REVIEW 3 major objections 6 minor 33 references
KisMATH: Do LLMs Have Knowledge of Implicit Structures in Mathematical Reasoning?
T0 review · 3 major / 6 minor · reviewed 2026-08-06 · deepseek-v4-flash
Pith's one-line read Chain-of-thought math reasoning is causal, not decoration: the paper argues that intermediate mathematical expressions in LLM reasoning traces are genuine mediators of the final answer, and that models internally favor the same derivation…
desk verdict Solid dataset and a consistently supported narrow mediation claim, but the rank test for internal graph realization uses a mismatched baseline and the causal framing overshoots; worth a serious referee with revisions. read the letter →
The pith
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
The reading
What carries the argument
The carrying object is the Causal CoT Graph (CCGraph), a directed acyclic graph whose nodes are mathematical expression spans parsed from the question, reasoning trace, and answer, and whose edges connect expressions that share a parse-tree component or exact string match. Construction starts at the answer node, recursively matches earlier spans, prunes nodes with no path to a question node, and reverses edges. Two probes drive the analysis: attention suppression, which zeroes out the influence of reasoning-node tokens across all layers and heads to model their absence, and path probability, which multiplies token-level probabilities along an R-path and compares its rank against equal-length random paths. These two operations turn the abstract hypothesis that intermediate math matters into measurable entropy shifts and rank distributions.
What would settle it
Run attention suppression on CCGraph reasoning nodes versus equal-length sequences of math tokens that are not on the graph, matched for token frequency and position in the same trace; if the entropy shifts are statistically indistinguishable, the mediation effect is not specific to the graph-aligned structure. Alternatively, compute R-path ranks against random paths that contain only math tokens drawn from the same trace; if the 100th-percentile spike disappears, the path-emphasis result reflects arithmetic predictability rather than implicit graph realization.
Extended reading notes
Core claim
On the paper's own terms, the central discovery is that causal CoT graphs extracted from solution traces capture dependencies that matter to the models. Suppressing attention to reasoning-node tokens raises the entropy of the first answer token substantially across all 15 tested models, with reported p-values below 1e-12, so the answer distribution is causally sensitive to those intermediate expressions. In addition, the probability of a graph-aligned reasoning path ranks at or near the 100th percentile against random paths of the same length, indicating that models favor the exact derivation chains the graphs identify. The authors interpret the mediation result as a necessary condition for reasoning and the path-probability result as evidence that structures similar to the graphs are internally realized.
Load-bearing premise
Attention suppression is assumed to faithfully implement the counterfactual that the suppressed reasoning tokens were absent, and if zeroing those attention weights pushes the models off-distribution, the large entropy shift is not necessarily a causal effect.
Editorial extensions
If this is right
- Answer distributions of LLMs are causally tied to intermediate mathematical expressions, so chain-of-thought traces play a functional role rather than being post-hoc decoration.
- Graph-aligned interventions, such as suppressing a single reasoning node, give a controlled way to change or probe an answer, far more precise than random token perturbation.
- CCGraphs provide a scalable automatic annotation method for mathematical reasoning traces, enabling dataset-scale studies of reasoning structure and comparison across models.
- The two observed regimes in path-probability ranks, exponential and bell-shaped, tie a model's internal uncertainty along reasoning paths to exploration behavior and pass@k performance.
Reading between the lines
- The same extraction procedure could be extended beyond parsed math expressions to symbolic or logical expressions in code, formal proofs, or scientific derivations, turning the graph test into a general probe for compositional reasoning.
- If the mediation finding is robust, inference-time interventions that upweight graph-aligned reasoning tokens, or training objectives that reward them, might improve answer reliability in multi-step mathematics.
- The random-path baseline in the path-probability experiment compares math-token spans to prose-token spans; matching random paths to math tokens of similar frequency would separate arithmetic predictability from graph alignment.
- The bell-shaped regime suggests a testable scheme: deliberately inserting high-entropy fork tokens could increase rollout diversity and pass@k, provided the causal interpretation of those forks is correct.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The paper proposes Causal CoT Graphs (CCGraphs), automatically extracted from LLM-generated reasoning traces, and introduces KisMATH, a dataset of 1,671 mathematical reasoning problems (GSM8K, MATH500, AIME) paired with such graphs. Using attention suppression and path-probability rank tests across 15 open-weight LLMs, it claims (i) that reasoning nodes in CCGraphs are causal mediators of the final answer, and (ii) that LLMs assign higher probability to CCGraph-identified reasoning paths than to random token paths, suggesting that the models internally realize structures similar to the graphs. It also identifies two behavioral regimes in path-probability distributions and connects them to exploration behavior in sampling.
