Lexical Tone is Hard to Quantize: Probing Discrete Speech Units in Mandarin and Yor\`ub\'a

Opeyemi Osakuade , Simon King This is my paper

Pith reviewed 2026-05-10 17:13 UTC · model grok-4.3

classification 💻 cs.CL cs.LG
keywords lexical tonediscrete speech unitsquantizationself-supervised learningMandarinYorubaprosodyspeech representation
0
0 comments X

The pith

Quantization of self-supervised speech representations prioritizes phonetic structure over lexical tone.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

The paper tests whether discrete speech units produced by quantizing SSL model latents preserve the lexical tone information that the continuous representations already contain. Experiments on Mandarin and Yoruba show that tone is encoded reliably in the latents but becomes much less recoverable once the representations are discretized, and that this pattern holds for multiple quantization techniques. A simple two-stage clustering procedure that first captures phonetics and then clusters the residuals improves tone recovery. The authors conclude that standard quantization strategies are inherently limited for suprasegmental features and call for tone-aware or prosody-aware alternatives.

Core claim

Discrete speech units obtained by quantizing SSL latent representations encode lexical tone less reliably than the original continuous latents because quantization favors segmental phonetic structure; this limitation persists across different quantization methods, as demonstrated by probing experiments on tone-labeled Mandarin and Yoruba speech data.

What carries the argument

Probing classifiers that measure tone classification accuracy from discrete units versus continuous latents, together with a residual K-means procedure that clusters phonetics first and then the residual representation to retain tone.

If this is right

  • Standard DSUs are likely suboptimal for downstream tasks that depend on prosody or tone, such as text-to-speech synthesis and multimodal dialogue in tonal languages.
  • SSL latent representations contain usable tone information that is systematically discarded by current discretization pipelines.
  • A residual clustering step after initial phonetic quantization can recover some of the lost tone information without retraining the underlying SSL model.
  • New quantization techniques explicitly designed to preserve suprasegmental features are required for high-quality speech representations in tone languages.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

  • The same quantization bias probably affects other suprasegmental cues such as intonation, stress, and rhythm in non-tonal languages.
  • Multilingual or low-resource speech systems may inherit systematic disadvantages for tone languages unless quantization is redesigned.
  • Joint text-speech models that rely on DSUs could see improved performance on tonal languages if tone-preserving discretization becomes standard.

Load-bearing premise

The chosen probing classifiers and tone-labeled datasets isolate lexical tone encoding without confounding effects from speaker, context, or dataset-specific artifacts.

What would settle it

A quantization method that produces discrete units from which tone can be classified at least as accurately as from the original continuous latents, while still preserving phonetic discriminability, would falsify the central claim.

Figures

Figures reproduced from arXiv: 2604.07467 by Opeyemi Osakuade, Simon King.

Figure 1
Figure 1. Figure 1: Weighted F1 scores for Mandarin and Yorub` a phone and tone classification using K-Means codebooks of varying sizes. ´ Solid lines represent no pooling (phone segment-level), while dashed lines represent pooled (phone segment-level) features. Dotted lines denote the corresponding HuBERT latent baselines. The x-axis is logarithmic to highlight performance gains across orders of magnitude in codebook size. 2… view at source ↗
Figure 2
Figure 2. Figure 2: L1 refers to first-pass K-means on the mean-pooled phone segment at different K; L2 represents clustering on resid￾uals. While L1 performs well for vowels, L2 boosts tone clas￾sification, getting closer to the original (unquantised) latents. Dotted lines indicate latent baselines. results in a set of K centroids (i.e., vectors in latent space). Each frame in the dataset is then replaced with the closest ce… view at source ↗
read the original abstract

