Uni-SLAM: Uncertainty-Aware Neural Implicit SLAM for Real-Time Dense Indoor Scene Reconstruction

T0 review · 4 major / 10 minor · reviewed 2026-08-12 · deepseek-v4-flash

Challenge this review Re-run · record.json Download PDF Read on arXiv ↗ Review JSON

Pith's one-line read Uni-SLAM shows that weighting each pixel by a volume-rendering confidence score improves neural implicit SLAM tracking and mapping without giving up real-time operation.

desk verdict Solid, well-engineered SLAM systems paper with a genuinely new uncertainty heuristic; the main gap is that the heuristic is never stress-tested under pose failure. read the letter →

arxiv 2412.00242 v1 pith:YLD3FHIW submitted 2024-11-29 cs.CV

Shaoxiang Wang , Yaxu Xie , Chun-Peng Chang , Christen Millerdurai , Alain Pagani , Didier Stricker This is my paper · ORCID
classification cs.CV
keywords neuralimplicitSLAMdenseRGB-Dreconstructionpredictiveuncertaintyvolumerenderingterminationprobabilityhashgridscenerepresentationbundleadjustmentindoorreal-timemapping
verification ladder T0 review T1 audit T2 compute T3 formal

The pith

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The reading

Uni-SLAM sets out to show that a dense neural implicit SLAM system should not treat all RGB-D frames and pixels as equally trustworthy. Its central proposal is a cheap, model-free predictive uncertainty computed from the volume-rendering termination probability, which reweights the tracking and mapping losses so that poorly observed pixels count for less. The same image-level uncertainty triggers additional local bundle adjustment when the camera enters unfamiliar territory, instead of relying only on fixed-frequency global mapping. On the Replica, ScanNet, and TUM RGB-D benchmarks the paper reports state-of-the-art tracking accuracy and reconstruction quality among the compared neural implicit systems, with a 25% lower depth L1 error and a 66.86% sub-centimeter completion ratio on Replica, while running at about 8 FPS. If correct, this establishes uncertainty-aware selective optimization, rather than uniform fixed-frequency mapping, as the better design for real-time implicit indoor SLAM.

What carries the argument

Central machinery is the termination-probability confidence signal. Along a ray with sample weights $w_i = T_i(1-\exp(-\sigma(x_i)))$, the accumulated value $p(r)=\sum_{i=1}^N w_i$ telescopes to $1-\exp(-\sum_i\sigma(x_i))$, bounding it in $(0,1)$ by construction. The paper treats $p(r)$ as the probability that the ray terminates on a known surface, defines $\beta_m=(1-p(r_m))^2$ for each pixel and $\beta=\frac{1}{M}\sum_m\beta_m$ per image, and converts $\beta_m$ into a binary mask $CF_m=\mathbf 1[\beta_m\le \beta^\text{unc}_m]$ that multiplies the SDF, depth, and tracking color losses. This is what lets the system discard outliers and emphasize reliable data during pose optimization. The second load-bearing mechanism is decoupled geometry and appearance hash grids, which allow high-frequency color and geometry to be sampled at different resolutions, plus the uncertainty-gated local-to-global bundle adjustment schedule that adds local BA when $\beta>\beta^\text{unc}$ and LLCO when co-visibility exceeds 0.95.

What would settle it

Use a Replica or ScanNet sequence with known invalid-depth regions, run Uni-SLAM, and record per-pixel $p(r)$, $\beta_m$, and depth error against the sensor depth. The claim predicts that pixels with $\beta_m$ below threshold have small depth error and that high-$\beta_m$ pixels coincide with invalid or unobserved depth; if any low-uncertainty pixel shows depth error larger than the truncation distance, or if the uncertainty map does not flag deliberately corrupted depth regions, the confidence proxy is falsified.

