A Visuo-Tactile Data Collection System with Haptic Feedback for Coarse-to-Fine Imitation Learning

Yeseung Kim , Nayoung Oh , Jun Park , Teetat Thamronglak , Daehyung Park
Authors on Pith no claims yet

Pith reviewed 2026-05-12 01:04 UTC · model grok-4.3

classification 💻 cs.RO
keywords visuo-tactile sensinghaptic feedbackimitation learningcoarse-to-fine learningmanipulation policiestemporal annotationdirect-drive grippercontact-rich demonstrations
0
0 comments X

The pith

A direct-drive gripper with real-time annotation fuses force sensing and task structure to produce datasets for coarse-to-fine imitation learning.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper describes a data collection system in which an operator actuates a gripper directly with the fingers, so contact forces reach the hand without mechanical decoupling. Visual and tactile sensors record the scene and contact geometry while a button on the gripper handle lets the operator mark important moments of the task as they happen. The resulting multimodal recordings carry both rich sensory streams and explicit temporal labels, which are intended for imitation learning methods that first acquire the overall task sequence and then refine the force details. Readers might care because many robot manipulation failures stem from poor force modulation, and demonstrations that retain the demonstrator's natural sense of touch could supply the missing information.

Core claim

The system uses a direct-drive gripper that the operator actuates with the fingers to preserve natural haptic feedback. Integrated visual sensors and custom tactile arrays capture image streams and contact geometry. A handle-mounted push button enables the operator to annotate the task's temporal structure in real time by marking task-critical regions. By fusing in-hand force perception with in-situ temporal annotation, the system produces multimodal datasets designed for coarse-to-fine learning algorithms that exploit structural task knowledge, enabling the development of high-quality manipulation policies.

What carries the argument

Direct-drive gripper that transmits contact forces to the operator's fingers, combined with visuo-tactile sensing and a push-button annotator for real-time marking of task phases.

If this is right

  • The collected demonstrations contain explicit temporal structure that coarse-to-fine algorithms can exploit directly.
  • In-hand force perception remains coupled to the operator's actions, supporting demonstration of variable contact forces.
  • The resulting datasets pair visual, tactile, and annotated temporal information in a single recording session.
  • High-quality manipulation policies become feasible for tasks that require precise force regulation during contact.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • Real-time annotation during collection could reduce the need for later manual segmentation of demonstration trajectories.
  • The preserved haptic channel might allow demonstrators to convey force profiles that are difficult to infer from vision or position alone.
  • The same hardware pattern could be adapted to record demonstrations for tasks with variable object properties, such as deformable or fragile items.

Load-bearing premise

The direct-drive gripper preserves natural haptic feedback well enough to let operators demonstrate subtle force changes more effectively than conventional teleoperation systems that separate the hand from contact forces.

What would settle it

A side-by-side comparison in which the same contact-rich task is demonstrated with both the direct-drive system and a conventional decoupled teleoperator, followed by training and testing of policies on force-sensitive success metrics to check whether the new data produces measurably superior force modulation.

Figures

Figures reproduced from arXiv: 2605.08757 by Daehyung Park, Jun Park, Nayoung Oh, Teetat Thamronglak, Yeseung Kim.

Figure 1
Figure 1. Figure 1: Overview of our visuo-tactile data collection system. (a) The hardware design, featuring direct-drive finger grips for haptic feedback, tactile sensors, a camera, and an annotation button. (b) Sample tactile readings from the left (L) and right (R) sensors during contact with different objects. The white boundary outlines the entire object, while the magenta overlay indicates the part occluded by the gripp… view at source ↗
Figure 2
Figure 2. Figure 2: Single-demonstration summary of the toy insertion task collected with our device: (a) gripper position trajectory (b) gripper width over time (c) images and tactile measurements of event frames. 3.3 Data Representation The collected dataset consists of time-aligned sequences of visual observations (i.e., images), 6-DoF end-effector poses, gripper widths, tactile readings, and critical-region labels [PITH_… view at source ↗
read the original abstract

We present a visuo-tactile data-collection system that generates temporally structured, contact-rich demonstrations for imitation learning. Conventional systems often decouple the operator from contact forces, which hinders the demonstration of subtle force modulation. Our system introduces a direct-drive gripper that the operator actuates with the fingers, preserving natural haptic feedback. Integrated visual sensors and custom tactile arrays capture image streams and contact geometry. A handle-mounted push button enables the operator to annotate the task's temporal structure in real time by marking task-critical regions. By fusing in-hand force perception with in-situ temporal annotation, the system produces multimodal datasets designed for coarse-to-fine learning algorithms that exploit structural task knowledge, enabling the development of high-quality manipulation policies.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

2 major / 0 minor

Summary. The paper presents a visuo-tactile data-collection system for imitation learning that uses a direct-drive gripper to preserve natural haptic feedback during operator demonstrations, combined with integrated visual sensors, custom tactile arrays, and a handle-mounted push button for real-time temporal annotation of task-critical regions. The resulting multimodal datasets are designed to support coarse-to-fine learning algorithms that exploit structural task knowledge for contact-rich manipulation tasks.

