Object Manipulation of the Variable Topology Truss system

Andrew Jang-Ho Bae , Myeongjin Choi , Haorui Li , Mark Yim , TaeWon Seo This is my paper

Pith reviewed 2026-05-14 18:52 UTC · model grok-4.3

classification 💻 cs.RO
keywords Variable Topology Trussobject manipulationhybrid controlforce feedbacktruss robotstatic modelposition and force control
0
0 comments X

The pith

A hybrid control framework enables reliable object manipulation in Variable Topology Truss systems by combining position and force regulation.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper presents a strategy for manipulating objects with truss robots that can change their topology. It uses a hybrid controller that handles both position and force at the same time without separating them explicitly. At the hardware level, each truss member uses force feedback from sensors to produce accurate axial forces even with friction. At the task level, a static model calculates what forces each member needs to apply to achieve the desired forces at the end-effector. Experiments on single members and full systems, including demonstrations with two different setups, show that this method achieves consistent position and force tracking for object manipulation.

Core claim

The proposed hybrid control framework regulates position and force concurrently without explicit decoupling. At the actuator level, sensor-based force feedback generates desired axial forces despite high friction. At the task level, a static model computes required member forces from end-effector forces. Experiments confirm consistent and reliable object manipulation with the VTT system in two representative configurations.

What carries the argument

The hybrid control framework using sensor-based force feedback controllers at each member and a static model of the VTT to compute member forces from desired end-effector forces.

If this is right

  • The VTT system can achieve reliable object manipulation tasks.
  • Force tracking performance is effective on both individual modules and the complete system.
  • Position and force can be controlled together in truss robots with passive joints.
  • The approach works across different truss configurations.
  • Quantitative assessment shows combined position and force tracking is achievable.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • Truss robots might be used for tasks requiring both precise positioning and force application in unstructured environments.
  • This control method could be adapted for other reconfigurable robotic structures beyond trusses.
  • Further work might explore real-time adaptation of the topology during manipulation.
  • Similar static models might simplify control in other cable or strut based systems.

Load-bearing premise

The static model of the VTT accurately computes the required member forces from the desired end-effector forces and the sensor-based force feedback can overcome high actuator friction.

What would settle it

An experiment where the VTT fails to maintain consistent force or position tracking during object manipulation despite using the proposed controllers would disprove the claim.

Figures

Figures reproduced from arXiv: 2605.13086 by Andrew Jang-Ho Bae, Haorui Li, Mark Yim, Myeongjin Choi, TaeWon Seo.

