arxiv: 2605.02707 · v1 · submitted 2026-05-04 · 💻 cs.CV · cs.AI

Recognition: 2 theorem links

· Lean Theorem

SAIL: Structure-Aware Interpretable Learning for Anatomy-Aligned Post-hoc Explanations in OCT

Tienyu Chang , Tianhao Li , Ruogu Fang , Jiang Bian , Yu Huang

Authors on Pith no claims yet

Pith reviewed 2026-05-08 18:11 UTC · model grok-4.3

classification 💻 cs.CV cs.AI

keywords OCT imagingexplainable AIretinal anatomypost-hoc explanationsstructure-aware learningdeep learning interpretabilityanatomical priorsattribution maps

0 comments

The pith

Integrating retinal anatomical priors into model representations produces sharper and more anatomy-aligned post-hoc explanations for OCT images.

A machine-rendered reading of the paper's core claim, the machinery that carries it, and where it could break.

Deep learning detects retinal diseases accurately in OCT scans but its explanations often ignore the eye's layered structure. The SAIL framework embeds retinal anatomical priors directly into learned representations and fuses them with semantic features. This change alone, without altering any standard explanation method, yields attribution maps that follow layer boundaries and reduce noise. Experiments across several OCT datasets show more clinically useful explanations result. Ablations confirm that both the priors and their careful fusion with semantics are needed for the gains.

Core claim

The SAIL framework integrates retinal anatomical priors at the representation level and couples them with semantic features via a fusion design. Without modifying standard post-hoc explainability methods, this representation yields sharper and more anatomically aligned attribution maps. Comprehensive experiments on diverse OCT datasets demonstrate that the structure-aware method consistently enhances interpretability and produces clinically meaningful explanations, while ablations establish that both priors and fusion are required for best quality.

What carries the argument

The SAIL fusion design that encodes retinal anatomical priors at the representation level and couples them with semantic features to shape post-hoc attributions.

If this is right

Attribution maps better respect retinal layer boundaries and delineate fine-grained lesions.
Noise is suppressed while clinically relevant structures are highlighted.
Standard post-hoc methods produce usable explanations once the underlying representations are structure-aware.
Interpretability gains appear consistently across multiple OCT datasets.
Both anatomical priors and semantic features plus proper fusion are necessary for the observed quality.

Where Pith is reading between the lines

These are editorial extensions of the paper, not claims the author makes directly.

The same prior-integration approach could be tested on other layered medical images such as ultrasound or MRI.
Improved anatomical alignment in explanations may increase clinician trust and ease regulatory review for OCT-based AI tools.
If the fusion step generalizes, similar representations might support more reliable lesion localization beyond explanation quality.

Load-bearing premise

Retinal anatomical priors can be accurately captured and fused at the representation level to respect boundaries and suppress noise across varied OCT datasets without adding new biases.

What would settle it

Direct visual comparison on expert-annotated OCT test images where SAIL attribution maps show no measurable improvement in boundary alignment or noise reduction over standard methods would disprove the claim.

Figures

Figures reproduced from arXiv: 2605.02707 by Jiang Bian, Ruogu Fang, Tianhao Li, Tienyu Chang, Yu Huang.

**Figure 1.** Figure 1: Overview of the proposed SAIL framework. (a) Stan view at source ↗

**Figure 2.** Figure 2: Encoder–decoder fusion module. Encoder feature view at source ↗

**Figure 3.** Figure 3: Explainability performance for baseline and SAIL models. (a) Using Grad-CAM. (b) Using Grad-CAM++. (c) Using view at source ↗

**Figure 4.** Figure 4: Case-study attribution map comparisons across view at source ↗

**Figure 5.** Figure 5: Data curation and cohort construction pipeline for view at source ↗

**Figure 6.** Figure 6: Case-study attribution map comparisons across diseases, models, and XAI methods. view at source ↗

read the original abstract

Optical coherence tomography (OCT), a commonly used retinal imaging modality, plays a central role in retinal disease diagnosis by providing high-resolution visualization of retinal layers. While deep learning (DL) has achieved expert-level accuracy in OCT-based retinal disease detection, its "black box" nature poses challenges for clinical adoption, where explainability is essential for clinical trust and regulatory approval. Existing post-hoc explainable AI (XAI) methods often struggle to delineate fine-grained lesion structures, respect anatomical boundaries, or suppress noise, limiting the trustworthiness of their explanations. To bridge these gaps, we propose a Structure-Aware Interpretable Learning (SAIL) framework that integrates retinal anatomical priors at the representation level and couples them with semantic features via a fusion design. Without modifying standard post-hoc explainability methods, this representation yields sharper and more anatomically aligned attribution maps. Comprehensive experiments on diverse OCT datasets demonstrate that our structure-aware method consistently enhances interpretability, producing clinically meaningful and anatomy-aware explanations. Ablation studies further show that strong interpretability requires both structural priors and semantic features, and that properly fusing the two is critical to achieve the best explanation quality. Together, these results highlight structure-aware representations as a key step toward reliable explainability in OCT.