Discrete speech units (DSUs) are derived by quantising representations from models trained using self-supervised learning (SSL). They are a popular representation for a wide variety of spoken language tasks, including those where prosody matters. DSUs are especially convenient for tasks where text and speech are jointly modelled, such as text-to-speech and multimodal dialogue systems. But we have found that DSUs encode suprasegmental information less reliably than segmental structure, which we demonstrate in this work using lexical tone, though this limitation likely extends to other suprasegmental features such as prosody. Our investigations using the tone languages Mandarin and Yor\`ub\'a show that the SSL latent representations themselves do encode tone, yet DSUs obtained using quantisation tend to prioritise phonetic structure, which makes lexical tone less reliably encoded. This remains true for a variety of quantisation methods, not only the most common, K-means. We conclude that current DSU quantisation strategies have limitations for suprasegmental features, which suggests a need for new, tone-aware (or prosody-aware) techniques in speech representation learning. We point towards a potential form of the solution by performing K-means clustering once to encode phonetic information, then again on the residual representation, which better encodes lexical tone.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Referee Report

2 major / 2 minor

Summary. The paper claims that SSL latent representations encode lexical tone in Mandarin and Yorùbá, but DSUs from quantization (K-means and others) prioritize phonetic structure and encode tone less reliably; this holds across quantizers, and a two-stage residual clustering approach is proposed to improve tone capture while retaining phonetic information.

Significance. If the probing results are robust, the work identifies a practically important limitation of current DSU methods for suprasegmental features in tone languages, with direct relevance to TTS, multimodal dialogue, and prosody modeling. The multi-language, multi-quantizer design and the concrete residual-clustering suggestion are strengths that could guide follow-on representation learning.

major comments (2)
  1. [Methods / Probing setup] Methods and experimental setup: the central claim that quantization causes a drop in tone encoding (relative to continuous latents) depends on the probing classifiers and tone-labeled datasets isolating lexical tone rather than correlated phonetic, speaker, or contextual signals. No details are provided on dataset sizes, speaker balancing, controls for tone-vowel co-occurrence, or utterance-level context, nor are error bars or statistical tests reported; this makes it impossible to verify whether the observed drop is specific to tone or to proxy features.
  2. [Results / Discussion] Results interpretation: the abstract states that SSL latents encode tone yet DSUs do not, but without ablation studies removing phonetic content or speaker identity from the probes, the comparison between continuous and discrete representations risks confounding the effect of quantization with loss of non-tone information.
minor comments (2)
  1. [Abstract and throughout] Notation: the language name appears inconsistently as 'Yor`ub'a' and 'Yorùbá'; standardize throughout.
  2. [Figures] Figures: ensure all plots of classification accuracy include error bars, legend entries for each quantizer, and explicit comparison to the continuous baseline.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the constructive feedback and positive assessment of the work's significance. We address the major comments point by point below.

read point-by-point responses

  1. Referee: [Methods / Probing setup] Methods and experimental setup: the central claim that quantization causes a drop in tone encoding (relative to continuous latents) depends on the probing classifiers and tone-labeled datasets isolating lexical tone rather than correlated phonetic, speaker, or contextual signals. No details are provided on dataset sizes, speaker balancing, controls for tone-vowel co-occurrence, or utterance-level context, nor are error bars or statistical tests reported; this makes it impossible to verify whether the observed drop is specific to tone or to proxy features.

    Authors: We agree that additional details on the datasets and probing setup are required to strengthen the claims and allow verification that the tone-encoding drop is attributable to quantization. In the revised manuscript we will expand the Methods section with dataset sizes, speaker balancing, any implemented controls for tone-vowel co-occurrence and utterance-level context, plus error bars and statistical tests on the probing accuracies. revision: yes

  2. Referee: [Results / Discussion] Results interpretation: the abstract states that SSL latents encode tone yet DSUs do not, but without ablation studies removing phonetic content or speaker identity from the probes, the comparison between continuous and discrete representations risks confounding the effect of quantization with loss of non-tone information.

    Authors: We acknowledge the risk of confounding. The current design applies identical tone probes to both continuous and discrete representations, so any performance gap is due to the quantization step itself. To further isolate tone, we will add ablation experiments (or expanded discussion of existing controls) in the revision; if full ablations are not feasible we will explicitly note the limitation. revision: partial

Circularity Check

0 steps flagged

No circularity: empirical probing study with independent results

full rationale

This is an empirical investigation that applies standard SSL models, multiple quantization methods (including but not limited to k-means), and probing classifiers to externally labeled Mandarin and Yorùbá tone datasets. No derivations, equations, or first-principles claims appear; the central observation (DSUs encode tone less reliably than continuous latents) is measured directly from classification accuracies on held-out data. The residual-clustering suggestion is presented as a forward-looking proposal, not as a redefinition or fit that tautologically reproduces the input observations. No self-citations are invoked to justify uniqueness or forbid alternatives, and all measurements rest on independent, publicly available resources rather than parameters fitted to the target quantity itself.