Significance. If the haptic-preservation and annotation mechanisms prove effective, the system could meaningfully improve demonstration quality for imitation learning in robotics by enabling operators to convey subtle force modulations that are typically lost in decoupled teleoperation setups, potentially leading to more robust policies for tasks requiring precise contact control.

major comments (2)
  1. [Abstract] Abstract: The central claim that the direct-drive gripper 'preserves natural haptic feedback' sufficiently to enable 'better demonstration of subtle force modulation than conventional decoupled systems' is load-bearing for the entire contribution, yet the manuscript supplies no force-transmission measurements, operator studies, or baseline comparisons to support it.
  2. [Abstract] Abstract: The assertion that the system 'enables the development of high-quality manipulation policies' via coarse-to-fine algorithms rests on untested design assumptions; no experimental results, policy training outcomes, or data-quality metrics are reported to validate that the collected datasets actually yield superior performance.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the detailed and constructive review. We agree that the abstract makes strong claims about haptic preservation and policy enablement that are not quantitatively validated in the current manuscript, which is primarily a system description paper. We will revise the abstract and add clarifications to better align claims with the presented scope and evidence. We respond to each major comment below.

read point-by-point responses

  1. Referee: [Abstract] Abstract: The central claim that the direct-drive gripper 'preserves natural haptic feedback' sufficiently to enable 'better demonstration of subtle force modulation than conventional decoupled systems' is load-bearing for the entire contribution, yet the manuscript supplies no force-transmission measurements, operator studies, or baseline comparisons to support it.

    Authors: We acknowledge that the manuscript provides no quantitative force-transmission data, operator studies, or direct comparisons to decoupled teleoperation systems. The direct-drive gripper is mechanically designed for direct finger actuation of the jaws to transmit contact forces without filtering intermediaries, which is described in the hardware section. We will revise the abstract to frame this as a design choice intended to preserve natural feedback, rather than asserting comparative superiority. We will also expand the gripper description with qualitative rationale and any available mechanical specifications to support the design intent. revision: partial

  2. Referee: [Abstract] Abstract: The assertion that the system 'enables the development of high-quality manipulation policies' via coarse-to-fine algorithms rests on untested design assumptions; no experimental results, policy training outcomes, or data-quality metrics are reported to validate that the collected datasets actually yield superior performance.

    Authors: The manuscript centers on the visuo-tactile collection hardware, sensors, and real-time annotation mechanism for producing structured multimodal demonstrations. No policy training, imitation learning experiments, or quantitative data-quality metrics are included, as these fall outside the scope of this system-focused work. The abstract statement is prospective, highlighting the data's intended suitability for coarse-to-fine algorithms that leverage temporal structure. We will revise the abstract to clarify that the system is designed to support such learning approaches without claiming empirical validation or superior performance in this paper. revision: yes

Circularity Check

0 steps flagged

No circularity: hardware proposal with no derivations or fitted predictions

full rationale

The paper describes a visuo-tactile data collection system and direct-drive gripper for generating imitation learning datasets. No mathematical derivations, equations, parameter fitting, predictions, or uniqueness theorems appear in the provided abstract or description. The central claims rest on engineering design choices and qualitative assertions about haptic feedback preservation, without any self-referential reductions, fitted inputs renamed as outputs, or load-bearing self-citations. The work is self-contained as a descriptive systems paper; external validation would require separate empirical comparisons, but none of the internal logic reduces to its own inputs by construction.

Axiom & Free-Parameter Ledger

0 free parameters · 0 axioms · 1 invented entities

This is an engineering system-description paper with no mathematical model, free parameters, or theoretical axioms; the components are standard robotics hardware assembled in a new configuration.

invented entities (1)
  • direct-drive gripper with haptic feedback no independent evidence
    purpose: To transmit contact forces directly to the human operator during demonstration
    Described as a core innovation but no independent evidence or prior validation is provided in the abstract.

pith-pipeline@v0.9.0 · 5436 in / 1167 out tokens · 45469 ms · 2026-05-12T01:04:19.786218+00:00 · methodology

discussion (0)

Sign in with ORCID, Apple, or X to comment. Anyone can read and Pith papers without signing in.