Figure 1
Figure 1. Figure 1: The conceptual rendering and hardware prototype of the VTT system; (a) 3D-rendered scene of search-and [PITH_FULL_IMAGE:figures/full_fig_p002_1.png] view at source ↗
Figure 2
Figure 2. Figure 2: Picture of a member module in the VTT system [PITH_FULL_IMAGE:figures/full_fig_p003_2.png] view at source ↗
Figure 3
Figure 3. Figure 3: The CAD modeling of the spiral zipper actuator [PITH_FULL_IMAGE:figures/full_fig_p004_3.png] view at source ↗
Figure 4
Figure 4. Figure 4: The control architecture of the VTT system [PITH_FULL_IMAGE:figures/full_fig_p004_4.png] view at source ↗
Figure 5
Figure 5. Figure 5: Mathematical schematics of the VTT system in a tetrahedral configuration. Black circles represent the nodes [PITH_FULL_IMAGE:figures/full_fig_p005_5.png] view at source ↗
Figure 6
Figure 6. Figure 6: Block diagram of the hybrid position/force control for object manipulation using the VTT system. [PITH_FULL_IMAGE:figures/full_fig_p005_6.png] view at source ↗
Figure 7
Figure 7. Figure 7: Two manipulation configuration of VTT. (a) Schematic of the double tetrahedral configuration; (b) Picture [PITH_FULL_IMAGE:figures/full_fig_p007_7.png] view at source ↗
Figure 8
Figure 8. Figure 8: Experimental setups for force control evaluation. Orange components indicate the force measurement devices [PITH_FULL_IMAGE:figures/full_fig_p008_8.png] view at source ↗
Figure 9
Figure 9. Figure 9: Experimental results of force control of the Spiral-Zipper under ramp input signals of [PITH_FULL_IMAGE:figures/full_fig_p008_9.png] view at source ↗
Figure 10
Figure 10. Figure 10: Experimental results of force control in the tetrahedral topology under target forces ranging from [PITH_FULL_IMAGE:figures/full_fig_p009_10.png] view at source ↗
Figure 11
Figure 11. Figure 11: Experimental results of xy plane grab manipulation with two tetrahedron VTT. (a) 3D trajectory. (b) Internal [PITH_FULL_IMAGE:figures/full_fig_p011_11.png] view at source ↗
Figure 12
Figure 12. Figure 12: Experimental results of xyz plane grab manipulation with two tetrahedron VTT. (a) 3D trajectory. (b) [PITH_FULL_IMAGE:figures/full_fig_p012_12.png] view at source ↗
Figure 13
Figure 13. Figure 13: Snapshots of the double tetrahedron VTT manipulation experiment. (a) 0:00 min; (b) 0:18 min; (c) 0:42 min; [PITH_FULL_IMAGE:figures/full_fig_p013_13.png] view at source ↗
Figure 14
Figure 14. Figure 14: Snapshots of the double tetrahedron VTT manipulation experiment. (a) 0:00 min; (b) 1:13 min; (c) 1:52 min; [PITH_FULL_IMAGE:figures/full_fig_p015_14.png] view at source ↗
read the original abstract

This paper presents an object manipulation strategy for the Variable Topology Truss (VTT) system, a truss robot that comprises actuated truss members connected by passive spherical joints. Although truss robots were originally proposed as rapidly deployable manipulators, manipulation strategy has not been studied thoroughly. To enable manipulation, we introduce a hybrid control framework that regulates position and force concurrently without explicit decoupling. At the actuator level, each member employs a sensor-based force feedback controller to generate the desired axial forces despite high actuator friction. At the task level, the forces applied at the end-effector nodes are produced by computing the required member forces using a static model of the VTT. We evaluate force-tracking performance through experiments on both a single member module and the full VTT system. Finally, we demonstrate object manipulation using two representative configurations and quantitatively assess combined position and force tracking performance. Experimental results confirm that the proposed approach enables consistent and reliable object manipulation with the VTT system.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

1 major / 1 minor

Summary. The paper presents a hybrid control framework for object manipulation with the Variable Topology Truss (VTT) system, combining actuator-level sensor-based force feedback to overcome high friction with task-level computation of member forces via a static model of the VTT to produce desired end-effector forces. Experiments evaluate force-tracking on a single member and the full system, followed by demonstrations of object manipulation in two configurations with quantitative assessment of combined position and force tracking, concluding that the approach enables consistent and reliable performance.

Significance. If the static model inversion remains accurate under real joint friction and topology changes, this work would advance truss robots beyond deployment toward practical manipulation tasks by providing a concurrent position-force control strategy without explicit decoupling. The hardware experiments on both single-module and full-system setups constitute a concrete strength, offering direct evidence of feasibility that is rare in truss-robot literature.

major comments (1)
  1. [Abstract and Experiments] The central claim that the static model correctly inverts desired end-effector forces into member forces (abstract) is load-bearing yet lacks isolated validation. The single-member force-tracking tests and two-configuration demonstrations do not separate model accuracy from low-level controller effects; if passive-joint friction or geometric compliance is omitted, computed forces will be systematically biased and actuator feedback cannot correct errors at the wrong nodes.
minor comments (1)
  1. [Results] The quantitative assessment of combined position and force tracking would be strengthened by reporting error bars, standard deviations, or repeated-trial statistics rather than qualitative statements of consistency.