Axiom & Free-Parameter Ledger

1 free parameters · 1 axioms · 0 invented entities

The central claim rests on the assumption that standard SSL models and tone-annotated corpora provide an unbiased view of tone encoding; no new entities or fitted constants are introduced beyond routine clustering hyperparameters.

free parameters (1)
  • number of clusters K
    Chosen for each quantizer; affects how phonetic vs tonal information is partitioned.
axioms (1)
  • domain assumption SSL latent representations encode both segmental and suprasegmental information
    Invoked to interpret why tone is present before but not after quantization.

pith-pipeline@v0.9.0 · 5534 in / 1166 out tokens · 62003 ms · 2026-05-10T17:13:46.663364+00:00 · methodology

discussion (0)

Sign in with ORCID, Apple, or X to comment. Anyone can read and Pith papers without signing in.

Reference graph

Works this paper leans on

41 extracted references · 41 canonical work pages · 1 internal anchor

  1. [1]

    To use these continuous representations in downstream tasks, it is often necessary to discretise them into Discrete Speech Units (DSUs)

    Introduction Self-supervised learning (SSL) has become a key component of many speech processing systems, providing rich latent rep- resentations that encode phonetic, lexical, and prosodic infor- mation [1, 2, 3]. To use these continuous representations in downstream tasks, it is often necessary to discretise them into Discrete Speech Units (DSUs). DSUs ...

    work page

  2. [2]

    Lexical Tone is Hard to Quantize: Probing Discrete Speech Units in Mandarin and Yor\`ub\'a

    Method Our method involves extracting SSL representations from pre- trained foundation models, quantising them using various meth- ods, then probing for both phonetic and tonal information. arXiv:2604.07467v1 [cs.CL] 8 Apr 2026 Figure 1:Weighted F1 scores for Mandarin and Yor `ub´a phone and tone classification using K-Means codebooks of varying sizes. So...

    work page internal anchor Pith review Pith/arXiv arXiv 2026

  3. [3]

    Data are fixed and SSL models are frozen

    Quantisation Methods The quantisation method is the only experimental variable. Data are fixed and SSL models are frozen. Any variations in the in- formation found by the probes can be attributed to the quantisa- tion strategy alone. 3.1. Classic K-means (Frame-level clustering) Our baseline applies standard K-means clustering directly to frame-level late...

    work page

  4. [4]

    Results and Discussion We use probing to evaluate how well each quantisation method preserves phonetic and tonal information. 4.1. Classic K-means degrades tone information We find consistently thatquantisation tends to degrade tone more than phone.While SSL latents yield near-ceiling F1 scores for both phone and tone classification (e.g., 0.99 / 0.94 on ...

    work page

  5. [5]

    This is a standard methodology, but ultimately we need to measure downstream task performance

    Limitations Our analysis used only representation probing rather than down- stream tasks. This is a standard methodology, but ultimately we need to measure downstream task performance. Our probes used forced alignments. This is not a limitation, since they are only required during evaluation, not quantisation. However, our Residual K-means approach requir...

    work page

  6. [6]

    While tone is well encoded in the con- tinuous SSL latents, our probing results show that discretisation always degrades tonal information more than segmental infor- mation

    Conclusion This study examined how a range of quantisation strategies rep- resent lexical tone in two typologically distinct tone languages, Mandarin and Yor`ub´a. While tone is well encoded in the con- tinuous SSL latents, our probing results show that discretisation always degrades tonal information more than segmental infor- mation. We believe that thi...

    work page

  7. [7]

    We thank Korin Richmond for his constructive suggestions and detailed review of an earlier draft, which greatly improved the presentation of this work

