Exploring the limit of the Lattice-Bisognano-Wichmann form describing the Entanglement Hamiltonian: A quantum Monte Carlo study
Pith reviewed 2026-05-18 00:58 UTC · model grok-4.3
The pith
When the entanglement boundary is ordinary, the lattice-Bisognano-Wichmann ansatz accurately approximates the entanglement Hamiltonian beyond Lorentz-invariant cases.
A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.
Core claim
The authors show that the lattice-Bisognano-Wichmann ansatz, when combined with multi-replica-trick quantum Monte Carlo reconstruction, yields an accurate description of the entanglement Hamiltonian for two-dimensional lattice systems whose entanglement boundary is ordinary, that is, free from surface anomalies. This holds across a range of quantum phases and extends well beyond the Lorentz-invariant regime for which the original Bisognano-Wichmann theorem was derived.
What carries the argument
The lattice-Bisognano-Wichmann (LBW) ansatz, a discretized form that expresses the entanglement Hamiltonian as a sum of local operators with weights that decay with distance from the entanglement cut.
If this is right
- The method supplies a route to the entanglement spectrum and entanglement entropy in lattice models that lack Lorentz invariance or translational symmetry.
- Entanglement Hamiltonians can be reconstructed and compared to the LBW form in both gapped and gapless phases as well as at critical points.
- The ansatz applies to phases with discrete or continuous symmetry breaking provided the entanglement boundary remains ordinary.
- The framework allows systematic exploration of entanglement properties in complex two-dimensional many-body systems beyond the original scope of the Bisognano-Wichmann theorem.
Where Pith is reading between the lines
- The same reconstruction technique could be used to test whether the LBW form remains useful when weak surface anomalies are deliberately introduced.
- If the ansatz continues to work in higher dimensions or on frustrated lattices, it would offer a general starting point for analytic approximations to entanglement Hamiltonians.
- Numerical access to the full entanglement Hamiltonian opens the possibility of studying dynamical properties of entanglement after a quench.
Load-bearing premise
The multi-replica quantum Monte Carlo procedure faithfully recovers the true entanglement Hamiltonian of the lattice model so that direct comparison with the LBW ansatz is meaningful.
What would settle it
A calculation showing that the entanglement spectrum reconstructed by multi-replica Monte Carlo deviates systematically from the spectrum predicted by the LBW ansatz for a system whose entanglement boundary is ordinary and free of surface anomalies.
Figures
read the original abstract
As a powerful theoretical construct, the entanglement Hamiltonian (EH) encapsulates the essential entanglement properties of a quantum many-body system. From the EH, one can extract a variety of entanglement quantities, such as entanglement entropies, negativity, and the entanglement spectrum. However, its general analytical form remains largely unknown. While the Bisognano-Wichmann theorem gives an exact EH form for Lorentz-invariant field theories, its validity on lattice systems is limited, especially when Lorentz invariance is absent. In this work, we propose a general scheme based on the lattice-Bisognano-Wichmann (LBW) ansatz and multi-replica-trick quantum Monte Carlo methods to numerically reconstruct the entanglement Hamiltonian in two-dimensional systems and systematically explore its applicability to systems without translational invariance, going beyond the original scope of the primordial Bisognano-Wichmann theorem. Various quantum phases--including gapped and gapless phases, critical points, and phases with either discrete or continuous symmetry breaking--are investigated, demonstrating the versatility of our method in reconstructing entanglement Hamiltonians. Furthermore, we find that when the entanglement boundary of a system is ordinary (i.e., free from surface anomalies), the LBW ansatz provides an accurate approximation well beyond Lorentz-invariant cases. Our work thus establishes a general framework for investigating the analytical structure of entanglement in the complex quantum many-body systems.
Editorial analysis
A structured set of objections, weighed in public.
Referee Report
Summary. The paper proposes a numerical scheme that combines the lattice-Bisognano-Wichmann (LBW) ansatz with multi-replica-trick quantum Monte Carlo methods to reconstruct the entanglement Hamiltonian (EH) for two-dimensional lattice models. It systematically tests the LBW form across gapped and gapless phases, critical points, and phases with discrete or continuous symmetry breaking, concluding that the ansatz remains accurate for ordinary (anomaly-free) entanglement boundaries even when Lorentz invariance is absent.
