BCS-BEC crossover driven by small Fermi pockets of a high-Tc cuprate superconductor

Fermi arcs observed in underdoped cuprates have sparked debate over whether they represent segments of a large Fermi surface or small Fermi pockets. This ambiguity has long hindered their classification as either the conventional Bardeen-Cooper-Schrieffer (BCS) regime or the strongly coupled Bose-Einstein condensation (BEC) crossover limit. Here, using angle-resolved photoemission spectroscopy and quantum oscillations, we demonstrate the coexistence of a small Fermi pocket and a large superconducting gap in the clean inner CuO2 layers of the four-layer cuprate Ba2Ca3Cu4O8(F,O)2. This coexistence constitutes a hallmark of the BCS-BEC crossover and has remained elusive for decades. Despite the presence of antiferromagnetic (AF) order, the superconducting gap in the small pocket is remarkably large, yielding a gap-to-Fermi-energy ratio (Delta_pocket/e_F ~ 0.6) and a critical-to-Fermi-temperature ratio (Tc/TF ~ 1.3) that reach the theoretical upper bound for two-dimensional superconductivity. Unexpectedly, this BCS-BEC crossover emerges not as the carrier density decreases but as it increases, abruptly within a narrow doping range of less than 1%. These results provide a long-sought microscopic foundation for the d-wave pairing mechanism in doped AF-Mott insulators.