Lean theorems connected to this paper

Citations machine-checked in the Pith Canon. Every link opens the source theorem in the public Lean library.

What do these tags mean?
matches
The paper's claim is directly supported by a theorem in the formal canon.
supports
The theorem supports part of the paper's argument, but the paper may add assumptions or extra steps.
extends
The paper goes beyond the formal theorem; the theorem is a base layer rather than the whole result.
uses
The paper appears to rely on the theorem as machinery.
contradicts
The paper's claim conflicts with a theorem or certificate in the canon.
unclear
Pith found a possible connection, but the passage is too broad, indirect, or ambiguous to say the theorem truly supports the claim.

Reference graph

Works this paper leans on

25 extracted references · 25 canonical work pages · 1 internal anchor

  1. [1]

    In: Proceedings of Robotics: Science and Systems (RSS) (2023)

    Zhao, T.Z., Kumar, V., Levine, S., Finn, C.: Learning Fine-Grained Bimanual Manipulation with Low-Cost Hardware. In: Proceedings of Robotics: Science and Systems (RSS) (2023)

    work page 2023

  2. [2]

    In: Proceedings of the IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS) (2023)

    Li, X., Baum, M., Brock, O.: Augmentation enables one-shot generalization in learning from demonstration for contact-rich manipulation. In: Proceedings of the IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS) (2023)

    work page 2023

  3. [3]

    In: Proceedings of the IEEE International Conference on Robotics and Automation (ICRA) (2021)

    Johns, E.: Coarse-to-fine imitation learning: Robot manipulation from a single demonstration. In: Proceedings of the IEEE International Conference on Robotics and Automation (ICRA) (2021)

    work page 2021

  4. [4]

    Oh, N., Jang, J., Jung, M., Park, D.: DiSPo: Diffusion-ssm based policy learning for coarse-to-fine action discretization (2025), https://arxiv.org/abs/2409.14719

    work page arXiv 2025

  5. [5]

    In: Proceedings of Robotics: Science and Systems (RSS) (2023)

    Chi,C.,Xu,Z.,Feng,S.,Cousineau,E.,Du,Y.,Burchfiel,B.,Tedrake,R.,Song,S.: Diffusion policy: Visuomotor policy learning via action diffusion. In: Proceedings of Robotics: Science and Systems (RSS) (2023)

    work page 2023

  6. [6]

    In: Proceedings of Robotics: Science and Systems (RSS) (2024)

    Chi, C., Xu, Z., Pan, C., Cousineau, E., Burchfiel, B., Feng, S., Tedrake, R., Song, S.:Universalmanipulationinterface:In-the-wildrobotteachingwithoutin-the-wild robots. In: Proceedings of Robotics: Science and Systems (RSS) (2024)

    work page 2024

  7. [7]

    In: Proceedings of Conference on robot learning (CoRL) (2022)

    Zhu, Y., Joshi, A., Stone, P., Zhu, Y.: Viola: Imitation learning for vision-based manipulation with object proposal priors. In: Proceedings of Conference on robot learning (CoRL) (2022)

    work page 2022

  8. [8]

    In: Proceedings of Conference on robot learning (CoRL) (2024) Visuo-Tactile Data Collection System 7

    Yu, K., Han, Y., Wang, Q., Saxena, V., Xu, D., Zhao, Y.: Mimictouch: Leverag- ing multi-modal human tactile demonstrations for contact-rich manipulation. In: Proceedings of Conference on robot learning (CoRL) (2024) Visuo-Tactile Data Collection System 7

    work page 2024

  9. [9]

    In: Proceedings of Robotics: Science and Systems (RSS) (2025)

    Zhang, H., Hu, S., Yuan, Z., Xu, H.: Doglove: Dexterous manipulation with a low- cost open-source haptic force feedback glove. In: Proceedings of Robotics: Science and Systems (RSS) (2025)

    work page 2025

  10. [10]

    In: Proceedings of Conference on robot learning (CoRL) (2024)

    Huang, B., Wang, Y., Yang, X., Luo, Y., Li, Y.: 3D ViTac: Learning Fine-Grained Manipulation with Visuo-Tactile Sensing. In: Proceedings of Conference on robot learning (CoRL) (2024)

    work page 2024

  11. [11]

    In: Proceedings of the IEEE-RAS International Conference on Humanoid Robots

    Park, D., Kapusta, A., Hawke, J., Kemp, C.C.: Interleaving planning and control for efficient haptically-guided reaching in unknown environments. In: Proceedings of the IEEE-RAS International Conference on Humanoid Robots. pp. 809–816. IEEE (2014)

    work page 2014

  12. [12]

    Nature Communications15(08 2024)