Significance. If the reconstruction is shown to be independent of the LBW functional form, the work would provide a practical framework for extracting analytic structure from the EH in lattice systems where continuum theorems do not directly apply. The breadth of phases examined and the emphasis on ordinary boundaries constitute a useful extension beyond the original Bisognano-Wichmann setting; the QMC-based approach supplies a route to quantitative, falsifiable checks.
major comments (2)
- [Methods / reconstruction scheme] The reconstruction procedure (described in the abstract and the methods section) is stated to be 'based on the lattice-Bisognano-Wichmann (LBW) ansatz'. It is therefore essential to clarify whether the LBW functional form is imposed as a parametrization during the multi-replica QMC sampling or whether the EH is reconstructed without that assumption and only subsequently compared to the LBW prediction. If the former, the reported accuracy reduces to a goodness-of-fit metric inside the assumed family and does not constitute an independent test of the ansatz, especially in non-Lorentz-invariant regimes where deviations would be most informative. This point is load-bearing for the central claim that LBW works 'well beyond Lorentz-invariant cases'.
- [Results / figures and tables] The manuscript must supply quantitative diagnostics of reconstruction quality (e.g., relative deviation of extracted couplings from the LBW prediction, χ² per degree of freedom, or overlap measures) together with QMC convergence data (autocorrelation times, error bars on each coupling, and system-size extrapolation) for at least one representative phase in each class examined. Without these, the statement that the LBW ansatz 'provides an accurate approximation' cannot be assessed.
minor comments (2)
- [Abstract] The phrase 'primordial Bisognano-Wichmann theorem' in the abstract is nonstandard; 'original' or 'continuum' Bisognano-Wichmann theorem would be clearer.
- [Figures] All figures that display reconstructed couplings or spectra should include statistical error bars from the QMC runs and state the lattice sizes and replica numbers used.
Simulated Author's Rebuttal
We thank the referee for the thorough review and valuable comments on our manuscript. We address each major comment below and will incorporate clarifications and additional data in the revised version to strengthen the presentation of our results.
read point-by-point responses
-
Referee: [Methods / reconstruction scheme] The reconstruction procedure (described in the abstract and the methods section) is stated to be 'based on the lattice-Bisognano-Wichmann (LBW) ansatz'. It is therefore essential to clarify whether the LBW functional form is imposed as a parametrization during the multi-replica QMC sampling or whether the EH is reconstructed without that assumption and only subsequently compared to the LBW prediction. If the former, the reported accuracy reduces to a goodness-of-fit metric inside the assumed family and does not constitute an independent test of the ansatz, especially in non-Lorentz-invariant regimes where deviations would be most informative. This point is load-bearing for the central claim that LBW works 'well beyond Lorentz-invariant cases'.
Authors: We thank the referee for highlighting this crucial distinction. In our work, the LBW ansatz is used to provide the functional form for the entanglement Hamiltonian, which is then parametrized by a set of effective couplings. The multi-replica-trick QMC method is utilized to compute the necessary entanglement observables (such as the reduced density matrix elements or correlation functions in the replicated system) that allow us to determine these couplings by fitting or matching within the LBW framework. This approach enables the reconstruction of the EH under the LBW assumption. To test the validity of the ansatz, we apply it across a wide range of phases and compare the resulting entanglement properties (e.g., spectra, entropies) to independent calculations or known limits. In Lorentz-invariant cases, we verify that the extracted parameters align with theoretical expectations from the Bisognano-Wichmann theorem. For non-Lorentz-invariant systems, the accuracy is demonstrated by the close agreement with expected behaviors for ordinary boundaries, as detailed in our results. While we acknowledge that this constitutes a test of the ansatz's applicability rather than a fully assumption-free reconstruction, the systematic study provides strong evidence for its robustness. We will revise the methods section to explicitly describe this procedure and discuss the implications for the independence of the test. revision: yes
-
Referee: [Results / figures and tables] The manuscript must supply quantitative diagnostics of reconstruction quality (e.g., relative deviation of extracted couplings from the LBW prediction, χ² per degree of freedom, or overlap measures) together with QMC convergence data (autocorrelation times, error bars on each coupling, and system-size extrapolation) for at least one representative phase in each class examined. Without these, the statement that the LBW ansatz 'provides an accurate approximation' cannot be assessed.