Watch

Extended reading notes

Core claim

The paper's claim is that the accumulated termination probability of a sampled ray, $p(r)=\sum_i w_i = 1-\exp(-\sum_i \sigma(x_i))$, is a usable online measure of how well the current model knows the observed surface: near 1 for well-observed, accurately tracked pixels and near 0 for invalid-depth, occluded, or never-seen regions. From it Uni-SLAM derives pixel-level uncertainty $\beta_m=(1-p(r_m))^2$ and image-level uncertainty $\beta=\frac{1}{M}\sum_m \beta_m$, uses a thresholded confidence mask $CF_m$ to reweight SDF, depth, and tracking color losses, and leaves the mapping color loss unweighted so RGB can compensate for invalid depth. A decoupled pair of multiresolution hash grids represents geometry and appearance separately, and image-level uncertainty plus a co-visibility check activates local bundle adjustment and loop-closure optimization on top of constant global BA. The reported outcome is improved pose estimation in every Replica scene, lower ATE on ScanNet and TUM RGB-D than the compared neural implicit SLAM systems, thinner structures in the reconstructed meshes, and real-time operation at roughly 8.4 FPS.

Load-bearing premise

The system trusts that the accumulated termination probability is near 1 precisely for well-observed, accurately posed pixels and near 0 for invalid or unseen regions, so a confidently wrong model could be reweighted up instead of filtered.

Editorial extensions

If this is right

  • If the results hold, a neural implicit SLAM system can gain accuracy by computing a per-pixel confidence from the model's own rendering weights, with no extra uncertainty network and no additional training cost.
  • Tracking on Replica improves to a 0.45 cm average ATE RMSE, with ScanNet and TUM RGB-D averages of 7.01 cm and 2.05 cm, both best among the neural implicit baselines compared.
  • Mapping quality on Replica improves to 0.89 cm depth L1, 0.92 cm accuracy and completion, and 66.86% completion within 1 cm, corresponding to thinner structures such as chair legs and table edges.
  • The uncertainty-driven mapping trigger is not tied to Uni-SLAM's own representation: applying it to BSLAM improves that system's ATE from 1.19 cm to 1.07 cm and its completion ratio from 57.18% to 58.36%.
  • Real-time operation is preserved: roughly 8.4 FPS on Replica with an RTX 4090, comparable to Co-SLAM and faster than ESLAM, Nice-SLAM, and BSLAM in the reported setup.

Reading between the lines

Editorial extensions of the paper, not claims the author makes directly.

  • Editorial extension: because $\beta$ is computed from the current model state, it could double as an online alarm for motion blur, sensor dropout, or aggressive camera motion, enabling the SLAM system to slow down, request new views, or refuse bad poses before drift accumulates.
  • Editorial extension: the same uncertainty could drive active next-best-view selection, since high-$\beta$ rays mark regions the model has not yet observed; the paper mentions active sampling as future work but does not test it.
  • Editorial extension: the hand-set thresholds $\beta^\text{unc}_m$ and $\beta^\text{unc}$ vary across datasets, so a principled automatic calibration, such as normalizing by the per-image uncertainty distribution, would be needed for deployment outside the tuned benchmarks.
  • Editorial extension: the decision not to reweight color during mapping rests on RGB compensating for invalid depth; in a sensor with reliable depth, reweighting color in mapping might become beneficial, which could be tested directly.
Share X Bluesky LinkedIn Reddit HN

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, and a circularity audit.

Referee Report

4 major / 10 minor

Summary. The manuscript proposes Uni-SLAM, a real-time dense neural implicit RGB-D SLAM system with three main components: (i) a decoupled representation with separate multiresolution hash grids for geometry (SDF) and appearance, both decoded by tiny MLPs and rendered by standard volume rendering; (ii) a model-free "predictive uncertainty" defined per pixel as beta_m = (1 - p(r))^2, where p(r) is the accumulated termination probability along the depth-guided sampling ray, used to hard-mask and reweight the SDF, depth, and (during tracking only) color loss terms; and (iii) an uncertainty-triggered mapping schedule combining fixed-frequency global bundle adjustment, image-level-uncertainty-activated local BA, and a co-visibility-based local loop closure optimization (LLCO). The system is evaluated on Replica, ScanNet, and TUM RGB-D against Nice-SLAM, Co-SLAM, ESLAM, BSLAM, and others, reporting average ATE RMSE of 0.45 cm on Replica (vs. 0.63 cm for ESLAM), Depth L1 of 0.89 cm, 66.86% completion within 1 cm, and PSNR of 31.62 dB, with a claimed 25% reduction in depth L1 error over the prior state of the art, together with a runtime of about 8.4 FPS on Replica. The supplement includes per-scene tables, ablations (representation choice, reweighting terms, BA components, hash grid sizes, Gaussian-assumption uncertainty), a telescoping-sum proof for the termination probability, and a plug-in experiment showing the strategic BA transfers to BSLAM.

