FishRoPE: Projective Rotary Position Embeddings for Omnidirectional Visual Perception

Rahul Ahuja , Mudit Jain , Bala Murali Manoghar Sai Sudhakar , Venkatraman Narayanan , Pratik Likhar , Varun Ravi Kumar , Senthil Yogamani

Authors on Pith no claims yet

Pith reviewed 2026-05-10 16:28 UTC · model grok-4.3

classification 💻 cs.CV cs.AI

keywords fisheye camerasrotary position embeddingsvision foundation modelsomnidirectional visionBEV segmentationobject detectionLoRA adaptationautonomous vehicle perception

0 comments

The pith

FishRoPE reparameterizes attention to angular separation in spherical coordinates to adapt frozen vision foundation models to fisheye geometry.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

Vision foundation models assume rectilinear pinhole camera geometry, but fisheye cameras introduce severe radial distortion that breaks this assumption. The paper establishes that reparameterizing rotary position embeddings to compute attention based on angular separation in spherical coordinates, rather than pixel distances, allows these models to handle fisheye inputs consistently. Combined with lightweight LoRA fine-tuning on a frozen DINOv2 backbone, this transfers rich self-supervised features to fisheye perception tasks without requiring task-specific pretraining or large annotated datasets. A reader would care because fisheye cameras are standard in autonomous vehicles for their wide surround coverage, making efficient adaptation crucial where full retraining is impractical. The method delivers state-of-the-art results on 2D detection and bird's-eye-view segmentation benchmarks.

Core claim

FishRoPE is a projective rotary position embedding that reparameterizes the attention mechanism in the spherical coordinates of the fisheye projection so that both self-attention and cross-attention operate on angular separation rather than pixel distance. This, together with Low-Rank Adaptation on a frozen DINOv2 backbone, adapts vision foundation models to fisheye geometry and achieves state-of-the-art performance on WoodScape 2D detection at 54.3 mAP and SynWoodScapes BEV segmentation at 65.1 mIoU.

What carries the argument

FishRoPE, the Fisheye Rotary Position Embedding that reparameterizes attention to angular separation in spherical coordinates instead of pixel distance.

If this is right

Achieves state-of-the-art 54.3 mAP on WoodScape 2D object detection.
Achieves state-of-the-art 65.1 mIoU on SynWoodScapes BEV segmentation.
Introduces negligible computational overhead and is architecture-agnostic.
Naturally reduces to the standard rotary position embedding formulation under pinhole geometry.
Enables feature transfer from pinhole-trained models to fisheye without task-specific pretraining.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

The approach could be generalized to other camera models with non-linear projections by deriving appropriate coordinate reparameterizations for attention.
It highlights the importance of geometric consistency in positional encodings for cross-domain transfer in computer vision.
Future work might explore integrating FishRoPE with multi-view fusion techniques for improved omnidirectional 3D perception.
Validation on additional real-world fisheye datasets would test if the gains hold beyond the synthetic and specific benchmarks used.

Load-bearing premise

Reparameterizing attention to angular separation in spherical coordinates suffices to align geometrically inconsistent features from pinhole-trained models with fisheye images.

What would settle it

If a baseline using standard position embeddings with the same LoRA adaptation matches or exceeds FishRoPE's performance on the WoodScape and SynWoodScapes benchmarks, the claim that angular reparameterization is key would be falsified.

Figures

Figures reproduced from arXiv: 2604.10391 by Bala Murali Manoghar Sai Sudhakar, Mudit Jain, Pratik Likhar, Rahul Ahuja, Senthil Yogamani, Varun Ravi Kumar, Venkatraman Narayanan.

**Figure 1.** Figure 1: Architecture overview. FishRoPE comprises (1) a frozen DINOv2 backbone with LoRA adaptation for multi-scale feature extraction from fisheye images, (2) a FishRoPE-enhanced feature encoder that embeds fisheye-aware angular geometry into self-attention, and (3) task-specific heads for 2D detection and BEV segmentation via Kannala–Brandt view transformation. the inverse Kannala–Brandt (KB) projection [8]: r &… view at source ↗