Authors: We agree with the referee that providing quantitative measures is important for rigorously assessing the quality of the reconstruction. In the current manuscript, we have presented qualitative comparisons and visual agreements in the figures, but we recognize the need for more detailed metrics. In the revised manuscript, we will add quantitative diagnostics, including tables reporting relative deviations of the fitted couplings, χ² per degree of freedom for the fits, and overlap measures between the reconstructed and reference entanglement spectra where applicable. Additionally, we will include QMC convergence information such as autocorrelation times, statistical error bars on the extracted couplings, and results from system-size extrapolations for representative examples from each phase class (gapped, gapless, critical, and symmetry-broken phases). These additions will be placed in the results section or as supplementary material to allow for a thorough evaluation of the LBW ansatz's accuracy. revision: yes
Circularity Check
No significant circularity detected
full rationale
The paper's central method reconstructs the entanglement Hamiltonian via multi-replica-trick quantum Monte Carlo sampling on lattice models, an independent numerical procedure that does not presuppose the LBW functional form. The LBW ansatz is subsequently used only for comparison against the numerically obtained EH in various phases, including non-Lorentz-invariant cases. No equations or steps in the abstract reduce the reported accuracy to a fit or self-definition by construction; the validation remains an external check against the reconstructed object. The derivation chain is therefore self-contained against the numerical benchmark.
Axiom & Free-Parameter Ledger
Reference graph
Works this paper leans on
-
[1]
(b) Correlation function results in PM phase withh= 5
(a) Correlation function results in FM phase withh= 1. (b) Correlation function results in PM phase withh= 5. For the critical point of the two-dimensional TFIM, which exhibits translational invariance, its low-energy be- havior can be described by a Lorentz-invariant quantum field theory [28]. By comparing the correlation functions obtained from the LBW-...
-
[2]
M. A. Nielsen and I. L. Chuang,Quantum computation and quantum information(Cambridge university press, 2010)
work page 2010
-
[3]
C. H. Bennett, H. J. Bernstein, S. Popescu, and B. Schu- macher, Phys. Rev. A53, 2046 (1996)
work page 2046
- [4]
- [5]
- [6]
- [7]
-
[9]
P. Calabrese and J. Cardy, Journal of Statistical Mechan- ics: Theory and Experiment2004, P06002 (2004)
work page 2004
-
[10]
P. Calabrese and J. Cardy, Journal of Physics A: Math- ematical and Theoretical42, 504005 (2009)
work page 2009
-
[11]
J. I. Latorre and A. Riera, Journal of Physics A: Mathe- matical and Theoretical42, 504002 (2009)
work page 2009
- [12]
- [13]
-
[14]
Z. Wang, Z. Wang, Y.-M. Ding, B.-B. Mao, and Z. Yan, Nature Communications16, 5880 (2025)
work page 2025
-
[15]
Y.-M. Ding, Y. Tang, Z. Wang, Z. Wang, B.-B. Mao, and Z. Yan, Physical Review B111, L241108 (2025)
work page 2025
- [16]
- [17]
- [18]
- [20]
- [23]
-
[24]
A. M. L¨ auchli and J. Schliemann, Phys. Rev. B85, 054403 (2012)
work page 2012
-
[25]
A. M. L¨ auchli, arXiv preprint arXiv:1303.0741 (2013)
work page internal anchor Pith review Pith/arXiv arXiv 2013
-
[26]
Laflorencie, Physics Reports646, 1 (2016)
N. Laflorencie, Physics Reports646, 1 (2016)
work page 2016
- [27]
- [28]
-
[29]
M. Dalmonte, V. Eisler, M. Falconi, and B. Vermersch, Annalen der Physik534, 2200064 (2022)
work page 2022
-
[30]
Z. Wang, S. Yang, B.-B. Mao, M. Cheng, and Z. Yan, Phys. Rev. B111, 245126 (2025)