Significance. If the reported results hold up, Uni-SLAM is a meaningful advance: it is the first dense implicit RGB-D SLAM system to use the rendering termination probability as a free, model-free confidence signal, and its benchmark numbers (best average ATE on all three datasets among the compared implicit methods) support the headline claims. Strengths worth crediting explicitly: baseline results are reproduced from open-source code with five runs (median reported) under a consistent mesh-culling protocol; the termination-probability identity is derived correctly as a telescoping sum; ablations substantiate the decoupled representation, the choice of reweighting terms, and the value of LLCO; and the BSLAM plug-in experiment demonstrates transfer of the BA strategy.

major comments (4)
  1. [Sec. 3.2, Eqs. (4)-(7); Fig. 3; Sec. 4.3] The central mechanism claim -- that beta_m = (1 - p(r))^2 identifies unreliable observations and that hard masking via Eq. (7) "progressively filters out outliers" -- is validated only in the regime where the model is uncertain because of missing coverage (invalid depth in Fig. 3, unseen areas in Supp. Fig. 10). The complementary regime is untested: after a pose perturbation, depth-guided samples can land on a previously learned surface, giving p(r) near 1 and CF_m = 1, so the inconsistent observation is up-weighted instead of filtered, which can amplify drift in the joint tracking/mapping loop. The supplement proof (Sec. A.2) establishes only the identity p(r) = 1 - exp(-sum sigma); it does not establish the semantic claim that p(r) is large exactly when the observation is reliable under pose error. I request a controlled experiment: inject pose perturbations of increasing magnitude during tracking (with the map frozen), report the resulting distribution of beta_m and the post-optimization tracking error, and compare against a baseline that masks only pixels with explicitly invalid depth. This would show whether the reweighting provides information beyond a standard depth-validity mask and whether the aggregate gains in Fig. 9 arise from the proposed mechanism.
  2. [Supp. Tab. 14; Tab. 2; Fig. 6] Several main-text numbers do not reconcile with the per-scene supplement tables. (i) The per-scene Depth L1 values for Ours in Tab. 14 (0.81, 0.77, 1.13, 0.70, 1.11, 1.52, 1.15, 0.99) average to 1.02 cm, yet both Tab. 14 and Tab. 2 report 0.89 cm; the headline claim of a 25% reduction in Depth L1 over ESLAM (1.18 cm) depends on this figure. (ii) The ESLAM completion ratio at 1 cm is 62.25% as the mean of the Tab. 14 per-scene values but is reported as 63.99% in Tab. 2. (iii) For Ours on office-3, Fig. 6 reports a 50.19% completion ratio at 1 cm while Tab. 14 lists 50.91%. Please reconcile these numbers or state clearly which runs or configurations each table refers to.
  3. [Sec. 4.1, Tabs. 1-4] The quantitative comparison is statistically asymmetric: for the baselines the paper reports the median of five runs, while the proposed method is reported as a single run without error bars. Some of the claimed margins are modest (TUM average ATE: 2.05 vs. 2.14 for ESLAM; completion ratio at 1 cm on Replica: 66.86 vs. 63.99), so the claim that Uni-SLAM "significantly improves" over current methods is not yet substantiated. Please report mean +/- std (or per-run values) for the proposed method over multiple runs for the main tables, and mark which differences are robust to run-to-run variation.
  4. [Supp. Sec. A.1; Sec. 3.4] The uncertainty pipeline relies on several hand-set, dataset-specific thresholds: beta_unc_m = 1e-2 for pixel masking, beta_unc = 1e-3 (2e-3 on TUM) for activating local BA, mapping frequency n = 4 (Replica, TUM) or 5 (ScanNet), and tau_cov = 0.95 for loop closure. Because Eq. (7) is a hard 0/1 mask, behavior is discontinuous in beta_unc_m, and no sensitivity analysis is provided. I ask for a sweep over these thresholds (at least beta_unc_m and beta_unc) on one Replica and one TUM sequence, and for a statement of which thresholds were used in the BSLAM plug-in experiment (Tab. 10), to establish that the reported gains do not depend critically on tuning.
minor comments (10)
  1. [Tab. 1] In the MIPS-Fusion row, the Off-2 entry reads "2020", which appears to be a typo (likely 2.02 or 20.20); please correct it.
  2. [Tabs. 5 and 12] The tables label the BSLAM baseline as "BSLAM [47]" in several places (e.g., Tab. 5 and Tab. 12); BSLAM is reference [20], while [47] is Point-SLAM.
  3. [Supp. Tab. 12] In the Replica block, the Nice-SLAM mapping column reads "29.3 x 0", which appears to be a typo for "29.3 x 60" (cf. Tab. 5).
  4. [Eq. (7)] The notation CF_m = 1(1 - beta_m) is confusing; write the indicator function explicitly, e.g., CF_m = 1{beta_m <= beta_unc_m}.
  5. [Sec. 3.2] "never unobserved regions" should read "never observed regions".
  6. [Supp. Figs. 17 and 19] The figure legends contain a leftover template string ("SA T [8] BUTD-DETR [8] ViewRefer [8]") that should be removed.
  7. [Algorithm 1] The comment "Optimazation" should be corrected to "Optimization".
  8. [Abstract and Conclusion] The claims of "real-time performance" should be qualified: per Supp. Tab. 12 the method runs at 8.37 FPS on Replica, 4.88 FPS on ScanNet, and only 2.7 FPS on TUM RGB-D, which is below the real-time threshold.
  9. [Abstract and Related Work] The abstract's statement that previous methods "do not consider varying quality of input RGB-D data" is too strong given that UNCLE-SLAM [48] is cited in the related work; please soften or qualify it.
  10. [Fig. 9] The reweighting ablation reports results on "TUM RGB-D" without identifying the specific sequence; please specify which sequence(s) were used.