**Figure 2.** Figure 2: shows qualitative detection comparisons on WoodScape. FishRoPE correctly localizes a peripheral pedestrian that the baseline misses, illustrating the benefit of angular position encoding at high incidence angles [PITH_FULL_IMAGE:figures/full_fig_p006_2.png] view at source ↗

read the original abstract

Vision foundation models (VFMs) and Bird's Eye View (BEV) representation have advanced visual perception substantially, yet their internal spatial representations assume the rectilinear geometry of pinhole cameras. Fisheye cameras, widely deployed on production autonomous vehicles for their surround-view coverage, exhibit severe radial distortion that renders these representations geometrically inconsistent. At the same time, the scarcity of large-scale fisheye annotations makes retraining foundation models from scratch impractical. We present \ours, a lightweight framework that adapts frozen VFMs to fisheye geometry through two components: a frozen DINOv2 backbone with Low-Rank Adaptation (LoRA) that transfers rich self-supervised features to fisheye without task-specific pretraining, and Fisheye Rotary Position Embedding (FishRoPE), which reparameterizes the attention mechanism in the spherical coordinates of the fisheye projection so that both self-attention and cross-attention operate on angular separation rather than pixel distance. FishRoPE is architecture-agnostic, introduces negligible computational overhead, and naturally reduces to the standard formulation under pinhole geometry. We evaluate \ours on WoodScape 2D detection (54.3 mAP) and SynWoodScapes BEV segmentation (65.1 mIoU), where it achieves state-of-the-art results on both benchmarks.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

FishRoPE offers a practical geometric tweak to RoPE for fisheye cameras, but the paper's claims rest on unablated assumptions about early-layer features.

read the letter

FishRoPE gives a geometric reparameterization of rotary position embeddings tailored to fisheye spherical geometry. The paper reports state-of-the-art results on two fisheye benchmarks by combining it with light LoRA adaptation on a frozen DINOv2 backbone. What stands out is the clean formulation that reduces to ordinary RoPE under pinhole assumptions. This makes it easy to plug into existing vision foundation models without changing the architecture much. The focus on angular separation in attention addresses the mismatch between rectilinear training data and fisheye inputs in a targeted way. For applications like autonomous driving where fisheye cameras provide wide coverage but labeled data is limited, this low-overhead adaptation is appealing. The softer part is the lack of supporting details. The abstract mentions the SOTA numbers but skips ablations, such as whether the gains come from the angular attention or just the LoRA fine-tuning. It is not clear if the early patch embeddings, which still see the distorted pixel grid, get any geometric correction or if attention alone is meant to handle it. Dataset splits and projection model specifics are not justified here either. These gaps make it hard to judge how robust the approach really is. This paper is for researchers adapting foundation models to real-world camera setups in vehicles. A reader interested in practical BEV or detection pipelines for surround-view systems would get value from the method if the experiments check out. I would recommend sending it for peer review. The idea is worth exploring further with the missing controls added.

Referee Report

2 major / 2 minor

Summary. The manuscript proposes FishRoPE, a lightweight adaptation framework for vision foundation models (VFMs) on fisheye imagery. It freezes a DINOv2 backbone, applies LoRA for feature transfer without task-specific pretraining, and introduces Fisheye Rotary Position Embeddings that reparameterize self- and cross-attention to operate on angular separation in spherical coordinates rather than pixel distance. The method is architecture-agnostic, adds negligible overhead, and reduces to standard RoPE under pinhole geometry. It reports SOTA results of 54.3 mAP on WoodScape 2D detection and 65.1 mIoU on SynWoodScapes BEV segmentation.

Significance. If the results and geometric consistency claims hold, the work provides a practical route to deploy existing pinhole-trained VFMs on omnidirectional fisheye perception without full retraining or large fisheye datasets, which is valuable for autonomous driving applications. The architecture-agnostic design, explicit reduction to standard RoPE, and emphasis on frozen backbones with minimal adaptation are clear strengths that could enable broader adoption.

major comments (2)

[Abstract / Method] Abstract and Method description: the central claim that reparameterizing only self- and cross-attention to angular separation in spherical coordinates renders pinhole-trained DINOv2 features geometrically consistent on fisheye inputs is load-bearing but unsupported by isolating evidence. The frozen backbone's patch embedding and early layers still operate directly on the distorted pixel grid (trained under rectilinear assumptions) and receive only light LoRA adaptation; no experiments, feature visualizations, or alignment metrics demonstrate that attention reparameterization alone propagates consistency to overcome local receptive-field misalignment with the fisheye projection model.
[§4] §4 (Experiments): the SOTA claims of 54.3 mAP and 65.1 mIoU are presented without error bars, standard deviations across runs, or ablation tables separating FishRoPE from LoRA. This makes it impossible to determine whether the reported gains arise from the angular reparameterization or from other factors, directly undermining the sufficiency argument for the attention-only modification.