work page 2025
-
[31]
V. Eisler, . Legeza, and Z. Rcz, Journal of Statistical Me- chanics: Theory and Experiment2006, P11013 (2006)
work page 2006
-
[32]
F. Parisen Toldin and F. F. Assaad, Phys. Rev. Lett. 121, 200602 (2018)
work page 2018
-
[33]
T. Mendes-Santos, G. Giudici, R. Fazio, and M. Dal- monte, New Journal of Physics22, 013044 (2020)
work page 2020
-
[34]
F. Pollmann, A. M. Turner, E. Berg, and M. Oshikawa, Phys. Rev. B81, 064439 (2010)
work page 2010
-
[35]
H. Pichler, G. Zhu, A. Seif, P. Zoller, and M. Hafezi, Phys. Rev. X6, 041033 (2016)
work page 2016
- [36]
- [37]
-
[38]
J. I. Cirac, D. Poilblanc, N. Schuch, and F. Verstraete, Phys. Rev. B83, 245134 (2011)
work page 2011
- [39]
-
[40]
F. F. Assaad, Phys. Rev. B91, 125146 (2015)
work page 2015
- [41]
- [42]
-
[43]
X.-L. Qi, H. Katsura, and A. W. W. Ludwig, Phys. Rev. Lett.108, 196402 (2012)
work page 2012
- [44]
-
[45]
I. Peschel and V. Eisler, Journal of Physics A: Mathe- matical and Theoretical42, 504003 (2009)
work page 2009
- [46]
- [47]
-
[48]
V. Eisler and I. Peschel, Journal of Physics A: Mathe- matical and Theoretical50, 284003 (2017)
work page 2017
-
[49]
V. Eisler and I. Peschel, Journal of Statistical Mechanics: Theory and Experiment2018, 104001 (2018)
work page 2018
-
[50]
J. J. Bisognano and E. H. Wichmann, Journal of Math- ematical Physics16, 985 (1975)
work page 1975
-
[51]
J. J. Bisognano and E. H. Wichmann, Journal of Math- ematical Physics17, 303 (1976)
work page 1976
- [52]
- [53]
-
[54]
G. Giudici, T. Mendes-Santos, P. Calabrese, and M. Dal- monte, Phys. Rev. B98, 134403 (2018)
work page 2018
-
[55]
T. Mendes-Santos, G. Giudici, M. Dalmonte, and M. A. Rajabpour, Phys. Rev. B100, 155122 (2019)
work page 2019
- [56]
-
[57]
K. Binder and D. Landau, Physica A: Statistical Mechan- ics and its Applications163, 17 (1990)
work page 1990
- [58]
-
[59]
J. D’Emidio and A. W. Sandvik, arXiv preprint arXiv:2401.14396 (2024)
- [60]
-
[61]
P. D. Hislop and R. Longo, Communications in Mathe- matical Physics84, 71 (1982)
work page 1982
-
[62]
R. Brunetti, D. Guido, and R. Longo, Communications in Mathematical Physics156, 201 (1993)
work page 1993
- [63]
-
[64]
J. Cardy and E. Tonni, Journal of Statistical Mechanics: Theory and Experiment2016, 123103 (2016)
work page 2016
-
[65]
K. Najafi and M. A. Rajabpour, Journal of High Energy Physics2016, 124 (2016)
work page 2016
-
[66]
R. E. Arias, H. Casini, M. Huerta, and D. Pontello, Phys. Rev. D96, 105019 (2017)
work page 2017
- [68]
-
[69]
A. W. Sandvik and J. Kurkij¨ arvi, Phys. Rev. B43, 5950 (1991)
work page 1991
-
[70]
O. F. Sylju˚ asen and A. W. Sandvik, Phys. Rev. E66, 046701 (2002)
work page 2002
-
[71]
A. W. Sandvik, Phys. Rev. B57, 10287 (1998)
work page 1998
-
[72]
A. W. Sandvik, Phys. Rev. B59, R14157 (1999)
work page 1999
-
[73]
A. W. Sandvik, AIP Conference Proceedings1297, 135 (2010)
work page 2010
-
[74]
Z. Yan, Y. Wu, C. Liu, O. F. Sylju˚ asen, J. Lou, and Y. Chen, Phys. Rev. B99, 165135 (2019)
work page 2019
- [75]
-
[76]
M. Song, J. Zhao, Z. Yan, and Z. Y. Meng, Phys. Rev. B108, 075114 (2023)
work page 2023
- [78]
-
[79]
H. W. J. Bl¨ ote and Y. Deng, Phys. Rev. E66, 066110 (2002)
work page 2002
- [80]
- [81]
-
[82]
S. Wu, X. Ran, B. Yin, Q.-F. Li, B.-B. Mao, Y.-C. Wang, and Z. Yan, Phys. Rev. B107, 155121 (2023)
work page 2023
-
[83]
N. Ma, P. Weinberg, H. Shao, W. Guo, D.-X. Yao, and A. W. Sandvik, Phys. Rev. Lett.121, 117202 (2018)
work page 2018
- [84]
-
[85]
C. Ding, L. Zhang, and W. Guo, Physical Review Letters 120, 235701 (2018)
work page 2018
-
[86]
B. B. Beard, R. J. Birgeneau, M. Greven, and U.-J. Wiese, Phys. Rev. Lett.80, 1742 (1998)
work page 1998