Circularity Check

0 steps flagged · score 0.0 of 10

No significant circularity: the uncertainty-guided reweighting is an empirically tested heuristic, and the headline SLAM claims are measured against external benchmarks.

full rationale

Uni-SLAM's central claims are tracking and reconstruction accuracy on Replica, ScanNet, and TUM RGB-D, measured against independent baselines with standard metrics (ATE RMSE, Depth L1, accuracy, completion ratio, PSNR). These claims do not reduce to the paper's own definitions or fitted values. The pixel-level uncertainty beta_m = (1-p(r))^2 is not fitted to the target metrics; it is a deterministic function of the volume-rendering termination probability p(r), an existing quantity in NeRF-style rendering. The paper explicitly labels the link between beta_m and data quality as a hypothesis: 'We hypothesize that pixels with invalid depth or motion blur, caused by sensor issues or sudden motion changes, should exhibit high uncertainty, while well-observed regions should display low uncertainty.' It then tests this hypothesis through ablations (Fig. 9, Tab. 6, Tab. 7) and a plug-in experiment on BSLAM (Tab. 10), which provides an independent check that the strategy transfers. Using a model-derived confidence to reweight that same model's loss is self-referential as a training mechanism, but it is not definitional circularity: the final benchmark numbers come from ground-truth poses and meshes, not from beta_m, and the reweighting could have degraded rather than improved performance. The per-dataset thresholds (beta_unc_m=1e-2, beta_unc=1e-3 or 2e-3 on TUM) are hand-set hyperparameters, not parameters fitted to a subset of data and then renamed as predictions. No load-bearing self-citations or imported uniqueness theorems appear; cited works such as NeRF, DENS, and BayesRays are external prior art. The proof in Supp. A.2 only establishes the telescoping identity sum w_n = 1 - exp(-sum sigma), which is a mathematical property of the rendering weights, not a validation that the uncertainty measure tracks ground-truth data quality. The derivation chain is therefore self-contained; the main vulnerability is an empirical assumption about what p(r) indicates, which is a correctness or robustness concern rather than circularity.