Significance. The manuscript's main strengths are its scale and reproducibility: it constructs graphs for 1,671 problems and tests 15 models, far exceeding prior annotated datasets of 10–30 traces, and it publicly releases data, code, and prompts. The mediation analysis in Section 5.1 is consistently supported across models, and the framing of indirect effect as a necessary condition for reasoning is a useful conceptual contribution. However, the second headline claim (ii) rests on a rank test whose baseline is not matched for token type, and the causal reading of attention suppression is imported from prior work without on-model diagnostics. These issues weaken the strongest conclusions, but they are addressable within the manuscript's scope and do not undermine the dataset or the mediation finding.
major comments (3)
- [Section 5.3, Eq. (5)–(6), Figures 4/8] The random-path baseline is token-type mismatched. R paths are sequences of parsed mathematical expressions, while random paths are defined as equal-length token sequences from the same trace 'avoiding CCGraph nodes'; since CCGraph nodes constitute essentially all parseable mathematical content on question-to-answer dependency paths, the random-path tokens are almost exclusively natural-language tokens. Eq. (5) multiplies conditional token probabilities, and the two token classes have different systematic predictability: math tokens are often formulaic and reuse numerals/variables from the question, while prose tokens include connectives and function words. The observed 100th-percentile rank spike could therefore reflect arithmetic-token predictability rather than alignment with the specific CCGraph paths. Because claim (ii) in the abstract directly rests on this test, a matched control is required—for example, random paths with identical math-token density drawn from the same trace, or a shuffle of math tokens that are not part of R paths.
- [Section 4, Eqs. (2)–(3), used in Sections 5.1–5.2 and 6.1] The attention-suppression intervention assumes that zeroing attention from a token set across all layers and heads implements the counterfactual 'these tokens were absent.' The paper cites Bogdan et al. (2025) for the assertion that this does not induce out-of-distribution behavior, but that validation was performed on a different set of models; no such diagnostic is provided for the 15 open-weight LLMs studied here. If the intervention pushes the model into an OOD activation regime, the large entropy increases in Table 2 and Figure 3 would be expected regardless of the suppressed tokens' causal role. The authors should add a control, such as suppressing an equal number of randomly chosen tokens not on the CCGraph, or comparing against substitution with placeholders, to support the causal interpretation.
- [Section 3.1, Algorithm 1 and MATCH rule] The edge criterion 'their parse trees share a common node' is permissive; any shared numeral or symbol can create an edge, and the resulting graph is not validated against human-annotated dependencies, in contrast to the small-scale graphs of Tan (2023), Lee et al. (2025), and Bogdan et al. (2025). The manual intervention for approximately 10% of trivial graphs, also described in the Limitations, is a potential source of bias since it is not given as a fully automated rule. Because R paths are selected from these graphs and feed the main rank test, an independent validation of CCGraph edges, or a sensitivity analysis using a stricter MATCH rule, is needed to rule out that the rank spike reflects general math-token predictability rather than the specific graph structure.
minor comments (6)
- [Title/Abstract/body] The dataset name appears as 'KisMA TH' in the title, abstract, and several places in the body due to a spacing artifact; please correct to 'KisMATH' throughout.
- [Section 5.3, Eq. (6)] The definition of rank_M(R) is a fraction between 0 and 1, but the text reports '100th percentile'; state explicitly how rank values map to percentiles (e.g., rank = 1.0 corresponds to the 100th percentile).
- [Section 3.1, Algorithm 1] The EXPAND procedure terminates when the context is fully composed of question nodes, but it is not clear whether question-to-question edges are ever added before that point; a small worked example of the graph-construction steps would improve clarity.
- [Section 6.1, Table 3] The multiple-comparison correction used to set α' = 2.2e-4 is not described; please state the method (e.g., Bonferroni) in the text or caption.
- [Figure 5] The two panels in Figure 5 lack a clear legend distinguishing DeepSeek R1 32B from Qwen3 32B; add direct labels or split the panels explicitly.
