Ophiuchus: Incentivizing Tool-augmented "Think with Images" for Joint Medical Segmentation, Understanding and Reasoning

Recent medical MLLMs have made significant progress in generating step-by-step textual reasoning chains. However, they still struggle with complex clinical tasks that necessitate dynamic and iterative focusing on fine-grained visual regions. To close this gap, we introduce Ophiuchus, a versatile, tool-augmented framework that equips an MLLM to (i) decide when fine-grained visual evidence is needed, (ii) determine where to probe and ground within the medical image, and (iii) seamlessly weave the relevant sub-image content back into an interleaved, multimodal chain of thought for precise segmentation and diagnosis. Ophiuchus moves beyond mere tool-calling by tightly fusing the MLLM's inherent grounding and reasoning capabilities with external tools, enabling more accurate and trustworthy decisions. The core of our method is a three-stage training strategy: cold-start SFT for basic tool selection; self-reflection fine-tuning to strengthen decision revision; and agentic tool reinforcement learning to elicit sophisticated, expert-like diagnostic behaviors. Extensive experiments show that Ophiuchus consistently outperforms both closed-source and open-source SOTA methods across diverse medical benchmarks, including VQA, detection, and reasoning-based segmentation. Our project code is available at https://github.com/SII-zyj/Ophiuchus.