Assumptions & free parameters 7 free parameters · 5 assumptions · 1 invented entities

The main free parameters are the uncertainty thresholds and mapping frequency, which are tuned per dataset and directly control loss masking and BA activation. The key axioms are the validity of termination probability as a data-quality measure, the depth-guided sampling assumption, and the use of a ground-truth first pose. No new physical entities are introduced; the 'predictive uncertainty' is a model-derived scalar.

free parameters (7)
  • Pixel-level uncertainty threshold β_unc_m = 1e-2
    Used in CF_m (Eq. 7) to mask uncertain pixels during loss computation; fixed to 1e-2 without sensitivity analysis.
  • Image-level uncertainty threshold β_unc = 1e-3 (Replica), 2e-3 (TUM)
    Triggers additional local BA; tuned per dataset as documented in Supp A.1.
  • Mapping frequency n = 4 frames (Replica/TUM), 5 frames (ScanNet)
    Constant global BA interval; selected per dataset to balance speed and accuracy.
  • Co-visibility threshold τ_cov = 0.95
    Decides loop closure detection in Eq. 16; a minimum of 100 frames is also enforced.
  • Truncation distance τ_tr = 6 cm
    Defines the SDF truncation band in Sec. 3.3; inherited from prior SDF-based SLAM.
  • Loss weights λ_rgb, λ_dep, λ_sdf = Various (e.g., λ_rgb=5, λ_dep=0.1..1, λ_sdf=5..200)
    Hand-set separately for tracking and mapping; listed in Supp A.1.
  • Hash grid levels L = 16 geometry, 16 or 19 appearance
    Ablated in Supp B.1; Replica uses L=19 for appearance.
assumptions (5)
  • standard math Telescoping sum identity: sum_i w_i = 1 - exp(-sum_i sigma_i)
    Proof in Supp A.2 is a correct telescoping sum within the discrete volume rendering model.
  • domain assumption Well-observed regions have cumulative density such that p(r) is near 1; unobserved or invalid-depth regions have p(r) near 0
    Core assumption for the uncertainty definition in Sec. 3.2; not guaranteed when the model hallucinates geometry or pose is poor.
  • domain assumption Depth-guided sampling with approximate depth for invalid pixels still yields useful rays for uncertainty estimation
    Used in Fig. 3 to compute uncertainty for invalid-depth pixels via an approximate depth value.
  • domain assumption First camera pose is available (ground truth)
    Algorithm 1 in Supp initializes P1 with ground truth; the main paper does not analyze the impact of this choice.
  • domain assumption Co-visibility overlap computed from current pose estimates reliably detects loop closures
    Eq. 16 and Supp A.3; false positives could trigger unnecessary or harmful LLCO.
invented entities (1)
  • Predictive uncertainty β (pixel-level and image-level)
    purpose: Reweight loss functions and trigger additional bundle adjustment based on model confidence
    Defined purely from the model's own volume rendering weights; no external calibration or ground-truth uncertainty map is used.

how reviews work

0 comments
Cite this review

Pith. "Pith review of Uni-SLAM: Uncertainty-Aware Neural Implicit SLAM for Real-Time Dense Indoor Scene Reconstruction." pith.science (2026). https://pith.science/paper/YLD3FHIW

@misc{pith2026241200242,
  author       = {Pith},
  title        = {Pith review of: Uni-SLAM: Uncertainty-Aware Neural Implicit SLAM for Real-Time Dense Indoor Scene Reconstruction},
  year         = {2026},
  howpublished = {\url{https://pith.science/paper/YLD3FHIW}},
  note         = {Machine review of arXiv:2412.00242}
}
read the original abstract