Simulated Author's Rebuttal

1 responses · 0 unresolved

We thank the referee for the constructive feedback on our manuscript describing the hybrid control framework for object manipulation with the Variable Topology Truss system. We address the major comment point by point below.

read point-by-point responses

  1. Referee: [Abstract and Experiments] The central claim that the static model correctly inverts desired end-effector forces into member forces (abstract) is load-bearing yet lacks isolated validation. The single-member force-tracking tests and two-configuration demonstrations do not separate model accuracy from low-level controller effects; if passive-joint friction or geometric compliance is omitted, computed forces will be systematically biased and actuator feedback cannot correct errors at the wrong nodes.

    Authors: We agree that explicit isolation of the static model's accuracy would strengthen validation of the central claim. The single-member experiments isolate and confirm the actuator-level force feedback controller's ability to achieve desired axial forces despite friction. In the full-system experiments, member forces are computed directly from the static model inversion of desired end-effector forces and then tracked; the reported quantitative position and force tracking results at the end-effector nodes therefore provide evidence that the overall inversion and control loop perform as intended for the tested configurations and loads. We acknowledge that unmodeled effects such as passive-joint friction or compliance could introduce bias, and the current experiments do not fully decouple these from controller performance. To address this, we will add a dedicated discussion subsection on static model validation, including analysis of potential discrepancies and how closed-loop tracking mitigates them, along with any available measured-versus-computed force comparisons from the existing data. This constitutes a partial revision. revision: partial

Circularity Check

0 steps flagged

No circularity: static model and feedback validated experimentally

full rationale

The derivation relies on standard truss statics to invert end-effector forces into member forces, paired with independent sensor-based force feedback at the actuator level. Experiments on single-member tracking and full-system manipulation provide external validation rather than self-referential fitting. No self-definitional equations, fitted inputs renamed as predictions, or load-bearing self-citations that reduce the central claim to its own inputs appear in the provided text. The approach is self-contained against physical benchmarks.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 0 invented entities

The paper's central claim rests on the validity of the static model and the effectiveness of the force feedback controller, which are standard in robotics but specifics are not detailed here.

axioms (1)
  • domain assumption The static model of the VTT can be used to compute member forces from end-effector forces
    Central to the task-level control as per abstract.

pith-pipeline@v0.9.0 · 5471 in / 1179 out tokens · 94951 ms · 2026-05-14T18:52:44.632774+00:00 · methodology

discussion (0)

Sign in with ORCID, Apple, or X to comment. Anyone can read and Pith papers without signing in.

Reference graph

Works this paper leans on

26 extracted references · 26 canonical work pages

  1. [1]

    Variable geometry truss and its application to deployable truss and space crane arm.Acta Astronautica, 12(7-8):599–607, 1985

    Koryo Miura, Hiroshi Furuya, and Kenichi Suzuki. Variable geometry truss and its application to deployable truss and space crane arm.Acta Astronautica, 12(7-8):599–607, 1985

    work page 1985

  2. [2]

    Trussarm—a variable-geometry-truss manipulator

    Peter C Hughes, Wayne G Sincarsin, and Kieran A Carroll. Trussarm—a variable-geometry-truss manipulator. Journal of Intelligent Material Systems and Structures, 2(2):148–160, 1991

    work page 1991

  3. [3]

    Tetrobot: A modular approach to parallel robotics.IEEE Robotics & Automation Magazine, 4(1):42–50, 1997

    Gregory J Hamlin and Arthur C Sanderson. Tetrobot: A modular approach to parallel robotics.IEEE Robotics & Automation Magazine, 4(1):42–50, 1997

    work page 1997

  4. [4]

    Dynamic rolling locomotion and control of modular robots.IEEE Transactions on robotics and automation, 18(1):32–41, 2002

    Woo Ho Lee and Arthur C Sanderson. Dynamic rolling locomotion and control of modular robots.IEEE Transactions on robotics and automation, 18(1):32–41, 2002. 13 APREPRINT- MAY14, 2026

    work page 2002

  5. [5]