- [Appendix C, Figure 9(a)] The GSM8K wrong-label example uses the bracket notation 'Ground Truth:150 [240]' without explanation; clarify that 240 is the corrected ground truth.
Circularity Check
No circularity: CCGraph construction is independent of the probed models, and both headline results are empirical measurements with no fitted parameter or self-citation chain forcing them.
full rationale
CCGraphs are extracted from OpenAI o3 traces by Algorithm 1: spans are parsed with SymPy and edges are added only when two parsed expressions match exactly or share a parse-tree node, expanding recursively from the answer to question nodes. This construction does not use the 15 open-weight models, their answer entropies, or their token probabilities, so the later measurements are not definitional echoes of the graph builder. The mediation experiments (Sections 5.1 and 5.2) apply attention suppression from Bogdan et al. (2025) to pre-defined graph nodes and record entropy shifts; no parameter is fitted from the entropy data to define the nodes. The R-path realization test (Section 5.3) computes token-level conditional probabilities (Eqs. 4-5) and compares R paths against random paths; a 100th-percentile spike is an empirical outcome that could have failed to occur. The paper does depend on two assumptions that are not circular: that attention suppression is a valid counterfactual intervention without out-of-distribution artifacts (cited to Bogdan et al. 2025), and that random paths avoiding CCGraph nodes are a matched baseline. The second assumption is questionable—CCGraph nodes are mostly mathematical expressions while non-CCGraph tokens are largely natural language, so the rank contrast may partly reflect token-type predictability rather than graph alignment—but this is a validity/correctness concern, not a circular reduction: the high rank of R paths is not entailed by the definitions alone. The authors' self-citations (Asher and Lascarides 2003; Sharma et al. 2025) are used as background and contrast and are not load-bearing. Accordingly, no circular step meets the quoted-reduction bar.
Assumptions & free parameters
free parameters (3)
- k (number of longest Q-to-A paths analyzed) =
5 (GSM8K), 10 (MATH500, AIME)
- MATCH rule for edges =
exact string match or shared SymPy parse-tree node
- Random-path baseline construction =
same token count as R path, tokens avoiding CCGraph nodes
assumptions (5)
- domain assumption Attention suppression (Eqs. 2-3) validly implements the counterfactual absence of the suppressed tokens without problematic OOD behavior
- domain assumption String or parse-tree overlap between expressions indicates a causal dependency
- domain assumption o3-generated traces are valid stand-ins for reasoning structure when probing other models
- ad hoc to paper Manual intervention on ~10% trivial graphs does not bias the graphs
- domain assumption Token-level probability product (Eq. 5) is a meaningful proxy for path likelihood
invented entities (1)
-
Causal CoT Graph (CCGraph)
Cite this review
Pith. "Pith review of KisMATH: Do LLMs Have Knowledge of Implicit Structures in Mathematical Reasoning?." pith.science (2026). https://pith.science/paper/XOHHC2MO
@misc{pith2026250711408,
author = {Pith},
title = {Pith review of: KisMATH: Do LLMs Have Knowledge of Implicit Structures in Mathematical Reasoning?},
year = {2026},
howpublished = {\url{https://pith.science/paper/XOHHC2MO}},
note = {Machine review of arXiv:2507.11408}
}
read the original abstract
Chain-of-thought (CoT) traces have been shown to improve performance of large language models on a plethora of reasoning tasks, yet there is no consensus on the mechanism by which this boost is achieved. To shed more light on this, we introduce Causal CoT Graphs (CCGraphs), which are directed acyclic graphs automatically extracted from reasoning traces that model fine-grained causal dependencies in language-model outputs. A collection of 1671 mathematical reasoning problems from MATH500, GSM8K, and AIME, together with their associated CCGraphs, has been compiled into our dataset -- KisMATH. Our detailed empirical analysis with 15 open-weight LLMs shows that (i) reasoning nodes in the CCGraphs are causal contributors to the final answer, which we argue is constitutive of reasoning; and (ii) LLMs emphasize the reasoning paths captured by the CCGraphs, indicating that the models internally realize structures similar to our graphs. KisMATH enables controlled, graph-aligned interventions and opens avenues for further investigation into the role of CoT in LLM reasoning.