    Acknowledgements This work was supported in part by the UKRI Centre for Doc- toral Training in Natural Language Processing, funded by the UKRI (grant EP/S022481/1) and the University of Edinburgh. We thank Korin Richmond for his constructive suggestions and detailed review of an earlier draft, which greatly improved the presentation of this work

    work page

  8. [8]

    Percep- tion of Phonological Assimilation by neural speech recognition models,

    C. Pouw, M. d. H. Kloots, A. Alishahi, and W. Zuidema, “Percep- tion of Phonological Assimilation by neural speech recognition models,”Computational Linguistics, vol. 50, no. 4, pp. 1557– 1585, 2024

    work page 2024

  9. [9]

    Self-Supervised Speech Representations Are More Phonetic than Semantic,

    K. Choi, A. Pasad, T. Nakamura, S. Fukayama, K. Livescu, and S. Watanabe, “Self-Supervised Speech Representations Are More Phonetic than Semantic,” inProc. Interspeech, 2024, pp. 4578– 4582

    work page 2024

  10. [10]

    Prosodic Struc- ture Beyond Lexical Content: A Study of Self-Supervised Learn- ing,

    S. Wallbridge, C. Minixhofer, C. Lai, and P. Bell, “Prosodic Struc- ture Beyond Lexical Content: A Study of Self-Supervised Learn- ing,” inProc. Interspeech, 2025, pp. 4723–4727

    work page 2025

  11. [11]

    DiscreteSLU: A Large Language Model with Self- Supervised Discrete Speech Units for Spoken Language Under- standing,

    S. Shon, K. Kim, Y .-T. Hsu, P. Sridhar, S. Watanabe, and K. Livescu, “DiscreteSLU: A Large Language Model with Self- Supervised Discrete Speech Units for Spoken Language Under- standing,” inProc. Interspeech, 2024, pp. 4154–4158

    work page 2024

  12. [12]

    Toward joint language modeling for speech units and text,

    J.-C. Chou, C.-M. Chien, W.-N. Hsu, K. Livescu, A. Babu, A. Conneau, A. Baevski, and M. Auli, “Toward joint language modeling for speech units and text,” inFindings of the Association for Computational Linguistics: EMNLP 2023, 2023, pp. 6582– 6593

    work page 2023

  13. [13]

    An empirical analysis of discrete unit representations in speech language modeling pre- training,

    Y . Labrak, R. Dufour, and M. Rouvier, “An empirical analysis of discrete unit representations in speech language modeling pre- training,” inInternational Conference on Text, Speech, and Dia- logue. Springer, 2025, pp. 13–24

    work page 2025

  14. [14]

    wav2vec 2.0: A framework for Self-Supervised Learning of Speech Represen- tations,

    A. Baevski, Y . Zhou, A. Mohamed, and M. Auli, “wav2vec 2.0: A framework for Self-Supervised Learning of Speech Represen- tations,”Advances in Neural Information Processing Systems, vol. 33, pp. 12 449–12 460, 2020

    work page 2020

  15. [15]

    HuBERT: Self-Supervised Speech Representation Learning by masked prediction of hidden units,

    W.-N. Hsu, B. Bolte, Y .-H. H. Tsai, K. Lakhotia, R. Salakhut- dinov, and A. Mohamed, “HuBERT: Self-Supervised Speech Representation Learning by masked prediction of hidden units,” IEEE/ACM Transactions on Audio, Speech, and Language Pro- cessing, vol. 29, pp. 3451–3460, 2021

    work page 2021

  16. [16]

    Speech resynthesis from Dis- crete Disentangled Self-Supervised Representations,

    A. Polyak, Y . Adi, J. Copet, E. Kharitonov, K. Lakhotia, W.-N. Hsu, A. Mohamed, and E. Dupoux, “Speech resynthesis from Dis- crete Disentangled Self-Supervised Representations,” inProc. In- terspeech, 2021, pp. 3615–3619

    work page 2021

  17. [17]