Editorial analysis

A structured set of objections, weighed in public.

Desk editor's note, referee report, simulated authors' rebuttal, and a circularity audit. Tearing a paper down is the easy half of reading it; the pith above is the substance, this is the friction.

Desk Editor's Note private letter to a colleague

SAIL fuses retinal layer priors into the feature representation before standard post-hoc XAI, which is a clean way to get more anatomy-respecting maps in OCT but leaves the robustness to prior errors untested.

read the letter

The paper's core move is to build a structure-aware representation by fusing anatomical priors with semantic features, then hand that off to unchanged explainers like Grad-CAM. This produces attribution maps that better follow retinal layers and cut noise, according to the experiments they ran on multiple OCT datasets. The ablations reportedly confirm that both the priors and the fusion step matter for the gains they see. That part is straightforward and targets a real clinical pain point: explanations that cross layer boundaries or highlight artifacts are hard for ophthalmologists to trust. The approach keeps the post-hoc methods untouched, which makes it easier to adopt on top of existing models. The soft spots are around the priors themselves. The method assumes the anatomical segmentation is reliable enough that fusing it does not lock explanations onto wrong boundaries or suppress real lesions. The stress-test note flags exactly this, and the abstract gives no numbers on how the system behaves when the prior network makes mistakes or when the data shifts to new scanners or patient populations. Without sensitivity checks or error propagation analysis, the claim that it introduces no new biases stays unverified. The quantitative improvements are described only in general terms, so it is difficult to judge effect size. This is for readers working on explainable models in ophthalmology or medical imaging more broadly. Someone looking for a practical fusion trick to improve layer alignment in attributions will find usable ideas here. I would send it to peer review. The method is clearly stated and the motivation is solid, so referees can pressure-test the missing robustness experiments and the actual metrics.

Referee Report

2 major / 2 minor

Summary. The paper proposes the Structure-Aware Interpretable Learning (SAIL) framework for OCT imaging. It integrates retinal anatomical priors at the representation level and fuses them with semantic features via a dedicated design. This representation is claimed to yield sharper, more anatomically aligned attribution maps when used with unmodified standard post-hoc XAI methods. Comprehensive experiments on diverse OCT datasets are said to demonstrate consistent enhancement in interpretability, with ablation studies confirming that both structural priors and semantic features, along with proper fusion, are required for best explanation quality.

Significance. If the central claims hold under rigorous validation, the work would be moderately significant for medical XAI. It offers a concrete way to inject domain-specific anatomical structure into learned representations to improve post-hoc explanations in a clinically relevant imaging modality, without requiring changes to existing explainers. This could support greater clinical trust, though the absence of quantitative metrics and robustness tests in the current presentation limits immediate impact.

major comments (2)

[Ablation studies and experiments on diverse OCT datasets] The central claim that the fused structure-aware representation produces attribution maps that respect anatomical boundaries and suppress noise without introducing new biases rests on the assumption that retinal anatomical priors can be accurately captured. However, no experiments quantify sensitivity to errors in prior extraction (e.g., from an upstream segmentation network) or to domain shift across clinical OCT datasets. This is load-bearing because any misalignment in the priors could force explanations onto incorrect layer boundaries or mask lesions.
[Abstract] The abstract states that experiments demonstrate 'consistent enhancement' and that ablations confirm the necessity of both priors and fusion, yet no quantitative metrics, statistical tests, dataset sizes, or implementation details are provided to support these assertions. Without such evidence, it is impossible to assess whether the observed improvements are meaningful or reproducible.

minor comments (2)

Clarify the exact mathematical formulation of the fusion design between anatomical priors and semantic features, ideally with equations showing how the combined representation is constructed.
Provide more detail on how the retinal anatomical priors are extracted and encoded at the representation level, including any preprocessing or network components used.

