protection response. We will expand §3 and §4 with these mechanisms and a diagram of the initialization sequence. revision: yes

  2. Referee: [§5] §5 (Evaluation): the security evaluation and overhead measurements (Table 2, BEEBS/CoreMark-Pro rows) assume uncontended DWT resources. No experiment or analysis is provided for the case in which a pre-existing watchpoint or range comparator is already in use, which would either disable protection or require additional context-switch overhead, directly affecting the 'negligible on real-world applications' and 'system-wide' claims.

    Authors: We agree that the reported numbers reflect the uncontended case, which matches the intended deployment on embedded devices where DWT is not simultaneously used for profiling. In contended scenarios, WATSON can fall back to using the remaining available comparators or disable protection entirely, incurring either reduced coverage or the overhead of a context-switch to save/restore DWT state. We will add an explicit limitations paragraph in §5 discussing these trade-offs and their impact on the 'system-wide' claim, while noting that the primary target environments (bare-metal IoT firmware without concurrent debug) remain unaffected. No new benchmark runs are feasible within the revision timeline, but the qualitative analysis will be included. revision: partial

Circularity Check

0 steps flagged

No significant circularity; design and claims rest on external hardware features and benchmark measurements

full rationale

The paper describes an implementation of shadow-stack protection via standard ARM Cortex-M data watchpoint hardware, with compatibility to existing compiler CFI options. No equations, fitted parameters, or predictions appear in the abstract or described sections. Claims of overhead (7.33% on BEEBS, 1.81% on CoreMark-Pro) and security are tied to direct prototype measurements on external benchmarks and applications rather than any self-referential reduction or self-citation chain. The central premise (using address-matching watchpoints for write protection) is justified by the documented behavior of the DWT unit, which is an independent hardware specification. No load-bearing self-citations, ansatzes, or renamings of known results are present. This is a standard engineering evaluation against external workloads.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 0 invented entities

The central claim rests on the availability and exclusive usability of data watchpoints for protection; no free parameters are introduced and no new entities are postulated.

axioms (1)
  • domain assumption Data watchpoints in standard hardware debug units can be configured to enforce write protection on a designated shadow stack region without interfering with normal program execution or other system functions.
    This is the core enabling premise invoked for the protection mechanism and compatibility claims.