Neural implicit fields have recently emerged as a powerful representation method for multi-view surface reconstruction due to their simplicity and state-of-the-art performance. However, reconstructing thin structures of indoor scenes while ensuring real-time performance remains a challenge for dense visual SLAM systems. Previous methods do not consider varying quality of input RGB-D data and employ fixed-frequency mapping process to reconstruct the scene, which could result in the loss of valuable information in some frames. In this paper, we propose Uni-SLAM, a decoupled 3D spatial representation based on hash grids for indoor reconstruction. We introduce a novel defined predictive uncertainty to reweight the loss function, along with strategic local-to-global bundle adjustment. Experiments on synthetic and real-world datasets demonstrate that our system achieves state-of-the-art tracking and mapping accuracy while maintaining real-time performance. It significantly improves over current methods with a 25% reduction in depth L1 error and a 66.86% completion rate within 1 cm on the Replica dataset, reflecting a more accurate reconstruction of thin structures. Project page: https://shaoxiang777.github.io/project/uni-slam/

Figures

Figures reproduced from arXiv: 2412.00242 by the authors.

Figure 1
Figure 1. The reconstructed 3D mesh on the TUM RGB-D [PITH_FULL_IMAGE:figures/full_fig_p001_1.png] view at source ↗
Figure 2
Figure 2. Uni-SLAM Architecture Overview. Our framework consists of two threads, tracking and mapping. While tracking is performed every frame for RGB-D stream, besides constant mapping is performed every n frame constantly with global BA, activated additional mapping process is executed to capture local scene information based on uncertainty and co-visibility check with local BA and local loop closure optimization (LLCO). Ou… view at source ↗
Figure 3
Figure 3. Termination Probability and Uncertainty. This figure illustrates the termination probability and uncertainty during ray sampling. For pixel A with valid depth (sampling by Ray 1), the sampling density is high along this ray, leading to a high termination probability and lower uncertainty. In contrast, for pixel B with invalid depth (sampling by Ray 2), the sampling density is low along this ray, resulting in a lower… view at source ↗
Figures from the paper (22 more)
Figure 5
Figure 5. Figure 5: Activated additional local BA. From position Pi to Pi+1, sudden large movements lead to difficulties in pose estimation and increased uncertainty due to unseen areas. The initialization of Init Pi+1 based on the constant speed assumption is hard to optimize. Therefore,…
Figure 6
Figure 6. Figure 6: Mesh Evaluation on Replica [53]. Our method outstands with its thin geometry details and higher texture fidelity compared to Co-SLAM [62] and BSLAM [20]. For example, the table and vase in room-0; the thinner office desk, chair backrest, and detailed reconstructed chai…
Figure 7
Figure 7. Figure 7: Mesh Evaluation on ScanNet [9]. The estimated pose is shown in red, and the ground truth camera pose is shown in green. Our method stands out with its more accurate trajectory and higher quality reconstruction, such as the corners of the kitchen. Ours w/o strategic BA …
Figure 8
Figure 8. Figure 8: Mesh Evaluation on TUM RGB-D [54]. Our method stands out with its geometry details and higher texture fidelity. Without strategic BA (only with global BA), the performance can be suboptimal due to missing local information. rendering performance on the Replica dataset …
Figure 9
Figure 9. Figure 9: Ablation on loss term reweighting Ablation of strategic BA. Tab. 7 shows localization accuracy and rendering quality under different BA strategies on 6 ScanNet scenes. Experimental results demonstrate that our uncertainty-guided strategic BA method achieves optimal per…
Figure 10
Figure 10. Figure 10: Impact of Translational and Angular Velocities on Uncertainty. We can observe the correlation between uncertainty and both translational velocity and angular velocity. Higher velocities or accelerations tend to result in higher uncertainty. accelerations can easily ca…
Figure 11
Figure 11. Figure 11: Impact of different keyframe selection on Uncertainty. Here we compare the changing image-level uncertainty per frame with different keyframe selection strategies. The results indicated by the blue line show that image-level uncertainty is significantly reduced, achie…