minor comments (2)

[§4.1] The selection and train/test splits of WoodScape and SynWoodScapes are not justified in §4.1; adding a brief rationale or reference to standard splits would improve reproducibility.
[Method] Notation for the spherical coordinate mapping and the exact form of the angular-separation rotary embedding could be clarified with an explicit equation in the Method section to make the reduction to standard RoPE fully transparent.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the constructive and insightful comments. We address each major point below, providing our strongest honest defense while committing to revisions that strengthen the evidence and statistical rigor of the manuscript.

read point-by-point responses

Referee: [Abstract / Method] Abstract and Method description: the central claim that reparameterizing only self- and cross-attention to angular separation in spherical coordinates renders pinhole-trained DINOv2 features geometrically consistent on fisheye inputs is load-bearing but unsupported by isolating evidence. The frozen backbone's patch embedding and early layers still operate directly on the distorted pixel grid (trained under rectilinear assumptions) and receive only light LoRA adaptation; no experiments, feature visualizations, or alignment metrics demonstrate that attention reparameterization alone propagates consistency to overcome local receptive-field misalignment with the fisheye projection model.

Authors: We agree that isolating evidence would strengthen the central claim. The patch embeddings and early frozen layers extract local descriptors from the distorted grid, but these descriptors remain largely useful as they capture appearance rather than global geometry. LoRA provides targeted adaptation to these features for fisheye inputs, while FishRoPE ensures that subsequent self- and cross-attention layers operate on angular separations in spherical coordinates, thereby enforcing geometric consistency at the level where spatial relationships are integrated. This design choice is supported by the explicit reduction to standard RoPE under pinhole geometry and the architecture-agnostic nature of the method. However, we acknowledge the absence of direct isolating experiments in the current version. In the revision we will add: (i) attention map visualizations contrasting standard RoPE and FishRoPE on fisheye inputs, and (ii) quantitative alignment metrics (e.g., reprojection error of known 3D landmarks) comparing the two while holding LoRA fixed. These additions will demonstrate how consistency propagates through the attention layers. revision: yes
Referee: [§4] §4 (Experiments): the SOTA claims of 54.3 mAP and 65.1 mIoU are presented without error bars, standard deviations across runs, or ablation tables separating FishRoPE from LoRA. This makes it impossible to determine whether the reported gains arise from the angular reparameterization or from other factors, directly undermining the sufficiency argument for the attention-only modification.

Authors: We concur that error bars and isolating ablations are necessary for rigorous evaluation. The reported figures reflect our primary experimental runs. In the revised manuscript we will rerun all benchmarks across multiple random seeds (minimum three) and report means with standard deviations for both 54.3 mAP and 65.1 mIoU. We will also insert a dedicated ablation table that includes: (a) frozen DINOv2 + LoRA with standard RoPE, and (b) frozen DINOv2 + LoRA + FishRoPE. This comparison will isolate the contribution of the angular reparameterization from LoRA adaptation alone, directly addressing whether the performance gains are attributable to FishRoPE. revision: yes

Circularity Check

0 steps flagged

No circularity: FishRoPE is a direct geometric reparameterization

full rationale

The paper presents FishRoPE as an explicit reparameterization of rotary position embeddings to operate on angular separation in spherical coordinates rather than pixel distance, with the explicit property that it naturally reduces to standard RoPE under pinhole geometry. This reduction is a designed consistency property of the formulation, not a derived claim obtained by fitting parameters to target metrics or by self-referential definition. The adaptation framework (frozen DINOv2 + LoRA) and reported results (54.3 mAP on WoodScape, 65.1 mIoU on SynWoodScapes) are empirical evaluations on external benchmarks; no load-bearing derivation step in the abstract or described method reduces by construction to the inputs or to a self-citation chain. The approach is stated to be architecture-agnostic with negligible overhead, confirming the derivation chain remains self-contained and independent.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 1 invented entities

The approach rests on the domain assumption that angular separation in spherical coordinates adequately models fisheye projection for attention; no free parameters or new entities are explicitly introduced beyond the method itself.

axioms (1)

domain assumption Attention mechanisms can be reparameterized using angular distances derived from fisheye projection geometry
Invoked to justify why FishRoPE transfers features from pinhole-trained models

invented entities (1)

FishRoPE no independent evidence
purpose: Reparameterized rotary position embedding for fisheye spherical coordinates
New method component introduced to handle radial distortion