    Mao, Q., Liao, Z., Yuan, J., Zhu, R.: Multimodal tactile sensing fused with vi- sion for dexterous robotic housekeeping. Nature Communications15(08 2024). https://doi.org/10.1038/s41467-024-51261-5

    work page doi:10.1038/s41467-024-51261-5 2024

  13. [13]

    Funk, N., Chen, C., Schneider, T., Chalvatzaki, G., Calandra, R., Peters, J.: On the importance of tactile sensing for imitation learning: A case study on robotic match lighting (2025), https://arxiv.org/abs/2504.13618

    work page internal anchor Pith review Pith/arXiv arXiv 2025

  14. [14]

    Communications En- gineering4(02 2025)

    Agarwal, A., Wilson, A., Man, T., Adelson, E., Gkioulekas, I., Yuan, W.: Vision- based tactile sensor design using physically based rendering. Communications En- gineering4(02 2025). https://doi.org/10.1038/s44172-025-00350-4

    work page doi:10.1038/s44172-025-00350-4 2025

  15. [15]

    In: Proceedings of Confer- ence on robot learning (CoRL) (2023)

    Guzey, I., Evans, B., Chintala, S., Pinto, L.: Dexterity from touch: Self-supervised pre-training of tactile representations with robotic play. In: Proceedings of Confer- ence on robot learning (CoRL) (2023)

    work page 2023

  16. [16]

    In: Proceedings of Conference on robot learning (CoRL) (2023)

    Wang, C., Fan, L., Sun, J., Zhang, R., Fei-Fei, L., Xu, D., Zhu, Y., Anandku- mar, A.: Mimicplay: Long-horizon imitation learning by watching human play. In: Proceedings of Conference on robot learning (CoRL) (2023)

    work page 2023

  17. [17]

    In: Proceedings of Conference on robot learning (CoRL) (2021)

    Wong, J., Tung, A., Kurenkov, A., Mandlekar, A., Fei-Fei, L., Savarese, S., Martín- Martín, R.: Error-aware imitation learning from teleoperation data for mobile ma- nipulation. In: Proceedings of Conference on robot learning (CoRL) (2021)

    work page 2021

  18. [18]

    In: Proceedings of Conference on robot learning (CoRL) (2019)

    Brown, D.S., Goo, W., Niekum, S.: Better-than-demonstrator imitation learning via automatically-ranked demonstrations. In: Proceedings of Conference on robot learning (CoRL) (2019)

    work page 2019

  19. [19]

    In: Proceedings of Conference on robot learning (CoRL) (2018)

    Mandlekar, A., Zhu, Y., Garg, A., Booher, J., Spero, M., Tung, A., Gao, J., Em- mons,J.,Gupta,A.,Orbay,E.,Savarese,S.,Fei-Fei,L.:Roboturk:Acrowdsourcing platform for robotic skill learning through imitation. In: Proceedings of Conference on robot learning (CoRL) (2018)

    work page 2018

  20. [20]

    In: Proceedings of Robotics: Science and Systems (RSS) (2024)

    Zhang, X., Boularias, A.: One-shot imitation learning with invariance matching for robotic manipulation. In: Proceedings of Robotics: Science and Systems (RSS) (2024)

    work page 2024

  21. [21]

    Montiel, J.M., D

    Campos, C., Elvira, R., Rodríguez, J.J.G., M. Montiel, J.M., D. Tardós, J.: Orb- slam3: An accurate open-source library for visual, visual–inertial, and multimap slam. IEEE Transactions on Robotics37(6), 1874–1890 (2021)

    work page 2021

  22. [22]

    In: Proc

    Park, D., Noseworthy, M., Paul, R., Roy, S., Roy, N.: Inferring task goals and constraints using bayesian nonparametric inverse reinforcement learning. In: Proc. Conf. on robot learning. vol. 100, pp. 1005–1014 (2020)

    work page 2020

  23. [23]

    IEEE Robotics and Automation Letters9(1), 279–286 (2023)

    Jang, J., Song, M., Park, D.: Inverse constraint learning and generalization by transferable reward decomposition. IEEE Robotics and Automation Letters9(1), 279–286 (2023)

    work page 2023

  24. [24]

    arXiv preprint arXiv:2507.11000 (2025)

    Cho,M.,Jang,J.,Park,D.:ILCL:Inverselogic-constraintlearningfromtemporally constrained demonstrations. arXiv preprint arXiv:2507.11000 (2025)

    work page arXiv 2025

  25. [25]

    Intelligent Service Robotics (2024)

    Kim, Y., Kim, D., Choi, J., Park, J., Oh, N., Park, D.: A survey on integration of large language models with intelligent robots. Intelligent Service Robotics (2024)

    work page 2024