    Tetrahedral robotics for space exploration

    Steven Curtis, Matthew Brandt, Greg Bowers, Gary Brown, Cynthia Cheung, Caner Cooperider, Mike Desch, Noah Desch, John Dorband, Kyle Gregory, et al. Tetrahedral robotics for space exploration. In2007 IEEE Aerospace Conference, pages 1–9. IEEE, 2007

    work page 2007

  6. [6]

    Inverse kinematics of variable-geometry truss manipulators.Journal of Robotic Systems, 8(2):249–266, 1991

    Frank Naccarato and Peter Hughes. Inverse kinematics of variable-geometry truss manipulators.Journal of Robotic Systems, 8(2):249–266, 1991

    work page 1991

  7. [7]

    Adaptive truss manipulator space crane concept.Journal of Spacecraft and Rockets, 30(1):111–115, 1993

    Gun-Shing Chen and Ben K Wada. Adaptive truss manipulator space crane concept.Journal of Spacecraft and Rockets, 30(1):111–115, 1993

    work page 1993

  8. [8]

    A hyper-redundant manipulator.IEEE Robotics & Automation Magazine, 1(4):22–29, 1994

    Gregory S Chirikjian and Joel W Burdick. A hyper-redundant manipulator.IEEE Robotics & Automation Magazine, 1(4):22–29, 1994

    work page 1994

  9. [9]

    Inverse kinematics for the variable geometry truss manipulator via a lagrangian dual method.International Journal of Advanced Robotic Systems, 13(6):1729881416666779, 2016

    Yanchun Zhao, Shiqiang Hu, and Yongsheng Yang. Inverse kinematics for the variable geometry truss manipulator via a lagrangian dual method.International Journal of Advanced Robotic Systems, 13(6):1729881416666779, 2016

    work page 2016

  10. [10]

    Space variable geometry truss manipulator experimental system design and implementation

    Dingdong Shen and Shiqiang Hu. Space variable geometry truss manipulator experimental system design and implementation. InProceedings of the 2017 International Conference on Mechatronics Systems and Control Engineering, pages 15–19, 2017

    work page 2017

  11. [11]

    An untethered isoperimetric soft robot.Science Robotics, 5(40), 2020

    Nathan S Usevitch, Zachary M Hammond, Mac Schwager, Allison M Okamura, Elliot W Hawkes, and Sean Follmer. An untethered isoperimetric soft robot.Science Robotics, 5(40), 2020

    work page 2020

  12. [12]

    Grasp analysis and manipulation kinematics for isoperimetric truss robots

    Zachary M Hammond, Nathan S Usevitch, and Sean Follmer. Grasp analysis and manipulation kinematics for isoperimetric truss robots. In2021 IEEE International Conference on Robotics and Automation (ICRA), pages 6140–6146. IEEE, 2021

    work page 2021

  13. [13]

    Dynamics of closed linked variable geometry truss manipulators.Acta astronautica, 36(5):251–259, 1995

    Hiroshi Furuya and Kenichi Higashiyama. Dynamics of closed linked variable geometry truss manipulators.Acta astronautica, 36(5):251–259, 1995

    work page 1995

  14. [14]

    Dynamics and control of variable-geometry truss structures.Acta Astronautica, 45(12):717–728, 1999

    BA Boutin, Arun K Misra, and VJ Modi. Dynamics and control of variable-geometry truss structures.Acta Astronautica, 45(12):717–728, 1999

    work page 1999

  15. [15]

    Design of a modular hydraulically driven variable geometry truss structure and its nonlinear controller architecture for highly dexterous motion

    Sven Rost, Yevgen Sklyarenko, Frank Schreiber, and Walter Schumacher. Design of a modular hydraulically driven variable geometry truss structure and its nonlinear controller architecture for highly dexterous motion. In 8th International Fluid Power Conference, 2012

    work page 2012

  16. [16]