    Neural codec language models are zero-shot Text-to-Speech synthesiz- ers,

    S. Chen, C. Wang, Y . Wu, Z. Zhang, L. Zhou, S. Liu, Z. Chen, Y . Liu, H. Wang, J. Li, L. He, S. Zhao, and F. Wei, “Neural codec language models are zero-shot Text-to-Speech synthesiz- ers,”IEEE Transactions on Audio, Speech, and Language Pro- cessing, vol. 33, pp. 705–718, 2025

    work page 2025

  18. [18]

    Enhanced Direct Speech-to-Speech Transla- tion Using Self-Supervised Pre-training and Data Augmentation,

    S. Popuri, P.-J. Chen, C. Wang, J. Pino, Y . Adi, J. Gu, W.-N. Hsu, and A. Lee, “Enhanced Direct Speech-to-Speech Transla- tion Using Self-Supervised Pre-training and Data Augmentation,” inProc. Interspeech, 2022, pp. 5195–5199

    work page 2022

  19. [19]

    Textless direct Speech-to- Speech Translation with Discrete Speech Representation,

    X. Li, Y . Jia, and C.-C. Chiu, “Textless direct Speech-to- Speech Translation with Discrete Speech Representation,” in Proc. ICASSP. IEEE, 2023, pp. 1–5

    work page 2023

  20. [20]

    Generative spoken dialogue language modeling,

    T. A. Nguyen, E. Kharitonov, J. Copet, Y . Adi, W.-N. Hsu, A. Elkahky, P. Tomasello, R. Algayres, B. Sagot, A. Mohamed et al., “Generative spoken dialogue language modeling,”Trans- actions of the Association for Computational Linguistics, vol. 11, pp. 250–266, 2023

    work page 2023

  21. [21]

    Recent advances in speech language models: A sur- vey,

    W. Cui, D. Yu, X. Jiao, Z. Meng, G. Zhang, Q. Wang, S. Y . Guo, and I. King, “Recent advances in speech language models: A sur- vey,” inProceedings of the 63rd Annual Meeting of the Associ- ation for Computational Linguistics (Volume 1: Long Papers), 2025, pp. 13 943–13 970

    work page 2025

  22. [22]

    ToneUnit: A speech discretization approach for tonal language speech synthe- sis,

    D. Tao, D. Tan, Y . T. Yeung, X. Chen, and T. Lee, “ToneUnit: A speech discretization approach for tonal language speech synthe- sis,”CoRR, 2024

    work page 2024

  23. [23]

    Encoding of lexical tone in Self-Supervised Models of Spoken Language,

    G. Shen, M. Watkins, A. Alishahi, A. Bisazza, and G. Chrupała, “Encoding of lexical tone in Self-Supervised Models of Spoken Language,” inProceedings of the 2024 Conference of the North American Chapter of the Association for Computational Linguis- tics: Human Language Technologies (Volume 1: Long Papers), 2024, pp. 4250–4261

    work page 2024

  24. [24]

    Do discrete self-supervised repre- sentations of speech capture tone distinctions?

    O. Osakuade and S. King, “Do discrete self-supervised repre- sentations of speech capture tone distinctions?”arXiv preprint arXiv:2410.19935, 2024

    work page arXiv 2024

  25. [25]

    Yip,Tone

    M. Yip,Tone. Cambridge University Press, 2002

    work page 2002

  26. [26]

    Tone: A linguistic survey,

    V . Fromkin, “Tone: A linguistic survey,” inTone: A Linguistic Survey, V . Fromkin, Ed. Academic Press, 1978, pp. 1–28

    work page 1978

  27. [27]

    The perception of tones and phones,

    D. Burnham and K. Mattock, “The perception of tones and phones,” inLanguage Experience in Second Language Speech Learning. John Benjamins Publishing Company, 2008, pp. 259– 280

    work page 2008

  28. [28]

    AISHELL-1: An open mandarin speech corpus,

    H. Buet al., “AISHELL-1: An open mandarin speech corpus,” in O-COCOSDA, 2017

    work page 2017

  29. [29]

    BibleTTS: A large corpus for multilingual Text-to-Speech in the wild,

    J. Meyer and H. Ha, “BibleTTS: A large corpus for multilingual Text-to-Speech in the wild,” 2022

    work page 2022

  30. [30]