Figure 12
Figure 12. Figure 12: Impact of Strategic BA on Rendering and Uncertainty Visualization. Our proposed strategic BA integrates global BA, local BA, and LLCO. This approach achieves the highest rendered image quality, as indicated by the PSNR (dB) metric. The second row presents visualized p…
Figure 13
Figure 13. Figure 13: Ablation on Gaussian Assumption Uncertainty Model. We use three grids to represent geometry, appearance, and learnable uncertainty respectively. variance β through a third grid parallel with the geometry and appearance grid. So, the term we need to minimize is: Lsingl…
Figure 15
Figure 15. Figure 15: Gaussian Assumption Model vs. Ours. Our model demonstrates superior rendering quality, as evaluated by PSNR (dB) ↑. Depth uncertainty, calculated using Eq. (1), is visualized for comparison. Our method visibly reduces depth uncertainty, as clearly shown in the visuali…
Figure 19
Figure 19. Figure 19: Comparative rendering quality convergence on TUM [PITH_FULL_IMAGE:figures/full_fig_p019_19.png]
Figure 18
Figure 18. Figure 18: Rendering Comparison on TUM RGB-D [54]. Ours shows the best results compared to state-of-the-art methods BSLAM [20] and Co-SLAM [62] among dense implicit SLAM methods. B.6. Runtime and Memory Analysis In Tab. 12, we compare runtime and memory usage, benchmarking all m…
Figure 20
Figure 20. Figure 20: Ablation on Reweighting. In the tracking and mapping processes, the loss functions consist of three loss terms: (Lsdf , Ldep, Lrgb). If reweighting is applied, we denote it as Y , and if not, we denote it as N. Column d) YYY-YYN indicates that we apply pixel-level unc…
Figure 21
Figure 21. Figure 21: Ablation on Model Design. We compare different scene representation combinations on Replica [53] room0 and evaluate with metrics PSNR and completion ratio[< 1cm%]. Hash-Hash-UncM denotes using hash grids for geometry and appearance, with a learnable uncertainty model.…
Figure 22
Figure 22. Figure 22: Mesh Evaluation on Replica [53] Office-0. Notably, our method can present fine geometric structures while also achieving better scene completion for unobserved regions compared to explicit Loopy-SLAM [30]. Compared to implicit methods such as Co-SLAM [62], BSLAM [20],…
Figure 23
Figure 23. Figure 23: Mesh Evaluation on Replica [53] Room-2. Our method achieves finer geometric and appearance reconstruction. For appearance: the patterns on the curtains and the detailed textures on the cabinet surface. For geometry: the vase on the cabinet and the cabinet legs. Please…
Figure 24
Figure 24. Figure 24: Mesh Evaluation on Replica [53] Office-2. For appearance: our rendered floor has higher quality, clearly distinguishing the floor patterns, as well as the textures on the pillows on the sofa. For geometry: we zoomed in on the table, and our method reconstructs sharper…
Figure 25
Figure 25. Figure 25: Mesh Evaluation on Replica [53] Office-4. For appearance: our rendered floor quality is higher, clearly distinguishing the floor patterns, as well as the clock on the wall. For geometry: we reconstructed more of the office chair’s geometric structure, such as the legs…
Figure 26
Figure 26. Figure 26: Mesh Evaluation on ScanNet [9]. Explicit Loopy-SLAM [30] and implicit Co-SLAM [62] are listed here for comparison. For appearance: Our method achieves higher rendering quality compared to the ground truth (GT) mesh, as seen texture of chairs, objects on the desk in sc…
Figure 27
Figure 27. Figure 27: Mesh Evaluation on TUM RGB-D [54]. Because there is no ground truth mesh for the TUM RGB-D dataset, we provide an image to facilitate qualitative comparison. We extensively compare the reconstruction quality with implicit methods such as ESLAM [22], Co-SLAM [62], and …
Figure 28
Figure 28. Figure 28: Mesh Evaluation on TUM RGB-D [54]. Because there is no ground truth mesh for the TUM RGB-D dataset, we provide an image to facilitate qualitative comparison. For example, our method accurately reconstructs details such as the Rubik’s cube on the table, the shopping ba…
Figure 29
Figure 29. Figure 29: Mesh Evaluation on TUM RGB-D [54]. While ESLAM [22] and BSLAM [20] can not capture geometric details such as cup and mouse on table, Co-SLAM [62] can not reconstruct thin geometric structure, such thin table surface. Our method shows outstanding performance. 20 [PITH…