    Force, compliance and position control for a space frame manipulator

    Samuel N Cubero and John Billingsley. Force, compliance and position control for a space frame manipulator. In Proceedings F ourth Annual Conference on Mechatronics and Machine Vision in Practice, pages 124–129. IEEE, 1997

    work page 1997

  17. [17]

    Topological reconfiguration planning for a variable topology truss.Journal of Mechanisms and Robotics, 13(4):040901, 2021

    Alexander Spinos, Devin Carroll, Terry Kientz, and Mark Yim. Topological reconfiguration planning for a variable topology truss.Journal of Mechanisms and Robotics, 13(4):040901, 2021

    work page 2021

  18. [18]

    Design of a spherical robot arm with the spiral zipper prismatic joint

    Foster Collins and Mark Yim. Design of a spherical robot arm with the spiral zipper prismatic joint. In2016 IEEE international conference on robotics and automation (ICRA), pages 2137–2143. IEEE, 2016

    work page 2016

  19. [19]

    Slip modeling and simulation of spiral zipper friction-driven prismatic actuator

    Seohyeon Lee, Sahoon Ahn, Devin Carroll, Mark Yim, and TaeWon Seo. Slip modeling and simulation of spiral zipper friction-driven prismatic actuator. In2021 IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS), pages 9347–9352. IEEE, 2021

    work page 2021

  20. [20]

    Optimization-based nonimpact rolling locomotion of a variable geometry truss.IEEE Robotics and Automation Letters, 4(2):747–752, 2019

    Sumin Park, Eugene Park, Mark Yim, Jongwon Kim, and TaeWon Seo. Optimization-based nonimpact rolling locomotion of a variable geometry truss.IEEE Robotics and Automation Letters, 4(2):747–752, 2019

    work page 2019

  21. [21]

    Polygon-based random tree search planning for variable geometry truss robot.IEEE Robotics and Automation Letters, 5(2):813–819, 2020

    Sumin Park, Jangho Bae, Seohyeon Lee, Mark Yim, Jongwon Kim, and TaeWon Seo. Polygon-based random tree search planning for variable geometry truss robot.IEEE Robotics and Automation Letters, 5(2):813–819, 2020

    work page 2020

  22. [22]

    Polygon-based random tree search algorithm for a size-changing robot.IEEE Robotics and Automation Letters, 2021

    Jangho Bae, Sumin Park, Mark Yim, and Taewon Seo. Polygon-based random tree search algorithm for a size-changing robot.IEEE Robotics and Automation Letters, 2021

    work page 2021

  23. [23]

    Locomotion planning of a truss robot on irregular terrain

    Jangho Bae, Inha Park, Mark Yim, and TaeWon Seo. Locomotion planning of a truss robot on irregular terrain. In 2023 IEEE/RSJ International Conference on Intelligent Robots and Systems (IROS), pages 824–829. IEEE, 2023

    work page 2023

  24. [24]

    Towards a variable topology truss for shoring

    Alexander Spinos and Mark Yim. Towards a variable topology truss for shoring. In2017 14th International Conference on Ubiquitous Robots and Ambient Intelligence (URAI), pages 244–249. IEEE, 2017

    work page 2017

  25. [25]

    The role of dynamic models in cartesian force control of manipulators.The International Journal of Robotics Research, 8(4):51–72, 1989

    Chae H An and John M Hollerbach. The role of dynamic models in cartesian force control of manipulators.The International Journal of Robotics Research, 8(4):51–72, 1989

    work page 1989

  26. [26]

    Hybrid position/force control: A correct formulation.The International journal of robotics research, 11(4):299–311, 1992

    William D Fisher and M Shahid Mujtaba. Hybrid position/force control: A correct formulation.The International journal of robotics research, 11(4):299–311, 1992. 14 APREPRINT- MAY14, 2026 (a) (b) (c) (d) (e) (f) Figure 14: Snapshots of the double tetrahedron VTT manipulation experiment. (a) 0:00 min; (b) 1:13 min; (c) 1:52 min; (d) 3:31 min; (e) 4:23 min; ...

    work page 1992