Simulated Author's Rebuttal

2 responses · 0 unresolved

We thank the referee for the constructive and detailed feedback on our manuscript. The comments highlight important aspects of robustness and clarity that we will address in the revision to strengthen the presentation of our results.

read point-by-point responses

Referee: [Ablation studies and experiments on diverse OCT datasets] The central claim that the fused structure-aware representation produces attribution maps that respect anatomical boundaries and suppress noise without introducing new biases rests on the assumption that retinal anatomical priors can be accurately captured. However, no experiments quantify sensitivity to errors in prior extraction (e.g., from an upstream segmentation network) or to domain shift across clinical OCT datasets. This is load-bearing because any misalignment in the priors could force explanations onto incorrect layer boundaries or mask lesions.

Authors: We agree that quantifying sensitivity to inaccuracies in the extracted anatomical priors is a valuable addition for validating the framework's reliability. In the revised manuscript, we will include new experiments that introduce controlled perturbations (e.g., boundary shifts and label noise) to the priors derived from the upstream segmentation network and report the resulting impact on attribution map quality using our existing metrics. Regarding domain shift, our current evaluation already spans multiple diverse OCT datasets acquired under different clinical conditions and scanners; we will augment this with an explicit cross-dataset transfer analysis to measure consistency in explanation alignment and faithfulness scores. revision: yes
Referee: [Abstract] The abstract states that experiments demonstrate 'consistent enhancement' and that ablations confirm the necessity of both priors and fusion, yet no quantitative metrics, statistical tests, dataset sizes, or implementation details are provided to support these assertions. Without such evidence, it is impossible to assess whether the observed improvements are meaningful or reproducible.

Authors: We concur that the abstract would benefit from greater specificity to allow readers to immediately gauge the scale and significance of the results. In the revision, we will update the abstract to include concrete quantitative outcomes (e.g., average percentage gains in layer-boundary alignment and explanation faithfulness), dataset sizes and diversity, and references to the statistical tests used. Full implementation details, hyperparameters, and training protocols are already provided in the Methods section and supplementary material; we will add an explicit pointer in the abstract to these resources to support reproducibility. revision: yes

Circularity Check

0 steps flagged

No significant circularity; framework proposal validated by experiments

full rationale

The paper introduces the SAIL framework as a method to integrate retinal anatomical priors with semantic features at the representation level, then applies unmodified standard post-hoc XAI techniques to produce attribution maps. The central claims rest on empirical results from experiments and ablation studies across OCT datasets, showing improved alignment and sharpness. No equations, derivations, or predictions are presented that reduce the claimed benefits to a fitted parameter, self-defined quantity, or self-citation chain. The structure is a standard proposal-plus-validation pattern with no load-bearing self-referential steps.

Axiom & Free-Parameter Ledger

0 free parameters · 1 axioms · 1 invented entities

Abstract-only review provides no explicit free parameters, detailed axioms, or invented entities beyond the high-level framework description. The approach implicitly assumes that anatomical priors are well-defined and beneficial when fused with semantic features.

axioms (1)

domain assumption Retinal anatomical priors can be represented and integrated at the feature level to improve explanation quality
Core premise of SAIL stated in the abstract but without implementation specifics.

invented entities (1)

Structure-aware representation no independent evidence
purpose: To yield sharper and more anatomically aligned attribution maps
New representation introduced by the SAIL framework

pith-pipeline@v0.9.0 · 5528 in / 1208 out tokens · 46159 ms · 2026-05-08T18:11:57.177730+00:00 · methodology

discussion (0)

Lean theorems connected to this paper

Citations machine-checked in the Pith Canon. Every link opens the source theorem in the public Lean library.

IndisputableMonolith/Cost (Jcost = ½(x+x⁻¹)−1) washburn_uniqueness_aczel unclear

?

unclear
Relation between the paper passage and the cited Recognition theorem.

F_f = α F̂_enc + (1−α) F̂_dec, α = σ(w) ∈ (0,1), where w is a learnable scalar

What do these tags mean?

matches: The paper's claim is directly supported by a theorem in the formal canon.
supports: The theorem supports part of the paper's argument, but the paper may add assumptions or extra steps.
extends: The paper goes beyond the formal theorem; the theorem is a base layer rather than the whole result.
uses: The paper appears to rely on the theorem as machinery.
contradicts: The paper's claim conflicts with a theorem or certificate in the canon.
unclear: Pith found a possible connection, but the passage is too broad, indirect, or ambiguous to say the theorem truly supports the claim.