    Duanmu,The phonology of standard Chinese

    S. Duanmu,The phonology of standard Chinese. Oxford Uni- versity Press, 2007

    work page 2007

  31. [31]

    Lexicalisation of tonal downstep in yoruba,

    K. Adeniyi, “Lexicalisation of tonal downstep in yoruba,”Cana- dian Journal of Linguistics/Revue canadienne de linguistique, vol. 65, no. 4, pp. 535–555, 2020

    work page 2020

  32. [32]

    Downstep and high raising: interacting factors in yoruba tone production,

    Y . O. Laniran, “Downstep and high raising: interacting factors in yoruba tone production,”Journal of phonetics, vol. 31, no. 2, pp. 203–250, 2003

    work page 2003

  33. [33]

    AfriHuBERT: A Self-Supervised Speech Representation Model for African Lan- guages,

    J. O. Alabi, X. Liu, D. Klakow, and J. Yamagishi, “AfriHuBERT: A Self-Supervised Speech Representation Model for African Lan- guages,” inProc. Interspeech, 2025, pp. 4023–4027

    work page 2025

  34. [34]

    Montreal forced aligner: Trainable text-speech align- ment using kaldi,

    M. McAuliffe, M. Socolof, S. Mihuc, M. Wagner, and M. Son- deregger, “Montreal forced aligner: Trainable text-speech align- ment using kaldi,” inProc. Interspeech, 2017, pp. 498–502

    work page 2017

  35. [35]

    Yoruba-g2p: A tone-aware grapheme-to-phoneme converter for Yor `ub´a,

    O. Osakuade, “Yoruba-g2p: A tone-aware grapheme-to-phoneme converter for Yor `ub´a,” https://github.com/OpeyemiOsakuade/ yoruba-g2p, 2025, gitHub repository

    work page 2025

  36. [36]

    Analysis methods in neural language processing: A survey,

    Y . Belinkov and J. Glass, “Analysis methods in neural language processing: A survey,”Transactions of the Association for Com- putational Linguistics, vol. 7, pp. 49–72, 2019

    work page 2019

  37. [37]

    A structural probe for finding syn- tax in word representations,

    J. Hewitt and C. D. Manning, “A structural probe for finding syn- tax in word representations,” inProc. of the 2019 NAACL: Human Language Technologies, Volume 1 (Long and Short Papers), 2019, pp. 4129–4138

    work page 2019

  38. [38]

    SUPERB: Speech Processing Universal PERformance Benchmark,

    S. wen Yang, P.-H. Chi, Y .-S. Chuang, C.-I. J. Lai, K. Lakhotia, Y . Y . Lin, A. T. Liu, J. Shi, X. Chang, G.-T. Lin, T.-H. Huang, W.-C. Tseng, K. tik Lee, D.-R. Liu, Z. Huang, S. Dong, S.-W. Li, S. Watanabe, A. Mohamed, and H. yi Lee, “SUPERB: Speech Processing Universal PERformance Benchmark,” inProc. Inter- speech, 2021, pp. 1194–1198

    work page 2021

  39. [39]

    SpeechGLUE: How well can Self-Supervised Speech Models capture linguistic knowl- edge?

    T. Ashihara, T. Moriya, K. Matsuura, T. Tanaka, Y . Ijima, T. Asami, M. Delcroix, and Y . Honma, “SpeechGLUE: How well can Self-Supervised Speech Models capture linguistic knowl- edge?” inProc. Interspeech, 2023, pp. 2888–2892

    work page 2023

  40. [40]

    RepCodec: a speech represen- tation codec for speech tokenization,

    Z. Huang, C. Meng, and T. Ko, “RepCodec: a speech represen- tation codec for speech tokenization,” inProceedings of the 62nd Annual Meeting of the Association for Computational Linguistics (Volume 1: Long Papers), 2024, pp. 5777–5790

    work page 2024

  41. [41]

    Segmentation- Variant Codebooks for Preservation of Paralinguistic and Prosodic Information,

    N. Sanders, Y . Li, K. Richmond, and S. King, “Segmentation- Variant Codebooks for Preservation of Paralinguistic and Prosodic Information,” inProc. Interspeech, 2025, pp. 5403–5407

    work page 2025
